Instructions for Use and Installation
Freestanding Electric Cookers:
- TEE54SS
For your safety
Safety of children and the infirm . . . . . . . . . . . . . . . . . . . . . . . . 3
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
During use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service and spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Use and Care
Description of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Oven & Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
How to use your hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
How to use your oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Positioning the oven trays & shelves . . . . . . . . . . . . . . . . . . . . 15
Cooking modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Practical cooking advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cooktop cleaning & maintenance . . . . . . . . . . . . . . . . . . . . . . 22
Oven cleaning & maintenance. . . . . . . . . . . . . . . . . . . . . . . . . 23
Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Installation
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Instructions for Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Combustible surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Anti-tilting plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Replacing the power supply lead. . . . . . . . . . . . . . . . . . . . . . . 31
Before leaving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Contents
2
For Your Safety
We recommend that you read the instructions in this owner's
manual carefully before use for the best performance and to
extend the life of your appliance. It will provide you with all the
information you need to ensure its safe installation, use and
maintenance. Retain this owner's manual for future reference.
To maintain the efficiency and safety of this appliance, we
recommend that you do the following:
· Always call the Technika service department if there are any
faults with your appliance.
· Always use original spare parts available from Technika.
· This appliance is designed for non-commercial, household use
and it must not be altered in any way.
· This appliance can only be used safely when it is correctly
connected to an efficient earthing system in compliance
with current electrical safety standards.
· If the supply cord or plug is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Packaging items such as plastic bags, polystyrene, nails, etc. are
potentially dangerous, and therefore appropriate measures must
be taken to prevent children and the disabled from coming into
contact with them.
Safety of children and the infirm
This appliance must only be used by adults. Make sure that
children do not touch the controls or play with the appliance.
The exposed parts of this appliance heat up during cooking and
remain hot for some time even after it is switched off. Keep children
well away until the appliance has cooled down.
Cleaning and maintenance
Keep the appliance thoroughly cleaned. Food residues may cause
fire risks.
3
During use
· The appliance becomes hot. Take care not to touch the
surface of the hob. Care should be taken to avoid touching
heating elements inside the oven. To avoid burns and
scalds, children should be kept away.
· WARNING: Accessible parts will become hot when in use.
To avoid burns and scalds, children should be kept away.
· This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
· Young children should be supervised to ensure that they do
not play with the appliance.
· DO NOT use a steam cleaner to clean the appliance.
·
homes and for non-commercial purposes. It should not be
used for any other purpose.
· After using the appliance, make sure that all controls are in
'CLOSED' or 'OFF' position.
· DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE
APPLIANCE STORAGE DRAWER OR NEAR THIS
APPLIANCE.
· DO NOT STORE OR USE FLAMMABLE LIQUIDS OR ITEMS
IN THE VICINITY OF THIS APPLIANCE.
· Only use the appliance to cook food and nothing else.
· Disconnect the appliance from the electrical mains if it is
not functioning properly and before cleaning or performing
maintenance.
· The use of suitable heat proof gloves should be worn when
handling hot utensils and pans.
· Use oven gloves to place cookware in the oven or when
removing it. Always grip the oven door handle in the centre.
This product is designed to cook foods inside private
For Your Safety
4
During use (con’t)
· Do not allow pots to boil dry, as damage to the hotplate may
result.
· Do not operate hotplates without a pot, fry pan etc.
· Do not allow cookware to overhang hob onto adjacent
bench tops, this will cause scorching to the bench top
surface.
· Do not let cooking pots overhang the sides or front of hob
or get too close to the hotplate control knobs.
· Do not use pots and pans which are unsteady, as they
could become unbalanced.
· Do not use mats, heat diffusers or wok stands. These will
cause a temperature build-up which can damage the cook
top.
· Warning: Ensure that no downward pressure is applied to
the oven door when open; in particular, do not allow a child
to climb on to open oven door. Do not push down or apply
any weight on open oven door.
· If the gas oven does not light within 5-8 seconds, allow 1
minute for gas to disperse clear before trying again.
· The appliance is not intended to be operated by means of
external timer or separated remote-control system.
· Danger of fire: Do not store items on the cooking surfaces.
· Caution: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
· Warning: Unattended cooking on a hob with fat or oil can
be dangerous and may result in a fire.
· The appliance must not be installed behind a decorative
door in order to avoid overheating.
· The cooker must not be placed on a base.
For Your Safety
5
For Your Safety
Installation
· Installation of the appliance and its connection to the
electrical mains must only be carried out by Authorised
Personnel. Before any service procedure, it is important to
check that the appliance is DISCONNECTED from the
electrical mains.
· DO NOT MODIFY THIS APPLIANCE.
· After removing the appliance from the packaging, make
sure that it is undamaged and that the electrical lead is in
perfect condition. Otherwise, contact your dealer before
operating the appliance.
· Make sure that air is able to circulate freely around the
appliance.
· WARNING: In order to prevent accidental tipping of the
appliance, for example a child climbing onto the open oven
door, the stabilising means must be installed. Refer to the
instructions for installation.
· Technika will not accept any liability as a result of any
damage due to incorrect installation or improper use.
6
For Your Safety
7
Avoid the following:
· Touching the appliance with wet parts of the body.
· Using the appliance while barefoot.
· Improper or dangerous operation.
· Obstructing the ventilation or heat dissipation slots.
· Allowing power supply cables of other appliances to come into
contact with hot parts of the oven.
· Exposing the appliance to atmospheric agents such as rain, or
direct sunlight.
· Using the oven for storage purposes.
· Using flammable liquids near the appliance.
Authorised personnel must be contracted to...
· Install the appliance according to these installation instructions
and any local requirements.
· Replace the temperature probe if it is damaged. The probe is
part of thermostat. Only use the temperature sensing probe
recommended for this oven.
Technika Service Department must be contacted...
· If in doubt about the operation of the appliance.
· If in doubt about the soundness of the appliance after removing
it from its packaging.
· If the power supply cable has been damaged or needs to be
replaced.
· If the appliance requires a service or you need spare parts.
For Your Safety
8
Service and spare parts
If the appliance fails to operate correctly, never attempt to repair
the appliance yourself. Repairs by unskilled persons may cause
damage and accidents. First refer to the contents of this manual. If
you do not find the necessary information, contact your nearest
Service Center. Servicing work on this appliance must be carried
out by Authorised Personnel. Always request the use of original
spare parts.
For Service & Spare Parts please contact: 1800 333 244
Use and Care
Description of the appliance
1. Maintop
2. Electric Heating Plates (Ø180)
3. Electric Heating Plates (Ø145)
4. Control knob (cooktop burners)
5. Cooking mode selection knob
6. Cooking temperature selection knob
9
1
2
5
6
3
2
3
2
Note: Photo may not be identical to the appliance you purchased.
Use and Care
10
Oven & accessories
The oven has enamel pressed oven side panels and a range of
shelf options as shown below. There are five shelf positions on the
oven.
Grill Tray with
removable insert
Oven Shelf
Shelf
Supports
