Technika STBHDV2010 User Manual
STBHDV2010
Digital TV Receiver
For assistance, please call our Tesco Electrical Helpline on 0845 4566767
USER MANUAL
Contents
Accessories ............................................................2
Introduction .............................................................2
Safety Precautions .................................................2
Overview of the Remote Control ............................4
Viewing Controls and Connections of the Set-Top-
Box .........................................................................5
Front Panel .........................................................5
Rear Panel ..........................................................5
Inserting Batteries in the Remote Control...............6
Connecting the Set-Top Box to a TV Set ................6
Antenna Connection ...............................................7
Power On-Off ..........................................................7
First Time Installation..............................................8
Changing Channels ................................................8
Adjusting the Volume ..............................................8
Mute ....................................................................8
On-Screen Information ...........................................9
Menu System..........................................................9
Viewing the Main Menu ......................................9
Information Banner .............................................9
Selecting a Speci c Channel ..............................9
Operating the Channel List ...............................10
Moving a Channel .............................................10
Deleting Channels ...........................................10
Renaming Channels ........................................10
Adding Locks to Channels ...............................10
Setting Favourites ............................................10
Event Options ....................................................11
Select Channel & Exit ....................................11
Con guration .....................................................11
Active channels .............................................12
Scan Encrypted ............................................12
Output Settings .............................................12
TV Type ..................................................12
TV Out ....................................................12
AC3 Audio ..............................................12
SPDIF Delay ...........................................12
Digital Audio ...........................................12
HDMI Resolution ....................................12
HDMI HDCP ...........................................12
Receiver Upgrade .........................................13
Parental Settings ..........................................13
Menu Lock ..............................................13
Guidance ................................................13
Set Pin ....................................................13
Low Power ....................................................13
Audio Description ..........................................13
Low Power ..............................................13
Audio Description ...................................13
Available Langs. .....................................13
Preferred Language (Optional) ...............14
Relative Volume (Optional) .....................14
Auto Sleep ....................................................14
Conguring Language Preferences ..................14
Preferred .......................................................14
Current (*) .....................................................14
English - 1 -
IP Settings ........................................................14
Installation.........................................................14
Automatic Channel Scan ..............................14
Manual Channel Scan ..................................15
First Time Installation ....................................15
OSD Warning Messages ........................................15
No Signal ..........................................................15
No Channels Have Been Added Yet .................15
Displaying Text .....................................................15
General Characteristics ........................................17
Hardware Con guration........................................17
Digital Capabilities ...............................................17
Remote Control ....................................................17
Tuners ..................................................................17
Front Panel ...........................................................17
Audio ....................................................................18
Digital Audio..........................................................18
A / V & Data In / Out .............................................18
Tv Scart ..............................................................18
Features
• DVB and VBI teletext.
• 200 channel.s
• DVB 7 days event information (7-days EPG).
• TV scart (with RGB and CVBS support).
• HDMI output.
• Automatic tuning.
• Favourite list.
• Parental lock options.
• DVB-T2 compliant.
• Manual and automatic search options.
• On-Screen-Display.
• Automatic day light saving time updating.
• Decoding & Video Out: PAL.
• Multi-format audio decoder.
• Multi language audio support (up to 10).
• Audio mute and volume control.
Accessories
Please make sure that the following items are included
with your device.
Batteries
Remote Controller
Instruction Book HDMI lead
RF lead SCART lead
2 X AAA
Introduction
• Thank you for choosing this product. This manual
will guide you for the proper operation of your settop-box.
• Before operating the set-top-box, please read this
manual thoroughly. Please do keep this manual
in a safe place for future references. Read the
corresponding instructions of this handbook prior to
the rst usage of the device, even when the usage
of electronic devices is familiar to you.
• Notice especially the chapter SAFETY PRECAUTIONS
and INFORMATION. Carefully keep the handbook as
future reference. When selling the device or giving it
away, absolutely give these direction for use.
Safety Precautions
POWER: The receiver should be plugged into a 220-
240 V AC 50Hz supply only.
LEADS: Ensure the power supply lead, and all other
leads, are positioned so they are not likely to be
walked on or pinched by things placed on or against
them. Pay particular attention to the power lead, where
it enters the mains plug and where it comes out of the
receiver. Do not connect or adjust leads when the
receiver is plugged in.
TEMPERATURE AND MOISTURE: Do not leave or
use the receiver in a hot, cold or humid area. Do not
allow the receiver to get wet - from drips or splashes
- as this may be dangerous. Do not place water- lled
objects such as ower vases, on top of the receiver.
VENTILATION: Slots and openings in the receiver’s
cover are for ventilation. Do not cover or block them
as this could lead to overheating.
CLEANING: Unplug the receiver before it is cleaned.
Use a lightly dampened cloth only. Do not use liquid
or aerosol cleaners.
HEAT AND FLAMES: The receiver should not be
placed near to naked ames or sources of intense
heat, such as an electric re. Ensure that no naked
ames sources, such as lighted candles, are placed
on top of the Receiver.
LIGHTNING: Before a storm and lightning or when
going on holiday, disconnect the AC adapter and aerial
lead from the wall sockets..
REPLACEMENT PARTS: If your receiver needs a
replacement part, ensure the person undertaking
the repair uses parts which are speci ed by the
manufacturer or have the same speci cations as the
original part. Other parts may cause a re, electric
shock or other hazards.
BATTERY DISPOSAL: Batteries, including those
which are heavy metalfree, should not be disposed
of with household waste. Please dispose of used
batteries in an environment friendly manner. Find
out about the legal regulations which apply in your
area.
English - 2 -
Important Safety information
Mains supply
Mains lead
Symbols
Safe use and care of your equipment
Read
Protect the mains lead.
Avoid harsh conditions
Never
To save power,
Don't
Pull
This product is designed for domestic use only. Commercial or any other use may invalidate the
guarantee and might be dangerous.
Ventilation
Cleaning
Important Safety warnings
To prevent electric shock, do not remove any cover.
If anything goes wrong, don't try and fix it yourself, get a qualified service agent to look at the product.
Do not expose this equipment to dripping or splashing or place any objects filled with liquids, such as vases,
on the equipment.
Never put a naked flame source such as lighted candles on or near this equipment.
Small parts. Do not let young children play with the equipment.
English - 3 -
Overview of the Remote Control
English - 4 -
Viewing Controls and Connections of the Set-Top-Box
Front Panel
Rear Panel
1. ANTENNA IN : You can connect antenna to aerial input of the box.
2. TV OUT : You can use aerial TV out to connect aerial to your TV.
3. ETHERNET: Use this to connect the box to an active LAN connection.
4. HDMI OUTPUT : You connect the box to your TV’s HDMI input (if
available) by using HDMI connection cable.
5. TV SCART : If your TV has a scart connector, you can connect the
box to your TV using a scart cable.
6. OPTICAL AUDIO : You can use this connector to output the digital
audio to an external device. See your audio system instruction book
for further information.
7. POWER SUPPLY : DC IN (12V) power connection.
Make sure that you connect all cables and connections before you plug the unit into the mains supply. After you
connect the unit to the mains supply, the LED light located on the front panel will be red (Standby mode).
English - 5 -
