Tecom Co GR2512 Users manual

2/1-port FXS ATA WiFi-Router Quick User Guide

2/1-port FXS ATA WiFi-Router

Quick User Guide

Page 0

Preliminary

2/1-port FXS ATA WiFi-Router Quick User Guide

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interence in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

l Reorient the receiving antenna. l Relocate the equipment with respect to the receiver. l Plug the equipment into a different outlet so that equipment and receiver are on different branch

circuits.

l Consult the dealer or an experienced radio/television technician for help.

FCC Caution: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment; such modifications could void the user’s authority to operate the equipment. This equipment complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This equipment may not cause harmful interference, and (2) this equipment must accept any interference received, including interference that may cause undesired operation.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. IEEE 802.11b or 802.11g operation of this product in the USA is firmware-limited to channels 1 through 11.

Europe CE Declaration of Conformity

This equipment complies with the requirements relating to electromagnetic compatibility, EN55022 Class B for ITE and EN 50082-1. This meets the essential protection requirements of the European Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

Environment

The phone you have purchased, as well as any used batteries must not be disposed of with household waste. You should return these to your distributor if they are replaced or dispose of them in an approved recycling centre.

Trademarks

Windows 98/2000/XT/NT™ and Internet Explorer™ are registered trademarks of Microsoft Corporation. All other company, brand and product names, like Netscape Navigator™ are trademarks or registered trademarks of their respective owners.

Page 1

2/1-port FXS ATA WiFi-Router Quick User Guide

WARNING!

1. Read these installation instructions carefully before connecting the 2/1-port FXS ATA WiFi-Router to its power source.

2. To reduce the risk of electric shock, do not remove the cover from the 2/1-port FXS ATA WiFi-Router or attempt to dismantle it. Opening or removing covers may expose you to dangerous voltage levels. Equally, incorrect reassembly could cause electric shock on re-use of the appliance.

3. Do not expose the 2/1-port FXS ATA WiFi-Router to Fire, direct sunlight or excessive heat.

4. Do not expose the 2/1-port FXS ATA WiFi-Router to rain, water or moisture.

5. Do not install the 2/1-port FXS ATA WiFi-Router in an environment likely to present a THREAT OF IMPACT.

6. The 2/1-port FXS ATA WiFi-Router is designed to work in temperatures from 5oC to 45oC.

7. To ensure compliance with international safety standards, only use the power adapter that is supplied with the unit.

8. The 2/1-port FXS ATA WiFi-Router must be installed at least 1 meter from radio frequency equipment, such as TVs, radios, hi-fi or video equipment (which radiate electromagnetic fields).

9. Do not connect the WAN port to any network other than an Ethernet network.

10. Do not attempt to upgrade your 2/1-port FXS ATA WiFi-Router in an unstable power environment. This could cause unexpected issues.

11. Do not work on the system or connect or disconnect cables during lightning storms.

12. Children don't recognize the risks of electrical appliances. Therefore use or keep the 2/1-port FXS ATA WiFi-Router only under supervision of adults or out of the reach from children.

13. No repair can by performed by the end user, if you experience difficulties with this equipment, for

repair or warranty information, please contact your supplier.

Page 2

1 Introduction

The 2/1-port FXS ATA WiFi-Router is a SIP- based high performance WiFi IP gateway with embedded router. It is ideal for residential/SOHO or even SME VoIP communications. It can support 2 FXS ports for phone or FAX. Furthermore, this product is configurable for matching with different telephones, facsimiles, voice mail systems, IVR system and different country networks over the world by software settings.

This router is built with a powerful router and full wire-speed Ethernet switch that not only save money and space, but also offer unbeatable superior voice quality for VoIP calls. This router can be configured downgrade to an IP-Sharer/NAT or a pure bridged switch for various applications. Of course, the WiFi facility enables user's PCs to connect to Internet or link this VoIP router to Internet world. This WiFi support brings a lot of convenience, benefits and mobility for better productivity.

This Quick Guide takes you through the basic steps necessary to install and configure your 2/1-port FXS ATA WiFi-Router, as well as establish a connection from your phone to the Internet.

The package contains:

- One 2/1-port FXS ATA WiFi-Router

- One 13VDC / 800mA power adapter for use with the 2/1-port FXS ATA WiFi-Router

- This Quick User Guide

The System Requirements: Before starting, you must ensure the following items:

- You already have a cable or DSL broadband connection to the Internet.

- The modem must have an Ethernet port for connection to your 2/1-port FXS ATA WiFi-Router.

2 Features

2/1-port FXS ATA WiFi-Router Quick User Guide

Physical

- Temperature: Operating 0

- Humidity: Operating 15% to 85%, Storage: 10% to 90%

- 2 or 1 FXS (POTS) ports

- 100/10Mbps RJ45 Ethernet ports for WAN & LAN

- 1 WiFi antenna support IEEE 802.11b/g

- LEDs: PWR, LAN4, LAN3, LAN2, LAN1, WAN, FXS1, FXS2

- 1 DC power input Jack (2.5mm) for a switching power supply

- 1 Reset button for Factory default setting

Key Features

- Superior voice quality and versatile features support

- Integrated wire and wireless access in box

- Support Telephone/FAX over IP

- Embedded router and L2/L3/L4 switch mechanism

- Supports rich supplementary call features

- Intelligent Dial Plan and flexible route selection

- Good interoperability with Soft switch, IP-Centrex, IP-PBX, and SIP servers

- Support generic or secure APS

- Auto provisioning, web management and security enhancement

- Cyber attack and broadcast storm protection

to 45 o C, Storage: -20o to 70 o C
