Tecumseh THG1352YGS Performance Data Sheet

Performance Data Sheet

THG1352YGS

General Information

Model THG1352YGS Refrigerant R-134a
Test Condition ASHRAE Performance Test Voltage 220V ~ 50HZ
Return Gas 32.2°C (90°F) RETURN GAS Motor Type N/A

Performance Information

Evap

Temp (°C)

-40

-35

-30

-25

-23.3

-20

-15

-10

Condensing Temperature (°C)

30 40 50 60

Btu/h 193 178 146 108

Watts (Power) 67.5 67.3 65.1 61.7

Amps 0.83 0.81 0.80 0.80

Lb/h 2.46 2.20 1.75 1.22

Btu/h 275 256 221 180

Watts (Power) 77.1 78.3 77.2 74.7

Amps 0.83 0.81 0.81 0.81

Lb/h 3.53 3.26 2.79 2.24

Btu/h 378 355 316 273

Watts (Power) 87.3 90.4 90.8 89.8

Amps 0.85 0.84 0.83 0.83

Lb/h 4.84 4.55 4.05 3.47

Btu/h 504 476 434 388

Watts (Power) 97.7 103 106 106

Amps 0.87 0.87 0.87 0.87

Lb/h 6.44 6.11 5.58 4.97

Btu/h 552 523 479 432

Watts (Power) 101 107 111 112

Amps 0.88 0.88 0.89 0.89

Lb/h 7.05 6.71 6.17 5.54

Btu/h 652 621 575 526

Watts (Power) 108 116 121 124

Amps 0.89 0.90 0.92 0.92

Lb/h 8.35 7.99 7.42 6.76

Btu/h 825 789 740 688

Watts (Power) 118 129 137 143

Amps 0.91 0.94 0.97 0.98

Lb/h 10.6 10.2 9.60 8.89

Btu/h 1020 983 930 875

Watts (Power) 127 142 154 163

Amps 0.92 0.97 1.01 1.04

Lb/h 13.3 12.8 12.2 11.4

COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW

C1 1.476459E+03 3.637234E+01 5.746910E-01 1.922261E+01
C2 5.703655E+01 -2.047091E+00 -2.644255E-02 8.041933E-01
C3 7.366787E+00 4.533667E+00 1.082560E-02 1.112120E-01
C4 5.705524E-01 -6.314711E-02 -6.504402E-04 1.078637E-02
C5 -1.532665E-01 1.132445E-01 7.880896E-04 -1.072366E-03
C6 -2.741457E-01 -3.928763E-02 3.158131E-05 -3.428595E-03
C7 1.375672E-03 -4.346608E-04 -7.243212E-06 5.279411E-05
C8 -8.886909E-05 9.445961E-04 5.221595E-06 -1.396140E-05
C9 8.600728E-04 -2.182332E-04 -4.073442E-06 -3.814260E-06

C10 1.842135E-03 1.655163E-04 -9.896090E-07 1.932276E-05

Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3

Te = Evaporator Temperature

Tc = Condensing Temperature
