TECHVISION INFORMATION TECHNOLOGY TVE1001I User Manual

TABLET PC

Quick Start Guide

Model: TVE100１I

UserManual

Safety Precautions

1. This production is suitable for use in non-tropic areas below 2,000 meters, and the mark

in the nameplate indicates the

product is suitable for use in non-tropic areas.

2. Prevent the Tablet PC from falling to the ground or being strongly impacted otherwise.

3. Do not use it in the long term in any environment where the air is too cold, too hot (<35℃), too humid or with too much dust. Do not

expose the Tablet PC to sunlight.

4. Avoid using it in the strong magnetic and strong static environment as much as possible.

5. Once any water or other liquid splashes onto the Tablet PC, close it immediately and do not use it until it dries out.

6. Do not clean the Tablet PC with any detergent containing chemical element or other liquid to avoid causing damage due to

corrosion and becoming damp. If cleaning is really necessary, clean it with dry soft cloth tissue paper.

7. Our company shall not bear any and all responsibilities for loss or deletion of material inside the machine caused due to abnormal

software and hardware operation, maintenance or any other accident.

8. Please back up your important material at any time to avoid loss.

9. Please do not disassemble the Tablet PC by yourself; otherwise you will lose the right to warranty.

10. Replacement with incorrect type batteries may cause explosion. Make sure to use original batteries.

1

UserManual

Packing List

Please check box for the following items

1. Device

2. User Manual

3. Product Warranty

4. USB Adaptor
External pipo keyboard

5.

Other accessories can be purchased at local retailers
The accessories may not be compatible with other devices

Power Adaptor Specification:
MODEL:
INPUT: AC 100-240V 50/60Hz 0.3A MAX
OUTPUT: 5.0V

TVE1001I

2.0A

2

UserManual

Device description

①Touch screen：You can click and drag in the touch screen.
②Front Camera：You can take photos and videos etc.
③Volume-：Turn down the volume.
④Volume+：Turn up the volume.
⑤POWER：

Keep pressing button over 2 seconds for power on/ off, press
button once to turn on screen from sleep mode.
⑥
⑦
⑧
⑨
⑩
⑪

⑫
⑬

：Micro USB, Micro-5pin connector.

Micro HDMI：Micro HDMI Output.

Micro USB connection.

Earphone jack：3.5mm standard earphone jack.

Micro SD/TF card：Micro SD/TF card slot.

Speaker.

Rear Camera：You can take photos and videos etc.

Pen.

【TIPS 】：

1. When the battery is low, it will power off automatically.

2. Shutdown illegally, when you restart, device would scan

and repair the disk. The screen will stay at the progress bar for

a long time .

【Note】：The pictures in the user manu al are just for your reference.

① ② ③④⑤

⑪

⑥
⑦

⑧
⑨

⑩

⑫ ⑬

3

UserManual

Setting up for the first time

Charging your device ：
For first-time use, you need to charge the device for ten hours.
After that you can recharge the device as needed.
Connect the DC-in jack to your device and plug the AC adapter
into any AC outlet.
【TIPS】:

1. This device adopts built-in polymer battery. Only the

specified charger should be used.

2. It is normal for the device’s surface to become warm during

charging or long periods of use. All devices are factory tested

before release.

3. If you do not use this set for a long time, please charge/release it once

one month to avoid deep discharge. The damage caused by battery over-consuming is not included in the warranty.

Battery Saving
To save battery running life, please see below key points. With below suggestions, battery can run longer time after fully charged
each time.

1. When device is not in use, press power button once to go to sleep mode.

2. Shut down the applications when not in use.

3. Turn off WLAN when not in use

4. Shut off application sync selection

5. Set a shorter time for display backlight

6. Reduce brightness of display

4

UserManual

Power On
Keep pressing power button over 2 seconds, device will start up opening screen.

Sleep Mode
After devise is on, press power button once and it goes to sleep mode. The screen is now on standby and under low battery
consumption. To wake up device, press one more time power button.

Power off
When you are not using the device, keep pressing power button over 2 seconds, the screen will display slide down.
