Technics SE-R1 Operating Instructions
Owner’s Manual
Stereo Power Amplifier
Manuel d’utilisation
Amplificateur de puissance
SE-R1
Music is borderless and timeless,
touching people’s hearts across cultures and generations.
Each day the discovery of a truly emotive experience
from an unencountered sound awaits.
Let us take you on your journey to rediscover music.
Sans frontières, la musique est aussi intemporelle, touchant le
coeur des gens en traversant les cultures et les générations.
Tous les jours, nous attendons la révélation d'une expérience
émotionnelle authentique à partir d'un son venu de nulle part.
Permettez-nous de vous emmener en voyage pour redécouvrir
la musique.
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
If you have any questions, visit:
U.S.A.: www.panasonic.com/support
Canada: www.panasonic.ca/english/support
Register online at www.panasonic.com/register
(U.S. customers only)
∫ Features of this unit
This unit offers the following features:
Full-digital amplifier with a high-precision jitter reduction circuit and PWM conversion circuit
This unit is a full-digital amplifier. Its specially-designed jitter reduction circuit and high-precision PWM conversion circuit eliminate
distortion, noise, and jitter.
LAPC (Load Adaptive Phase Calibration)
Adaptive processing of speaker impedance flattens frequency amplitude and phase characteristics. The result is the reproduction
of sound with rich spatial expression.
GaN-FET Driver
High-speed, loss-less switching is required to achieve pure amplification of accurately generated PWM signals. For this reason,
this unit is provided with a high-speed GaN-FET Driver with super-low ON resistance.
∫ Recommended devices
We recommend using Technics devices (optional) for superior audio quality.
Product name Model number
Network Audio Control Player SU-R1
Speaker System SB-R1
(4)
4
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the
safety instructions on the unit and the applicable safety instructions listed
below. Keep these operating instructions handy for future reference.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider t han the other. A groundingtype plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when
unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
WAR NING
Unit
≥ To reduce the risk of fire, electric shock or product damage,
– Do not expose this unit to rain, moisture, dripping or splashing.
– Do not place objects filled with liquids, such as vases, on this unit.
– Use only the recommended accessories.
– Do not remove covers.
– Do not repair this unit by yourself. Refer servicing to qualified service personnel.
– Do not place heavy items on this unit.
AC power supply cord
≥ The power plug is the disconnecting device.
Install this unit so that the power plug can be unplugged from the socket
outlet immediately.
CAUTION
Unit
≥ Do not place sources of naked flames, such as lighted candles, on this unit.
≥ Do not put any objects on this unit. This unit becomes hot while it is on.
≥ Do not touch the output terminals of the speakers with your hands or other
objects while the speakers are in use. Depending on the conditions of use,
doing so may expose you to high voltage.
Placement
≥ To reduce the risk of fire, electric shock or
product damage,
– Do not install or place this unit in a bookcase,
built-in cabinet or in another confined space.
Ensure this unit is well ventilated.
– Do not obstruct this unit’s ventilation openings
with newspapers, tablecloths, curtains, and
similar items.
≥ More than one person is required to move or
carry the unit.
≥ Ensure that the placement location is sturdy
enough to accommodate the weight of this unit
(> 15).
≥ Do not lift or carry this unit by holding any of its
knobs. Doing so may cause this unit to fall,
resulting in personal injury or malfunction of this
unit.
CAUTION :
Conforms to UL STD 60065.
Certified to CAN/CSA STD C22.2 No.60065.
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
≥ Reorient or relocate the receiving antenna.
≥ Increase the separation between the equipment and receiver.
≥ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
≥ Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded interface cables when
connecting to peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Responsible Party:
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://www.panasonic.com/contactinfo
THE FOLLOWING APPLIES ONLY IN CANADA
CAN ICES-3(B)/NMB-3(B)
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of disposal.
CAUTION
RISK OF ELECTRIC SHOCK
DO
NOT OPEN
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
English
(5)
5
Table of contents
IMPORTANT SAFETY INSTRUCTIONS..............................5
Accessories.........................................................................6
Unit care ..............................................................................6
Control reference guide .....................................................7
Getting started ....................................................................8
About descriptions in this Owner’s Manual
≥Pages to be referred to are indicated as “@ ±±”.
≥The illustrations shown may differ from your unit.
Accessories
∏ 1 AC power supply cord
(K2CB2YY00107)
Operations........................................................................ 13
Troubleshooting............................................................... 14
Specifications................................................................... 15
Limited Warranty (ONLY FOR U.S.A.)............................. 16
Limited Warranty (ONLY FOR CANADA)........................ 17
(ONLY FOR CANADA)
The enclosed Canadian French label sheet corresponds to the English display on the unit.
≥ Product numbers provided in this Owner’s Manual are correct as of December 2014. These may be subject to change.
≥ Do not use AC power supply cord with other equipment.
Unit care
Pull out the AC power supply cord from the outlet before maintenance. Clean this unit with a soft cloth.
≥ When dirt is heavy, wring a wet cloth tightly to wipe the dirt, and then wipe it with a soft cloth.
≥ Do not use solvents including benzine, thinner, alcohol, kitchen detergent, a chemical wiper, etc. This might cause the exterior case to be
deformed or the coating to come off.
(6)
6
Control reference guide
This unit
∫ Front
1 Unit on/off button [ ]
Use this button to turn the unit on and off.
[ ] (off): The unit is off.
[ ] (on): The unit is on.
≥ The unit is still using a small amount of power in off mode. Off
mode uses less power. (> 15)
2 Power indicator
The color of the indicator changes according to the status
of this unit.
Blue The unit is on.
The unit is in standby mode.
Red
3 Peak power meter
Display the output level.
4 LAPC indicator (> 13)
5 [DIMMER]
Adjust the brightness of the light and the indicators.
Each press of this button switches the brightness.
6 [LAPC] (> 13)
Measure the characteristics of the amplifier and correct
its output.
≥ The function does not work when the speaker selector knob is
set to [OFF].
7 Input selector knob (> 13)
Select the input source or gain value.
8 Speaker selector knob (> 13)
Select the output speakers.
≥ To turn on this unit from standby mode,
press the unit on/off button on this unit to
the [ ] position, and press it again
to the [ ] position.
∫ Rear
9 Speaker terminals [SPEAKERS] (> 8)
:
Analog audio input terminal [UNBALANCED] (>11)
; Analog audio input terminal [BALANCED] (> 11)
< Analog audio input selector switch (> 11)
Switch the analog audio input.
≥ This switch does not work when the input selector knob is set
to [DIGITAL].
= System terminal [Technics Digital Link IN] (> 10)
> Auto off switch [AUTO OFF]
Turn on/off auto off function.
≥ Auto off function:
This unit is designed to conserve its power consumption and
save energy. The unit will turn to standby mode automatically
if there is no sound and it is not being used for approximately
20 minutes.
– To cancel this function, set to [OFF].
? Product identification marking
The model number is indicated.
@ AC IN terminal [AC IN T] (> 12)
English
(7)
7
Getting started
≥Turn off all equipment before connection and read the appropriate operating instructions.
≥Do not connect the AC power supply cord until all other connections are complete.
≥Insert the plugs of the cables to be connected all the way in.
≥Do not bend cables at sharp angles.
WARNING:
RISK OF HAZARDOUS ENERGY! MAKE PROPER SPEAKER CONNECTIONS. CONNECT CABLES AS DESCRIBED IN
THIS OWNER'S MANUAL.
Speaker connection
∫ Single wiring connection
e.g.,
SB-R1 Speaker cable Speaker cable SB-R1
This unit
(rear)
≥When using single wiring connection, set the speaker selector knob to [A] or [B]. (> 13)
1 Turn the knobs to loosen them, and insert the core wires.
2 Tighten the knobs.
(8)
8
∫ Bi-wiring connection
DO NOT
e.g.,
SB-R1
This unit
(rear) SB-R1
English
Speaker cable Speaker cable
≥When making bi-wiring connections, set the speaker selector knob to [A+B]. (> 13)
≥ When the connections are completed, pull the speaker cables lightly to check that they are connected firmly.
≥ Be careful not to cross (short-circuit) or reverse the polarity of the speaker wires as doing so may damage the
amplifier.
≥ Wire the polarity (r/s) of the terminals correctly. Not doing so may adversely affect stereo effects or cause
malfunction.
≥ For details, refer to the operating instructions of the speakers.
(9)
9
System control connection to an SU-R1
≥You can input digital audio signals to this unit and play back music.
≥You can automatically link this unit with the SU-R1 and operate them easily with the remote control of the SU-R1. (> 14)
This unit
(rear) SU-R1
≥ When using the system control function, set the input selector knob to [DIGITAL]. (> 13)
≥ Use category 7 or above straight LAN cables (STP) when connecting to peripheral devices.
≥ We recommend using cables with a length of 3 m (9.9 ft) or less.
≥ Do not connect an SU-R1 in any other way than described above.
Cable for system control
(not supplied)
10
(10)
Connecting to analog audio output devices
You can input analog audio signals to this unit and play back music.
e.g.,
This unit
Pre-amplifier, etc.
(rear) Pre-amplifier, etc.
*1
English
Audio cable
(not supplied)
*1 Select [BALANCED] or [UNBALANCED]. Set the analog audio input selector switch to a position that corresponds to the device you want to
play.
*2 We recommend using cables with a length of 3 m (9.9 ft) or less.
≥When connecting to an analog audio output device, set the input selector knob to [ANALOG]. (> 13)
XLR cable*
(not supplied)
2
∫ To disconnect the XLR cables
Pull out the XLR cables while pressing [PUSH] at the top of the terminals.
(11)
11
Loading...
