Performance Data Sheet
AVA9522ZXG
General Information
Model AVA9522ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 21000 18800 16600 14400 12200 10000 7840
Watts 2610 2640 2660 2680 2700 2720 2730
Amps 4.02 4.03 4.03 4.03 4.03 4.02 4.02
Lb/h 369 347 325 303 281 258 235
Btu/h 24500 21900 19400 16900 14400 11900 9360
Watts 2750 2790 2840 2880 2920 2960 3000
Amps 4.16 4.19 4.22 4.25 4.28 4.30 4.32
Lb/h 428 404 379 355 331 306 282
Btu/h 28100 25200 22400 19500 16600 13700 10900
Watts 2880 2950 3020 3090 3150 3210 3270
Amps 4.31 4.37 4.43 4.49 4.54 4.60 4.64
Lb/h 493 466 440 413 386 360 333
Btu/h 32100 28800 25500 22200 19000 15700 12500
Watts 3020 3110 3200 3290 3380 3460 3540
Amps 4.46 4.56 4.65 4.74 4.82 4.90 4.98
Lb/h 566 536 507 478 448 419 390
Btu/h 36400 32700 28900 25300 21600 18000 14300
Watts 3150 3270 3380 3490 3600 3710 3810
Amps 4.61 4.74 4.86 4.98 5.10 5.21 5.32
Lb/h 648 615 582 550 518 486 453
Btu/h 41100 37000 32800 28700 24600 20500 16500
Watts 3280 3420 3560 3690 3820 3950 4080
Amps 4.75 4.91 5.07 5.22 5.38 5.52 5.67
Lb/h 740 704 668 632 596 561 525
Btu/h 46500 41800 37200 32600 28000 23500 19000
Watts 3400 3560 3720 3880 4040 4190 4340
Amps 4.86 5.06 5.26 5.45 5.64 5.82 6.00
Lb/h 843 803 763 724 685 645 607
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 3.838795E+04 2.384597E+03 3.970402E+00 5.417200E+02
C2 1.263062E+03 -7.812646E+00 -1.932156E-02 1.491681E+01
C3 -2.170195E+02 2.649883E+00 4.339915E-04 -2.160193E+00
C4 5.634520E+00 -5.036631E-03 4.391822E-05 1.609516E-01
C5 -7.578378E+00 4.371023E-01 5.987511E-04 -5.285325E-02
C6 -1.237947E-02 6.892169E-03 6.745736E-06 3.057178E-04
C7 1.315078E-01 -2.628557E-03 -9.349463E-06 1.626936E-03
C8 -5.399950E-02 8.075737E-04 3.629183E-06 -6.795032E-04
C9 5.549870E-03 -2.952354E-05 -3.309904E-07 7.240869E-05
C10 2.735251E-05 -5.893569E-05 -5.314696E-08 -3.629190E-06
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AVA9522ZXG
General Information
Model AVA9522ZXG Refrigerant R-404A
Test Condition ARI Performance Test Voltage 460V 3~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type 3PH
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 37800 34400 31000 27500 24000 20500 16900
Watts 3070 3200 3320 3450 3570 3700 3820
Amps 4.53 4.66 4.79 4.92 5.05 5.18 5.30
Lb/h 610 584 558 532 504 476 446
Btu/h 43500 39500 35500 31500 27500 23500 19500
Watts 3180 3330 3490 3640 3780 3930 4080
Amps 4.64 4.81 4.99 5.16 5.33 5.49 5.65
Lb/h 705 674 644 613 582 550 517
Btu/h 49300 44700 40100 35600 31000 26500 22000
Watts 3260 3450 3640 3820 3990 4160 4330
Amps 4.72 4.94 5.16 5.37 5.58 5.79 5.99
Lb/h 805 769 733 698 662 626 590
Btu/h 55300 50000 44800 39700 34600 29500 24400
Watts 3320 3550 3770 3980 4190 4390 4590
Amps 4.79 5.05 5.31 5.57 5.82 6.07 6.32
Lb/h 911 869 828 787 746 706 665
Btu/h 61600 55600 49800 44000 38200 32500 26900
Watts 3340 3610 3870 4130 4370 4610 4830
Amps 4.82 5.14 5.44 5.75 6.04 6.34 6.62
Lb/h 1020 975 928 881 835 789 744
Btu/h 68300 61600 55000 48500 42100 35700 29500
Watts 3330 3640 3950 4240 4530 4800 5060
Amps 4.83 5.19 5.55 5.90 6.24 6.58 6.91
Lb/h 1150 1090 1030 982 929 877 826
Btu/h 75400 67900 60500 53300 46200 39100 32200
Watts 3260 3630 3980 4320 4650 4970 5270
Amps 4.81 5.22 5.62 6.02 6.41 6.79 7.17
Lb/h 1280 1210 1150 1090 1030 972 915
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.538706E+04 2.447698E+03 4.159320E+00 3.225907E+02
C2 1.949066E+03 -1.431292E+01 -2.871819E-02 2.262017E+01
C3 -1.125402E+02 5.967647E-01 -3.314725E-03 -5.682786E-01
C4 2.732086E+00 -3.346844E-01 -3.801701E-04 1.034128E-01
C5 -1.164331E+01 6.120357E-01 8.383472E-04 -1.019380E-01
C6 -1.759087E-02 9.437323E-03 8.700748E-06 5.835362E-04
C7 9.904101E-02 -9.097374E-03 -3.663645E-06 1.370663E-03
C8 -9.017687E-02 7.855257E-03 2.907048E-06 -1.290788E-03
C9 2.541521E-02 -2.102214E-03 -7.069410E-07 3.749119E-04
C10 -2.038601E-03 9.807659E-05 -1.575228E-08 -3.747009E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
