OPERATION MANUAL
STATE-OF-THE ART BREAKTHROUGH TECHNOLOGY
Dear Artist,
Congratulations on owning the rst comprehensive glass
grinder with worldwide voltage capabilities!
THE GRINDER®’s features and accessories have been
compiled after thorough study of glass artists needs. Thank
you for purchasing the ultimate glass grinding
machine which we hope will make your studio time the most
pleasant experience.
Please take a few moments to read this manual and become
acquainted with your GRINDER, to get the best performance
from your machine. If you have any questions, please feel
free to visit our website, www.techniglass.com for
more information.
Be sure to register your GRINDER to activate its warranty
with the option to gain access to Techniglass Corporation
company updates, promotions, and news! Go to techniglass.
com and tell us about your new GRINDER experience – any
comments and feedback you may have – we would love to
hear from you!
On behalf of our entire team, thank you for choosing
Techniglass for all your glass grinding needs. Our designers
and engineers are dedicated to creating the most advanced
and innovative products, we are inspired by the ingenuity of all
glass artists.
Here’s to the instruments that help make inspiration a reality.
Cheers,
Mike Hacikyan
Mike Hacikyan
President | Techniglass Corporation
P.S. Find your serial number on the back of your machine.
For quick reference and convenience
write the number here: __________________________
if you ever need to call our service line.
If you experience any issues, don’t hesitate to call us at
716-525-1001 so our team can assist you.
•
Always use eye protection while
operating this glass grinder.
•
Use only a properly grounded,
three-prong outlet
•
Water from reservoir must not reach
electrical outlet
•
Power off THE GRINDER when
not in use
•
Before grinding, ensure the water
reservoir is adequately filled
•
DO NOT OVERFILL THE
WATER RESERVOIR
•
Always install Water Shaft Seal on
shaft when using upper platform
•
When removing LumiShield® Arm,
always cover slot with LumiShield
Mount Cap
SAFETY PRECAUTIONS
ASSEMBLY
BACK
FRONT
RIGHT
LEFT
1 2
3 4a
4b 4c
1 Insert the power cord into inlet
2 Remove the Lift Grid
3 Slide Quick Fit Bit® down shaft
4 Install Aqua Flow System
®
Wet the brush bristles prior to installation
5 Add water until it reaches base of Aqua Flow System Brush
6 Position Lift Grid
7 Install the Guard into slot
8 Insert LumiShield® Arm into slot
5a 5b
6 7
8a 8b
WATER LEVEL
ASSEMBLY CONTINUED
9 10
11a 11b
9 Slide transparent shield into channel
10 Insert Everwear Bit Guard
11 Light /Power Switch
ASSEMBLY CONTINUED
1 Remove The Guard
®
2 Remove Quick-Fit® Bit
3 Remove Everwear Bit Guard
4 Remove brush
1 2
3 4a
4b 4c
PREPARING THE GRINDER
FOR THE MINI G® PLATFORM
2 3
1a 1b
MINI G® PLATFORM ASSEMBLY
1 Install Shaft Water Seal on shaft of LOWER platform
2 Align and Install UPPER platform over shaft
3 Install Aqua Flow System
®
4 Add water until it reaches base of Aqua Flow System Brush
5 Install 1/4" or 1/8" jewelry bit
6 Position Lift Grid over UPPER platform
4a 4b
WATER LEVEL
MINI G® PLATFORM ASSEMBLY CONTINUED
5 6
MAINTENANCE
1 2
3
1 Power OFF the Grinder
2 Drain water from reservoir
3 Install brush on scraper
4 Scrape excess debris from reservoir surface
5 Brush surface with soap and water to remove additional debris
6 Clean eye shield with soft cloth
4
5 6
SERIAL NUMBER WARRANTY REGISTRATION
Be sure to register THE GRINDER serial number, found on
your GRINDER, with Techniglass Corporation within 90
days of purchase to ensure warranty validity.
Fill out the form included in the or visit
www.techniglass.com/grinder/registration
to register your GRINDER.
Registering your purchase links your product to your
account for proof of ownership, warranty service and
recall notifications.
Plus, it’s only two simple steps!
If you wish to receive information on products, promotions,
and contests make sure you check the box at the bottom
to opt-in!
