Performance Data Sheet
TPB9423YAA
General Information
Model TPB9423YAA Refrigerant R-134a
Test Condition ARI Performance Test Voltage 115V ~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 1960 1820 1690 1550 1410 1270 1140
Watts 335 340 345 350 355 360 365
Amps 5.87 5.89 5.91 5.93 5.95 5.97 5.99
Lb/h 27.5 26.7 25.8 25.0 24.2 23.3 22.5
Btu/h 2310 2150 1980 1820 1650 1480 1320
Watts 355 362 369 375 382 388 395
Amps 5.96 5.99 6.03 6.06 6.09 6.12 6.15
Lb/h 32.1 31.2 30.2 29.2 28.2 27.2 26.2
Btu/h 2690 2500 2300 2110 1910 1720 1520
Watts 377 385 394 402 410 418 426
Amps 6.07 6.11 6.15 6.20 6.24 6.28 6.32
Lb/h 37.4 36.2 35.0 33.9 32.7 31.5 30.3
Btu/h 3100 2870 2650 2420 2200 1980 1750
Watts 400 410 420 430 439 449 458
Amps 6.19 6.25 6.30 6.35 6.41 6.46 6.51
Lb/h 43.1 41.8 40.5 39.1 37.8 36.4 35.1
Btu/h 3520 3270 3020 2760 2510 2260 2000
Watts 425 436 448 459 470 481 492
Amps 6.34 6.41 6.47 6.54 6.60 6.66 6.73
Lb/h 49.5 48.0 46.5 44.9 43.4 41.9 40.4
Btu/h 3970 3690 3410 3130 2840 2560 2280
Watts 452 464 477 490 502 515 528
Amps 6.52 6.60 6.67 6.74 6.82 6.89 6.96
Lb/h 56.4 54.7 53.0 51.4 49.7 48.0 46.3
Btu/h 4440 4130 3820 3510 3200 2890 2580
Watts 480 494 508 523 537 551 565
Amps 6.73 6.82 6.90 6.98 7.07 7.15 7.23
Lb/h 63.9 62.1 60.2 58.4 56.5 54.6 52.7
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 3.050909E+03 2.934401E+02 5.716881E+00 3.409237E+01
C2 1.154941E+02 1.448624E+00 -4.042783E-03 1.144239E+00
C3 -1.364273E+01 5.076556E-01 1.865571E-03 -8.300524E-02
C4 4.808201E-01 2.552455E-02 3.540199E-04 1.092920E-02
C5 -5.860261E-01 3.199904E-02 2.536137E-04 -3.298523E-03
C6 1.415821E-04 2.018328E-04 2.196149E-06 9.861337E-06
C7 -9.765071E-04 2.178573E-04 5.283667E-06 1.891726E-05
C8 2.739462E-04 -4.838590E-05 -1.149800E-06 -3.632333E-06
C9 -3.099726E-06 -1.200292E-06 -3.412332E-08 -2.036061E-07
C10 -2.900925E-06 -1.342499E-06 -1.102492E-08 -5.908204E-08
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
TPB9423YAA
General Information
Model TPB9423YAA Refrigerant R-134a
Test Condition ARI Performance Test Voltage 115V ~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 3900 3570 3270 2990 2730 2480 2230
Watts 392 430 456 474 485 495 504
Amps 6.16 6.38 6.52 6.61 6.68 6.75 6.84
Lb/h 49.5 48.1 46.8 45.6 44.2 42.6 40.7
Btu/h 4390 4030 3690 3390 3100 2820 2550
Watts 421 460 487 505 518 528 539
Amps 6.32 6.55 6.70 6.80 6.88 6.95 7.05
Lb/h 55.9 54.4 53.0 51.7 50.3 48.6 46.6
Btu/h 4930 4530 4160 3820 3500 3200 2900
Watts 452 492 519 538 552 563 575
Amps 6.50 6.74 6.90 7.01 7.09 7.17 7.28
Lb/h 62.8 61.2 59.8 58.4 57.0 55.2 53.2
Btu/h 5510 5070 4670 4300 3950 3620 3300
Watts 486 526 554 573 587 599 611
Amps 6.71 6.96 7.13 7.24 7.33 7.41 7.52
Lb/h 70.3 68.7 67.3 65.8 64.3 62.5 60.4
Btu/h 6140 5670 5230 4820 4440 4080 3740
Watts 522 562 590 609 624 635 648
Amps 6.96 7.21 7.38 7.50 7.59 7.67 7.78
Lb/h 78.5 76.9 75.4 73.9 72.3 70.5 68.4
Btu/h 6830 6320 5840 5400 4990 4600 4230
Watts 561 601 628 648 662 674 687
Amps 7.25 7.50 7.67 7.79 7.87 7.96 8.07
Lb/h 87.4 85.7 84.2 82.7 81.1 79.3 77.1
Btu/h 7580 7030 6510 6040 5600 5180 4770
Watts 603 642 669 688 702 713 726
Amps 7.57 7.82 7.99 8.10 8.19 8.27 8.37
Lb/h 97.0 95.3 93.8 92.3 90.7 88.9 86.7
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 5.459755E+03 -7.909269E+02 -1.219943E+00 5.615001E+01
C2 1.340795E+02 1.383476E+00 -3.057451E-02 1.117869E+00
C3 -6.460844E+01 2.660881E+01 1.833996E-01 -7.125152E-01
C4 6.256447E-01 7.982582E-02 7.204799E-04 4.666624E-03
C5 -1.002138E+00 2.494157E-02 5.914040E-04 -3.151504E-03
C6 4.022436E-01 -2.048791E-01 -1.549524E-03 6.284391E-03
C7 5.511943E-03 1.348803E-04 3.145956E-06 5.966628E-05
C8 -2.038694E-03 -5.354772E-04 -4.817838E-06 2.555280E-05
C9 2.321640E-03 8.450224E-05 -8.551490E-07 2.443450E-06
C10 -1.104167E-03 5.291691E-04 4.375021E-06 -2.083349E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
