Performance Data Sheet
AWF5524EXG
General Information
Model AWF5524EXG Refrigerant R-22
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
-15
-10
-5
0
5
10
15
20
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 5870 4830
Watts 964 920
Amps 1.76 1.73
Lb/h 75.3 65.0
Btu/h 7630 6500 5420
Watts 1060 1030 1000
Amps 1.87 1.85 1.83
Lb/h 97.5 86.7 75.9
Btu/h 9480 8260 7080 5940
Watts 1150 1130 1120 1110
Amps 1.97 1.96 1.95 1.95
Lb/h 121 109 97.9 86.3
Btu/h 11400 10100 8840 7590 6370
Watts 1230 1230 1230 1230 1240
Amps 2.06 2.06 2.07 2.08 2.08
Lb/h 145 133 121 109 95.8
Btu/h 13500 12100 10700 9340 8000
Watts 1310 1320 1330 1350 1370
Amps 2.14 2.16 2.18 2.20 2.22
Lb/h 170 158 145 133 119
Btu/h 15800 14200 12700 11200 9750 8320 6900
Watts 1370 1400 1430 1460 1490 1510 1520
Amps 2.21 2.24 2.28 2.32 2.35 2.38 2.41
Lb/h 197 185 171 158 144 128 112
Btu/h 18200 16500 14900 13200 11600 10100 8510
Watts 1430 1470 1520 1570 1620 1650 1670
Amps 2.27 2.32 2.37 2.43 2.48 2.53 2.57
Lb/h 226 213 199 185 170 154 137
Btu/h 20900 19000 17200 15400 13700 12000 10300
Watts 1480 1540 1600 1670 1730 1780 1820
Amps 2.31 2.38 2.46 2.53 2.60 2.66 2.72
Lb/h 257 243 229 214 198 182 164
Btu/h 23700 21700 19700 17800 15900 14000 12200
25
30
35
40
45
50
55
Watts 1510 1590 1680 1760 1840 1910 1960
Amps 2.35 2.44 2.53 2.62 2.71 2.80 2.88
Lb/h 290 276 261 245 229 212 193
Btu/h 26800 24600 22500 20400 18300 16300 14200
Watts 1540 1640 1750 1850 1940 2030 2100
Amps 2.37 2.49 2.60 2.71 2.82 2.93 3.03
Lb/h 326 311 296 279 262 244 225
Btu/h 30100 27800 25500 23200 21000 18800 16500
Watts 1560 1680 1800 1920 2040 2140 2230
Amps 2.39 2.52 2.66 2.79 2.93 3.06 3.18
Lb/h 365 349 333 316 298 279 259
Btu/h 33700 31200 28800 26300 23900 21400 19000
Watts 1560 1700 1850 1990 2130 2250 2350
Amps 2.39 2.55 2.71 2.87 3.03 3.18 3.33
Lb/h 406 390 373 356 337 317 296
Btu/h 37700 35000 32300 29600 27000 24400 21800
Watts 1550 1720 1880 2050 2210 2350 2470
Amps 2.38 2.57 2.75 2.94 3.12 3.30 3.47
Lb/h 451 434 416 398 379 358 337
Btu/h 41900 39000 36100 33300 30400 27600 24800
Watts 1530 1720 1910 2100 2280 2440 2590
Amps 2.36 2.58 2.79 3.00 3.21 3.42 3.61
Lb/h 499 481 463 444 424 403 380
Btu/h 46500 43400 40300 37200 34200 31100 28100
Watts 1490 1710 1920 2130 2340 2520 2690
Amps 2.33 2.57 2.82 3.06 3.29 3.53 3.75
Lb/h 551 533 514 494 473 451 428
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.376709E+04 2.150021E+03 2.377326E+00 2.597472E+02
C2 5.675328E+02 -1.212794E+01 -5.750221E-03 5.473033E+00
C3 -1.767869E+02 -2.739063E+01 -1.039322E-02 -1.928724E+00
C4 4.243119E+00 -3.159394E-01 -4.377181E-04 2.804090E-02
C5 -1.898244E+00 3.974580E-01 2.910905E-04 -2.554396E-03
C6 3.240925E-01 2.670821E-01 1.088123E-04 9.043557E-03
C7 2.791540E-02 -7.991822E-04 -3.387432E-08 3.113642E-04
C8 -1.953820E-02 2.003653E-03 2.777885E-06 -1.545761E-05
C9 -1.585864E-03 -6.238214E-04 -9.319174E-08 -4.746453E-05
C10 -4.928692E-04 -8.524082E-04 -3.551181E-07 -3.627785E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AWF5524EXG
General Information
Model AWF5524EXG Refrigerant R-22
Test Condition ARI Performance Test Voltage 380V 3~ 50HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
-15
-10
-5
0
5
10
15
20
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 4810 3960
Watts 804 767
Amps 1.70 1.67
Lb/h 61.7 53.3
Btu/h 6250 5330 4440
Watts 884 858 838
Amps 1.81 1.79 1.78
Lb/h 79.9 71.1 62.2
Btu/h 7770 6770 5800 4870
Watts 959 943 934 927
Amps 1.91 1.90 1.90 1.89
Lb/h 98.8 89.6 80.3 70.7
Btu/h 9380 8300 7240 6220 5220
Watts 1030 1020 1030 1030 1030
Amps 2.00 2.00 2.01 2.02 2.02
Lb/h 119 109 99.2 89.1 78.6
Btu/h 11100 9920 8780 7660 6560
Watts 1090 1100 1110 1130 1140
Amps 2.07 2.09 2.11 2.13 2.15
Lb/h 140 129 119 109 97.5
Btu/h 12900 11700 10400 9200 8000 6820 5660
Watts 1140 1170 1190 1220 1250 1260 1270
Amps 2.14 2.17 2.21 2.25 2.28 2.31 2.33
Lb/h 162 151 141 129 118 105 92.0
Btu/h 14900 13600 12200 10900 9540 8250 6980
Watts 1190 1230 1270 1310 1350 1380 1390
Amps 2.20 2.25 2.30 2.35 2.40 2.45 2.49
Lb/h 186 175 163 152 139 126 112
Btu/h 17100 15600 14100 12700 11200 9810 8410
Watts 1230 1280 1340 1390 1440 1490 1510
Amps 2.24 2.31 2.38 2.45 2.52 2.58 2.64
Lb/h 211 199 188 176 163 149 134
Btu/h 19400 17800 16200 14600 13000 11500 9970
25
30
35
40
45
50
55
Watts 1260 1330 1400 1470 1540 1590 1630
Amps 2.28 2.37 2.45 2.54 2.63 2.71 2.79
Lb/h 238 226 214 201 188 174 158
Btu/h 21900 20200 18400 16700 15000 13300 11700
Watts 1280 1370 1460 1540 1620 1690 1750
Amps 2.30 2.41 2.52 2.63 2.74 2.84 2.94
Lb/h 267 255 242 229 215 200 184
Btu/h 24700 22800 20900 19000 17200 15400 13600
Watts 1300 1400 1500 1610 1700 1790 1860
Amps 2.32 2.45 2.58 2.71 2.84 2.97 3.08
Lb/h 299 286 273 259 244 229 212
Btu/h 27700 25600 23600 21600 19600 17600 15600
Watts 1300 1420 1540 1660 1770 1880 1960
Amps 2.32 2.47 2.63 2.78 2.94 3.08 3.23
Lb/h 333 320 306 291 276 260 243
Btu/h 30900 28700 26500 24300 22100 20000 17900
Watts 1290 1430 1570 1710 1840 1960 2060
Amps 2.31 2.49 2.67 2.85 3.03 3.20 3.37
Lb/h 370 356 341 326 311 294 276
Btu/h 34400 32000 29600 27300 25000 22600 20300
Watts 1270 1430 1590 1750 1900 2040 2160
Amps 2.29 2.50 2.70 2.91 3.11 3.31 3.50
Lb/h 409 395 380 364 348 330 312
Btu/h 38100 35600 33000 30500 28000 25500 23000
Watts 1240 1420 1600 1780 1950 2110 2250
Amps 2.26 2.50 2.73 2.96 3.19 3.42 3.64
Lb/h 451 437 421 405 388 370 351
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.948122E+04 1.793209E+03 2.305286E+00 2.129104E+02
C2 4.651908E+02 -1.011522E+01 -5.575972E-03 4.486153E+00
C3 -1.449073E+02 -2.284495E+01 -1.007828E-02 -1.580942E+00
C4 3.477966E+00 -2.635069E-01 -4.244539E-04 2.298465E-02
C5 -1.555938E+00 3.314969E-01 2.822696E-04 -2.093795E-03
C6 2.656496E-01 2.227578E-01 1.055149E-04 7.412851E-03
C7 2.288148E-02 -6.665520E-04 -3.284782E-08 2.552200E-04
C8 -1.601492E-02 1.671132E-03 2.693706E-06 -1.267034E-05
C9 -1.299889E-03 -5.202933E-04 -9.036775E-08 -3.890587E-05
C10 -4.039912E-04 -7.109447E-04 -3.443569E-07 -2.973634E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
