Performance Data Sheet
VSA9512ZXG
General Information
Model VSA9512ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 380V 3~ 50HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 9850 8910 8040 7230 6520 5890 5380
Watts 1100 1270 1430 1590 1750 1900 2040
Amps 2.30 2.51 2.72 2.92 3.11 3.28 3.45
Lb/h 163 160 156 154 151 149 147
Btu/h 10800 9850 8900 8010 7190 6460 5820
Watts 1100 1280 1450 1620 1780 1940 2090
Amps 2.29 2.51 2.73 2.94 3.14 3.34 3.53
Lb/h 183 180 176 173 170 168 165
Btu/h 12000 10900 9870 8880 7950 7100 6320
Watts 1100 1280 1460 1630 1800 1970 2140
Amps 2.27 2.50 2.72 2.95 3.17 3.38 3.59
Lb/h 206 202 198 195 192 188 185
Btu/h 13400 12200 11100 9980 8920 7930 7000
Watts 1100 1280 1460 1640 1820 2000 2180
Amps 2.25 2.48 2.72 2.95 3.19 3.42 3.64
Lb/h 231 227 223 219 215 212 208
Btu/h 15200 13900 12700 11400 10200 9080 7990
Watts 1100 1280 1470 1650 1840 2030 2210
Amps 2.22 2.46 2.71 2.95 3.20 3.44 3.69
Lb/h 258 254 250 246 241 237 233
Btu/h 17500 16100 14700 13400 12000 10700 9410
Watts 1100 1280 1470 1660 1860 2050 2250
Amps 2.20 2.45 2.70 2.95 3.21 3.47 3.73
Lb/h 289 284 280 275 270 266 261
Btu/h 20500 18900 17400 15900 14400 12900 11400
Watts 1100 1290 1480 1680 1880 2080 2280
Amps 2.19 2.43 2.69 2.95 3.22 3.49 3.77
Lb/h 322 317 312 307 302 297 292
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.826501E+04 -2.946281E+02 5.053340E-01 1.913163E+02
C2 1.891642E+02 3.352268E+00 2.103179E-03 3.804315E+00
C3 -1.020004E+02 1.708231E+01 2.179490E-02 -3.432723E-01
C4 2.528244E+00 2.136947E-02 4.251717E-05 4.113774E-02
C5 1.049667E+00 -1.538365E-01 -2.627243E-04 5.988060E-03
C6 -1.876296E-01 1.491541E-02 2.620436E-05 -6.706259E-04
C7 1.704078E-01 2.782582E-03 3.330641E-06 2.267712E-04
C8 -2.874995E-02 -1.592635E-03 -2.478204E-06 -9.256072E-06
C9 -1.244225E-02 1.521025E-03 2.624282E-06 -6.255368E-05
C10 1.847274E-03 -1.279632E-04 -2.264417E-07 6.190044E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
VSA9512ZXG
General Information
Model VSA9512ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 13600 12600 11600 10500 9410 8250 7040
Watts 1350 1530 1710 1890 2070 2260 2450
Amps 2.42 2.58 2.74 2.89 3.06 3.22 3.39
Lb/h 198 196 193 191 188 185 182
Btu/h 15200 14100 13000 11800 10600 9380 8090
Watts 1360 1540 1730 1920 2110 2300 2500
Amps 2.44 2.61 2.77 2.94 3.11 3.29 3.47
Lb/h 223 220 218 215 212 209 206
Btu/h 16600 15400 14200 13000 11700 10400 9040
Watts 1370 1560 1750 1940 2140 2330 2540
Amps 2.45 2.62 2.80 2.98 3.16 3.34 3.53
Lb/h 250 248 245 242 239 236 233
Btu/h 18000 16800 15500 14100 12800 11300 9890
Watts 1370 1570 1760 1960 2160 2370 2570
Amps 2.45 2.63 2.82 3.01 3.20 3.39 3.59
Lb/h 280 277 274 271 268 265 262
Btu/h 19400 18000 16600 15200 13700 12200 10700
Watts 1370 1570 1780 1980 2190 2390 2600
Amps 2.45 2.64 2.84 3.03 3.23 3.43 3.64
Lb/h 313 310 307 304 301 297 294
Btu/h 20700 19300 17800 16200 14700 13000 11400
Watts 1380 1590 1790 2000 2210 2420 2640
Amps 2.46 2.66 2.86 3.06 3.27 3.48 3.69
Lb/h 348 345 342 339 335 332 328
Btu/h 22100 20500 18900 17200 15600 13800 12100
Watts 1390 1600 1810 2020 2240 2450 2670
Amps 2.46 2.67 2.88 3.09 3.30 3.52 3.74
Lb/h 386 383 380 376 373 369 366
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.135441E+04 -5.639560E+01 1.222113E+00 2.172869E+02
C2 4.518393E+02 -7.229286E+00 -1.228692E-02 4.819447E+00
C3 -1.001281E+02 1.766780E+01 1.519330E-02 -2.442159E-01
C4 -7.382275E-01 -7.528292E-02 -1.469580E-04 5.387191E-02
C5 -1.835013E+00 1.272133E-01 2.102418E-04 -2.257976E-03
C6 1.261271E-01 -5.266928E-03 -7.675577E-06 3.102226E-04
C7 2.223180E-02 3.125661E-03 4.403769E-06 5.964282E-05
C8 -1.241946E-02 -7.929201E-04 -1.062863E-06 -2.366424E-05
C9 1.373478E-03 -1.550974E-05 -3.013297E-08 1.818551E-06
C10 -1.008246E-03 4.892986E-05 7.062361E-08 -2.506088E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
