MIDOR REFINERY EXPANSION – ALEXANDRIA, EGYPT
William Lopez (Aug 25, 2022 15:16 GMT+2)
William Lopez
R. Sulis (Aug 27, 2022 12:06 GMT+2)
R. Sulis
Salvatore Longo (Aug 27, 2022 12:45 GMT+2)
Salvatore Longo
Juan Lopez (Aug 27, 2022 13:34 GMT+2)
Juan Lopez
Project N° Unit Document Code
2544 58 NM 1571
MIDOR Doc. Code: 2544-58-LS-0059-01
Rev.Serial N° Page
1S 1/501
INSTRUMENT CABLE LIST
UNIT 58
This document and its att achments, if any, contains confidential and proprietary information belonging to MIDOR, and/ or other third parties, including T.EN TECHNIP ENERGIES ITALY S.p.A. . The intended recipient of the informat ion contained herein shall not divulge the same to any third party
or sell, trade, publish, reproduce or reverse engineer the same, in any manner, wit hout MIDOR prior written consent and/or T .EN TECHNIP ENERGIES ITA LY S.p.A. prior written consent, and shall not put in use the inform ation for any pur pose unrelated to that for which it has been transmitted t o
recipient. Any disclosure and use of the contents hereof shall be subject to any s ubsisting agreements between MIDOR, T .EN TECHNIP ENERGIES I TALY S.p.A. and the intended recipient. The c opyright in this document and/or attachments is owned by M IDOR and T.EN TECHNIP ENERGIES
1S 25/8/2022
A 24/11/2020
REV. DATE
ITALY S.p.A., while the underlying IP is owned by other Technology Providers and any reproduction or adaptation thereof shall require MIDOR’s and/or, when needed, T.EN TE CHNIP ENERGIES I TALY S.p.A.'s express written approval.
(BOLD/ITALIC REVISION REFLECT ISSUED TSI)
FINAL REVISION
FINAL ISSUE
STATUS
DOCUMENT REVISIONS
W.LOPEZ
P.SEPULVEDA R.SULIS
WRITTEN BY
(name & visa)
R.SULIS
CHECKED BY
(name & visa)
S.LONGO
J.D LOPEZ
G.FLORIO / J.D.LOPEZ
APPROV./AUTHOR. BY
(name & visa)
T.EN TECHNIP ENERGIES ITALY S.p.A. - 00148 ROMA - Viale Castello della Magliana, 68
Page 2
MIDOR REFINERY EXPANSION – ALEXANDRIA, EGYPT
GENERAL NOTES
1. Cable routing according to cross section defined in IFC documents
2. Cable length contains routing inside the buildings and 5% contigency
3. The default length for conventional single cables from Instrument to Junction Boxes is 40 m
4. The final revision has been identified with bold, italic and grey highlighted letters reflecting the issued TSI.
REFERENCE DOCUMENT / DRAWINGS
2544-00-JSD-1501-01
2544-00-DW-1512-02
2544-00-DW-1512-01
2544-00-DW-1572-02
2544-00-SP-1574-01
2544-58-DW-1572-01
2544-58-DW-1572-02
Job Specification for Design for Instrument Numbering
Control And Safety System Architecture
Wiring Principle Among Field / Control Room And Substation
Instrument Main Cable Routing
Data Sheets for Instrument Cables
Main Cable Routing U58
Cable Routing Cross Section U58
Project N° Unit Document Code Serial N° Rev. Page
2544 58
1S 2/5NM 1571 01
MIDOR Doc. Code: 2544-58-LS-0059-01
CONVENTIONS FOR CABLE DESCRIPTION
SH FRES
OSH FRET
IS PS
NIS FGS
WA COM
NA MOV
FO MMS
X TEL
Individual Shield
Overall Shield
Intrinsically Safe
Non-Intrinsically Safe
Armoured Cable
Non-Armoured Cable
Fiber Optic Cable
Multilayer Cable
MUX
TCK
TCT
MCC
CONVENTIONS FOR CABLE SERVICE
Fire Resistant Cable
Flame Retardant Cable
Power Supply Cable
Fire & Gas Cable
Communication Cable
Motorized Valve Pakscan Loop Cable
Machinery Monitoring System Cable
Telecom Cable
Multiplexer Temperature Cable
Extension Cable for Thermocuple Type K
Extension Cable for Thermocuple Type T
Electrical/Instrumentation Interface Cable
recipient. Any disclosure and use of the contents hereof shall be subject to any subsisting agreem ents between MIDOR, T. EN TECHNIP ENERGIES ITALY S.p.A . and t he intended recipient. The copyright in this document and/or attachments is owned by M IDOR and T.EN TE CHNIP ENERGIES
ITALY S.p.A., while the underlying IP is owned by other Technology Providers and any reproduction or adaptation thereof shall require MIDOR’s and/or, when needed, T.EN TE CHNIP ENERGIES I TALY S.p.A.'s express written approval.
This document and it s attachments, if any, c ontains confidential and proprietary information belonging to MI DOR, and/or other t hird parties, including T.EN TECHNIP ENE RGIES ITALY S.p.A. . The intended recipient of t he information contained herein shall not divulge t he same to any third party or
sell, trade, publish, reproduce or r everse engineer the same, in any manner, without MIDOR prior written consent and/or T. EN TECHNIP ENERGIE S ITA LY S.p.A. prior written consent, and shall not put in use the information for any purpose unrelated to that for which it has been transmitted to
T.EN TECHNIP ENERGIES ITALY S.p.A. - 00148 ROMA - Viale Castello della Magliana, 68
Page 3
CABLE IDENTIFICATION
MIDOR REFINERY EXPANSION – ALEXANDRIA, EGYPT
Project N° Unit Document Code Serial N° Rev. Page
2544 58
NM 1571 01 1S 3/5
MIDOR Doc. Code: 2544-58-LS-0059-01
MIDOR
CODE
COMMODITY CODE
(CABLE TYPE)
SERVICEDESCRIPTION
8 1574IP01A16OWNTNN0 01X02X16AWG+SH - NIS - WA Analog & Digital Signals (not Eex-i) 420
TOTAL
QTY (M)
recipient. Any disclosure and use of the contents hereof shall be subject to any subsisting agreem ents between MIDOR, T. EN TECHNIP ENERGIES ITALY S.p.A . and t he intended recipient. The copyright in this document and/or attachments is owned by M IDOR and T.EN TE CHNIP ENERGIES
ITALY S.p.A., while the underlying IP is owned by other Technology Providers and any reproduction or adaptation thereof shall require MIDOR’s and/or, when needed, T.EN TE CHNIP ENERGIES I TALY S.p.A.'s express written approval.
This document and it s attachments, if any, c ontains confidential and proprietary information belonging to MI DOR, and/or other t hird parties, including T.EN TECHNIP ENE RGIES ITALY S.p.A. . The intended recipient of t he information contained herein shall not divulge t he same to any third party or
sell, trade, publish, reproduce or r everse engineer the same, in any manner, without MIDOR prior written consent and/or T. EN TECHNIP ENERGIE S ITA LY S.p.A. prior written consent, and shall not put in use the information for any purpose unrelated to that for which it has been transmitted to
T.EN TECHNIP ENERGIES ITALY S.p.A. - 00148 ROMA - Viale Castello della Magliana, 68
Page 4
TIE-IN LIST
Project N° Unit Document Code Serial N° Rev. Page
2544 58 NM 1571 01 1S 4/5
MIDOR Doc. Code: 2544-58-LS-0059-01
MIDOR REFINERY EXPANSION – ALEXANDRIA, EGYPT
ITEM TIE-IN NUMBER CABLE TAG
TIE IN
SOW
TIE IN SOW (REMARKS)
1 TP-I-58-002 C-58-FT-1002 NW NEW SINGLE CABLE TO BE CONNECT TO THE EXISTING JB
RLC-58-FT-005TP-I-58-0042
NEW SINGLE CABLE TO BE LAID AND FROM THE NEW LOCATION TO THE EXISTING JB
EXISTING SINGLE CABLE TO BE DISMANTLED.
recipient. Any disclosure and use of the contents hereof shall be subject to any subsisting agreem ents between MIDOR, T. EN TECHNIP ENERGIES ITALY S.p.A . and t he intended recipient. The copyright in this document and/or attachments is owned by M IDOR and T.EN TE CHNIP ENERGIES
ITALY S.p.A., while the underlying IP is owned by other Technology Providers and any reproduction or adaptation thereof shall require MIDOR’s and/or, when needed, T.EN TE CHNIP ENERGIES I TALY S.p.A.'s express written approval.
This document and it s attachments, if any, c ontains confidential and proprietary information belonging to MI DOR, and/or other t hird parties, including T.EN TECHNIP ENE RGIES ITALY S.p.A. . The intended recipient of t he information contained herein shall not divulge t he same to any third party or
sell, trade, publish, reproduce or r everse engineer the same, in any manner, without MIDOR prior written consent and/or T. EN TECHNIP ENERGIE S ITA LY S.p.A. prior written consent, and shall not put in use the information for any purpose unrelated to that for which it has been transmitted to
T.EN TECHNIP ENERGIES ITALY S.p.A. - 00148 ROMA - Viale Castello della Magliana, 68
Page 5
MIDOR REFINERY EXPANSION – ALEXANDRIA, EGYPT
Project N° Unit Document Code Serial N° Rev. Page
5/52544 58 NM 1571 01 1S
MIDOR Doc. Code: 2544-58-LS-0059-01
TOFROM
*DEVICE
REV
UNIT
TIE‐IN
PULLAREA
1S 58 I3 58‐004 C‐58‐FT‐005 01X02X16AWG+SH‐NIS‐WA 40 58‐FT‐005 ‐‐ 58‐JE‐01(E) FR‐32(E) 157401IP01A16OWNTNN‐400 1/2"NPT M20S
1S 58 I3 58‐002 C‐58‐FT‐1002 01X02X16AWG+SH‐NIS‐WA 40 58‐FT‐1002 ‐‐ 58‐JE‐01(E) FR‐32(E) 157401IP01A16OWNTNN‐400 1/2"NPT M20S
1S 58 I3 ‐‐ C‐58‐XS‐1070 01X02X16AWG+SH‐NIS‐WA 220 58‐XS‐1070 58‐EHT‐01 46‐JB‐201 FR‐501 01DP01A16OWNTNN0‐901 1/2"NPT M20S
CABLETAG CABLEDESCRIPTION
(TP‐I‐XX‐YYY)
(m)
CABLELENGTH
*JUNCTION
BOX
*JBPACKAGE
*JBFRAME
*PACKAGE
*DEVICE
*JUNCTION
BOX
*JBORLCP
PACKAGE
*JBFRAME
*PACKAGE
CABLEDRUMTAG
CABLEGLAND
FROM
TO
ROUTING
