Performance Data Sheet
AWF5530EXG
General Information
Model AWF5530EXG Refrigerant R-22
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
-15
-10
-5
0
5
10
15
20
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 8000 6810
Watts 1140 1200
Amps 2.21 2.33
Lb/h 103 91.4
Btu/h 9880 8640 7420
Watts 1240 1310 1350
Amps 2.32 2.43 2.51
Lb/h 127 115 103
Btu/h 11900 10600 9300 8070
Watts 1340 1410 1470 1500
Amps 2.43 2.54 2.62 2.66
Lb/h 152 140 128 117
Btu/h 14100 12700 11300 9970 8720
Watts 1430 1510 1580 1630 1650
Amps 2.52 2.64 2.72 2.78 2.80
Lb/h 178 167 155 143 131
Btu/h 16400 15000 13500 12000 10600
Watts 1510 1610 1690 1750 1780
Amps 2.61 2.73 2.83 2.89 2.93
Lb/h 207 195 183 170 158
Btu/h 19000 17400 15800 14200 12700 11300 10000
Watts 1590 1700 1790 1870 1920 1950 1950
Amps 2.69 2.82 2.92 3.00 3.06 3.09 3.10
Lb/h 237 226 213 200 187 174 163
Btu/h 21700 20000 18300 16600 14900 13300 11900
Watts 1650 1780 1890 1980 2050 2100 2130
Amps 2.76 2.90 3.02 3.11 3.18 3.24 3.27
Lb/h 270 258 245 232 218 204 191
Btu/h 24700 22900 21000 19100 17300 15500 13900
Watts 1710 1850 1980 2090 2180 2250 2300
Amps 2.82 2.97 3.10 3.22 3.31 3.39 3.45
Lb/h 305 293 280 266 251 236 222
Btu/h 27900 26000 23900 21900 19900 17900 16100
25
30
35
40
45
50
55
Watts 1750 1910 2060 2190 2300 2390 2460
Amps 2.87 3.04 3.18 3.32 3.43 3.53 3.62
Lb/h 342 330 317 302 287 271 256
Btu/h 31400 29300 27100 24900 22700 20500 18500
Watts 1790 1960 2130 2280 2410 2530 2630
Amps 2.90 3.09 3.25 3.41 3.55 3.68 3.80
Lb/h 382 370 356 341 325 308 291
Btu/h 35200 32900 30500 28100 25700 23300 21000
Watts 1800 2000 2180 2360 2520 2660 2780
Amps 2.92 3.12 3.31 3.49 3.66 3.82 3.98
Lb/h 426 413 399 383 366 348 330
Btu/h 39200 36800 34200 31600 29000 26400 23900
Watts 1810 2020 2230 2430 2610 2780 2930
Amps 2.93 3.15 3.36 3.57 3.77 3.96 4.15
Lb/h 472 459 444 428 409 390 371
Btu/h 43600 41000 38200 35400 32500 29700 26900
Watts 1790 2030 2260 2480 2690 2890 3070
Amps 2.91 3.16 3.40 3.64 3.87 4.10 4.33
Lb/h 522 509 493 476 457 436 416
Btu/h 48400 45500 42500 39500 36400 33300 30200
Watts 1760 2020 2280 2520 2760 2990 3200
Amps 2.88 3.16 3.43 3.70 3.96 4.23 4.50
Lb/h 576 562 546 527 507 486 463
Btu/h 53400 50400 47200 43900 40500 37200 33800
Watts 1710 1990 2270 2550 2820 3070 3320
Amps 2.83 3.14 3.44 3.74 4.05 4.35 4.66
Lb/h 633 619 602 582 561 538 515
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.017618E+04 3.553011E+02 3.600070E-01 1.909124E+02
C2 4.901298E+02 1.060649E+01 3.172068E-02 3.937233E+00
C3 2.955237E+01 1.457158E+01 4.221444E-02 1.299367E+00
C4 5.474756E+00 -3.385968E-01 -5.397035E-04 4.369247E-02
C5 5.639177E-01 -3.133148E-02 -3.787981E-04 3.600730E-02
C6 -1.882147E+00 1.937588E-02 -2.044341E-04 -2.459774E-02
C7 2.432637E-02 -1.763347E-03 -1.449937E-06 2.686924E-04
C8 -2.522603E-02 2.652114E-03 4.752564E-06 -9.950937E-05
C9 -1.303541E-02 1.451229E-03 2.708954E-06 -2.079478E-04
C10 7.003457E-03 -4.262845E-04 1.863173E-07 8.000998E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AWF5530EXG
General Information
Model AWF5530EXG Refrigerant R-22
Test Condition ARI Performance Test Voltage 380V 3~ 50HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
-15
-10
-5
0
5
10
15
20
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 6630 5640
Watts 933 981
Amps 2.16 2.27
Lb/h 85.5 75.7
Btu/h 8190 7160 6150
Watts 1010 1070 1100
Amps 2.27 2.37 2.45
Lb/h 105 95.4 85.6
Btu/h 9860 8780 7710 6680
Watts 1090 1150 1200 1220
Amps 2.37 2.48 2.55 2.60
Lb/h 126 116 106 96.6
Btu/h 11700 10500 9370 8260 7220
Watts 1160 1230 1290 1320 1340
Amps 2.46 2.57 2.66 2.71 2.74
Lb/h 148 138 128 118 108
Btu/h 13600 12400 11200 9950 8810
Watts 1230 1310 1370 1420 1450
Amps 2.55 2.67 2.76 2.82 2.86
Lb/h 171 162 152 141 131
Btu/h 15700 14400 13100 11800 10500 9340 8280
Watts 1290 1380 1460 1520 1560 1590 1590
Amps 2.63 2.75 2.85 2.93 2.98 3.02 3.03
Lb/h 196 187 177 166 155 144 135
Btu/h 18000 16600 15200 13700 12300 11000 9830
Watts 1350 1450 1530 1610 1670 1710 1730
Amps 2.70 2.83 2.94 3.04 3.11 3.16 3.19
Lb/h 223 214 203 192 180 169 159
Btu/h 20500 18900 17400 15900 14300 12900 11500
Watts 1390 1500 1610 1690 1770 1830 1870
Amps 2.75 2.90 3.03 3.14 3.23 3.30 3.36
Lb/h 252 243 232 220 208 196 184
Btu/h 23100 21500 19800 18100 16500 14800 13300
25
30
35
40
45
50
55
Watts 1430 1550 1670 1780 1870 1940 2000
Amps 2.80 2.96 3.11 3.23 3.35 3.45 3.54
Lb/h 283 273 262 250 237 224 212
Btu/h 26000 24300 22500 20600 18800 17000 15300
Watts 1450 1590 1730 1850 1960 2060 2140
Amps 2.83 3.01 3.17 3.33 3.46 3.59 3.71
Lb/h 317 307 295 282 269 255 241
Btu/h 29100 27300 25300 23300 21300 19300 17400
Watts 1470 1630 1770 1910 2040 2160 2260
Amps 2.85 3.05 3.23 3.41 3.57 3.73 3.88
Lb/h 353 342 330 317 303 288 273
Btu/h 32500 30500 28400 26200 24000 21900 19800
Watts 1470 1640 1810 1970 2120 2260 2380
Amps 2.85 3.07 3.28 3.48 3.68 3.87 4.05
Lb/h 391 381 368 354 339 323 307
Btu/h 36100 34000 31700 29300 27000 24600 22300
Watts 1460 1650 1840 2020 2190 2350 2500
Amps 2.84 3.08 3.32 3.55 3.78 4.00 4.22
Lb/h 432 422 409 394 378 361 344
Btu/h 40100 37700 35200 32700 30100 27600 25000
Watts 1430 1640 1850 2050 2250 2430 2600
Amps 2.81 3.08 3.34 3.61 3.87 4.13 4.39
Lb/h 477 466 452 437 420 402 384
Btu/h 44300 41700 39100 36300 33600 30800 28000
Watts 1390 1620 1850 2080 2290 2500 2700
Amps 2.76 3.06 3.35 3.65 3.95 4.25 4.55
Lb/h 524 513 499 482 465 446 426
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.673908E+04 3.294834E+02 3.512299E-01 1.585769E+02
C2 4.056849E+02 8.349959E+00 3.094700E-02 3.256545E+00
C3 2.375640E+01 1.123723E+01 4.118482E-02 1.064486E+00
C4 4.534680E+00 -2.854177E-01 -5.265400E-04 3.619011E-02
C5 4.724303E-01 -1.632602E-02 -3.695591E-04 2.991129E-02
C6 -1.552827E+00 1.610577E-02 -1.994479E-04 -2.027404E-02
C7 2.015560E-02 -1.419122E-03 -1.414573E-06 2.226581E-04
C8 -2.089851E-02 2.284578E-03 4.636648E-06 -8.249002E-05
C9 -1.082135E-02 1.099793E-03 2.642882E-06 -1.726358E-04
C10 5.784064E-03 -3.292084E-04 1.817729E-07 6.599722E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
