TS-3100 User’s Manual
TS-3100 User’s Manual Technologic Systems
Technologic Systems, Inc.
16 East Laser Drive
Fountain Hills, AZ 85268
480-837-5200
FAX 837-5300
info@embeddedx86.com
http://www.embeddedx86.com/
This revision of the manual is dated
0D\ 2, 200
All modifications from previous versions are listed in the appendix.
Copyright © 1998-2001 by Technologic Systems, Inc. All rights reserved.
ii
0/2/0
TS-3100 User’s Manual Technologic Systems
Limited Warranty
Technologic Systems warrants this product to be free of defects in material and workmanship for a
period of one year from date of purchase. Technologic Systems will repair or replace the defective unit
during this warranty period in accordance with the following instructions:
• Contact Technologic Systems and obtain a Return Material Authorization (RMA) number and a
copy of the RMA form.
• Fill out the RMA form completely and include it and dated proof of purchase with the defective unit
being returned. Clearly print the RMA number on the outside of the package.
This limited warranty does not cover damages resulting from lighting or other power surges, misuse,
abuse, abnormal conditions of operation, or attempts to alter or modify the function of the product.
This warranty is limited to the repair or replacement o f the defective unit. In no event shall
Technologic Systems be liable or responsible for any loss or damages, including but not
limited to any lost profits, incidental or consequential damages, loss of business, or
anticipatory profits arising from the use or inability to use this product.
Repairs made after the expiration of the warranty period are subject to a flat rate repair charge and the
cost of return shipping. Please contact Technologic Systems to arrange for any repair service.
iii
TS-3100 User’s Manual Technologic Systems
Table Of Contents
LIMITED WARRANTY .............................................................................................................................................. III
1 INTRODUCTION...............................................................................................................................................5
2 DIFFERENCES BETWEEN TS-3100 AND TS-3200........................................................................................ 5
2.1 RAM/Memory.................................................................................................................................................................5
2.2 Flash Memory ................................................................................................................................................................5
2.3 Operating Systems Supported....................................................................................................................................... 5
2.4 Speed............................................................................................................................................................................. 5
2.5 Bus Size.........................................................................................................................................................................5
2.6 RS-485...........................................................................................................................................................................5
2.7 DIO Differences .............................................................................................................................................................6
2.8 Transferring Files from a Host System to the TS-3100..................................................................................................6
2.9 Development Tips..........................................................................................................................................................6
3 FEEDBACK AND UPDATES TO THE MANUAL .............................................................................................. 6
APPENDIX A - BOARD DIAGRAM AND DIMENSIONS............................................................................................7
APPENDIX B – SYSTEM MEMORY MAP ................................................................................................................. 8
APPENDIX C - FURTHER REFERENCES ............................................................................................................... 8
APPENDIX D - MANUAL REVISIONS....................................................................................................................... 8
iv
TS-3100 User’s Manual Technologic Systems
1 Introduction
The model TS-3100 is a compact, full-featured PC compatible Single Board Computer based on the
386EX processor. If you are coming up from the 8-bit microcontroller world, you will find that this
product provides much more performance and much quicker development since you can now use
standard PC development tools such as Turbo C or Quick Basic. If you have done work in the PC
world in the past, you will find you can now build applications for a very small target that does not
require a keyboard, video, floppy disks, or hard drives.
You can typically write and debug code on a host PC using standard development tools for the PC
platform, then simply copy it to and run it on the TS-3100 without modification. If additional peripherals
are required, the PC/104 expansion bus allows for many standard functions available off-the-shelf. It is
also very simple to create a custom PC/104 daughter board for those special features that differentiate
your product. Technologic Systems can provide technical support as well as a free quotation for any
custom hardware, software, or BIOS modifications you may require.
This manual is fairly short. This is because for the most part, the TS-3100 is a standard 80386-based
PC compatible computer, and there are hundreds of books about writing software for the PC platform.
The purpose of this manual is documenting where the TS-3100 differs from a standard PC.
2 Differences Between TS-3100 and TS-3200
The TS-3100 is almost identical to the TS-3200. The TS-3100 was designed to be an extremely lowcost PC/104 board where the full horsepower of a TS-3200 is not needed. Therefore, the manual for
the TS-3200 can be used except for the categories below detailing where they differ. A copy of the TS 3200 can be found on our web-page for the TS-3200, or on the utility diskette of the TS-3100.
2.1 RAM/Memory
The TS-3100 only has 512 Kbytes of 8-bit wide RAM and is not expandable. Some of this RAM is used
for BIOS shadowing and the operating system. The maximum user program size is limited to about 250
Kbytes, which is typically plenty for most DOS applications.
2.2 Flash Memory
The Flash memory uses a single 512 Kbyte chip. Some of this Flash memory is reserved for the BIOS
and for DOS. This leaves about 320 Kbytes of solid-state disk drive space available. If more disk space
is required, one can always add a DiskOnChip module.
2.3 Operating Systems Supported
Due to the limited RAM, only DOS-ROM is supported by Technologic Systems on the TS-3100.
2.4 Speed
Both the TS-3100 and the TS-3200 use an Intel 386EX chip running at 25 MHz clock rate. The TS3200 uses a high-speed SDRAM with a 16-bit interface to the processor. The TS-3100 differs in that it
uses a slower DRAM with only an 8-bit interface. This causes the TS-3100 to execute code at 40% as
fast as the TS-3200.
2.5 Bus Size
The TS-3100 only supports an 8-bit PC/104 Bus. Most PC/104 daughter boards only use 8-bits so this
is a minor limitation.
2.6 RS-485
The TS-3100 and the TS-3200 support RS-485 on pins 1 and 6 of the COM 1 header. Unlike the TS3200, the TS-3100 does not have a separate 3-pin header for RS-485.
5
TS-3100 User’s Manual Technologic Systems
2.7 DIO Differences
The TS-3100 has the exact same 37 DIO lines on headers DIO1, DIO2, and LCD as the TS-3200
does. The TS-3100 has slightly more flexibility on a few of the signals. Pins 6, 11, 12, 13, and 14 on
DIO1 and pin 12 on DIO2 can be either inputs or outputs (the TS -3200 can only use these lines as
inputs). On the TS-3100, all input signals on the DIO1, DIO2, and LCD ports can be 0 -5 Volts (the TS3200 has a 3.3V limitation on some of these lines).
2.8 Transferring Files from a Host System to the TS-3100
Although the TS-9500 (a PC/104 daughter board with VGA video and keyboard) can be used with the
TS-3100, the TS-9500 Compact Flash interface requires a full 16-bit PC/104 bus. This means that
Compact Flash cannot be used to transfer files from a host PC. Using Zmodem over a serial port is
the suggested method to transfer files to the TS-3100.
2.9 Development Tips
The use of a TS-3200 is recommended for Development. Besides being able to support a TS-9500
(useful in rapid development and on-board debugging with the VGA and keyboard support), the faster
speed and the ability to throttle the speed with a jumper (simulating a TS -3100) make it a perfect
developers tool for the TS-3100.
The use of the integrated BIOS debugger (INT3) is available on the TS -3100.
3 Feedback and Updates to the Manual
To help our customers make the most of our products, we are continually making additional and
updated resources available on the Technologic Systems web site (www.embeddedx86.com). These
include manuals, application notes, programming examples, and updated software and firmware.
Check in periodically to see what's new!
When we are prioritizing work on these updated resources, feedback from customers (and prospective
customers) is the number one influence. If you have questions, comments, or concerns about your TS -
3100 Embedded PC, please let us know. Details for contacting us are listed in the front of this manual.
6
TS-3100 User’s Manual Technologic Systems
Appendix A - Board Diagram and Dimensions
Figure 1 - Board Diagram
Coming Soon
Figure 2 - Board Dimensions (standard PC/104 8-bit
module dimensions)
Coming Soon
7
TS-3100 User’s Manual Technologic Systems
Appendix B – System Memory Map
Starting Address Size Resource
Hex Decimal
BIOS
(Shadow RAM)
DOS / BIOS Extension
PC/104 Bus
DiskOnChip or SRAM or PC/104 Bus
PC/104 Bus
PC/104 Bus
(Typically video BIOS)
PC/104 Bus
(Typically video memory)
Not Used
Lower Memory
(RAM)
Figure 3 – TS-3100 Memory Map (Not to scale)
64k
F0000h 960k
64k
E0000h 896k
D8000h 864k
D0000h 832k
C8000h 800k
C0000h 768k
A0000h 640k
70000h 448k
00000h 00000
32k
32k
32k
32k
128k
192k
448k
Appendix C - Further References
Technologic Systems Web Site
http://www.embeddedx86.com/
Technologic Systems TS-3200 Manual
http://www.embeddedarm.com/documentation/ts-3200-manual.pdf
Intel 386EX User's Guide
http://developer.intel.com/design/intarch/manuals/272485.htm
Maxim Integrated Products
http://www.maxim-ic.com/
Omen Technologies
http://www.omen.com/
PC/104 Consortium Web Site
http://www.pc104.org/
Appendix D - Manual Revisions
11/09/01 New manual
07/24/08 Fixed broken web links
8SGDWHG0DLOLQJ$GGUHVV
8
