Performance Data Sheet
AE2420Z-GS3C
General Information
Model AE2420Z-GS3C Refrigerant R-404A
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
-10
Condensing Temperature (°C)
30 40 50 60
Watts
(Capacity)
Watts (Power) 209 206 203 202
Amps 1.35 1.29 1.24 1.20
Watts
(Capacity)
Watts (Power) 241 241 240 241
Amps 1.46 1.43 1.42 1.41
Watts
(Capacity)
Watts (Power) 274 278 280 285
Amps 1.58 1.58 1.59 1.61
Watts
(Capacity)
Watts (Power) 307 316 323 332
Amps 1.70 1.73 1.77 1.82
Watts
(Capacity)
Watts (Power) 318 329 338 349
Amps 1.74 1.78 1.83 1.89
Watts
(Capacity)
Watts (Power) 339 354 368 382
Amps 1.82 1.88 1.95 2.03
Watts
(Capacity)
Watts (Power) 369 392 413 435
Amps 1.95 2.04 2.14 2.24
Watts
(Capacity)
Watts (Power) 396 428 459 489
Amps 2.08 2.20 2.33 2.46
200 150 102 58.3
286 227 169 113
389 319 247 176
511 426 338 249
557 466 372 276
654 551 443 333
819 696 566 432
1010 863 707 546
Page 2
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1987.152 232.6792 1.86553
C2 68.72599 -4.491148 0.0100051
C3 -14.29171 8.447128 0.0148705
C4 0.7894285 -0.1768427 0.000060299
C5 -0.5022986 0.2808527 0.000581848
C6 -0.1075976 -0.06256228 0.0000404042
C7 0.002550643 -0.001062246 0
C8 -0.006005493 0.002619281 0
C9 -0.00173048 -0.0004366624 0
C10 0.0004026551 0.0003845739 0
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Page 3
Performance Data Sheet
AE2420Z-GS3C
General Information
Model AE2420Z-GS3C Refrigerant R-404A
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 60HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
-10
Condensing Temperature (°C)
30 40 50 60
Watts
(Capacity)
Watts (Power) 247 248 238 217
Amps 1.14 1.12 1.08 1.00
Watts
(Capacity)
Watts (Power) 282 289 286 273
Amps 1.29 1.31 1.29 1.25
Watts
(Capacity)
Watts (Power) 319 331 335 329
Amps 1.46 1.51 1.52 1.51
Watts
(Capacity)
Watts (Power) 358 375 386 388
Amps 1.64 1.72 1.77 1.78
Watts
(Capacity)
Watts (Power) 372 391 404 408
Amps 1.71 1.80 1.86 1.88
Watts
(Capacity)
Watts (Power) 401 423 440 449
Amps 1.85 1.96 2.03 2.08
Watts
(Capacity)
Watts (Power) 449 476 498 514
Amps 2.06 2.20 2.31 2.39
Watts
(Capacity)
Watts (Power) 503 534 562 585
Amps 2.30 2.47 2.61 2.71
271 212 149 83.8
369 301 228 152
486 404 318 227
623 525 421 311
674 570 459 342
782 664 538 406
966 824 673 515
1180 1010 827 639
Page 4
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2307.708 516.9936 1.92046
C2 77.58715 13.71368 0.0365118
C3 -18.59349 3.53163 0.0346874
C4 0.8659821 0.2031463 0.000324071
C5 -0.6582021 0.001206745 0.000612438
C6 -0.08005505 0.01690819 -0.000163381
C7 0.002604427 0.001498437 0
C8 -0.0074341 -0.0005383707 0
C9 -0.001128497 0.001076963 0
C10 0.0001667062 -0.0002026364 0
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
