TechniSat AX1 User Manual

Operating Instructions
ASTRAST AR AX1
TechniSat
TechniSat
TechniSat
TechniSat
TechniSat
2
3
4
5
6
7
8
9
0
1
PROGRAMM
KAUFEN
FREQU
WEITER
ATS
A/B
TEXT
SPEICHERN
KLASSIK
POP
OLDIES
ROCK JAZZ
COUNTRY
SPEZ
REGION
NACHR
ALLGEMEIN
PA
FREI
DMX
FAV
Made in Germany!
2
2
3
4
5
6
7
8
9
0
1
PROGRAMM
LÖSCHEN
KAUFEN
FREQU
WEITER
ATS
A/B
TEXT
SPEICHERN
KLASSIK
POP
OLDIES
ROCK JAZZ
COUNTRY
SPEZ
REGION
NACHR
ALLGEMEIN
PA
FREI
DMX
FAV
On/Standby Sound on/off
DMX special functions
(not used at present)
DMX card message
Save
Automatic
tuning system
Volume up
down
Ten-key keypad
Channel type selection
Channel type mode
Channel selection
Alternate channels Mono A,
Mono B, Stereo
Delete Enter Frequency
free
FAV
DMX
Channel table
3
TechniSat
TechniSat
TechniSat
TechniSat
TechniSat
AUDIO-ANALOG
OPTEL
PC
AUDIO-DIGITAL
OUT OUTIN/OUTIN OUT
L
R
Channel number
display
On/Off switch Channel name,frequency,etc.
(display of channel information)
Integrated Smart Card reader
Channel keys
Satellite television receiver
LNB input
Power inlet
Electrical digital output jack
PC connector
Analogue audio input jacks
Analogue audio output jacks
3-digit LED display
Contents
1 Illustrations
2 Safety precautions
3 Connections
3.1 Outdoor unit
3.2 HiFi amplifier
3.3 Satellite television receiver
3.4 Personal computer
4 Installation
4.1 Calling the installation menu
4.2 LOF adjustment
4.3 Display language
4.4 Deleting all channels
5 Operation
5.1 General
5.2 Switching on and off
5.3 Channel selection
5.4 Kind of programme selection
5.5 Alternate channels
5.6 Sound
5.7 DMX card messages
4
6 Programming
6.1 Copying preprogrammation
6.2 Automatic tuning system (ATS)
6.3 Individual channel table
6.4 Directly entering channel data
6.5 Deleting channels
7 Troubleshooting notes
8 Technical data
Page
2
5
6 6 6 6 7
7 7 8 8 8
9 9 9
9 10 11 11 11
11 11 11 12 12 13
14
15
5
~
MADE IN GERMANY
I G TEST VIDEO
ANT
TV
LNB
DC 13/18V MAX 0,4A
( )
KANAL
230-240V
50 Hz
max. 24 V
A
>80%
<+15°C
+35°C
230V
2 Safety precautions
For your own protection, carefully read the safety precautions before starting to use your new device.
The manufacturer is not liable to damage caused by improper handling or by disregarding the safety precautions.
Take care that empty remote control batteries are not put into the household waste but disposed off properly (return to specialist stores, special waste)
Styrofoam packing harmful to the environment has not been used. The packing which can be recycled corresponds to the requirements of the new packing regulations.
Never open the device. There is danger of an electric shock. Repairs should only be carried out by qualified specialists.
Operational breaks: during a storm or when operation is interrupted for a long time disconnect the device from mains.
In the following cases disconnect the device from mains and ask a specialist for help:
- the power supply cord or the connector are damaged
- the device was exposed to humidity or a liquid has flown into the device
- in case of considerable malfunctions
- in case of considerable external damage.
6
3 Connections
3.1 Outdoor unit
If possible, try to use an outdoor unit with TWIN LNB to be able to receive satellite TV channels and digital radio channels at the same time, independent of each other. If you do not want to receive TV and digital radio channels at the same time, you may continue to use your V/H LNB (s.3.3 Satellite TV receivers).
Connect the LNB input of the ASTRASTAR AX 1 with the LNB of your receiving equipment using an adequate coax cable. If the LNB input is overloaded the message “cable error” appear s in the display after switching on. If there is a short-circuit on the LNB input,the ADR receiver switches off (a “ticking” is heard). In both cases switch off the ASTRASTAR AX 1 using the mains switch and eliminate the error cause. Obser ve also 4 “Installation”.
3.2 HiFi amplifier
Connect the audio analogue outputs of the ADR receiver ASTRASTAR AX 1 with an adequate amplifier input of your HiFi equipment (e.g. CD or AUX). Caution, the phono input is not adequate! Devices with digital inputs (amplifiers, DAT recorders etc.) you can connect to the electrical digital output. Corresponding connection cables you can buy from your TechniSat sales representative.
3.3 Satellite television receiver
If you want to operate your ADR receiver and a satellite television receiver with a V/H LNB connect the coax cable from the LNB input of the satellite television receiver to the TV receiver connection of the ADR receiver.
ADR ST3004 S
HiFi
Outdoor unit:
TWIN-LNB
ADR
2-way distributor
external voltage supply
ST3004 S
HiFi
Outdoor unit:
ISISAT A/B or ISISAT A/B/C for a single cable solution
You can also connect the ASTRASTAR AX 1 to an ISISAT serial distribution. Please take into consideration that in this case not all channels can be received.
ST3004 S
In this case you cannot receive TV channels and digital radio channels at the same time.
As soon as the ADR receiver is disconnected from the network or the ADR receiver is in standby mode the LNB voltage is switched through to the LNB by the satellite television receiver.
Moreover, you can connect the audio outputs of your satellite television receiver to the audio analogue inputs of your ADR receiver. The audio signals of the satellite television receiver are transmitted to the amplifier when the ADR receiver is disconnected from the network or is in standby mode.
3.4 Personal computer
You can connect a personal computer to the female connector PC IN/OUT that can be used to control the ADR receiver. The software and connection cables you can buy from your TechniSat sales representative.
4 Installation
4.1 Calling the installation menu
The installation menu includes the most important basic settings for the set-up of the ADR receiver. It can only be called with the help of a multiple key operation so that none of the settings are modified by mistake.
> switch off the ASTRASTAR AX 1 with > press or on the ADR receiver and > at the same time switch on the receiver again with
The individual settings are marked in the channel number display with the stages
E1 to E7. The function w hich is to be modified is
indicated via the information display.
E1 setting the remote control code E2 selecting the display language E3 adapting the local oscillator frequency E4 selecting the search mode for Astra or other satellites E5 selecting the search range E6 deleting the channel memory
E7 copying the preprogrammation
The individual settings
E1, E4 and E5 only serve for service purposes
or are provided for future applications. A modification becomes effective when switching to the next
stage.
7
ADRST3004 S
HiFi
Outdoor unit:
V/H-LNB
8
4.2 LOF adjustment
To adapt the ADR receiver to older outdoor equipments you can modify the factory-adjusted LOF of 9.75 GHz. Small frequency failures which may occur are compensated by the automatic fine tuning (AFC) of the ASTRASTAR AX 1.
> call the installation menu (see 4.1)
> call setting E3“LOF 9750”with or
> switch to “LOF 10000” or “ISI_AB” or “ISI_ABC” with
or
> press or repeatedly until “Standby”appears in
the display
Analogously, you can remodify the LOF to 9.75 GHz. Please take into consideration that you cannot receive all ADR channels with an ISISAT equipment.
4.3 Display language
You can switch the display language between German, English, Danish and Swedish.
> call the installation menu (see 4.1)
> call setting E2 “German”with or
> switch to the desired language with or
> press or repeatedly until “Standby”appears in
the display
Correspondingly, you can switch the display language again to German. The messages of the smart card are not affected by this modification. They always appear in English.
4.4 Deleting all channels
If you want to completely reprogramme your ASTRASTAR AX 1 you can delete the entire channel memory.Take into consideration that afterwards you have to programme new channels according to 6 “Programming”. To avoid an unintended deletion of all channels a multiple safety interrogation is integrated.
> call the installation menu (see 4.1)
> call setting
E6 “delete?”with or
> switch to “really?”with or
> switch to “with RC!”with or > delete the channel ta ble using the recessed delete key
( ) of the remote control
The function can be interrupted before pressing (delete) with or without deleting the channels.
9
5 Operation
The ADR receiver ASTRASTAR AX 1 is factory-preprogrammed to the at present most current assignation of all digital Astra radio channels. Chapter 6 tells you how to extend or update this preprogrammation.
5.1 General
The digital radio system of the Astra satellite broadcasts radio channels in CD quality. This digital System offers so-called “free” and “DMX” channels. The “free” channels are known public radio transmitters which broadcast their channels in digital sound quality. Additionally, channels from “Digital Music Express” (DMX) are broadcasted in the ADR system in encoded form. To receive these channels you need the decoder integrated in the ASTRASTAR AX 1 and a valid smart card. After you have payed a monthly charge the smart card becomes valid. For fur ther information refer to the DMX information sheet. Apart from music the DMX channels transmit additional information about title, interpreter, composer, album and order number of the running CD.This information can be indicated on a special remote control with display. This kind of remote control you can buy from your TechniSat sales representative.
5.2 Switching on and off
Preferentially, use the mains to switch the ASTRASTAR AX 1 on and off in order to save electricity costs and energy. For short operational breaks you can use the remote control function:
> switch on and to standby with . After the connection to the network the channel position that has
last been active for at least 5 sec.is adjusted.
As soon as the ADR receiver is in standby mode, “standby” is displayed for approx. 5 sec. in nor mal brightness. Dur ing this time the automatic tuning system can be called (see 6 “Programming”).
After the “standby” display is dim the ASTRASTAR AX 1 can be switched with all keys to the last activated channel.
5.3 Channel selection
The ADR receiver ASTRASTAR AX 1 has three channel tables: FREE, DMX and FAV. FREE contains all channels which can be received any time without additional charge. The DMX ta ble lists all “Digital Music Expr ess” channels which are transmitted in encoded form and can only be received with a valid smart card. In the FAV ta ble you can save your own favourite, i.e. preferential free channels and DMX channels. (Please refer to 6 “Programming” for information about the table assignation).
Table Identification Channel
FREE DMX LED off free channels without charge DMX DMX LED on “Digital Music Express” channels
(only receivable with a valid smart card)
DMX DMX LED blinking the smart card message can be
displayed with
FAV e.g. F 2 individual collection of free
channels and DMX channels
> selection of a desired channel tabel with , or To receive DMX channels a valid smart card must be inserted with
the contact side downwards into the card slot below the front lid.
Text
10
Within a channel table the channels can be selected as follows: > with ten-key keypad,e.g.
123 - channel position 123 12 (hold depressed) - channel position 12 6 (hold depressed) - channel position 6 1 (wait 3 s) - channel position 1
> with of the remote control or on
the ADR receiver
Channel numbers of unoccupied channel positions are ignored. To be able to set all channels also without the remote control, the
keys on the device switch from FREE to DMX at the end of the table. On request, you can leave the FAV table by connecting the installation menu from E1 ...E7,“STANDBY”.
If a transmission station transmits two different channels (MONO_A and MONO_B) instead of a stereo channel, the LED does not lighten and the two channels can be received independently of each other.
> with you can switch between the two MONO channels.
5.4 Kind of programme selection
Within the ADR system a fixed kind of programme which allows e.g. only to call successively programmes of the same kind is assigned to a channel.
The following kinds of programmes are differentiated:
Take into consideration that the kind of programme selection only works within the tables FREE and DMX. ASTRASTAR AX 1 automatically switches from the FAV table to the FREE or DMX table during the kind of programme selection.
Within the kind of programme mode one kind of programme is assigned to the numeral keys respectively.
> switch on the kind of programme mode with > select the desired kind of programme using a numeral key > switch to the next programme of the same kind of programme in
this table with , or the respective numeral key.
> you can leave the kind of programme mode by pressing
repeatedly or by calling a FREE,DMX or FAV table.
classics country pop special music oldies regional rock news jazz general
6 Programming
6.1 Copying preprogrammation
Your ADR receiver ASTRASTAR AX 1 contains a factory­preprogrammation of free channels and DMX channels which, on request, you can call if you have deleted your own programmation.
> call the installation menu (see 4.1)
> call setting E7 “copy?”with or
> switch to “really?”with or
> switch to “save!”with or
> delete the channel ta ble using the recessed (save)
key of the remote control
The procedure is indicated in the display with “Tabkopie”.After the copy procedure the FAV table is deleted.
Additional channels you can programme according to 6.4. Your own table must be reprepared according to 6.3.
6.2 Automatic tuning system (ATS)
To be able to save new ADR channels with unknown receive data the ASTRASTAR AX 1 has an automatic tuning system (ATS). This tuning system automatically saves all anti-interference digital radio
11
5.5 Alternate channels
> with In this process, you always switch between the current and the
previously adjusted channel and it is irrelevant whether you have changed the table in the meantime.
5.6 Sound
> with down,with up
> switch off completely with
5.7 DMX card messages
During the reception of DMX channels transmitter messages can be transmitted to your ADR receiver. These messages are displayed in English and can be indicated in the information display with
,as soon as the DMX LED is blinking.
PLEASE INSERT CARD INCORRECT CARD PLEASE WAIT THIS CARD IS BLOCKED WRONG CARD IS INSERTED PUSH BUTTON TO LISTEN YOUR CARD IS INVALID PROGRAMME IS BLOCKED INSERT OLD CARD INSERT NEW CARD THIS CHANNEL IS BLOCKED THE CARD HAS EXPIRED
Text
12
channels of the Astra system to the correct table FREE or DMX.The procedure takes approx. 30 min. Your individually prepared FAV table remains unaffected. The automatic tuning system saves the empty channels continuously according to the ascending Astra transponder number and the DMX channels according to their transmitted channel number. A repeated ATS run does not delete any channel which cannot be received at present, however, it adds new channels to the existing table.
> switch on standby mode with
> start the tuning system with during the first 5 sec.(display
is bright) The procedure is indicated in the display with “A.T.S.” You can only interrupt the automatic tuning system by pressing the
-key on the device.
Afterwards,you can prepare your own table according to 6.3.
6.3 Individual channel table
The ASTRASTAR AX 1 offers the possibility of saving 50 of your favourite channels in an individual table. In this table you can collect free channels as well as DMX channels.
> set the desired channel table with or
> set the favourite channel with the ten-key keypad or
> press the recessed (save) -key P and the bottom free channel position appear in the display. > On request, you can set a different channel position with the
ten-key keypad or
> press again (save) -key or
> interrupt the procedure with or
6.4 Directly entering channel data
In order to avoid having to start the tuning system for the storage of each newly broadcasted channel, you can directly enter the receiving data of this transmitter. The direct entry is also adequate for future digital radio channels of other satellites which are transmitting in the same norm. The receiving data of new transmitters are published in corresponding magazines, e.g. INFOSAT. The ASTRASTAR AX 1 identifies whether the currently received channel is a free channel or a DMX channel and offers the possibility of saving this new channel to channel positions 241 to 255 of the respective table.The table FREE or DMX is automatically selected.
The receiving parameters are indicated in the display.
> press and
13
> set the 1st IF of the channel with , or with the
ten-key keypad
> set the correct polar isation level (
A v = vertical, A h =
horizontal) with
> press and
> set the subcarrier frequency of the channel with ,
or with the ten-key keypad
> press (save)
> and, on request, set a channel position in the range of 241 to
255 using the ten-key keypad or The table is automatically selected.
> save the channel data on this channel position with
(save) or
> leave the setting with or without saving
6.5 Deleting channels
Due to the preprogrammation copy of the automatic tuning system undesired channels may be saved.These channels can be deleted individually.
> set the channel table with , or
> set the undesired channel using the ten-key keypad or
> press the recessed (delete-key) The receiver automatically switches to the next higher channel.
14
7 Troubleshooting notes
Malfunctions
Device cannot be switched on or “cable”/“error”appears in the display
No reception after switching on the receiver, signal LED is on
During operation: reception is interrupted, signal LED is fluttering or remains on.The audio signal is interfered.
Only with individual channels there are frequent disturbances in form of interruptions and whistleing in the audio signal.These disturbances are not put down to effects of the weather
No DMX channels can be received
The satellite television receiver connected to the ADR receiver cannot receive all TV channels
Possible causes
short-circuit in the LNB connection line
no signal available or the signal is too weak
receiving interferences due to effects of the weather: heavy rain or snow,heavy layer of clouds
receiving interferences due to the irradiation of adjacent satellites (e.g.of the satellite position 16° east)
the access to these channels is blocked
when you use a V/H LNB,the polarisation of the satellite antenna is given if the ADR receiver is on.
Elimination measures
switch off the device,disconnect the LNB line,eliminate the short-circuit
check the installation (e.g.selected LOF of the LNB),if necessary,redirect the satellite antenna
use bigger satellite antenna
direct the satellite antenna in an optimal way to ASTRA,then drive the satellite antenna by approx.0.5 to 1° east.This reduces the irradiation considerably.
check whether the smart card is inserted in the card slot (observe the notes for inserting the card).Switch the device off and on again.Consult the sales representative
switch off the ADR receiver or switch it to standby mode.
15
8 Technical data
Features
- integrated DMX decoder
- 255 channel positions for DMX channels
- 255 channel positions for freely receivable ADR channels
- 50 channel positions for individual channel table
- three-digit channel number display
- eight-digit LED point matrix for displays transmitter
identification,kind of channel and different operational states
- further additional displays via 3x LED (DMX,stereo,signal)
- operation of the device with standard or bidirectional remote
control.The bidirectional remote control presents the following
additional data in a 2 x 16-digit LCD display:
- music title
- interpreter
- composer
- album
- order number of the CD
- volume regulation via remote control
- RS 232 interface
Tuner
input frequency range 950 to 2050 MHz input resistance 75 ohms input level range 44 to 79 dB(V input connection F connector LNB voltage 0,+13, +18 V (400 mA) IF bandwidth 27 MHz tuning
1st IF increments 1 MHz with AFC
subcarrier frequency increments 1 kHz
tuning range 0.36 to 8.82 MHz per transponder
transponder usage 6.12 to 8.46 MHz
Audio
electrical audio digital output Cinch 0.5 Vp-p SPDIF format analogue audio output left/right Cinch analogue audio input left/right Cinch (in standby or when
NET OUT active)
audio system ISO/IEC 11172-3 Layer II
MUSICAM
audio mode mono, 2 channel mono,
stereo or joint stereo transmission
audio bit rate 192 kBit/s (gross bit rate 256
kBit/s) modulation QPSK bit error rate <= 1 x 10-5 (C/N = 9.5 dB for 26
MHz) audio frequency range 20 Hz to 20 kHz dynamic range audio 91.5 dB (typically) S/N audio 96 dB (typically) resolution 18 bits sampling frequency 48 kHz THD 0.003 % channel division -100 dB (20 Hz to 10 kHz)
Power supply
network voltage 230 V +/- 10 %,50 Hz power consumption <= 20 W
<= 11 W (without LNB)
<= 9 W (in standby mode)
<= 0.5W (mains off)
General
temperature range +15°C...+35°C atmospheric humidity <= 80 %
Dimensions
Height: 65 mm,width: 370 mm, depth: 270 mm,weight: 1.5 kg
Made in Germany!
Made in Germany!
TechniSat Satellitenfernsehprodukte GmbH
Postfach 560 · 54541 Daun · Germany
Loading...
