Tecumseh AWA9490ZXT Performance Data Sheet
Performance Data Sheet
AWA9490ZXT
General Information
Model AWA9490ZXT Refrigerant R-404A
Test Condition ARI Performance Test Voltage 230V 3~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 9020 7880 6740 5600 4470 3340 2210
Watts 1280 1240 1200 1160 1110 1070 1020
Amps 3.95 3.88 3.80 3.71 3.63 3.53 3.44
Lb/h 166 151 137 122 107 91.5 76.2
Btu/h 10600 9350 8060 6770 5490 4210 2940
Watts 1350 1320 1290 1260 1220 1190 1140
Amps 4.11 4.06 4.00 3.94 3.87 3.80 3.72
Lb/h 191 176 160 145 130 114 98.2
Btu/h 12400 10900 9450 8000 6560 5130 3710
Watts 1430 1410 1390 1370 1350 1320 1290
Amps 4.28 4.25 4.22 4.19 4.15 4.10 4.04
Lb/h 219 204 188 173 157 141 125
Btu/h 14200 12600 10900 9330 7720 6130 4540
Watts 1510 1510 1500 1490 1470 1460 1440
Amps 4.44 4.45 4.45 4.44 4.43 4.41 4.38
Lb/h 252 236 221 205 189 173 156
Btu/h 16200 14400 12600 10800 9000 7230 5480
Watts 1580 1590 1600 1600 1600 1600 1590
Amps 4.58 4.62 4.65 4.68 4.70 4.71 4.71
Lb/h 288 272 257 241 224 208 192
Btu/h 18300 16300 14400 12400 10400 8480 6540
Watts 1640 1660 1680 1700 1720 1730 1740
Amps 4.68 4.76 4.83 4.90 4.95 5.00 5.04
Lb/h 327 312 296 280 264 247 231
Btu/h 20700 18500 16300 14200 12000 9880 7770
Watts 1670 1710 1750 1790 1820 1850 1870
Amps 4.73 4.85 4.97 5.07 5.17 5.26 5.33
Lb/h 369 354 338 322 306 290 273
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.818375E+04 1.572950E+03 4.534052E+00 2.839572E+02
C2 5.688960E+02 -1.461695E+00 -8.804473E-03 4.984256E+00
C3 -1.138899E+02 -3.891398E+00 -7.696990E-03 -1.481401E+00
C4 2.578741E+00 -5.321660E-02 -1.816169E-04 7.545659E-02
C5 -3.290815E+00 2.223593E-01 5.473057E-04 -5.058944E-03
C6 -1.550841E-02 6.269737E-03 1.411331E-05 3.217699E-04
C7 3.896019E-02 -9.073291E-03 -1.998957E-05 -5.038404E-04
C8 -1.680584E-02 3.643718E-03 7.961835E-06 2.064875E-04
C9 1.792673E-03 -3.436848E-04 -7.395510E-07 -2.004591E-05
C10 1.004706E-04 -4.788158E-05 -1.086247E-07 -2.422582E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
