Performance Data Sheet
AE2410Z-FZ1A
General Information
Model AE2410Z-FZ1A Refrigerant R-404A
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
-10
Condensing Temperature (°C)
30 40 50 60
Btu/h 391 300 196 58.7
Watts (Power) 143 141 136 118
Amps 1.40 1.40 1.38 1.33
Lb/h 6.02 5.24 4.00 1.76
Btu/h 538 435 323 181
Watts (Power) 157 159 158 146
Amps 1.43 1.43 1.43 1.39
Lb/h 8.39 7.63 6.50 4.48
Btu/h 718 593 463 307
Watts (Power) 173 178 181 174
Amps 1.46 1.47 1.47 1.45
Lb/h 11.2 10.4 9.35 7.46
Btu/h 936 780 622 443
Watts (Power) 188 197 205 202
Amps 1.49 1.51 1.53 1.52
Lb/h 14.7 13.8 12.7 10.9
Btu/h 1020 851 682 493
Watts (Power) 194 204 213 212
Amps 1.51 1.53 1.55 1.55
Lb/h 16.1 15.1 13.9 12.1
Btu/h 1200 1000 808 595
Watts (Power) 204 217 228 231
Amps 1.53 1.56 1.59 1.60
Lb/h 19.0 17.8 16.6 14.8
Btu/h 1510 1270 1020 770
Watts (Power) 219 235 252 260
Amps 1.57 1.62 1.66 1.69
Lb/h 24.1 22.7 21.3 19.4
Btu/h 1880 1580 1280 973
Watts (Power) 233 253 274 288
Amps 1.62 1.67 1.74 1.79
Lb/h 30.3 28.6 26.9 24.8
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 4.483713E+03 2.677055E+02 1.766558E+00 6.118307E+01
C2 1.622070E+02 5.675897E-01 5.346065E-03 2.294723E+00
C3 -6.722196E+01 -4.315189E+00 -1.307969E-02 -7.784404E-01
C4 2.060633E+00 -5.158706E-02 -2.734799E-05 3.316638E-02
C5 -1.940563E+00 2.098353E-02 6.967884E-05 -1.698681E-02
C6 4.870946E-01 1.714826E-01 4.902844E-04 1.204062E-02
C7 7.988749E-03 -6.155174E-04 -1.516796E-07 1.805237E-04
C8 -1.896119E-02 1.337206E-04 3.083086E-06 -1.460564E-04
C9 3.908823E-03 8.137460E-04 3.838685E-06 9.303965E-05
C10 -3.318915E-03 -1.329473E-03 -3.434866E-06 -8.859041E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE2410Z-FZ1A
General Information
Model AE2410Z-FZ1A Refrigerant R-404A
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
-40
-35
-30
-25
-20
-15
-10
-5
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 422 371 321 268 209 140 58.7
Watts 144 142 142 140 137 130 118
Amps 1.40 1.40 1.40 1.40 1.39 1.37 1.33
Lb/h 6.27 5.86 5.44 4.90 4.18 3.16 1.76
Btu/h 502 448 394 339 278 208 126
Watts 151 151 151 151 149 143 133
Amps 1.42 1.42 1.42 1.42 1.41 1.39 1.36
Lb/h 7.54 7.12 6.71 6.21 5.52 4.56 3.24
Btu/h 593 533 475 415 351 279 194
Watts 159 159 161 162 161 157 149
Amps 1.43 1.43 1.44 1.44 1.43 1.42 1.39
Lb/h 8.94 8.51 8.10 7.61 6.96 6.05 4.79
Btu/h 694 627 563 498 429 352 264
Watts 167 168 171 173 174 171 164
Amps 1.45 1.45 1.46 1.46 1.46 1.45 1.43
Lb/h 10.5 10.1 9.63 9.14 8.51 7.63 6.43
Btu/h 808 733 660 588 512 429 336
Watts 175 177 181 184 186 185 180
Amps 1.46 1.47 1.48 1.48 1.49 1.48 1.47
Lb/h 12.3 11.8 11.3 10.8 10.2 9.34 8.18
Btu/h 936 850 768 687 602 512 411
Watts 183 186 191 196 199 200 196
Amps 1.48 1.49 1.50 1.51 1.52 1.52 1.51
Lb/h 14.2 13.7 13.2 12.7 12.0 11.2 10.1
Btu/h 1080 980 886 794 700 600 492
Watts 191 196 201 207 212 214 212
Amps 1.50 1.51 1.52 1.54 1.55 1.55 1.55
Lb/h 16.4 15.8 15.3 14.7 14.1 13.2 12.1
Btu/h 1230 1120 1020 913 807 697 577
Watts 199 205 212 219 225 228 228
Amps 1.52 1.53 1.55 1.57 1.58 1.59 1.59
Lb/h 18.9 18.2 17.6 17.0 16.3 15.5 14.3
Btu/h 1410 1280 1160 1040 924 801 670
0
5
10
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 3.045319E+03 3.844590E+02 2.053638E+00 4.292725E+01
C2 6.681307E+01 9.927014E-01 4.498843E-03 8.476156E-01
C3 -3.150595E+01 -6.382942E+00 -1.755927E-02 -5.421730E-01
C4 6.085352E-01 -6.523678E-03 -2.286075E-05 8.066360E-03
C5 -4.337555E-01 -3.921041E-03 -5.445327E-05 -4.661040E-03
C6 1.835226E-01 7.034606E-02 1.868006E-04 4.664015E-03
C7 1.369813E-03 -1.055414E-04 -2.600817E-08 3.095400E-05
C8 -3.251233E-03 2.292877E-05 5.286499E-07 -2.504397E-05
C9 6.702372E-04 1.395312E-04 6.582108E-07 1.595330E-05
C10 -5.690869E-04 -2.279618E-04 -5.889688E-07 -1.519040E-05
Watts 207 214 222 230 238 243 244
Amps 1.54 1.56 1.58 1.60 1.62 1.63 1.64
Lb/h 21.6 20.8 20.2 19.5 18.8 17.9 16.8
Btu/h 1600 1460 1320 1190 1050 914 770
Watts 215 222 232 241 250 257 260
Amps 1.57 1.58 1.61 1.63 1.66 1.68 1.69
Lb/h 24.7 23.8 23.0 22.3 21.5 20.6 19.4
Btu/h 1810 1650 1490 1340 1190 1040 879
Watts 222 231 241 252 262 271 275
Amps 1.59 1.61 1.64 1.67 1.70 1.72 1.74
Lb/h 28.0 27.0 26.2 25.3 24.5 23.5 22.3
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE2410Z-FZ1A
General Information
Model AE2410Z-FZ1A Refrigerant R-404A
Test Condition EN12900 ASERCOM Performance Test Voltage 240V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
Condensing Temperature (°C)
30 40 50 60
Watts
(Capacity)
Watts (Power) 143 141 136 117
Amps 1.40 1.40 1.38 1.33
Lb/h 2.75 2.38 1.82 0.85
Watts
(Capacity)
Watts (Power) 157 159 158 145
Amps 1.43 1.43 1.43 1.39
Lb/h 3.81 3.45 2.94 2.06
Watts
(Capacity)
Watts (Power) 173 178 181 173
Amps 1.46 1.47 1.47 1.45
Lb/h 5.10 4.72 4.23 3.40
Watts
(Capacity)
Watts (Power) 188 198 205 202
Amps 1.49 1.51 1.53 1.52
Lb/h 6.68 6.25 5.74 4.93
Watts
(Capacity)
Watts (Power) 194 204 213 212
Amps 1.51 1.53 1.55 1.55
Lb/h 7.29 6.83 6.31 5.50
Watts
(Capacity)
Watts (Power) 204 217 229 231
Amps 1.53 1.56 1.59 1.60
Lb/h 8.61 8.09 7.52 6.70
Watts
(Capacity)
Watts (Power) 219 236 252 260
115 88.1 57.5 17.2
158 128 94.5 52.9
210 174 136 89.9
274 229 182 130
299 249 200 144
351 294 237 175
443 371 300 226
Amps 1.57 1.62 1.66 1.69
Lb/h 10.9 10.3 9.65 8.78
Watts
(Capacity)
-10
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.314046E+03 2.698692E+02 1.766557E+00 2.742995E+01
C2 4.753819E+01 5.023964E-01 5.346036E-03 1.029955E+00
C3 -1.970082E+01 -4.565034E+00 -1.307963E-02 -3.312911E-01
C4 6.039119E-01 -5.374575E-02 -2.734915E-05 1.472174E-02
C5 -5.687229E-01 1.984515E-02 6.967915E-05 -7.498801E-03
C6 1.427534E-01 1.782637E-01 4.902834E-04 4.910479E-03
C7 2.341271E-03 -6.494456E-04 -1.516910E-07 7.729662E-05
C8 -5.556977E-03 9.789228E-05 3.083098E-06 -6.668663E-05
C9 1.145564E-03 8.176789E-04 3.838688E-06 3.873781E-05
C10 -9.726783E-04 -1.387814E-03 -3.434858E-06 -3.614739E-05
Watts (Power) 233 253 274 287
Amps 1.62 1.67 1.74 1.79
Lb/h 13.7 12.9 12.2 11.2
552 462 375 285
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
