Performance Data Sheet
TPA0413YXA
General Information
Model TPA0413YXA Refrigerant R-134a
Test Condition ARI Performance Test Voltage 115V ~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type N/A
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 1090 1010 935 858 782 707 632
Watts 204 207 211 214 217 220 224
Amps 3.51 3.52 3.52 3.53 3.54 3.54 3.55
Lb/h 15.3 14.8 14.3 13.8 13.3 12.9 12.4
Btu/h 1260 1170 1080 997 911 825 741
Watts 211 216 220 225 230 235 240
Amps 3.53 3.55 3.56 3.58 3.59 3.61 3.62
Lb/h 17.6 17.1 16.5 16.0 15.5 15.0 14.5
Btu/h 1440 1340 1240 1140 1040 942 846
Watts 217 224 230 236 243 249 256
Amps 3.56 3.58 3.61 3.63 3.66 3.68 3.70
Lb/h 20.1 19.5 18.9 18.3 17.8 17.2 16.7
Btu/h 1630 1510 1400 1280 1170 1060 954
Watts 224 232 240 248 256 264 272
Amps 3.59 3.63 3.66 3.69 3.73 3.76 3.79
Lb/h 22.8 22.1 21.4 20.8 20.2 19.6 19.0
Btu/h 1840 1710 1580 1450 1320 1190 1070
Watts 232 241 250 260 269 278 288
Amps 3.62 3.67 3.71 3.76 3.80 3.84 3.89
Lb/h 25.8 25.0 24.3 23.5 22.8 22.2 21.5
Btu/h 2070 1920 1780 1630 1490 1340 1200
Watts 240 251 261 272 283 294 304
Amps 3.65 3.71 3.76 3.82 3.87 3.93 3.98
Lb/h 29.3 28.4 27.5 26.7 25.8 25.0 24.3
Btu/h 2340 2170 2000 1840 1680 1520 1360
Watts 249 261 273 285 297 310 322
Amps 3.67 3.74 3.81 3.88 3.94 4.01 4.08
Lb/h 33.3 32.3 31.2 30.2 29.3 28.3 27.4
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.706120E+03 1.780973E+02 3.458540E+00 1.926737E+01
C2 5.322665E+01 -1.192800E+00 -1.065587E-02 5.216711E-01
C3 -7.619610E+00 3.280805E-01 6.233108E-04 -4.836249E-02
C4 2.698642E-01 7.665815E-03 4.780088E-05 5.210025E-03
C5 -2.660019E-01 3.019676E-02 1.911158E-04 -1.274686E-03
C6 -2.419504E-03 -2.346497E-05 3.131648E-07 -3.147752E-05
C7 8.488685E-03 2.663713E-04 -4.226203E-06 1.191867E-04
C8 -3.344357E-03 -1.047221E-04 1.713239E-06 -4.677813E-05
C9 3.342297E-04 1.046732E-05 -1.767847E-07 4.649906E-06
C10 1.467690E-05 4.019120E-08 -2.290090E-11 1.874465E-07
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
TPA0413YXA
General Information
Model TPA0413YXA Refrigerant R-134a
Test Condition ARI Performance Test Voltage 115V ~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type N/A
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 1830 1720 1610 1490 1380 1270 1160
Watts 223 233 243 253 263 273 282
Amps 3.58 3.64 3.69 3.75 3.81 3.87 3.94
Lb/h 24.1 23.5 23.0 22.5 22.0 21.5 21.0
Btu/h 2100 1960 1830 1690 1560 1420 1290
Watts 231 242 254 265 276 287 299
Amps 3.62 3.69 3.75 3.82 3.89 3.95 4.02
Lb/h 27.6 26.9 26.2 25.4 24.7 24.0 23.3
Btu/h 2400 2240 2070 1910 1750 1590 1430
Watts 238 251 264 277 290 302 315
Amps 3.66 3.74 3.82 3.90 3.97 4.05 4.12
Lb/h 31.6 30.7 29.8 28.9 27.9 27.0 26.1
Btu/h 2720 2530 2350 2160 1970 1790 1600
Watts 245 260 274 289 303 317 332
Amps 3.70 3.80 3.89 3.98 4.06 4.15 4.23
Lb/h 35.9 34.9 33.8 32.7 31.6 30.5 29.4
Btu/h 3070 2860 2640 2430 2220 2010 1800
Watts 251 267 284 300 316 332 348
Amps 3.73 3.85 3.95 4.05 4.15 4.25 4.35
Lb/h 40.7 39.5 38.3 37.0 35.8 34.5 33.2
Btu/h 3450 3200 2960 2730 2490 2250 2010
Watts 256 275 293 311 329 347 364
Amps 3.76 3.89 4.01 4.13 4.25 4.36 4.47
Lb/h 45.9 44.6 43.2 41.8 40.4 38.9 37.4
Btu/h 3850 3580 3310 3050 2780 2520 2260
Watts 260 281 301 321 341 361 380
Amps 3.77 3.92 4.06 4.20 4.33 4.46 4.58
Lb/h 51.4 50.0 48.5 46.9 45.3 43.7 42.1
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.054847E+03 1.611671E+02 3.332675E+00 1.282860E+01
C2 7.354296E+01 -7.897678E-01 -1.081604E-02 5.932044E-01
C3 -9.770024E-01 3.616166E-01 1.156565E-03 2.077400E-02
C4 4.841222E-01 -5.601986E-03 1.282215E-05 8.898500E-03
C5 -5.071341E-01 3.163635E-02 2.272728E-04 -3.652273E-03
C6 -1.264088E-03 2.567611E-04 1.580681E-06 7.025891E-06
C7 7.720465E-04 -2.111868E-04 -4.481746E-06 -2.644262E-05
C8 -6.407855E-04 1.835354E-04 4.103392E-06 2.446517E-05
C9 1.659087E-04 -5.000473E-05 -1.178708E-06 -7.099284E-06
C10 -3.368731E-06 2.206461E-06 9.233437E-08 5.815015E-07
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
