Tecumseh TVS120-63000 Parts Manuals

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 1 of 10
Engine Parts List #1

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 2 of 10
Engine Parts List #1

Ref # Part Number Qty DescriptionS/P/F

1 33968B "Cylinder (Incl. 2 & 20) (2-13/16")1 /P
2 26727 Dowel Pin1
6 33734 Element, Breather1
7 34214A Breather Ass'y. Incl. 6, 8, 9, 12 , & 12A1 S/P
8 33735 * Gasket, Breather1

9 30200 Screw, 10-24 x 9/16"1 /P
12 33886 Tube, Breather1 /P
14 28277 Flat Washer1
15 30589 Rod, Governor (Incl. 14)1
16 31383A Lever, Governor1 /P
17 31335 Clamp, Governor lever1
18 650548 Screw, 8-32 x 5/16"1 S
19 31361 Spring, Extension1
20 32600 Seal, Oil1
30 32881B Crankshaft1 /P
32 32323 Washer, Thrust NOTE: This thrust wash er

1

maynot be required if a new cranks hafthas
been installed. Check the pro per Mechanic's
Handbook for acceptabl e end play. Use this
.010" thrust was her if excess end play is
measured.

40 34535 Piston, Pin & Ring Set (Std.) 2-13/1 6"1
40 34536 Piston, Pin & Ring Set (.010" OS)1
40 34537 Piston, Pin & Ring Set (.020" OS)1
41 33562B Piston & Pin Ass'y. (Incl. 43)(Std.) 2-13/16"1 /P
41 33563B Piston & Pin Ass'y. (Incl. 43) .010" OS1 /P
41 33564B Piston & Pin Ass'y. (Incl. 43) .020" OS1 /P
42 33567 Ring Set (Std.) (2-13/16" Bore)1 S
42 33568 Ring Set (.010" OS)1
42 33569 Ring Set (.020" OS)1
43 20381 Piston Pin Retaining Ring1
45 32875 Rod Assy., Connecting (Incl. 46)1 S/P
46 32610A Bolt, Connecting rod1 /P
48 27241 Valve Lifter1
50 33553 Camshaft (MCR)1 S/P
52 29914 Oil Pump Ass'y.1
69 35261 * Gasket, Mounting flange1 S/P
70 34311C Flange Ass'y. Incl. 72, 72A, 73, 75 & 801 S/P
72 30572 Plug, Oil drain (Incl. 73)1 S/P
73 28833 * Drain Plug Gasket Not req. W/plastic plug1 /P
75 27897 Oil Seal1
80 30574 Shaft, Governor1 S/P
81 30590A Washer, Flat1 /P
82 30591 Gear Assy., Governor (Incl. 81)1 /P
83 30588A Spool, Governor1 /P
84 29193 Retaining Ring1
86 650488 Screw, 1/4-20 x 1-1/4"1 /P
89 610951 Flywheel Key1 /P
92 650815 Washer, Belleville1 /P

92A 650791 Washer, Flat1 /P

93 650607 Nut, Flywheel1 /P

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 3 of 10
Engine Parts List #1

Ref # Part Number Qty DescriptionS/P/F

100 730207 Magneto-to-Solid State Conv. Kit (Inc ludes

101 610118 Cover, Spark plug (Use as required)1
103 650489 Screw, 1/4-20 x 5/8"1
110 34231 Ground Wire1
118 730194 Rope Guide Kit (Use as required)1
119 33554A * Gasket, Head1 S/P
120 34342 Head, Cylinder1 S
125 29313C Exhaust Valve (Std.) (Incl. 151) (Inv erted

1 /P

solid state module, solid state flywheel key,
and instructions.) (Us e as required on
external ignition en gines only.)

1 /P

Ports)

125 29314B Intake Valve (Std.) (Incl. 151) (Conv entional

125 29315C Exhaust Valve (1/32" OS) (Incl. 151)

126 29313C Exhaust Valve (Std.) (Incl. 151) (Con ventional

126 29315C Exhaust Valve (1/32" OS) (Incl. 151)

126 32644A Intake Valve (Incl. 151) Inverted Po rts1 /P
126 34776 Exhaust Valve (Std.) (Incl. 151) (Con ventional

130 6021A Screw, 5/16-18 x 1-1/2" Use as requir ed1 /P
130 650697A Screw, 5/16-18 x 2-1/2" Use as requir ed1 /P
135 33636 Resistor Spark Plug - RJ17LM1 /P
150 31672 Spring, Valve1 /P
151 31673 Cap, Lower valve spring1
169 27234A Valve Cover Gasket1 /P
172 32755 Cover, Valve spring box1
174 650128 Screw, 10-24 x 1/2"1 /P
178 29752 Nut & Lock Washer 1/4-281 /P
179 30593 Clip, Wire1
182 6201 Screw, 1/4-28 x 7/8"1 /P
184 26756 * Gasket, Carburetor1 /P
185 31384A Pipe, Intake (Incl. 224)1 /P
186 34337 Link, Governor spring1
200 33131A Control Bracket (Incl. 202 thru 206)1 /P
202 33802 Spring, Compression1 S
203 31342 Spring, Compression1
204 650549 Screw, 5-40 x 7/16"1 S
205 650777 Screw, 6-32 x 21/32"1 S/P
206 610973 Terminal (Use as required)1
207 34336 Link, Throttle1 S
209 30200 Screw, 10-24 x 9/16"1 /P
210 27793 Conduit Clip1 /P
211 28942 Screw, 10-32 x 3/8"1 /P
223 650451 Screw, 1/4-20 x 1"1 /P
224 32649A Gasket, Intake pipe1 /P
238 650806 Screw, 10-32 x 5/8"1

www.mymowerparts.com

1 S/P

Ports)

1 /P

(Conventional Ports)

1 /P

Ports)

1 /P

(Conventional Ports)

1 S/P

Ports)

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 4 of 10
Engine Parts List #1

Ref # Part Number Qty DescriptionS/P/F

239 34338 * Gasket, Air cleaner1
240 34339 Body, Air cleaner1
246 34340 Air Filter (Poly) (also available in Packaged

246E 35435 Filter, Pre-air (Use as required)1 /P

250 34341A Cover, Air cleaner1 S/P
260 34345 Housing, Blower1 /P
261 30200 Screw, 10-24 x 9/16"1 /P
262 650831 Screw, 1/4-20 x 15/32"1
277 650774 Screw, 1/4-20 x 2-3/8" Use as requir ed1
277 650795 Screw, 1/4-20 x 2-1/4" Use as requir ed1
277 792005 Screw, 1/4-20 x 2-1/2" Use as requir ed1
287 650802 Screw, 1/4-20 x 5/8"1 /P
290 29774 Fuel Line (8.62") as req.)1 /P
290 30705 Fuel Line (Braided 16")(40 cm) Use as req.1 /P
290 30962 Fuel Line (Braided 32")(81 cm) Use as req.1 /P
290 34357 Fuel Line (Epichlorohydrin 6-3/4") 17 cm1 S/P
292 26460 Fuel Line Clamp1 /P
300 32170A Fuel Tank (Incl. 292 & 301)1 S/P
301 33032 Fuel Cap (Red 1-1/2" ID) also availab le in

1

Part #740023B)

1 /P

Packaged Part #740005B

305 34264 Oil Fill Tube1
306 34265 Gasket, Oil fill tube1
306 34282 "O" Ring This "O" ring is required wi th metal

307 33590 "O" Ring1
309 650562 Screw, 10-32 x 1/2"1 /P
310 34267 Oil Dipstick (Incl. 150)1 /P

313A 33876 Gasket, Stator1

325 27275 Wire Clip1 /P
326 34113 Plug, Screen1

370A 34346 Decal, Instruction1 S/P

370J 34870 Decal, Instruction (Optional)1

370H 34387 Decal, Instruction (Optional)1

370B 34363 Decal, Instruction1 /P

375 610964 Magneto (W/ring gear) Note: The compl ete

1

fill tube only when replacem ent mounting
flange with .777 dia. oi l fill hole has been
used.

1

magneto is not available as an as sembly. The
magneto number is for ref erence purposes
only. Order component parts individually, as
shown in the breakdown. (Refer to Division 5,
Sect ion B, page 35 or Fiche 8A, Grid G-1 for
breakdown)

377 30547A Breaker Points (also available in Pac kaged

378 30548B Condenser (also available in Packaged Part

379 631021 Inlet Needle, Seat & Clip Assy.1 S/P

1 /P

Part #740037B)

1 /P

#740037B)

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 5 of 10
Engine Parts List #1

Ref # Part Number Qty DescriptionS/P/F

380 632078A Carburetor (Incl. 184) (Refer to Divi sion 5,

1 S/P

Section A, page A2-10 or Fich e 8A, Grid E-13
for breakdown)

390A 590531 Side Mount Rewind Starter Refer to Di vision

400 33740D * Gasket Set (Incl. items marked *)1 S/P
420 730225 SAE 30, 4-Cycle Engine Oil (Quart)1 S
425 730571 Starter Muff Kit (Incl. 370J,426,427) Opt.1
426 32203 Starter Air Cleaner (Optional)1
427 32204 Starter Air Cleaner Bracket Optional1
436 611006 Stator Plate Ass'y. Incl. 377,378,437 , 442-4481 /P
437 30551 Spring, Breaker box cover1
438 610947 Cover, Dust1 /P
439 610955 Gasket, Stator cover1 /P
440 30992 Cam, Breaker1 /P
442 610385 Washer1 /P
443 610408 Nut, 8-321 /P
444 29181 Breaker Fastening Screw & Washer1 /P
445 610593 Condenser Fastening Screw1
446 33356 Terminal, Ground1 /P

1 S

5, Section C, page 32 or Fiche 8A, Grid G-3
for breakdown

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 6 of 10
Engine Parts List #2

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 7 of 10
Engine Parts List #2

Ref # Part Number Qty DescriptionS/P/F

32 32323 Washer, Thrust NOTE: This thrust wash er

92A 650791 Washer, Flat1 /P

118 730194 Rope Guide Kit (Use as required)1
238 650806 Screw, 10-32 x 5/8"1
239 34338 * Gasket, Air cleaner1
246 34340 Air Filter (Poly) (also available in Packaged

246E 35435 Filter, Pre-air (Use as required)1 /P

250 34341A Cover, Air cleaner1 S/P
287A Pop Rivet (3/16" Dia.) Purchase local ly1
287A 650735 Screw, 10-24 x 3/8" (Use as required)1
313A 33876 Gasket, Stator1

326 34113 Plug, Screen1

370J 34870 Decal, Instruction (Optional)1

370H 34387 Decal, Instruction (Optional)1

370 550223 Decal, Name1 /P

375 610964 Magneto (W/ring gear) Note: The compl ete

1

maynot be required if a new cranks hafthas
been installed. Check the pro per Mechanic's
Handbook for acceptabl e end play. Use this
.010" thrust was her if excess end play is
measured.

1

Part #740023B)

1

magneto is not available as an as sembly. The
magneto number is for ref erence purposes
only. Order component parts individually, as
shown in the breakdown. (Refer to Division 5,
Sect ion B, page 35 or Fiche 8A, Grid G-1 for
breakdown)

377 30547A Breaker Points (also available in Pac kaged

378 30548B Condenser (also available in Packaged Part

390A 590531 Side Mount Rewind Starter Refer to Di vision

425 730571 Starter Muff Kit (Incl. 370J,426,427) Opt.1

426 32203 Starter Air Cleaner (Optional)1

427 32204 Starter Air Cleaner Bracket Optional1

436 611006 Stator Plate Ass'y. Incl. 377,378,437 , 442-4481 /P

437 30551 Spring, Breaker box cover1

438 610947 Cover, Dust1 /P

439 610955 Gasket, Stator cover1 /P

440 30992 Cam, Breaker1 /P

442 610385 Washer1 /P

443 610408 Nut, 8-321 /P

444 29181 Breaker Fastening Screw & Washer1 /P

445 610593 Condenser Fastening Screw1

446 33356 Terminal, Ground1 /P

1 /P

Part #740037B)

1 /P

#740037B)

1 S

5, Section C, page 32 or Fiche 8A, Grid G-3
for breakdown

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 8 of 10
Engine Parts List #3

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 9 of 10
Engine Parts List #3

Ref # Part Number Qty DescriptionS/P/F

19 31361 Spring, Extension1
32 32323 Washer, Thrust NOTE: This thrust wash er

69 35261 * Gasket, Mounting flange1 S/P

92A 650791 Washer, Flat1 /P

118 730194 Rope Guide Kit (Use as required)1

182 6201 Screw, 1/4-28 x 7/8"1 /P

185 31384A Pipe, Intake (Incl. 224)1 /P

186 34337 Link, Governor spring1

206 610973 Terminal (Use as required)1

209 30200 Screw, 10-24 x 9/16"1 /P

223 650451 Screw, 1/4-20 x 1"1 /P

238 650806 Screw, 10-32 x 5/8"1

239 34338 * Gasket, Air cleaner1

240 34339 Body, Air cleaner1

246 34340 Air Filter (Poly) (also available in Packaged

1

maynot be required if a new cranks hafthas
been installed. Check the pro per Mechanic's
Handbook for acceptabl e end play. Use this
.010" thrust was her if excess end play is
measured.

1

Part #740023B)

246E 35435 Filter, Pre-air (Use as required)1 /P

250 34341A Cover, Air cleaner1 S/P

274 26754A * Gasket, Exhaust (Use as required)1 /P
275A 35603 Muffler (Incl. 277)1 S/P

277 650774 Screw, 1/4-20 x 2-3/8" Use as requir ed1

277 650795 Screw, 1/4-20 x 2-1/4" Use as requir ed1

277 792005 Screw, 1/4-20 x 2-1/2" Use as requir ed1
277A 30063 Screw, T-30, 1/4-20 x 1/2" as req.)1 /P
313A 33876 Gasket, Stator1

326 34113 Plug, Screen1

370J 34870 Decal, Instruction (Optional)1

370H 34387 Decal, Instruction (Optional)1

375 610964 Magneto (W/ring gear) Note: The compl ete

377 30547A Breaker Points (also available in Pac kaged

1

magneto is not available as an as sembly. The
magneto number is for ref erence purposes
only. Order component parts individually, as
shown in the breakdown. (Refer to Division 5,
Sect ion B, page 35 or Fiche 8A, Grid G-1 for
breakdown)

1 /P

Part #740037B)

378 30548B Condenser (also available in Packaged Part

390A 590531 Side Mount Rewind Starter Refer to Di vision

410 730574 Debris Screen Kit (Incl. 370H,411-413 ) Opt.1 S

411 35596 Debris Screen (Optional)1

412 35597 Debris Screen Bracket (Optional)1

1 /P

#740037B)

1 S

5, Section C, page 32 or Fiche 8A, Grid G-3
for breakdown

www.mymowerparts.com

For Discount Tecumseh Engine Parts Call 606-678-9623 or 606-561-4983

TVS120-63000 Page 10 of 10
Engine Parts List #3

Ref # Part Number Qty DescriptionS/P/F

413 650910 Screw, 8-32 x 1/4 (Optional)1 /P

415 730162 Muffler Adapter Kit (Incl. 274,277) U se as req1

425 730571 Starter Muff Kit (Incl. 370J,426,427) Opt.1

426 32203 Starter Air Cleaner (Optional)1

427 32204 Starter Air Cleaner Bracket Optional1

436 611006 Stator Plate Ass'y. Incl. 377,378,437 , 442-4481 /P

437 30551 Spring, Breaker box cover1

438 610947 Cover, Dust1 /P

439 610955 Gasket, Stator cover1 /P

440 30992 Cam, Breaker1 /P

442 610385 Washer1 /P

443 610408 Nut, 8-321 /P

444 29181 Breaker Fastening Screw & Washer1 /P

445 610593 Condenser Fastening Screw1

446 33356 Terminal, Ground1 /P

www.mymowerparts.com
