For Tecumseh Peerless Transmission Transaxle Parts Call 606-678-9623 or 606-561-4983
2500-2542A Page 1 of 5
Peerless #1
www.mymowerparts.com
For Tecumseh Peerless Transmission Transaxle Parts Call 606-678-9623 or 606-561-4983
Ref # Part Number Qty Description
1 772065 Transaxle Cover (Incl. 2A, 2B & 2C)
2C 780100 Needle Bearing
2A 780098 Needle Bearing
2 780097 Needle Bearing
2B 780099 Needle Bearing
3 770060B Transaxle Case (Incl. 2, 2A, 2B, 2C & 85B)
4 776209A Countershaft & Spacer (Incl. 18)
5 776120A Output Pinion (13 teeth)
6 778103 Output Gear (33 teeth)
8 792095 Woodruff Key No. 27 (Loose Part)2
10 784195 Shift Fork
12 778093A Bevel Pinion (13 teeth)
13 778085 Side Gear
14 778086 Pinion Gear
15 778084 Ring Gear
18 786094 Spacer (1-1/64" ID x 1-5/8" OD x .864 long)
20 792004 Steel Ball
21 792068 Set Screw, 1/4-20 x 1/2"
22 792003 Shifter Fork Spring
24 780012 Thrust Bearing
25 792067 Screw, 5/16-18 x 1"
26 792062 Snap Ring
26A 792064 Snap Ring
29B 780157 Thrust Washer (2 required)
29 780045 Thrust Washer
31A 780101 Thrust Washer
31 780156 Thrust Washer
39 786026 Dowel Pin
49 778087 Bevel Gear (30 teeth)
50 778088 Spur Gear (16 teeth)
51 778099 Spur Gear (20 teeth)
57 778102 Spur Gear (17 teeth)
58 778100 Cluster Gear (23 & 27 teeth)
67 776119 Brake Shaft
85 792010 Pipe Plug, 3/8" sq. hd.
85A 792019 Magnetic Drain Plug
87 788008 Oil Seal
87A 780034 Oil Seal
89 780103 Ball Bearing
92 780005 Spacer1
96 780104 Thrust Bearing
101 774200 Differential Carrier (threaded holes)
102 774199 Differential Carrier
103 792063 Screw, 3/8-16 x 3-5/16"
104 792011 Lockwasher, 3/8"
124A 788050 Gasket (Use as required)
124 788047 Case-to-Cover Gasket
136 782040 Axle Housing (8.770" long)
138 782039 Axle Housing (7.970" long)
149 784196A Shift Rod
152 786054 Body Core
155 792065 Screw, 1/2-13 x 1-1/2" (Use as requir ed)
155 792090 Screw, 1/2-13 x 2-3/4" (Use as requir ed)
155 792092 Screw, 1/2-13 x 2-1/2" (Use as requir ed)
155A 792069 Screw, 1/2-13 x 1-1/2"socket hd(Use a s req.)
156 792066 Lockwasher, 1/2"
2500-2542A Page 2 of 5
Peerless #1
www.mymowerparts.com
For Tecumseh Peerless Transmission Transaxle Parts Call 606-678-9623 or 606-561-4983
Ref # Part Number Qty Description
157 788049 Oil Seal
163 788048 Square Cut Seal
166 780005 Spacer (Loose Part)2
167 774446 Wheel Hub (obsolete)(use as required)
168 792098 Lug Bolt (obsolete)(use as required)
169 792096 Locking Tab (Loose Part)2
170 792097 Hex Nut, 1-14 (Loose Part)2
2500-2542A Page 3 of 5
Peerless #1
www.mymowerparts.com
For Tecumseh Peerless Transmission Transaxle Parts Call 606-678-9623 or 606-561-4983
2500-2542A Page 4 of 5
Peerless #2
www.mymowerparts.com
For Tecumseh Peerless Transmission Transaxle Parts Call 606-678-9623 or 606-561-4983
Ref # Part Number Qty Description
39 786026 Dowel Pin
47I 774444 Axle (18-7/32" long)
48I 774445 Axle (16-17/32" long)
2500-2542A Page 5 of 5
Peerless #2
www.mymowerparts.com
