Tecknet M008, M009 User Manual
TECKNET M008 Laser Gaming Mouse
TeckNet M008
Thank you for choosing the TECKNET M008 Laser Gaming Mouse. This
advanced level mouse uses the Avago A9800 sensor and is customized
for gaming. It achieves pinpoint precision and accuracy, reassuringly
stable performance and user safety. It supports RTS, FPS, MMORPG
games, as well as general webpage browsing (scrolling the mouse wheel)
and page scaling in software such as Office (Ctrl + rolling the mouse
wheel). Ergonomically designed, the mouse has a natural feel, allowing
long periods of comfortable gaming. DPI can be switched easily with the
highest DPI reaching 16400. You can also install software to customize
the button functions and improve your gaming experience.
EN
Product Features
• Specifically designed for Advanced Level game players, supporting RTS,
FPS, MMORPG games.
• Supports Macro Editing: The mouse can store 5 groups of user UI setting
which can be switched quickly to each other through specific buttons and
can be used on any computer.
• Variable DPI switching: 1000 / 2000 / 4000 / 8200 / 16400.
• Ergonomic-design: Provides a relaxed, comfortable hand position an
smooth operation.
• Compatible with both desktop and laptop PC.
• Meets Eye Safety Standard Level 1 regulations. Laser power is under 506μ
W(auto-power control).
• Key Life: More than 5 million clicks.
System Requirements
To use this mouse, your computer must meet the following hardware
requirements and run one of the operating systems listed below.
Operation System
Win XP, Vista, Win7, Win8 operating systems.
Note: The enhanced features only work under the operating systems listed
above. If you use the mouse under a different operating system, the mouse
may either not work or lose its enhanced features and function as a
standard mouse only.
Package Contents
1 x TECKNET M008 Gaming Mouse
1 x Variable Weight Set
1 x CD
1 x User Manual
Product Function
• Specialized multi-function set-up software, easy installation able to store
user settings.
• High-speed USB interface, up to USB 1.1, 2.0 full speed standard, and
supports 125 / 250 / 500 / 1000HZ switch.
• Default (1000 / 2000 / 4000 / 8200 / 16400)DPI switching function.
Software supports easy DP setting between 50-16400.
• Cool-looking 5-color light effect, switchable via a button on the underside.
• 4-color LED signal light indicating a change in DPI. Hardware memory
stores 5 sets of user UI setting（user interface), indicated by yellow /
green / blue / purple / red LED light respectively.
• Custom weights - comes with 8 weights (2.4g each) with auger-type
device.
• Metal chassis gives a solid feeling, balanced weight.
Software Interface
Main setup page and function introduction
EN
1. Left button: left button function (default position: ①).
2. Right button: right button function (default position: ②).
3. Middle button: middle button function (default position: ③).
4. Fire button: continuously click left button for 3 times, and set launch
frequency and repeating time with software(default position ④).
5. Report rate+: turn report rate up( default position ⑤ ).
6. Report rate-: turn report rate down (default position⑥).
7. DPI+: turn DPI up, one-way adjustment(default position ⑦）.
8. DPI-: turn DPI down, one-way adjustment(default position ⑧）.
9. L Alt: controls [Alt] button on your keyboard.(default position ⑨).
10. L Ctrl: controls [ Ctrl ] button on your keyboard.(default position ⑽）.
11. L Shift: controls [ Shift ] button on your keyboard(default position ⑾)）.
12. Forward: move to the next window(default position ⑿）.
13. Return: go back to the last window(default position ⒀）.
14. Single bond: can be set to control any button on your keyboard.
15. Key combination: can be set to act as key combinations of Ctrl，Shift
，Alt，Win + any key.
16. Basic function: including following functions: cut, copy, paste, select all,
search new document, print and save.
17. Advanced functions: window switching / closing, my computer,
operation, show desktop, lock computer, homepage, browser functions
such as Back, Forward, cancel, refresh, search favorites, E-mails.
18. Multimedia functions: Play / pause, stop, previous, next, volume
up/down, mute, media player, mute( micro-phone).
19. Macro definition: Macro manager can record any key on the keyboard
and mouse, press time and number of cycles.
a. Create a [ new ] file in macro selection, such as ａ,ｂ,ｃ…
b. Choose whether to increase the delay and the number of cycles
c.
Click on [start recording], then you will be able to start recording any key
on the keyboard, the key recorded will be displayed in the macros edit box
(press-certain time-release)
d. After recording, click the "stop recording"
e. If you want to modify the recorded content, you can make the following
changes in the macro options:
Insert after the selected: Insert contents after the selected location
Delete: Delete the selected content
Move to next line: Move the selected down to next line
EN
Move to previous line: Move the selected up to previous line
Copy: Copy the selected contents
Cut: Cut the selected contents
Paste: Pastes the contents copied or cut into the selected location
f. Click "OK" after confirming that the recording is complete
g. Press repeat: when you press and hold, macro is looping till the key is
released
h. Run macro, for instance, set mouse button ⑧ is "macro", press the
mouse button ⑧, you can play the recorded content after the recording is
complete.
20. DPI shift: Switch a 5-speed DPI.
21. Configuration Alt: Switch 5 modes.
22. Lighting switch: Switch 5 lighting effects,( Switch on the bottom button
of the mouse).
23. Disable button: Set buttons non-functional.
24. Mouse pointer acceleration: Adjust pointer speed.
25. Mouse movement speed: Adjust the mouse movement speed.
26. Mouse wheel speed: Adjust the mouse wheel speed.
27. Mouse double-click speed: Adjust mouse double-click speed and test
area.
28. 5 modes: mode1/mode2/mode3/mode4/mode5, 5 modes switch
(Switch is on the underside of the mouse).
29. Mouse rate: choose 125HZ / 250HZ / 500HZ / 1000HZ.
30.
Save configuration: Save configuration content into the computer (save
the file in the format *.PFD).
31. Load configuration: Load an existing document from the computer
settings.
32. Reset: Set the current configuration to the default factory settings.
33. Reset all: Set all configuration to the default factory settings.
34. OK: Run mouse with the above configuration and close the page.
35. Cancel: Cancel the setting and close the page.
36. Apply: Run mouse with the above configuration.
EN
1. 5 DPI: DPI1 / DPI2 / DPI3 / DPI4 / DPI5 Tick to select.
2. DPI setting: set 5 DPI value, XY axis peer / unequal adjustment,
adjustment range 50～16400DPI.
1. Brightness level: Adjust breathing lamp brightness.
2. Breathing rate: Adjust breathing rate of breathing lamp.
DPI setting
Lighting (Lighting eect adjustment)
EN
Working conditions
Suitable for a laptop or desktop computer with a USB1.1 or USB2.0
interface
Working voltage: 5V DC ±5%
Working current: ≤100mA
Working temperature: 0℃-45℃
Working humidity: ≤85%RH
Simple troubleshooting
1. Computer cannot detect the mouse and logo lights, wheel light does not
work:
Make sure the mouse is connected to your computer, whether the USB
protocol is supported by the operating system version or not, you can also
pull out and plug once again.
2. In the event of problems that cannot be resolved, please do not
disassemble, it should be sent immediately to the nearest dealer.
3. If the mouse does not work:
A) Verify that your computer’s power management features is turned off.
B) Check that the USB connector is firmly attached to the USB port of your
computer.
C) Still not working? Please try restoring the factory default settings.
Information
