Technika 19-811 User Manual
OPERATING INSTRUCTIONS
19-811
COLOUR TELEVISION WITH REMOTE CONTROL
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
Contents
Features ................................................................. 2
Introduction ............................................................. 2
Preparation ............................................................. 2
Safety Precautions ................................................. 3
Package Contents .................................................. 4
Environmental Information ..................................... 5
Repair Information .............................................. 5
Remote Control Buttons ......................................... 6
LED TV and Operating Buttons .............................. 7
Viewing the Back side Connections ....................... 7
Viewing the Connections - Side Connectors .......... 8
Power Connection .................................................. 8
Aerial Connection ............................................... 8
Using Digital Multimedia Connectors...................... 9
USB Memory Connection ................................... 9
Connecting the LED TV to a PC ............................. 9
Using Side AV Connectors ..................................... 9
Connecting to a DVD Player via HDMI ................. 10
Connecting to a DVD Player................................. 10
Remote Control Handset ...................................... 10
Inserting Batteries ............................................. 10
Switching On/Off ....................................................11
To Switch the TV On ..........................................11
To Switch the TV Off ..........................................11
Input Selection .......................................................11
Basic Operations ...................................................11
Operation with the Buttons on the TV ................11
Volume Setting ...............................................11
Programme Selection ....................................11
Viewing Main Menu ........................................11
AV Mode ........................................................11
Operation with the Remote Control ...................11
Volume Setting ...............................................11
Programme Selection (Previous or Next
Programme) ...................................................11
Programme Selection (Direct Access) ...........11
Viewing Electronic Programme Guide (EPG) ....... 12
First Time Installation............................................ 13
Installation ............................................................ 14
Automatic Channel Scan (Retune) Menu
Operation .......................................................... 14
Manual Tuning ..................................................... 14
Digital Manual Search....................................... 14
Analogue Manual Search ................................. 14
Analogue Fine Tune.......................................... 14
Clear Service List (*) ......................................... 14
Managing Stations: Channel List .......................... 15
Operating the Channel List ............................... 15
Moving a Channel ............................................. 15
Deleting a Channel ........................................... 15
Renaming a Channel ........................................ 15
Locking a Channel ............................................ 15
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
English - 1 -
Managing Stations: Favourites ............................. 15
Button Functions ............................................... 16
Managing Stations: Sorting Channel List ............. 16
On-Screen Information ......................................... 16
Media Playback Using Media Browser ................. 16
Viewing Photos via USB ................................... 17
Media Browser Settings .................................... 18
Changing Image Size: Picture Formats ................ 18
Confi guring Picture Settings ................................. 19
Operating Picture Settings Menu Items ............ 19
Picture Settings Menu Items ............................. 19
PC Picture Settings........................................... 20
Confi guring Sound Settings .................................. 21
Operating Sound Settings Menu Items ............. 21
Sound Settings Menu Items.............................. 21
Confi guring Your TV’s Settings ............................. 21
Operating Settings Menu Items ........................ 21
Settings Menu Items ......................................... 21
Using a Conditional Access Module ..................... 22
Viewing Conditional Access Menu (*) ............... 22
Confi guring Language Preferences ...................... 22
Language Settings ............................................ 23
Parental Control.................................................... 23
Parental Settings Menu Operation ................... 23
Timers ................................................................... 24
Setting Sleep Timer .......................................... 24
Setting Programme Timers ............................... 24
Adding a Timer .............................................. 24
Editing a Timer .............................................. 24
Deleting a Timer ............................................ 24
Confi guring Date/Time Settings ............................ 24
Confi guring Source Settings ................................. 25
Confi guring Other Settings ................................... 25
Operation .......................................................... 25
Other Features ..................................................... 26
Teletext ................................................................. 26
Tips ....................................................................... 26
Appendix A: PC Input Typical Display Modes ....... 27
Appendix B: AV and HDMI Signal Compatibility
(Input Signal Types) .............................................. 27
Appendix C: Supported DVI Resolutions.............. 28
Appendix D: Software Upgrade ............................ 28
Appendix E : Supported File Formats for USB
Mode..................................................................... 29
Specifi cations ....................................................... 30
Important Instruction ............................................. 31
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 101_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 1 03.11.2011 17:17:5803.11.2011 17:17:58
Features
Remote controlled colour LED TV.•
Fully integrated Terrestrial digital TV (DVB-T - MPEG2 ) •
HDMI connectors for digital video and audio. This •
connection is also designed to accept high defi nition
signals.
USB input.•
1000 programmes (analogue+digital).•
OSD menu system.•
Integrated tuner MPEG2 compatible.•
Scart socket for external devices (such as video, •
video games, audio set, etc.).
Stereo sound system. (German+Nicam)•
Teletext, fastext, TOP text.•
Headphone connection.•
Automatic programming system.•
Forward or backward manual tuning.•
Sleep timer / Child lock.•
Automatic sound mute when no transmission.•
NTSC playback. •
AVL (Automatic Volume Limiting).•
Auto power down.•
PLL (Frequency Search).•
PC input. •
Plug&Play for Windows 98, ME, 2000, XP, Vista, •
Windos 7.
Game Mode •
Introduction
Please read the corresponding instructions of this
handbook prior to the fi rst usage of the device, even
when the usage of electronic devices is familiar
to you. Notice especially the chapter SAFETY
PRECAUTIONS. Carefully keep the handbook as
future reference. When selling the device or giving it
away, absolutely give these direction for use.
Thank you for choosing this product. This manual will
guide you for the proper operation of your TV.
Before operating the TV, please read this
manual thoroughly. Please do keep this
manual in a safe place for future references.
This device is intended to receive and display TV
programs. The different connection options make
an additional expansion of the reception and display
sources possible (receiver, DVD player, DVD
recorder,
VCR, PC etc.). This device is only suitable for the
operation in dry interiors. This appliance is intended
solely for private domestic use and may not be used
for industrial and commercial purposes. We exclude
liability in principle, if the device is not used as
intended, or unauthorized modifi cations have been
made. To operate your LED TV in extreme ambient
conditions may cause the damage of the device.
Preparation
For ventilation, leave a free space of at least 10 cm
all around the set. To prevent any fault and unsafe
situations, please do not place any objects on top of
the set. Use this device in moderate climates.
10 cm
10 cm
10 cm
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 201_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 2 03.11.2011 17:17:5903.11.2011 17:17:59
English - 2 -
Safety Precautions
Read the following recommended safety
precautions carefully for your safety.
Power Source
The TV set should be operated only from a 220-240
V AC, 50 Hz outlet. Ensure that you select the correct
voltage setting for your convenience.
Power Cord
Do not place the set, a piece of furniture, etc. on the
power cord (mains lead) or pinch the cord. Handle the
power cord by the plug. Do not unplug the appliance
by pulling from the power cord and never touch the
power cord with wet hands as this could cause a short
circuit or electric shock. Never make a knot in the cord
or tie it with other cords. The power cords should be
placed in such a way that they are not likely to be
stepped on. A damaged power cord can cause fi re or
give you an electric shock. When it is damaged and
needs to be replaced, it should be done by qualifi ed
personnel.
Moisture and Water
Do not use this device in a humid and
damp place (avoid the bathroom, the
sink in the kitchen, and near the washing
machine). Do not expose this device to
rain or water, as this may be dangerous
and do not place objects filled with
liquids, such as fl ower vases, on top.
Avoid from dripping or splashing.
If any solid object or liquid falls into the cabinet, unplug
the TV and have it checked by qualifi ed personnel
before operating it any further.
Cleaning
Before cleaning, unplug the TV set
from the wall outlet. Do not use liquid
or aerosol cleaners. Use soft and dry
cloth.
Ventilation
The slots and openings on the TV set are intended for
ventilation and to ensure reliable operation. To prevent
overheating, these openings must not be blocked or
covered in anyway.
Heat and Flames
The set should not be placed near to
open fl ames and sources of intense heat
such as an electric heater. Ensure that
no open fl ame sources, such as lighted
candles, are placed on top of the TV. Batteries should
not be exposed to excessive heat such as sunshine,
fi re or the like.
Lightning
In case of storm and lightning or when
going on holiday, disconnect the power
cord from the wall outlet.
Replacement Parts
When replacement parts are required, make sure that
the service technician has used replacement parts,
which are specifi ed by the manufacturer or have the
same specifi cations as the original one. Unauthorized
substitutions may result in fi re, electrical shock or
other hazards.
Servicing
Please refer all servicing to qualifi ed
personnel. Do not remove the cover
yourself as this may result in an electric
shock.
Waste Disposal
Instructions for waste disposal:•
Packaging and packaging aids are recyclable and
should principally be recycled. Packaging materials,
such as foil bag, must be kept away from children.
Batteries, including those which are heavy metal-free,
should not be disposed of with household waste.
Please dispose of used battery in an environment
friendly manner. Find out about the legal regulations
which apply in your area.
Don’t try to recharge batteries. Danger of explosion. •
Replace batteries only with the same or equivalent
type.
This symbol on the product or on its packaging means
that your electrical and electronic device
should be disposed at the end of its
service life separately from your
household wastes. There are separate
collection systems for recycling in EU.
For more information, please contact the
local authority or the dealer where you
purchased the product.
Disconnecting the Device
The mains plug is used to disconnect TV set from
the mains and therefore it must remain readily
operable.
Headphone Volume
Excessive sound pressure from earphones
and headphones can cause hearing loss.
Installation
To prevent injury, this device must be securely
attached to the wall in accordance with the installation
instructions when mounted to the wall (if the option
is available).
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 301_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 3 03.11.2011 17:17:5903.11.2011 17:17:59
English - 3 -
LCD Screen
SCREEN
LANG
MENU
RETURN
OK
SOURCE FAV
PRESETS
SLEEP
?
INFO
EPG
V+
V-P-P-
P+
1
2
3
4
6
5
9
7 8
0
PIP
SUBTITLE
The LCD panel is a very high technology product with
about a million thin fi lm transistors, giving you fi ne
picture details. Occasionally, a few non-active pixels
may appear on the screen as a fi xed blue, green or
red point. Please note that this does not affect the
performance of your product.
Warning! Do not leave your TV in standby or operating
mode when you leave your house.
The Standby Off/On button doesn´t separate this
device completely from mains. Moreover the device
consumes power in the standby operation. In order to
separate the device completely from mains, the mains
plug has to be pulled from the mains socket. Because
of that the device should be set up in a way, that an
unobstructed access to mains socket is guaranteed,
so that in case of emergency the mains plug can be
pulled immediately. To exclude the danger of fi re, the
power cord should principally be separated from the
mains socket prior to a longer period of non-usage,
i.e. during vacations.
Electrical device not in the hands of children
Never let children use electrical device unsupervised.
Children can´t always recognize properly the
possible dangers. Batteries / accumulators can be
life threatening when swallowed. Store batteries
unreachable for small children. In case of swallowing
a battery medical aid has to be sought immediately.
Also keep the packaging foils away from children.
There is danger of suffocation.
Connection to a Television Distribution
System (Cable TV etc.) from Tuner
Device connected to the protective earthing of the
building installation through the mains connection or
through other apparatus with a connection to protective
earthing-and to a television distribution system using
coaxial cable, may in some circumstances create a
fi re hazard.
Connection to a cable distribution system has
therefore to be provided through a device providing
electrical isolation below a certain frequency range
(galvanic isolator, see EN 60728-11).
Note: The HDMI connection between PC and TV
may cause radio interference in which case it is
recommended to use VGA(DSUB-15) connection.
Package Contents
SUBTITLE
PIP
LANG
SCREEN
RETURN
MENU
OK
SOURCE
PRESETS
SLEEP
V+
P+
INFO
EPG
Remote Control
LED TV
Batteries: 2 X AAA
Instruction Book
Licence Notifi cation (optional)
Manufactured under license from Dolby
Laboratories.
TRADEMARK ACKNOWLEDGMENT
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.
1 X Video & Audio Connection Cable
Note: You should check the accessories after
purchasing. Make sure that each accessory is
included.
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 401_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 4 03.11.2011 17:18:0003.11.2011 17:18:00
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
English - 4 -
Environmental Information
This television is designed to consume less energy to save environment. •
You not only help to save the environment but also you can save money by reducing electricity bills thanks to the
energy effi ciency feauture of this TV. To reduce energy consumption, you should take the following steps:
You can use Power Save Mode setting, located in the Feature menu. If you set Power Save Mode as On, •
the TV will switch to energy-saving mode and luminance level of TV set will be decreased to optimum level.
Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.
When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce •
energy consumption.
Disconnect power when going away for longer time.•
Note that annually, using the TV set in Power Save Mode has more power effi ciency than disconnecting •
the TV from the mains plug instead of keeping stand-by mode. Therefore disconnect the TV from the mains
plug to save energy when you do not use. However it is highly recommended to activate Power Save Mode
setting to reduce your annual power consumption.
Please helps us to save environment by following these steps.•
Repair Information
Please refer all servicing to qualifi ed personnel. Only qualifi ed personnel must repair the TV. Please contact
your local dealer, where you have purchased this TV for further information.
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 501_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 5 03.11.2011 17:18:0103.11.2011 17:18:01
English - 5 -
V
SCREEN
LANG
SUBTITLE
PIP
MENU
RETURN
OK
SOURCE FAV
PRESETS
SLEEP
?
INFO
EPG
V+
V-P-P-
P+
1
2
3
4
6
5
9
7 8
0
V
Remote Control Buttons
Standby1.
Mono/Stereo - Dual I-II / Currrent Language (*) 2.
(in DVB channels)
Image size / Zooms videos (in Media Browser 3.
video mode)
Green button/List Schedule(in EPG)/Tag/Untag 4.
All(in favourite list)/Play-Slideshow(in Media
Browser)
Red button/Stop(in Media Browser)5.
Numeric buttons(**)6.
Teletext / Mix(in TXT mode) 7.
Cursor Left 8.
Menu on-off9.
AV / Source selection10.
Favourite Mode Selection(in DVB channels)11.
Volume Up12.
Info / Reveal (in TXT mode)13.
Mute14.
Volume Down15.
Programme Down / Page up(in DVB channels)16.
Electronic programme guide(in DVB channels)17.
Programme Up / Page down(in DVB channels)18.
Sleep Timer19.
Picture mode selecion. / Changes picture mode 20.
(in Media Browser video mode)
Okay (Confi rm) / Hold (in TXT mode)/ Edit 21.
Channel List
Cursor Down22.
Exit / Return / Index page (in TXT mode)23.
Cursor Right / Subpage (in TXT mode)24.
Cursor Up 25.
Previous programme26.
Yellow button/Pause (in Media Browser)/27.
Timeline Schedule(in EPG)
Blue button/Edit Channel List/Filter (İn Favourite 28.
List&EPG)/Loop-Shuffl e (in Media Browser)
No function29.
Subtitle on-off (in DVB channels)30.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SCREEN
MENU
SOURCE
INFO
V+
V
30
29
SUBTITLE
PIP
28
LANG
27
26
25
24
23
22
21
20
19
OK
PRESETS
P+
RETURN
SLEEP
18
EPG
17
16
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 601_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 6 03.11.2011 17:18:0103.11.2011 17:18:01
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
English - 6 -
LED TV and Operating Buttons
FRONT and REAR VIEW Control buttons VIEW Control Buttons
Up direction1.
Down direction2.
Programme/Volume / AV 3.
/ Standby-On selection
switch
Note:You can move the switch,
upward or downward to change
the volume. If you want to change
channels, press the middle of the
switch once (Position 3) and then
move upward or downward. If you
press the middle of the switch
once more, source OSD will be
displayed. If you press the middle
of the switch and hold about a
few seconds, the TV will switch to
standby mode. Main menu OSD
cannot be displayed via control
buttons.
Viewing the Back side Connections
DMI 1
H
SPDIF
Coax.OUT
HDMI 1: HDMI Input1.
HDMI Inputs are for connecting a device that has an HDMI socket. Your LED TV is capable of
displaying High Defi nition pictures from devices such as a High Defi nition Satellite Receiver or DVD
Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets
can accept either 720p or 1080p signals. No sound connection is needed for an HDMI to HDMI
connection.
RF Input2. connects to an aerial antenna system.
Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device
to the television with an appropriate antenna cable, as shown in the illustration in the following pages.
SCART 3. input or output for external devices. Connect the SCART cable between SCART socket on TV and
SCART socket on your external device (such as a decoder, a VCR or a DVD player).
Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.
Note: S-VHS signal is supported via the scart socket.
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 701_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 7 03.11.2011 17:18:0103.11.2011 17:18:01
English - 7 -
PC Input4. is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.
Note: You can use YPbPr to VGA cable(not supplied) to enable YPbPr signal via PC input.
S/PDIF Coaxial Out5. outputs digital audio signals of the currently watched source.
Use an SPDIF coaxial cable to trasfer audio signals to a device that has S/PDIF input
Viewing the Connections - Side Connectors
The CI Slot is used for inserting a CI card. A CI card allows you to view all the 1.
channels that you subscribe to. For more information, see “Conditional Access”
section.
Side USB input.2.
Side audio-video connection3. input is used for connecting video and audio signals
of external devices. To make a video connection, you must use the supplied AV
connection cable for enabling connection. First, plug singular jack of the cable to the
TV’s Side AV socket. Afterwards, insert your video cable’s (not supplied) connector
into the YELLOW input (located on the plural side) of the supplied AV connection
cable. Colours of the connected jacks should match.
To enable audio connection, you must use RED and WHITE inputs of the side AV
connection cable. Afterwards, insert your device’s audio cable’s connectors into
the RED and WHITE jack of the supplied side AV connection cable. Colours of the
connected jacks should match.
Note: You should use audio inputs of side AV connection cable (RED & WHITE)
to enable sound connection when connecting a device to your TV by using PC or
COMPONENT VIDEO input.
The headphone jack is used for connecting an external headphone to the system. 4.
Connect to the HEADPHONE jack to listen to the TV from headphones.
Volume/ Programme/ Source and Standby-On switch5.
o
MODE
Power Connection
IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.
After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the •
mains. Plug the power cable to the mains socket outlet.
Aerial Connection
Connect the aerial ,cable TV plug to the AERIAL INPUT socket located at the rear of the TV.•
1
HDMI
SPDIF
Coax.OUT
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 801_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 8 03.11.2011 17:18:0303.11.2011 17:18:03
English - 8 -
Using Digital Multimedia
Connectors
You can connect USB devices to your TV by using •
the USB input of the TV. This feature allows you to
display/play JPG, MP3 and video fi les stored in a
USB stick.
It is possible that certain types of USB devices (e.g. •
MP3 Players) may not be compatible with this TV.
You may back up your fi les before making any •
connections to the TV set in order to avoid any
possible data loss. Note that manufacturer will not
be responsible for any fi le damage or data loss.
Do not pull out USB module while playing a fi le.•
CAUTION: Quickly plugging and unplugging USB
devices, is a very hazardous operation. Especially,
do not repeatedly quickly plug and unplug the
drive. This may cause physical damage to the USB
player and especially the USB device itself.
SIDE VIEW USB MEMORY
USB
5Vdc
Max:500mA
USB Memory Connection
IMPORTANT: The TV should be switched off while
plugging or unplugging a USB device. Plug your
USB devices to the USB input of the TV. You can
connect a usb device to your TV by using the USB
input of the TV.
Note: It is possible certain types of hard disk drives
are not supported.
Connecting the LED TV to a
PC
For displaying your computer’s screen image on your
LED TV, you can connect your computer to the TV set.
Power off both computer and display before making
any connections. Use 15-pin D-sub display cable to
connect a PC to the LED TV. When the connection
is made, switch to PC source. See “Input selection”
section. Set the resolution that suits your viewing
requirements. Resolution information can be found
in the appendix parts.
PC VGA Cable
(Not supplied)
PC Input
(back)
Side AV Input
SIDE AV
Side Audio/Video
Connection Cable
(Supplied)
PC Audio Cable
(Not supplied)
Using Side AV Connectors
You can connect a range of optional equipment to your
LCD TV using side connectors of the TV.
For connecting a camcorder or camera , you should •
use AV socket (side). To do this, you must use the
supplied video/audio connection cable. First, plug
single jack of the cable to the TV’s AV I N socket
(side). Afterwards, insert your camera cable’s (not
supplied) connectors into the plural part of the video/
audio connection cable. Colours of the connected
jacks should match. See illustration below.
Afterwards, you should switch to • Side AV source. See
the section Input selection in the following sections
for more information.
AVConnection
Cable (supplied)
Or
AVCable
(not supplied)
SIDE AV
Headphone
Camera
To listen the TV sound from headphones, you •
should connect headphones to your TV by using the
HEADPHONE jack as illustrated above.
For assistance, please call our Tesco Electrical Helpline on 0845 456 6767
01_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 901_MB62_[GB]_woypbpr_3902UK_IDTV_BRONZE19_19910LED_10076214_50202491.indd 9 03.11.2011 17:18:0303.11.2011 17:18:03
English - 9 -
Loading...
