MULTIBAND P25
AIRBORNE TRANSCEIVER
REMOTE CONTROL
MODEL RC-7000
Installation and
Operating Instructions
Til Document No.
06RE377
Rev. N/C
June 2006
Technisonic Industries Limited
240 Traders Boulevard, Mississauga, Ontari o L4Z 1W7
Tel:(905)890-2113 Fax:(905)890-5338
www.til.ca
CAUTION
This unit contains static sensitive devices. Wear a grounded wrist strap and/or conductive gloves
when handling printed circuit boards.
WARNING: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept
any interfe rence received, including interference that may cause undesired operation.
Warning:
Changes or modifications not expressly approved by Technisonic Industries could void
the users authority to operate the equipment.
WARRANTY INFORMATION
The Model RC-7000 remote control is under warranty for one year from date of purchase. Failed
units caused by defective parts, or workmanship should be returned to:
Technisonic Industries Limited
240 Traders Boulevard
Mississauga,
Ontario L4Z 1W7
Tel: (905) 890-2113 Fax: (905) 890-5338
A Page
Summary of DO-160C Environmental Qualifications for Technisonic Model RC-7000, Remote Control
Head for the Model TDFM-7000 Transceiver..
Conditions
Section Description of Qualifications
Temperature and Altitude
4.0
Equipment qualified to categories C4
and D1.
Vibration
8.0
Equipment is qualified without shock
mounts to categories B, M and N.
Magnetic Effect
15.0
Equipment is class Z.
Power Input
16.0
Equipment qualified to category B.
Voltage Spike
17.0
Equipment qualified to category B.
RF Emission
21.0
Equipment qualified to category Z.
B Page
TABLE OF CONTENTS
Paragraph Title Page
SECTION 1 GENERAL DESCRIPTION
1.1 Introduction ................................ .................................................... 1-1
1.2 Description .....................................................................................1-1
1.3 Technical Summary.......................................................................... 1-1
SECTION 2 OPERATING INSTRUCTIONS
2.1 General.......................................................................................... 2-1
SECTION 3 INSTALLATION INSTRUCTIONS
3.1 General.......................................................................................... 3-1
3.2 Equipment Packing Log ..................................................................... 3-1
3.3 RC-7000 Installation......................................................................... 3-1
3.4 Installation Kit - Contents................................................................... 3-1
3.5 Pin Locations and Connections............................................................3-2
3.6 Wiring Instructions............................................................................ 3-3
3.7 Post Installation EMI test ...................................................................3-5
LIST OF TABLES
Table No. Title Page
3-1 9-pin D Connections......................................................................... 3-2
LIST OF ILLUSTRATIONS
Figure No. Title Page
3-1 Outline Drawing ............................................................................... 3-1
3-2 Wiring Connections and notes............................................................. 3-4
SECTION 1
GENERAL DESCRIPTION
1.1 INTRODUCTION
This publication provides operating and installation information on the RC -7000 remote
control.
1.2 DESCRIPTION
The RC-7000 is designed to be a remote control head for the TDFM-7000 series of
airborne transceivers. It is a seco ndary (slave) control point and is not intended to replace
the function of the front panel of the radio.
1.3 TECHNICAL CHARACTERISTICS
Specification Characteristic
Model Designation: RC-7000
Physical Dimensions: Approx. 5.75"x 3.75" x 1.3"
Weight: 11oz (311g)
Operating Temperature Range: -45° C to +60°C
Power Requirement:
Voltage: 28.0 Vdc, ± 15%
Current: 75mA minimum
150mA maximum
Communication Protocol: RS-232
119200,N,8,1
Panel Back Lighting: 28 VDC or 5VAC
(software configurable)
1-1
2-1
SECTION 2
OPERATING INSTRUCTIONS
2.1 GENERAL
The RC-7000 is designed to be a secondary control point for the TDFM-7000 airborne
transceiver. These instructions assume a working knowledge of the TDFM-7000.
Operation of the RC-7000 is similar to the TDFM-7000 except for a few differences
covered below.
2.2 FRONT PANEL
Refer to the diagram below:
2.3 POWER
The RC-7000 has an ON and an OFF button. Unlike the TDFM-7000 transceiver, you do
not have to hold the OFF button as it will shut off immediately
2.4 KNOBS
The RC-7000 does not have any rotary knobs since the volume function is not required.
The volume at the remote headset would be adjusted at the remote audio panel.
2.5 MODE KEY
The MODE key has the same effect as pressing the knob on the front of the
TDFM-7000. VOL, CHAN, NUMLOCK and RECALL are the available modes.
2-2
2.6 F1 – F7 KEYS
Function keys F1 through F4 operate the same as on the TDFM -7000 transceiver. F5, F6
and F7 are for future development and have no function at this time.
2.7 FUNC KEY
Pressing the function key will invoke the function menu. Functions include F1 to F4 as
quick channel keys and access to the configuration menu.
2.8 DISPLAY
The RC-7000 has a five line, 120 character LED display which always shows copy of
what is on the display of the radio except when editing the brightness setting.
2.9 GENERAL OPERATION
Switch on the RC-7000 by pressing the ON key. “TECHNISONIC” along with the
firmware version will be displayed and then the self test. If the transceiver is already on,
the normal screen will appear and the unit is ready to use. If the radio is off or is not
connected, the display will show “CONNECTING…..” until the radio is detected. If the
TDFM-7000 and RC -7000 are on the same power switch then the connecting message
will be seen for a few seconds as the radio takes longer to start up. The RC-7000
operates like the radio except for the functions previously mentioned. In the case where
the pilot and the remote operator select a function at the same time, the radio panel has
priority. No special settings have to be changed on the TDFM-7000 in order for the
remote to work nor does the radio care whether the remote is present. The remote does
not have to be switched on for the radio to work.
2.10 CONFIGURATION MENU
The configuration menu can be invoked in one of two ways. Pressing the F4, ESW and
TSW keys while the unit is powered up or selecting config menu from the functions
menu. ‘Configuration menu’ will be displayed at the top of the screen along with ‘Panel
Lighting:’. Pressing the SEL (select) soft key will toggle the condition between 5VAC and
28VDC. Pressing the EXIT soft key or the HOME key will save the selection and reboot
the RC-7000. No damage to the unit will occur if the wrong voltage is selected. Panel
lighting is the only configurable item in the RC-7000.
3-1
SECTION 3
INSTALLATION INSTRUCTIONS
3.1 GENERAL
This section contains information and instructions for the correct installation of the RC7000 remote control.
3.2 EQUIPMENT PACKING LOG
Unpack the equipment and check for any damage that may have occurred during transit.
Save the original shipping container for returns due to damage or warranty claims.
Check that each item on the pa cking slip has been shipped in the container.
3.3 INSTALLATION
The RC-7000 Remote Control is designed to be dzus mounted and should be installed in
conjunction with an IN-RC6 installation kit. See figure 3-1 for an outline drawing of the
unit with dimensions to facilitate the installation.
3.4 INSTALLATION KIT - CONTENTS
The IN-RC6 installation kit (P/N 029355 -1) consists of:
1. One 9 pin Cannon D mating connector (female) complete with crimp pins and
hood.
3-2
FIGURE 3-1 Outline Drawing for Model RC-7000
3-3
3.6 INSTALLATION - PIN LOCATIONS AND CONNECTIONS
J1 - 9 Pin D Connections - Use FEMALE Connector
Pin # Description
1 Ground
2 Debug
3 Reset
4 +28 Volts DC
5 Vcc
6 Backlight
7 RX Data
8 TX Data
9 Auto ON
TABLE 3-1
3.7 INSTALLATION - WIRING INSTRUCTIONS
Figure 3-2 shows all required connections and recommended wire sizes for the RC-7000 Remote
Control.
3.8 GROUND - PIN 1
Pin 1 should be connected to ground. The pin is internally connected to the chassis.
3.9 DEBUG - PIN 2
Do not connect. This pin is used for software updates at the factory.
3.10 RESET - PIN 3
Do not connect. This pin is also used for software updates at the factory.
3.11 +28 VOLTS DC - PIN 4
Connect to the 28 volt DC avionics bus through a 1 amp breaker.
3.12 VCC - PIN 5
Do not connect. This is a 5 volt output to supply the programmer for software updates at the
factory. Output current is rated at 200 mA.
3.13 BACKLIGHT - PIN 6
Connect to the aircraft dimmer bus. Backlighting is 28 volts DC or 5 volts AC.
3-4
3.14 TX AND RX DATA - PINS 7 AND 8
These pins are to be connected to the RS-232 pins on the TDFM -7000. TX data connects to RX
data on the radio and RX data from the remote goes to TX data on the radio.
3.15 AUTO ON - PIN 9
Connect this pin to ground if you wish the unit to turn on with the avionics master. Leave
unconnected otherwise.
FIGURE 3-2 Wiring connections and notes for the RC-7000.
3-5
APPENDIX TO INSTALLATION INSTRUCTIONS
POST INSTALLATION EMI TEST
3.7.1 PURPOSE
The purpose of this test is to identify any interference that the RC-7000 remote control head may cause with
existing aircraft systems.
3.7.2 TEST CONDITIONS
The RC-7000 should be installed and function tested. The TDFM-7000 transceiver should be on throughout this
test.
3.7.3 METHODOLOGY
Most of the EMI tests can be accomplished on the ground.
The GPS should be operational and navigating with at least the minimum compliment of satellites. The VHF comm
should have the squelch open. VOR/DME receivers should be selected for display. If possible, set up a
DME/Transponder ramp test set and adjust the output until the flags are out of view. The transponder and
encoder should be monitored with ramp test equipment. Set the output of the transponder test set to 3db above
the output necessary to achieve 90% reply. If possible set the ADF to a nearby navigation station.
Switch the RC -7000 on and off as often as required.
Observe the GPS for any degrada tion in satellite status or availability or flags. Listen for any noise or detected
audio signals on the VHF comm(s). Listen for any noise or detected audio signals on the VOR/LOC receiver
audio; look for any moment of flags or needles on the VOR/LOC/GS navigation display(s).
List the power plant, fuel and other electric instruments not already in the chart provided and note any anomalies
that occur due to operation of the RC-7000. Assess the results.
If the aircraft is equipped with an autopilot or a stability augmentation system, then test fly the aircraft and verify
that operation of the RC -7000 does not have adverse effects on these systems. After checking for gross effects
at a safe altitude, fly a coupled ILS approach and look for any anomalies.
3-6
3.7.4
RESULTS
If the installed system passes all of the applicable EMI tests, then no further action is required. If interference is
observed then the interference must be assessed against the appropriate standards of airworthiness for the
system in question. A complete discussion of all the standards of airworthiness to be applied in assessing EMI
effects is beyond the scope of this document.
3-7
3.7.5
PROCEDURE
List the power plant, fuel and other electric instruments not already included in the chart below and note
any anomalies that occur due to operation of the RC-7000. Assess the results.
STEP
SYSTEM
PASS
FAIL
NOTES
1
Com 1&2
2
Transponder & Encoder
3
ADF 1 & 2
4
VG
5
Glideslope 1&2
6
VOR/LOC 1&2
7
Compass
8
Directional Gyro
9
Fuel Pressure
10
Oil Temperature
11
Amps
12
Bus Voltage
3-8
STEP
SYSTEM
PASS
FAIL
NOTES
13
Fuel %
14
Ng
15
TOT
16
Torque %
17
Enunciators
18
Digital Clock
19
Oil Pressure
20
DME
21
GPS
22
Autopilot
23
Stability Augmentation Systems
24
Coupled ILS Approach
Note s:
