Performance Data Sheet
VSA9536ZXT
General Information
Model VSA9536ZXT Refrigerant R-404A
Test Condition ARI Performance Test Voltage 220V 3~ 50HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 43200 40100 37100 34000 30800 27700 24400
Watts 3080 3470 3860 4260 4660 5070 5480
Amps 14.6 15.3 16.0 16.7 17.4 18.2 18.9
Lb/h 675 670 665 660 654 648 642
Btu/h 47600 44300 40900 37500 34000 30600 27100
Watts 3160 3550 3940 4340 4740 5150 5560
Amps 14.8 15.4 16.2 16.9 17.6 18.3 19.1
Lb/h 752 746 741 735 730 723 717
Btu/h 52300 48600 45000 41200 37500 33700 29900
Watts 3240 3630 4030 4430 4830 5240 5650
Amps 14.9 15.6 16.3 17.0 17.8 18.5 19.3
Lb/h 836 830 824 818 812 805 798
Btu/h 57300 53300 49300 45300 41300 37200 33100
Watts 3340 3730 4120 4520 4920 5330 5750
Amps 15.1 15.8 16.5 17.2 18.0 18.7 19.5
Lb/h 928 921 915 908 901 894 886
Btu/h 62500 58200 53900 49600 45300 40900 36500
Watts 3450 3840 4230 4630 5030 5440 5850
Amps 15.2 16.0 16.7 17.4 18.2 18.9 19.7
Lb/h 1030 1020 1010 1010 998 990 982
Btu/h 68100 63500 58900 54300 49600 44900 40200
Watts 3570 3960 4350 4740 5150 5550 5960
Amps 15.4 16.2 16.9 17.6 18.4 19.2 20.0
Lb/h 1140 1130 1120 1110 1100 1090 1090
Btu/h 74000 69100 64200 59200 54200 49200 44200
Watts 3700 4090 4480 4870 5270 5680 6090
Amps 15.7 16.4 17.1 17.9 18.7 19.4 20.2
Lb/h 1250 1240 1240 1230 1220 1210 1200
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 4.294107E+04 -2.328019E+02 9.209311E+00 4.610938E+02
C2 1.131766E+03 9.137374E+00 -2.044433E-03 9.916234E+00
C3 -1.906520E+02 3.848183E+01 6.388953E-02 -4.116904E-01
C4 4.452495E+00 8.775075E-02 1.750788E-04 1.199968E-01
C5 -5.701682E+00 2.888613E-02 2.308723E-04 -1.363596E-03
C6 1.014983E-01 -1.346476E-02 -3.674195E-05 1.128485E-03
C7 2.082393E-02 1.531604E-03 3.311006E-06 5.409666E-04
C8 -7.975070E-03 -4.859092E-04 -1.158555E-06 -1.892989E-04
C9 4.993700E-04 -1.571209E-05 -1.965695E-08 7.085114E-06
C10 -7.877906E-04 1.149227E-04 3.122891E-07 -8.111537E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
VSA9536ZXT
General Information
Model VSA9536ZXT Refrigerant R-404A
Test Condition ARI Performance Test Voltage 220V 3~ 50HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 27600 25400 23200 21000 18800 16500 14200
Watts 2680 3090 3500 3920 4340 4760 5190
Amps 14.0 14.7 15.4 16.1 16.8 17.6 18.3
Lb/h 463 456 448 440 432 424 416
Btu/h 30900 28400 26000 23500 21000 18500 16000
Watts 2780 3180 3580 3990 4400 4820 5240
Amps 14.2 14.9 15.6 16.3 17.0 17.7 18.4
Lb/h 518 511 504 497 490 482 474
Btu/h 34400 31700 28900 26200 23500 20700 17900
Watts 2880 3270 3670 4070 4480 4890 5300
Amps 14.3 15.0 15.7 16.4 17.1 17.8 18.6
Lb/h 579 573 566 560 553 546 538
Btu/h 38000 35100 32100 29100 26100 23100 20000
Watts 2990 3370 3770 4160 4560 4960 5370
Amps 14.5 15.2 15.9 16.5 17.2 18.0 18.7
Lb/h 646 641 635 629 622 616 609
Btu/h 41900 38700 35500 32200 29000 25700 22300
Watts 3100 3480 3870 4260 4650 5040 5440
Amps 14.7 15.3 16.0 16.7 17.4 18.1 18.8
Lb/h 720 715 710 704 698 692 686
Btu/h 46100 42600 39100 35600 32000 28500 24900
Watts 3210 3590 3970 4360 4740 5130 5530
Amps 14.9 15.5 16.2 16.9 17.5 18.2 19.0
Lb/h 801 797 792 786 781 775 769
Btu/h 50500 46800 43000 39200 35400 31500 27700
Watts 3330 3710 4080 4460 4840 5220 5610
Amps 15.1 15.7 16.4 17.0 17.7 18.4 19.1
Lb/h 890 885 881 876 871 866 860
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 4.495869E+04 -5.706265E+02 8.575455E+00 5.212852E+02
C2 1.039701E+03 2.914848E+01 4.216864E-02 9.353252E+00
C3 -2.189865E+02 4.099715E+01 6.881348E-02 -7.483886E-01
C4 4.012871E+00 1.323914E-01 -6.086367E-05 1.244210E-01
C5 -5.040039E+00 -1.395250E-01 -9.519196E-05 1.273869E-02
C6 6.828875E-02 -1.100272E-02 -3.518014E-05 7.347995E-04
C7 2.668731E-02 -1.835910E-03 7.669711E-06 3.484973E-04
C8 -7.611097E-03 6.659091E-04 -1.161577E-06 -8.228564E-05
C9 1.030494E-04 -3.041109E-05 -1.307228E-07 -1.331788E-06
C10 -5.136310E-04 8.578171E-05 2.919481E-07 -5.571783E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
VSA9536ZXT
General Information
Model VSA9536ZXT Refrigerant R-404A
Test Condition ARI Performance Test Voltage 230V 3~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 33700 31000 28400 25800 23100 20400 17600
Watts 3070 3520 3970 4420 4880 5340 5800
Amps 11.1 12.1 13.0 14.0 15.1 16.1 17.1
Lb/h 561 554 547 539 532 523 515
Btu/h 37800 34800 31900 28900 25800 22800 19700
Watts 3180 3620 4070 4510 4970 5430 5890
Amps 11.3 12.2 13.2 14.2 15.2 16.3 17.3
Lb/h 631 623 616 608 600 592 584
Btu/h 42200 38800 35500 32200 28800 25400 22000
Watts 3280 3720 4160 4610 5060 5510 5970
Amps 11.4 12.4 13.4 14.4 15.4 16.4 17.5
Lb/h 707 700 692 684 676 667 659
Btu/h 46700 43100 39400 35700 32000 28200 24500
Watts 3400 3830 4260 4700 5150 5590 6050
Amps 11.7 12.6 13.6 14.6 15.6 16.6 17.6
Lb/h 790 783 775 767 758 750 740
Btu/h 51500 47500 43400 39400 35400 31300 27200
Watts 3520 3950 4380 4810 5240 5690 6130
Amps 11.9 12.9 13.9 14.8 15.8 16.8 17.8
Lb/h 881 873 864 856 847 838 829
Btu/h 56400 52100 47700 43300 38900 34500 30000
Watts 3670 4090 4510 4930 5360 5790 6230
Amps 12.3 13.2 14.2 15.1 16.1 17.1 18.1
Lb/h 977 969 961 952 943 934 924
Btu/h 61600 56900 52200 47400 42700 37900 33100
Watts 3850 4260 4670 5090 5500 5930 6360
Amps 12.8 13.7 14.6 15.6 16.5 17.4 18.4
Lb/h 1080 1070 1060 1050 1050 1040 1030
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 5.442646E+04 -4.514969E+02 3.408495E+00 6.145852E+02
C2 1.361632E+03 2.599513E+01 3.480293E-02 1.364767E+01
C3 -2.616848E+02 4.422462E+01 9.645144E-02 -6.981852E-01
C4 4.355330E+00 3.677465E-02 2.409632E-04 1.365529E-01
C5 -6.962475E+00 -5.121379E-02 4.611488E-05 -4.790114E-03
C6 7.238575E-02 -9.847613E-03 -3.208633E-05 8.887877E-04
C7 -6.442721E-03 9.957463E-03 3.886201E-05 2.479982E-05
C8 -4.586164E-04 -2.373529E-03 -9.119131E-06 -2.228115E-05
C9 2.996219E-04 -2.673803E-05 -1.284816E-07 2.090127E-06
C10 -5.753474E-04 9.352930E-05 3.125468E-07 -6.985275E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
VSA9536ZXT
General Information
Model VSA9536ZXT Refrigerant R-404A
Test Condition ARI Performance Test Voltage 230V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 53000 49200 45300 41400 37400 33500 29500
Watts 3580 4030 4470 4930 5380 5850 6320
Amps 11.9 13.0 14.0 15.0 16.1 17.2 18.2
Lb/h 826 818 811 803 795 787 779
Btu/h 58400 54200 49900 45600 41400 37000 32700
Watts 3690 4130 4580 5030 5490 5950 6420
Amps 12.1 13.2 14.2 15.2 16.3 17.4 18.5
Lb/h 919 911 903 894 886 878 869
Btu/h 64100 59500 54800 50200 45500 40900 36200
Watts 3810 4250 4700 5140 5600 6060 6530
Amps 12.4 13.4 14.4 15.5 16.6 17.7 18.8
Lb/h 1020 1010 1000 993 985 976 967
Btu/h 70000 65000 60000 55000 50000 44900 39900
Watts 3960 4400 4840 5280 5730 6190 6660
Amps 12.7 13.7 14.8 15.8 16.9 18.0 19.1
Lb/h 1130 1120 1110 1100 1090 1080 1070
Btu/h 76100 70800 65400 60100 54700 49300 43800
Watts 4140 4570 5010 5450 5900 6350 6810
Amps 13.1 14.1 15.2 16.2 17.3 18.4 19.5
Lb/h 1240 1230 1220 1210 1200 1190 1180
Btu/h 82600 76800 71100 65400 59600 53900 48100
Watts 4360 4780 5210 5650 6090 6530 6990
Amps 13.6 14.6 15.7 16.7 17.8 18.9 20.0
Lb/h 1370 1360 1350 1340 1330 1320 1300
Btu/h 89200 83200 77100 71000 64800 58700 52500
Watts 4610 5030 5450 5880 6310 6760 7200
Amps 14.2 15.3 16.3 17.3 18.4 19.5 20.5
Lb/h 1500 1490 1480 1470 1460 1440 1430
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 5.339609E+04 -1.594557E+02 4.014184E+00 5.755661E+02
C2 1.424166E+03 9.803160E+00 -1.388051E-02 1.265434E+01
C3 -2.422363E+02 4.283619E+01 9.308934E-02 -6.293973E-01
C4 5.306822E+00 3.462188E-02 9.420526E-05 1.406640E-01
C5 -7.314842E+00 8.967675E-02 4.982005E-04 -5.975736E-03
C6 5.471896E-02 -1.324176E-02 -2.749267E-05 4.450332E-04
C7 -4.013445E-04 7.502126E-03 2.206640E-05 2.163699E-04
C8 -7.924165E-04 -2.618096E-03 -7.647302E-06 -7.683285E-05
C9 2.644541E-04 5.253639E-05 1.581133E-07 2.866625E-06
C10 -4.414062E-04 1.269349E-04 2.790392E-07 -3.103002E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
