Performance Data Sheet
AE2390Y-FZ1A
General Information
Model AE2390Y-FZ1A Refrigerant R-134a
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
-10
Condensing Temperature (°C)
30 40 50 60
Btu/h 287 197 118 26.1
Watts (Power) 114 112 104 90.8
Amps 1.20 1.19 1.17 1.14
Lb/h 3.72 2.85 2.15 1.11
Btu/h 431 338 254 158
Watts (Power) 129 130 126 117
Amps 1.22 1.22 1.21 1.19
Lb/h 5.62 4.77 4.08 3.01
Btu/h 597 492 397 288
Watts (Power) 144 148 148 144
Amps 1.25 1.25 1.25 1.24
Lb/h 7.78 6.93 6.20 5.08
Btu/h 795 671 556 428
Watts (Power) 160 168 172 171
Amps 1.28 1.29 1.31 1.30
Lb/h 10.4 9.48 8.69 7.46
Btu/h 872 740 617 480
Watts (Power) 166 174 180 181
Amps 1.29 1.31 1.33 1.33
Lb/h 11.4 10.5 9.64 8.38
Btu/h 1040 887 745 590
Watts (Power) 177 188 196 200
Amps 1.32 1.34 1.37 1.38
Lb/h 13.6 12.6 11.7 10.3
Btu/h 1340 1150 976 786
Watts (Power) 194 209 221 230
Amps 1.37 1.40 1.44 1.46
Lb/h 17.6 16.5 15.4 13.9
Btu/h 1700 1480 1260 1030
Watts (Power) 213 231 247 261
Amps 1.42 1.47 1.52 1.56
Lb/h 22.5 21.2 20.0 18.3
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 3.956376E+03 1.833001E+02 1.483930E+00 4.623942E+01
C2 1.542055E+02 2.255087E+00 4.838639E-03 1.724962E+00
C3 -5.311262E+01 1.740646E+00 -5.203037E-03 -5.864248E-01
C4 2.539625E+00 9.924825E-03 5.079444E-05 3.123791E-02
C5 -1.196376E+00 4.294028E-02 2.787121E-04 -3.364202E-03
C6 4.753333E-01 2.406502E-02 3.157269E-04 1.067638E-02
C7 1.592990E-02 2.830096E-05 -5.564777E-08 2.261699E-04
C8 -1.514244E-02 1.957812E-04 2.648439E-06 -7.292683E-05
C9 -2.640139E-04 5.161939E-04 8.138165E-07 -2.293424E-05
C10 -3.639111E-03 -2.261608E-04 -2.424715E-06 -8.919601E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE2390Y-FZ1A
General Information
Model AE2390Y-FZ1A Refrigerant R-134a
Test Condition EN12900 ASERCOM Performance Test Voltage 220V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
-40
-35
-30
-25
-20
-15
-10
-5
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 322 265 215 171 127 79.7 26.1
Watts 114 114 113 110 105 99.1 90.8
Amps 1.21 1.20 1.19 1.18 1.18 1.16 1.14
Lb/h 4.14 3.48 3.01 2.62 2.24 1.76 1.11
Btu/h 401 343 293 248 203 155 101
Watts 122 122 122 120 117 112 105
Amps 1.22 1.21 1.20 1.20 1.19 1.18 1.17
Lb/h 5.16 4.52 4.05 3.68 3.30 2.82 2.16
Btu/h 486 426 374 326 279 229 173
Watts 130 131 132 131 129 125 120
Amps 1.23 1.22 1.22 1.22 1.21 1.21 1.19
Lb/h 6.25 5.61 5.15 4.78 4.39 3.91 3.23
Btu/h 578 515 459 408 358 305 245
Watts 138 140 142 142 141 139 135
Amps 1.24 1.24 1.24 1.24 1.24 1.23 1.22
Lb/h 7.43 6.79 6.33 5.95 5.55 5.05 4.36
Btu/h 680 612 552 496 441 383 318
Watts 146 149 152 153 154 153 150
Amps 1.26 1.25 1.26 1.26 1.26 1.26 1.25
Lb/h 8.73 8.09 7.62 7.22 6.81 6.29 5.57
Btu/h 793 719 653 592 531 467 396
Watts 154 158 162 165 166 167 165
Amps 1.27 1.27 1.28 1.29 1.29 1.29 1.29
Lb/h 10.2 9.53 9.04 8.62 8.19 7.65 6.90
Btu/h 920 839 766 697 629 558 479
Watts 163 168 173 177 179 181 181
Amps 1.29 1.30 1.30 1.31 1.32 1.33 1.33
Lb/h 11.8 11.1 10.6 10.2 9.73 9.15 8.36
Btu/h 1060 974 892 815 738 658 571
Watts 171 178 183 189 193 195 197
Amps 1.31 1.32 1.33 1.35 1.36 1.37 1.37
Lb/h 13.6 12.9 12.4 11.9 11.4 10.8 10.0
Btu/h 1220 1120 1030 946 859 769 672
0
5
10
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 2.751438E+03 1.336899E+02 1.688817E+00 3.795150E+01
C2 5.034752E+01 8.069729E-01 -2.430461E-05 4.639921E-01
C3 -3.174862E+01 1.640811E-01 -1.240628E-02 -5.712987E-01
C4 6.047004E-01 1.523113E-03 2.061409E-06 6.318518E-03
C5 -2.001823E-01 5.440004E-03 4.802768E-05 1.363917E-05
C6 2.080595E-01 8.317947E-03 1.328942E-04 4.889266E-03
C7 2.731465E-03 4.852703E-06 -9.541798E-09 3.878084E-05
C8 -2.596441E-03 3.357016E-05 4.541219E-07 -1.250460E-05
C9 -4.526988E-05 8.851061E-05 1.395433E-07 -3.932482E-06
C10 -6.239903E-04 -3.877929E-05 -4.157604E-07 -1.529424E-05
Watts 180 188 194 201 206 210 213
Amps 1.33 1.35 1.36 1.38 1.40 1.41 1.42
Lb/h 15.7 15.0 14.4 13.9 13.4 12.7 11.8
Btu/h 1400 1290 1190 1090 995 894 786
Watts 189 198 206 213 220 226 230
Amps 1.36 1.37 1.39 1.41 1.44 1.45 1.46
Lb/h 18.0 17.3 16.7 16.1 15.5 14.8 13.9
Btu/h 1610 1480 1370 1260 1150 1030 914
Watts 199 208 217 226 234 241 247
Amps 1.38 1.40 1.43 1.45 1.48 1.50 1.52
Lb/h 20.7 19.9 19.2 18.6 18.0 17.2 16.2
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE2390Y-FZ1A
General Information
Model AE2390Y-FZ1A Refrigerant R-134a
Test Condition EN12900 ASERCOM Performance Test Voltage 240V ~ 50HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR
Performance Information
Evap
Temp (°C)
-40
-35
-30
-25
-23.3
-20
-15
Condensing Temperature (°C)
30 40 50 60
Watts
(Capacity)
Watts (Power) 114 111 104 90.8
Amps 1.20 1.19 1.18 1.15
Lb/h 2.29 1.76 1.01 0.15
Watts
(Capacity)
Watts (Power) 129 129 126 117
Amps 1.22 1.21 1.21 1.19
Lb/h 3.39 3.01 2.42 1.73
Watts
(Capacity)
Watts (Power) 144 148 148 144
Amps 1.25 1.25 1.25 1.24
Lb/h 4.56 4.27 3.78 3.22
Watts
(Capacity)
Watts (Power) 160 168 172 171
Amps 1.28 1.29 1.31 1.30
Lb/h 5.89 5.64 5.21 4.72
Watts
(Capacity)
Watts (Power) 166 174 180 181
Amps 1.29 1.31 1.33 1.33
Lb/h 6.40 6.15 5.73 5.25
Watts
(Capacity)
Watts (Power) 177 188 196 200
Amps 1.32 1.34 1.37 1.38
Lb/h 7.49 7.23 6.81 6.33
Watts
(Capacity)
Watts (Power) 194 209 221 230
84.3 57.4 25.9
127 101 70.8 39.9
175 147 115 82.7
232 199 162 126
254 219 180 142
302 261 217 174
390 338 284 231
Amps 1.37 1.40 1.44 1.46
Lb/h 9.46 9.14 8.67 8.16
Watts
(Capacity)
-10
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.05717E+03 1.82248E+02 1.51628E+00 1.92496E+01
C2 4.92590E+01 2.09444E+00 2.65395E-03 9.75930E-01
C3 -6.67082E+00 1.75333E+00 -8.36526E-03 4.73810E-02
C4 8.57134E-01 5.84763E-03 -8.14498E-06 1.88083E-02
C5 -4.42449E-01 4.63947E-02 3.27281E-04 -5.69727E-03
C6 -8.20513E-02 2.43458E-02 3.97071E-04 -2.81766E-03
C7 5.61785E-03 -2.70096E-05 -6.44788E-07 1.38586E-04
C8 -5.68086E-03 1.93914E-04 3.08991E-06 -1.02128E-04
C9 4.38343E-04 4.76747E-04 4.51997E-07 1.32331E-05
C10 6.33993E-04 -2.32349E-04 -3.06752E-06 1.87562E-05
Watts (Power) 213 231 247 261
Amps 1.42 1.47 1.52 1.56
Lb/h 11.9 11.5 10.9 10.3
500 434 367 302
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
