TechniSat Cablestar 400 Technische details

CABLESTAR 400

Stereo radio for unencrypted digital radio programs via cable

EAN Item no.

4019588039438 0000/3943

BLUETOOTH VERSION & PROFILE

AVRCP (Audio Video Remote Control Profile): Yes

A2DP (Advanced Audio Distribution Profile ): Yes

CONNECTIONS

Audio in/AUX in: Yes

IEC-Connector: Yes

Headphone connection jack (3,5mm): 1

DECODER

Audio decoder: MPEG-1 & MPEG-2 layer I, II

DISPLAY

Type: OLED

ENVIRONMENT

Humidity: 5 - 90 % relative air humidity (non-condensing)

Ambient temperature: 5 - 35 °C

LOUDSPEAKERS

KEYFEATURES

Clock

Output performance: 20 W (RMS)

Stereo: 2 x 10 W

powered by ELAC: Yes

POWER SUPPLY

Nominal voltage: 230 V

Frequency: 50 Hz

Mains adapter: DC 12V / 3000 mA

Type of power supply: External

RADIO / RECEPTION

Aerial: DAB / FM telescopic antenna (replaceable)

TUNER

Tuner type: Digital cable

DVB-C Tuner: 1

Reception on: DVB radio

TUNER - CABLE

Reception range: 50 ... 858 MHz

Symbol rate: 2 ... 7 Mbaud

Demodulation: 64 / 256 QAM

FEC: Reed-Solomon (204, 188)

SCOPE OF DELIVERY

CABLESTAR 400, power supply, user manual
