Overview
The OPS-TCIS is a full-featured Windows PC in
OPS form factor for integration into Commercial
Displays. Targeted for Commercial Applications
such as Digital Signage, Quick Service Restaurant,
and/or Display Walls, the OPS-TCIS is based the
latest Intel Skylake CPU architecture with integrated
Intel Iris 540 Graphics.
The OPS-TCIS supports true 1080P an 4K video
with hardware assisted support for formats such as
MPEG2, H.264, and WM9.
The OPS-TCIS external connections include 2 USB
2.0, 2 USB 3.0 for connection to keyboard, mouse,
flash, or touch screen, 10/100/1000 LAN, Wifi, and
Display Port for connection to a second screen.
OPS-TCIS Option Slot PC
Windows PC for Commercial Display
Applications Based upon Skylake CPU
Specification
OS Windows 10 Pro
CPU 2.0 GHz Intel Skylake Dual Core I5 CPU
(6360U) or
2.4 GHz Intel Skylake Dual Core I7 CPU
(6660U)
Applications
Digital Signage
Quick Service Restaurants
Display Walls
Large Venue/Stadiums
Education
Medical
IPTV
Hospitality
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help
Contain FCC ID:PD93165D2
Features VPro
TPM V2.0
Memory 8 GB DDR4 (dual channel)
Storage 128 GB M.2 SSD
Video Output HDMI 1.4 (OPS Conn), Display Port 1.2
(EXT Conn)
Audio Output Stereo (OPS Conn), Display Port 1.2
(EXT Conn)
Network LAN: 100/1000 Base T
WIFI: 802.11 ac
Control USB2.0 x2, USB3.0 x2 (EXT Conn)
USB2.0 x2, USB3.0 x1 (OPS Conn)
UART (OPS Conn)
Power Input Voltage: 16 VDC
Power Dissipation: 50 Watts
Environmental Operating Temp: 0 to 40 C
Operating Humidity: 80% maximum
relative humidity; non condensing
General Dimensions: 200mm x 119mm x 30mm
Weight: 2.5 lb
OPS connector (TX25A)
Certifications FCC Section 15, CE
Technovare Systems, Inc.
16815 Von Karman Avenue, Suite 175
Irvine, CA 92606
714-966-9099
Product specification subject to change. 4/7/17
© 2017 Technovare Systems, Inc, Inc. All rights reserved.
