V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #1
Page 1 of 8
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #1
Page 2 of 8
Ref # Part Number Qty Description
1 31460A Cylinder Assy. (Cast iron liner) (2-1/2"0
2 27652 Pin, Dowel0
3 31461 Bushing, Crankshaft0
4 27876B Seal, Oil0
5 27878A Valve, Intake (Standard)0
5 27880A Valve, Intake (1/32" oversize)0
6 31469A Valve, Exhaust (Standard) (Long Life)0
6 31470A Valve, Exhaust (1/32" oversize) (Long Life)0
7 27882 Cap, Upper valve spring0
8 27881 Spring, Valve0
8A 27881 Spring, Valve0
9A 27883 Cap, Lower valve spring (Standard)0
9A 30964 Cap, Lower valve spring (1/32" oversize)0
9 27883 Cap, Lower valve spring (Standard)0
9 30964 Cap, Lower valve spring (1/32" oversize)0
10 20810 Pin, Valve spring retaining0
11 29477A Crankshaft Assy.0
12 29783 Pin, Crankshaft gear0
13 27884 Gear, Crankshaft0
14A 27886B Piston & Pin Assy. (.010 oversize)0
14A 27887B Piston & Pin Assy. (.020 oversize)0
14A 28739B Piston & Pin Assy. (Std.) (2-1/2")0
15 28986 Ring Set, Piston (Std.) (2-1/2")0
15 28987 Ring Set, Piston (.010 oversize)0
15 28988 Ring Set, Piston (.020 oversize)0
16 27888 Ring, Piston pin retaining0
17 31295C Rod Assy., Connecting0
18 650662B Bolt, Connecting rod0
18A 30682 Bolt, Connecting rod0
18A 32077 Bolt, Connecting rod0
19 26073 Washer, Connecting rod bolt0
20 28264 Nut0
21 34034 Lifter, Valve0
22 31521 Camshaft (No Compression Release) (Extended)0
23 30684 Gasket, Mounting flange0
24 32534 Flange, Mounting0
25 31355 Screen, Oil filter0
26 29117 Screw0
30 29673 Gasket, Filler plug0
31 27625 Plug, Oil filler0
32 31462 Bushing, Crankshaft0
34 27897 Seal, Oil0
34A 28926 Seal, Oil (Camshaft)0
35 650548 Screw, Hex washer hd., 8-32 x 5/160
36 31335 Clamp, Governor lever0
37 27642 Plug, Drain0
38 31356 Pump Assy., Oil0
39 30564 Screw0
39 650488 Screw0
41 28954 Cover, Oil filler hole0
42 28749 Screw, Phil. Rd. hd., w/neoprene washer,0
43 28747 Gasket, Oil filler tube0
47 28938B Gasket, Cylinder head0
48 30938A Head, Cylinder0
49 28833 Gasket, Oil drain0
50A 31560 Clip, Fuel line0
50A 32704 Clip, Fuel line0
50 32704 Clip, Fuel line0
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #1
Page 3 of 8
Ref # Part Number Qty Description
51A 26073 Washer, Connecting rod bolt0
51A 650690 Washer, Belleville0
51B 650691 Washer, Flat0
51 650694A Screw, Hex flange hd., 5/16-18 x 20
51 650697A Screw, Hex flange hd., 5/16-18 x 2-1/20
52 33636 Plug, Spark (Champion J-8 or equivalent)0
52 34251 Resistor Spark Plug0
53 27896 Gasket, Breather cover0
54 28423 Body, Breather0
55 28424 Element, Breather0
56 28425 Cover, Valve chamber0
57 27627 Tube, Breather0
58 650128 Screw0
59 650378 Screw0
60 27915 Gasket, Intake pipe0
61 31512 Pipe, Intake0
65 26756 Gasket, Carburetor0
67 32223A Housing, Blower (5.56 Dia. starter mtg. bolt0
69 6201 Screw0
69 6202 Screw0
70 8274 Lockwasher0
71 29752 Nut0
74 30936 Flange, Air cleaner0
76 27656 Washer, Flat0
76 650168 Washer, Flat0
77 30767 Spacer, Air cleaner0
78 650152 Screw0
79 610973 Terminal Assy.0
80 31342 Spring, Compression0
81 650549 Screw0
82 32181A Control Assy., Speed0
83 30200 Screw0
84 27272 Gasket, Air cleaner0
85 31691 Bracket, Air cleaner0
86 28820 Screw0
87 730127 Cleaner Assy., Air (Poly)0
88 30727 Element, Air cleaner0
89 31715 Body, Air cleaner0
95 29536 Baffle, Blower housing0
96 650561 Screw0
98 30884 Key, Flywheel0
99 31778 Spring, Coil0
100 30939A Cover, Cylinder head0
101 650489 Screw0
101 650516 Screw0
102 31362 Link, Governor spring0
103 31361 Spring, Governor0
104 30669 Rod, Governor0
105 31357 Lever, Governor0
106 31823 Link, Throttle0
107 28277 Washer, Flat0
109 31707A Spacer Assy., Governor0
110 30668 Shaft, Mechanical governor0
111 30591 Gear Assy., Governor0
112 29193 Ring, Retaining0
113 30588A Spool, Governor0
114 27793 Clip, Conduit0
115 28942 Screw0
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #1
Ref # Part Number Qty Description
117 30622 Extension, Blower housing0
118 650128 Screw0
119 30063 Screw0
119 30688 Screw, Hex hd. Sems, 1/4-20 x 1/20
120 650557 Nut0
122 27275 Clip, Hi-tension wire0
122 33685 Clip, Hi-tension wire0
123 650815 Washer, Belleville0
124 8116 Nut0
126 31525 Tank Assy., Fuel (2 qt.)0
127 33032 Cap, Fuel filler (Red Plastic) (Spurt0
127 34210 Cap, Fuel filler (Red Plastic) (Spurt0
127 410144B Cap, Fuel filler (White Plastic) (Std.)0
131 29747A Screw0
137 29716 Screw0
137 650601 Screw, Fil. hd., 1/4-28 x 20
143 590417 Screen, Starter cup0
144 32125 Cup, Starter0
157 28468 Wire, Ground (Female fitting both ends)0
169 31588 Plate, Muffler locking0
171 28921 Muffler0
172 30196 Screw0
172 6021A Screw, Hex flange hd., 5/16-18 x 1-1/20
172 650689 Screw0
172 650695A Screw, Hex flange hd., 5/16-18 x 2-1/40
172 650696 Screw, Hex hd., 5/16-18 x 2-3/40
172 650697A Screw, Hex flange hd., 5/16-18 x 2-1/20
172A 8274 Lockwasher0
173 27930 Gasket, Exhaust0
181 29573 Elbow, Oil drain (90ø)0
184 30747 Clip, Shorting0
185 16645 Lockwasher0
206 31873 Baffle, Air0
234B 31752 Decal, Air cleaner0
234D 31490 Decal, Oil0
234D 32130 Decal, Long Life0
234 34346 Decal, Instruction0
234A 31478 Decal, H.P. (4 H.P.)0
234A 31517 Decal, H.P. (5 H.P.)0
234A 32173 Decal, H.P. (6 H.P.)0
234A 34316 Decal, Name0
234C 31495 Decal, Speed control0
235 30547A Contact Assy., Breaker0
236 30548B Condenser0
237 631021 Inlet Needle, Seat & Clip Assy.0
240 631126 Carburetor0
241 610689A Magneto, Tecumseh0
242 590420 Starter, Rewind0
245 33234A Gasket Set0
Page 4 of 8
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #2
Page 5 of 8
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #2
Ref # Part Number Qty Description
51A 26073 Washer, Connecting rod bolt0
51A 650690 Washer, Belleville0
130 28511 Plate, Securing0
140 590343 Rope & Handle Assy., Starter0
141 28301 Pulley, Starter0
149 30063 Screw0
149 30688 Screw, Hex hd. Sems, 1/4-20 x 1/20
151 28726 Screw, Phil. rd. hd., 5-40 x 9/160
152 28727 Lockwasher0
153 28728 Nut0
154 30064 Cover, Rectifier panel0
155 30065 Nut, Long 5-400
156 30066 Screw0
163A 33018 Harness, Adapter0
201 28545 Grommet, Plastic0
202 33356 Terminal, Ground0
203 650643 Screw0
204 24522 Control, Throttle0
234G 30595 Decal, Ezee-start0
244 33518A Starter Motor Kit (110-120 Volt)0
244A 30811A Flywheel0
Page 6 of 8
97 29749 Clip, Retaining0
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #3
Page 7 of 8
www.mymowerparts.com
V40-50116F
For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983
Engine Parts List #3
Ref # Part Number Qty Description
116B 28837 Strainer & Fitting0
116 28584 Strainer & Elbow0
116A 29683 Strainer & Shut-off0
130 28511 Plate, Securing0
131 29747A Screw0
132 28819 Spring, Fuel line0
133 31613 Brace, Fuel tank0
134 29774 Line, Fuel (Braided 8.25")0
134 30705 Line, Fuel (Braided 16")0
134 30962 Line, Fuel (Braided 32")0
134 30965 Line, Fuel (Braided 48")0
135 26460 Clamp, Fuel line0
145 31668 Bag, Pre-cleaner0
146 31667 Spring, Pre-cleaner bag0
147 730512 Kit, Pre-cleaner0
162 8274 Lockwasher0
164 33323 Screen, Muffler0
165 33700 Cover & Tube, Muffler0
166 650578 Screw0
167 31288 Muffler Adapter Kit0
168 730130 Muffler Adapter Kit0
170 28443 Nut, Conduit (1/8" thick)0
170 32862 Nut, Conduit (1/4" thick)0
171E 391026 Muffler0
172 30196 Screw0
172 6021A Screw, Hex flange hd., 5/16-18 x 1-1/20
172 650689 Screw0
172 650695A Screw, Hex flange hd., 5/16-18 x 2-1/40
172 650696 Screw, Hex hd., 5/16-18 x 2-3/40
172 650697A Screw, Hex flange hd., 5/16-18 x 2-1/20
173 27930 Gasket, Exhaust0
179 30244 Nipple, Exhaust pipe (2-1/2")0
179 32332 Nipple, Exhaust pipe (2")0
179 32454 Nipple, Exhaust pipe (1-3/8")0
180 29574 Elbow, Exhaust (90ø)0
180 30209 Elbow, Exhaust (45ø)0
Page 8 of 8
72 31572 Strap, Fuel tank0
73 650556 Screw0
73 792028 Screw, Hex hd. Sems, 5/16-18 x 7/80
86 28820 Screw0
