Technomad Turnkey PA Systems
Get the sound your team, venue, or event deserves!
The Problem: You know you need a real sound system... for too long you’ve put up
with hard-to-hear speech, and music that sound like it’s coming through a telephone.
The problem is, what kind of loudspeakers to get? You want something that’s going to
last, but most “weather-resistant” loudspeakers only survive a season or two if you’re
lucky (and sound pretty terrible anyway). Then you have to figure out what kind of
amplifier to get, choose a mixer with all the connections you need, get a microphone,
pick the right cables, hook everything up correctly... What a hassle.
The Answer: Good news! Technomad, manufacturer of military-grade loudspeakers
for the US Armed forces and theme park and cruise ship customers around the globe,
presents its new Turnkey PA Systems. These are complete, ready-to-use PA systems
that include Technomad’s mil-spec weatherproof loudspeakers, mounting brackets,
speaker cables, and a pre-wired control rack with an expandable mixer (with mic and
CD-Tape inputs), a hand-held microphone, and a transport storage case. All you have
to do is plug in power, attach the loudspeaker cables, and... you’re done!
You don’t need ANY special audio knowledge to install and use a high quality PA
system at your stadium or venue (and we have mobile systems too, in case you need to
use your sound system in several places).
There are 3 sizes of system: small, medium, and large. The medium system handles
an entire high school football stadium with ease - home, field, and away sides.
The sound quality? Better than any outdoor audio system you’ve ever heard - speech
is clear even at long distances, or in windy / noisy environments, and music sound
great, with detailed highs and deep bass. No music store PA or cheap plastic “all-in-one”
PA system can compete with the military-grade power and realiability of Technomad.
And yes, you can install the loudspeakers permanently outdoors - they need no
special protection to sound great in any weather, for years and years. Read on to pick
your PA system, and finally get the PA system- and the sound quality - you deserve.
Shown: iPA3 System
Technomad
Audio. Anywhere
Turnkey PA Systems - examples
View of a Typical Football Field Loudspeaker Closeup
Loudspeakers Installed on Press Box Control Rack and Microphone
Turnkey PA System Installed in Gym Turnkey PA System in Gym
Turnkey PA Systems
Complete audio solutions for mobile or permanently-installed audio
Systems include Technomad Mil-Spec weatherproof loudspeakers
Systems include power-matched amplifier, a
mixer, microphone, wiring, stands / tripods
All electronics are pre-wired and installed in a
mil-spec flight case for secure transport
Integration & setup done at Technomad factory
Typical Setup Time: 15 minutes
No audio experience required to setup and use
Three Installation Systems (iPA1, iPA2, iPA3)
Three Mobile Systems (MPA1, MPA2, MPA3)
Included mixer with two mic inputs, three linelevel inputs
Outstanding music playback and voice projection
Need a complete audio solution for your mobile or permanently-installed audio project?
Technomad Turnkey PA systems combine our Mil-Spec
weatherproof loudspeakers with a power-matched amplifier, a mixer with mic / CD inputs, a hand-held dynamic
microphone, all wiring, mounting hardware or tripods,
and speaker cables.
All electronics are pre-wired and installed in a Mil-Spec
flight case for secure transport or storage. Because
Technomad assembles and tests your system at the factory, all you have to do is plug it into AC power and attach
the loudspeaker cables to the loudspeakers.
Most people have their systems up and running in 15
minutes, even if they have no prior audio expererience.
Ahand-held microphone is included, and the integrated
mixer allows two mic-level and three line-level sources
(such as a CD player, tape deck, or MP3 player) to be
attached to the system.
Technomad turnkey PA systems are ideal for academic
applications, event audio, sporting events, music playback, voice paging, and more.
Systems can be drop-shipped, and are shippable via UPS.
There are six turnkey PA system to choose from - three for
installations (which include wallmounts), and three for
mobile use (which include tripods).
Quick to set up and use, Technomad Turnkey PA systems
are the simple solution to your audio needs.
Complete, Pre-Integrated Technomad PA Systems
shown: mPA3 PA System - Two Berlin 15/H loudspeakers, amp/mixer rack
Technomad
Audio. Anywhere
Turnkey PA System
Specifications
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Wallmounts:
Speaker Cable:
Ship Weight:
Audience:
2 x Vienna 16
Samson Servo-550 or equiv. ( 2 x 175w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 x Technomad 512 mount
2 x 50’, 12 gauge
150 lbs (68 kG)
500+
iPA1 - small install PA system
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Tripods:
Speaker Cable:
Ship Weight:
Audience:
2 x Vienna 16
Samson Servo-550 or equiv. ( 2 x 175w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 Technomad S6 stands
2 x 50’, 12 gauge
150 lbs (68 kG)
500+
mPA1 - small mobile PA system
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Wallmounts:
Speaker Cable:
Ship Weight:
Audience:
2 x Noho C Install Model
Crown CE1000 or equiv. ( 2 x 275w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 x Technomad 694 mount
2 x 50’, 12 gauge
200 lbs (91 kG)
1000+
iPA2 - medium install PA system
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Tripods:
Speaker Cable:
Ship Weight:
Audience:
2 x Noho C Tour Model
Crown CE1000 or equiv. ( 2 x 275w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 Technomad S6 stands
2 x 50’, 12 gauge
200 lbs (91 kG)
1000+
mPA2 - medium mobile PA system
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Wallmounts:
Speaker Cable:
Ship Weight:
Audience:
2 x Berlin 15/H Install Model
Crown CE2000 or equiv. ( 2 x 400w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 x Technomad 694 mount
2 x 50’, 12 gauge
300 (136 kG)
2000+
iPA3 - large install PA system
Loudspeaker:
Amplifier:
Mixer:
Microphone:
Rack:
Tripods:
Speaker Cable:
Ship Weight:
Audience:
2 x Berlin 15/H Tour Model
Crown CE2000 or equiv. ( 2 x 400w)
Shure SCM262 or equiv. 2 mic in, 3 RCA in
Dynamic, Switched w/ Cable
Technomad ProRack 4U
2 Technomad S6 stands
2 x 50’, 12 gauge
300 (136 kG)
2000+
mPA3 - large mobile PA system
All Technomad turnkey PA systems are integrated at the Technomad factory, and are delivered “ready -to-use”.
Typical setup time is 15 minutes. Systems include Technomad high-performance weatherproof loudspeakers
and a pre-wired rack containing a mixer (5 inputs: 2 mic and 3 line ), and a power-matched amplfiier. A handheld mic, tripods (or wallmount brackets), and speaker cables are also included. System components and
specifications subject to change without notice.
pefect
for football and baseball
stadiums !
Technomad
Audio. Anywhere
Frequently Asked Questions
» Are Technomad Turnkey PA Systems REALLY weatherproof?
The loudspeakers included with Technomad Turnkey PA Systems are completely weatherproof. They are
impervious to rain, snow, sleet, salt fog, UV radiation, insect attack, rough handling, and more. They are
Military-Grade, and are constructed from thick, one-piece polyethylene. No other commercial loudspeaker
comes close to the physical and electrical reliability of Technomad. You can install your Technomad loudspeakers outdoors, permanently, year-round. The "control rack" - amplifier / mixer racks - can get wet when their lids
are attached, but should be protected from moisture when in-use.
» What makes these systems better than "music store" systems?
"Music store" PA systems are intended for general purpose, indoor sound reinforcement. They cannot survive
outside installation (the loudspeaker cones will break down, the cabinets will rot, metal will rust, etc). Also,
these systems are unable to project sound powerfully enough to cover large, outdoor areas. Speech will be
unclear, and music will lack impact. In contrast, Technomad Turnkey PAsystems offer an unmatched combination of military-grade reliability and powerful audio reproduction that handles large outdoor areas with ease.
» What makes these systems better than "all-in-one" systems?
People sometimes attempt to cover their indoor or outdoor even using a compact, "all-in-one" PA system.
While these systems are useful for small, low-volume indoor events (board meetings, etc) , they
are not powerful enough to project sound in large outdoor areas or in noisy, reverberant gyms. These systems
tend to be operated at the edge of their capacity, and sound strained, distored, or clipped when pushed too
hard. Sound quality suffers, and speech clarity is very poor. Also, these all-in-one systems are highly sensitive to
weather (rain, moisture, etc.) and cannot be installed permanently. A Technomad Turnkey PA system offers
VASTLY better music and speech quality than cheap plasticall-in-one systems, and and are orders of magnitude
more relaible.
» How clear / intelligible is speech through a Turnkey PA system?
Technomad Turnkey PA systems offer unmatched speech and voice clarity, freeof horn-mouth distortion and the
limited frequency range of other systems. Theresult? Speech is clear, intelligible, and natural sounding, even in
noisy orwindy environments. Choose Technomad Turnkey PAsystems for the best voiceclarity available.
» How is the sound quality? Can I play music through a Technomad Turnkey PA?
Technomad Turnkey PA systems equal the music playback quality of the finestcommercial PA systems. They
deliver "no-compromises" music quality,with deep bass and clear, detailed highs. Speech, singing voice, and
amplifiedinstruments all sound great when reproduced by a Technomad Turnkey PA system.
» Why should I used Technomad Turnkey PA systems instead of a "horn" system?
Horn systems degrade speech and destroy music quality. Technomad TurnkeyPA systems handle voice paging
and music playback, and do it all vastly betterthan a horn system or a "music store" PA system.
» Where can I install them?
Technomad Turnkey PA systems can be installed on a building, press-box, pole,or other sturdy structure. Note :
there is a best placeto install speakers in a stadium for best sound quality. See below... In general,Technomad
Turnkey PA systems can be used virtually everywhere.
» What is the best place to install loudspeakers in a football stadium? or a baseballstadium?
TThe natural instinct is to install loudspeakers on poles, facing the "homeside" stands. This is a mistake!
Speakers should be located on the PressBox, pointing directly across the field at the Away Side. ClickHere To
Read More! For baseball use, you should install speakersright behind home plate in a cluster, on loudspeaker
pointing @ 45 degrees left and the other @ 45 degrees right.
» What kind of power do they require?
All Technomad Turnkey PA systems operate off of standard 110/120V AC power.A 10A circuit provides ample
current.
» Can I hook up my existing audio equipment to a Technomad Turnkey PA?
YES. Technomad systems are "open"- we provide mixers with standardXLR, 1/4", and RCA connectors, allowing
you to plug virtually any audioplayback device (cd player, tape deck, iPOD, MP3 player, compouter) into thePA
system.
» What kind of operating range can I expect from the Technomad Turnkey PA systems?
Under optimal conditions the iPA1 or mPA1 (small install or small mobilesystems) will cover the home-side of a
football field, and some of the fielditself - @ 500+ people. The iPA2 or mPA2 (medium install or medium mobile
systems)will cover and ENTIRE football field - home side, field, and away side - @ 1000+people. The iPA3 or
mPA3 (large install or large mobile systems) will coververy large sports facilities - 2000+ people.
» Are Technomad Turnkey PA systems expandable? Can I add more speakers to a basicsystem later?
YES. You can add like-type loudspeakers to any Technomad Turnkey PA systemto bring the total quantity up to
6 loudspeakers. You do not need to changeyour amplfier to power six speakerss - this capability is built-in.
» What special training do I need to have to setup and use a TechnomadTurnkey PA system?
None! Technomad Turnkey PA systems are designed to be simple to setup and use,and come with detailed,
step-by-step instructions. Most people can haveTechnomad Turnkey PA system up and running in @ 15 minutes, even if they haveno prior audio experience.
To Order: contact Technomad at 1.800.464.7757 for the name of a local or national dealer.
Or, visit http://www.technomad.com/ and click on the “order “ tab.
