Performance Data Sheet
AWA9514ZXG
General Information
Model AWA9514ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 14500 12900 11300 9640 8000 6370 4730
Watts 1870 1850 1830 1810 1790 1760 1740
Amps 2.95 2.93 2.90 2.88 2.85 2.83 2.80
Lb/h 258 240 221 203 184 164 145
Btu/h 16900 15000 13200 11400 9540 7720 5890
Watts 1960 1960 1960 1950 1940 1930 1920
Amps 3.06 3.06 3.05 3.04 3.04 3.02 3.01
Lb/h 297 278 258 238 218 198 178
Btu/h 19200 17200 15200 13100 11100 9090 7070
Watts 2050 2070 2080 2090 2100 2110 2110
Amps 3.17 3.19 3.20 3.22 3.23 3.23 3.24
Lb/h 340 319 299 278 257 236 215
Btu/h 21700 19500 17200 15000 12700 10500 8290
Watts 2140 2170 2200 2230 2260 2280 2310
Amps 3.28 3.32 3.35 3.39 3.42 3.44 3.47
Lb/h 387 365 344 322 301 279 256
Btu/h 24400 21900 19400 17000 14500 12000 9600
Watts 2200 2260 2310 2360 2410 2450 2490
Amps 3.37 3.43 3.49 3.55 3.60 3.65 3.70
Lb/h 437 415 393 370 348 325 302
Btu/h 27300 24500 21800 19100 16400 13700 11000
Watts 2250 2330 2400 2470 2540 2610 2670
Amps 3.44 3.53 3.61 3.69 3.77 3.84 3.91
Lb/h 491 468 445 422 398 375 351
Btu/h 30300 27400 24400 21400 18500 15600 12600
Watts 2260 2360 2460 2560 2650 2740 2820
Amps 3.48 3.60 3.71 3.81 3.92 4.02 4.11
Lb/h 549 525 501 477 453 428 403
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.758306E+04 1.989642E+03 3.111326E+00 4.042877E+02
C2 7.802012E+02 -7.016957E+00 -7.774751E-03 8.885641E+00
Page 2
C3 -1.626467E+02 -1.707604E+00 -2.179726E-03 -1.836798E+00
C4 2.514406E+00 -1.868413E-01 -1.339816E-04 8.022962E-02
C5 -4.230931E+00 3.459798E-01 3.956315E-04 -1.944687E-02
C6 -2.988887E-03 6.063354E-03 5.261089E-06 4.792348E-04
C7 5.300549E-02 -9.707880E-03 -9.894852E-06 -2.171169E-04
C8 -2.240389E-02 3.655285E-03 3.702552E-06 5.985206E-05
C9 2.401010E-03 -3.187336E-04 -3.221039E-07 -1.024619E-06
C10 -1.048229E-05 -4.821375E-05 -4.151842E-08 -4.152762E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Page 3
Performance Data Sheet
AWA9514ZXG
General Information
Model AWA9514ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 26000 23600 21100 18700 16300 13800 11300
Watts 2230 2290 2360 2420 2470 2530 2590
Amps 3.27 3.35 3.42 3.50 3.57 3.64 3.70
Lb/h 421 402 382 361 341 320 299
Btu/h 29200 26500 23800 21100 18400 15700 13000
Watts 2300 2380 2470 2550 2630 2700 2780
Amps 3.34 3.44 3.54 3.64 3.74 3.83 3.92
Lb/h 473 452 431 410 389 367 345
Btu/h 32700 29700 26700 23700 20700 17700 14800
Watts 2350 2460 2560 2660 2760 2860 2960
Amps 3.40 3.53 3.65 3.77 3.89 4.01 4.12
Lb/h 530 508 486 464 441 419 396
Btu/h 36300 33000 29700 26400 23100 19800 16600
Watts 2390 2520 2640 2770 2890 3010 3120
Amps 3.46 3.60 3.74 3.88 4.02 4.17 4.31
Lb/h 593 570 546 522 499 475 452
Btu/h 40300 36500 32900 29200 25600 22100 18500
Watts 2410 2560 2710 2850 2990 3130 3270
Amps 3.51 3.67 3.83 3.99 4.15 4.31 4.48
Lb/h 662 637 612 587 562 537 512
Btu/h 44500 40400 36300 32300 28400 24500 20600
Watts 2410 2580 2750 2920 3080 3240 3400
Amps 3.55 3.73 3.90 4.09 4.27 4.45 4.64
Lb/h 737 710 684 657 631 605 578
Btu/h 49100 44500 40100 35700 31400 27200 22900
Watts 2400 2590 2780 2970 3150 3340 3520
Amps 3.59 3.78 3.98 4.18 4.38 4.58 4.78
Lb/h 819 790 761 733 705 678 650
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.439876E+04 1.951615E+03 2.940172E+00 3.885243E+02
C2 9.787645E+02 -5.763401E+00 -1.080747E-02 7.364927E+00
Page 4
C3 -1.230186E+02 -1.896186E+00 -9.262935E-04 -1.505009E+00
C4 3.515575E+00 -2.936732E-01 -1.945627E-04 1.106737E-01
C5 -5.979733E+00 4.088354E-01 4.300678E-04 -2.451300E-02
C6 -1.321522E-02 4.217281E-03 2.757139E-06 2.947432E-04
C7 5.190565E-02 -9.314251E-04 2.390864E-06 3.091232E-04
C8 -4.703379E-02 6.094561E-04 -2.374572E-06 -2.994313E-04
C9 1.320169E-02 -1.078752E-04 7.234803E-07 8.918720E-05
C10 -1.023670E-03 -2.856231E-05 -8.773713E-08 -1.030353E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
