Technics sl-pd887 User Manual
Specifications and Main Features
- Audio System: SL-PD887/SL-PD687
- Audio Channels: 2 (stereo)
- Frequency Response: 2—20 kHz, +1 dB from rated flatness
- Output: 2V (0dB level)
- Dynamic Range: 92 dB
- S/N: 100 dB
- THD: 0.007 % at 4KHz (0dB )
- Wow and Flutter: Unmeasurable levels
- DAC: MASH (1bit)
- Zout: 1 k Ω
- Zin: 10 k Ω or more
- Pickup Wavelength: 780nm
- Power consumption:
- For UK, Europe, Australia and New Zealand - 12W
- For Others - 14W
- Power Supply:
- For UK, Europe, Australia and New Zealand - AC - 50/60Hz 230-240V
- For Others: AC - 50/60Hz 110V/127V/220V/230-240V
- Dimensions: 430 x 125 x 370 mm
- Weight: 4.6 kg
Equipment Features:
- It is a disc player that can accommodate five discs simultaneously
- Customizing program for a pre recorded maximum of up to 32 choices
- Two operating modes are available for random play; one disc and several discs at the same time
- Play functions for ID scanning during track search
- The ability to rewind is IFO
- The user can choose from various forms of time display information.
- Automatic guide for recording edit function onto a tape.
- Provides a capability for infrared remote control
Frequently Asked Questions
Q1: What is capacity of discs in SL-PD887/ SL-PD687?
A1: It has a capacity for up to five compact discs.
Q2: How can I put a disc in the changer, if it is not playing the disc?
A2: Firstly, make sure the disc being loaded is on the correct side, as well as checking the disc for dirt, dust scratches, and warping. Only after checking all of this should a disc be replaced.
Q3: Is it possible to play a random play with the use of the changer?
A3: Yes, there is random play available with the changer along with one disc random play options.
Q4: How many program selections are available? How can I access this option?
A4: A total of 32 selections can be programmed and this can be accessed using the PROGRAM MODE option.
Q5: What do I do if there is precipitation accumulating inside the changer?
A5: In case rainwater is found accumulation, it is advisable to leave the changer unattended in a dry spot for 60 minutes after turning the power on.
Q6: Do all types of compact discs fit into the changer?
A6: No, the changer is aimed solely at compact discs which comply with the standards set forth.
Q7: Is there any correct procedure to clean the discs?
A7: A soft damp cloth should be used to slightly wipe down the disc with the intention to not damage the surface of the disc.
Q8: How can I fix a remote that’s not working?
A8: To start off, make sure batteries are placed correctly and make sure your remote is not too far away from the unit.
