Techni-Lux DL-ULTRALUX18VW User Manual

User Manual

DL-ULTRALUX18VW

Introduction

Unpacking: Thank you for purchasing DL-ULTRALUX18VW. Every unit has been thoroughly tested and

shipped in perfect condition. Carefully check the shipping carton for damage that may have occurred

during shipping. If the carton appears to be damaged, carefully inspect your unit for any damage and be

sure all accessories necessary to operate the unit has arrived intact. In the case damage has been found

or parts are missing, please contact the manufacturer or your dealer for further instructions. Do not return

this unit to your dealer without any previous attaining a return authorization.

Warning:

To prevent or reduce the risk of electrical shock or fire, Do not expose this to rain or moisture.

Caution:

There are no user serviceable parts inside this unit. Do not attempt any repairs yourself; doing so will void

your manufacturer warranty. In the unlikely event your unit may require service please contact the

manufacturer or your dealer.

Please recycle the shipping carton whenever possible.

General Instructions

To optimize the performance of this product, please read these operating instructions carefully to familiarize

you with the basic operations of this unit. These instructions contain important safety information regarding

the use and maintenance of this unit. Please keep this manual with the unit, for future reference.

Features

●Multi-Colors

●Color Strobe ● LED operation menu with function buttons

●Electronic Dimming 0-100% ●

●DMX-512 protocol ● Daisy Chain Units Together in DMX Mode

Safety Precautions

● To reduce the risk of electrical shock or fire, do not expose this unit to moisture.

● Do not spill water or other liquids into or on to your unit.

● Be sure that the local power outlet match that of the required voltage for your unit,

● Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt to

remove or break off the ground prong from the electrical cord. This prong is used to reduce the risk of

electrical shock and fire in case of an internal short.

● Disconnect from main power before making any type of connection.

● Do not remove the cover under any conditions. There are user serviceable parts inside.

● Never operate this unit when its rear cover is removed.

● Never plug this unit into a dimmer pack.

● Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6” (15cm)

between this device and a wall.

● Master/Slave synchronization

Sound active mode

1

● Do not attempt to operate this unit, if it becomes damaged.

● This unit is intended for indoor use only; use of this product outdoors voids all warranties.

● During long periods of non-use, disconnect the units main power.

● Always mount this unit un safe and stable matter.

● Power-supply cords should be routed so that they are not likely to be walked on or pinched by items

placed upon or against them, paying particular attention to the point they exit from the unit.

● Cleaning unit should be cleaned only as recommended by the manufacturer. See ‘Cleaning” for details.

● Heat –The appliance should be situated away from heat sources such as radiators, heat registers,

stoves, or other appliances (including amplifiers) that produce heat.

● The unit should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged.

B. Objects have fallen, or liquid has been spilled into the appliance.

C. The appliance has been exposed to rain or water.

D. The appliance does not appear to operate normally or exhibits s marked change in performance.

Set UP

Power Supply: Before plugging your unit in, be sure the source voltage in your area matches the voltage

required for your every suit. Every unit is available in 100v and 240v version. Because line voltage may

vary from venue to venue, you should be sure your unit voltage matches the wall outlet voltage before

attempting to operate you unit.

DMX Linking: To ensure proper DMX data transmission, when using several DMX units try to use the

shortest cable path possible. The order in which units are connected in a DMX line does not influence the

DMX addressing. For example; a unit assigned a DMX address of 1 may be placed anywhere in a DMX

line, at the beginning, at the end, or anywhere in the middle. When a unit is assigned a DMX address of 1,

the DMX controller knows to send DATA assigned to address 1 to that unit, no matter where it is located

in the DMX chain.

Operating Instructions

Operating Modes: You can use the series in 4 ways:

● Auto Mode-The series will automatically chase through the different colors.

● Sound-Active mode–The unit will react to sound, chasing through the built-in programs.

● DMX control mode – This function will allow you to control each individual units traits with a standard

DMX 512 controller.

● Master-slave mode – One unit will work as the master in the one of the above three modes, other units

in the chain will work in synchronization towards the master.

DMX Mode: Operating through a DMX controller give the user the freedom to create their own Programs

tailored to their own individual needs. This function also allows you to use your units as spot lights.

1. This function will allow you to control each individual unit’s traits with a standard DMX 512 controller.

2. The LED suit uses 1/2/3/4/5DMX channels to operate. Please see “DMX Values and Functions” for the

DMX traits.

3. To run your unit in DMX mode, plug in the unit via the XLR connections to any standard DMX controller.

Set your desired DMX address following the setup specifications that come with your DMX controller.

Touch Buttons

There are four touch buttons under the LED display: Menu, Up,

Down, Enter. Normally, the LED will display the current DMX

2
