Technicolor - Thomson TM9237 User Manual

Safety Information

WARNING:

TO PREVENT FIRE

OR ELECTRICAL

SHOCK HAZARD,

DO NOT EXPOSE THIS PR ODUCT

TO RAIN OR MOISTURE.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT.

THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF "DANGEROUS VOLTAGE" INSIDE THE PRODUCT.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION!

Invisible laser radiation when open. Avoid exposure to beam. Class 1 laser product. This system must be opened only by qualified technicians to prevent accidents caused by the laser beam.

LASER λ = 780 nm, P max = 5 mW Rating Information: At bottom of the unit this unit comply with the existing requirements

In accordance with the rating plate of the unit, this unit complies with current standards concerning electrical safety and electromagnetlc compatibillity.

Please respect the environment. Before throwing any batteries away, consult your distributor who may be able to take them back for specific recycling.

CAUTION – INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS FAILED OR DEFEATED. AVOID EXPOSURE TO BEAM.

 RAYONNEMENT LASER INVISIBLE

ATTENTION –

DANGEREUX EN CAS D'OUVERTURE ET LORSQUE LA SECURITE EST NEUTRALISEE. EXPOSITION DANGEREUSE AU FAISCEAU.

ADVARSEL!

USYNLIG LASERSTRĀLING, NĀR ENHEDEN ER ĀBEN OG SIKKERHEDSAFBRYDERNE ER UDE AF FUNKTION ELLER OMGĀET. UNDGĀ EKSPONERING FOR STRĀLEN.

VORSICHT!

UNSICHTBARE LASERSTRAHLUNG BEI GEÖFFNETER ABDECKUNG, FALLS SICHERHEITS-VERRIEGELUNG NICHT EINGERASTET IST ODER WENN SIE BEEINTRÄCHTIG IST. SETZEN SIE SICH NICHT DEM LASERSTRAHL AUS!

CLASS 1 LASER PRODUCT LASER KLASSE 1 LASERAPPARAT AV KLASS 1

AREIL A LASER LUOKAN 1 LASERLAITE LASERPRODUKT AF KLASSE 1

VARNING!

OSYNLIG LASERSTRĀLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRRARNA ÄR URKOPPLADE. TITTA EJ IN I STRĀLEN.

VARO

AVATTAESSA JA OHITETTAESSA SUOJALUKITUS OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

CLASSE 1

TM9237 EN 6/24/05, 5:36 PM1

Contents

General controls

Safety information

EN EN

Before you begin ................................. 1

General controls ...................................2

Display ................................................... 3

Radio ..................................................... 3

Before you begin

Useful Advice

Do not use your system immediately after transporting it from a cold place to a warm place, as condensation may cause the system to malfunction. If moisture forms inside this system, it may not operate properly. To correct the problem, turn off the power and wait about 30 minutes for moisture to evaporate

This system is fitted with a laser. To avoid accidents, it is to be opened by qualified technicians only.

Never leave the tray open as dust could cover the laser lens and/or the tray could be bumped into accidentally

Do not place the system near wet areas such as bathrooms and pool side. Avoid storing the system at humid places or near abnormally heated areas.

Power is continuously supplied to the system. To disconnect power completely, unplug the power cord from the power outlet.

Ensure minimum distance around the apparatus for sufficient ventilation.The ventilation should not be impeded by covering the ventilation openings with items, such as newspaper, etc.

No naked flame source, such as lighted candles, should be placed on the apparatus.

Attention should be paid to enviornment aspects of battery disposal.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

CD player ............................................... 4

Tape player ...........................................5

Troubleshooting tips ............................ 6

Maintenance ......................................... 7

More Information ................................. 8

Battery Power

You can insert 6 D-sized alkaline batteries (not supplied) and you can take your stereo just about anywhere. Open the battery compartment door on the back of the unit by pressing down on the arrow and pulling out the cover. Insert batteries in the battery compartment.(See diagram)

Note that the AC line cord must be unplugged from the jack on the back of the unit to operate on batteries.

ImportantImportant

Important:

ImportantImportant

Be sure to remove batteries when storing the set for more than 30 days.

system. Always return tape operatioin buttons to their off position before storing. This will relieve pressure on certain parts in the tape recorder that might deform after long periods of time. Be sure to dispose of leaky, weak or dead batteries properly according to federal, state, and local regulations. To prevent injury or damage, do not reverse batteries and do not mix battery type.

Leaky batteries can badly damage the

LEVEL

SELECT

(OFF)

APE

RADIO

REPEAT

PROG.

TRACK

PAUSE STOP/EJ. F.FWD REW PLAY REC.

PORTABLE CD PLAYER

RADIO CASSETTE RECORDER

CD MULTIFUNCTION DISPLAY

PLAY PAUSE

< TUNING >

108

170

BAND

106

1400

104

120

100

kHz

x10

MHz

MIX

OPEN

STOP

MIN. VOLUME MAX. — increases or decreases output volume

SELECT – selects among TAPE (OFF), RADIO and CD mode

DBBS – turns on/ off digital bass boost system

REPEAT – repeats one track or entire disc playback

PROG. – enters program mode for CD playing

TRACK – searches / skips CD track forward or backward

PLAY PAUSE – starts or pauses CD play

STOP – stops CD playback

OPEN

– opens the CD compartment door

MIX– plays CD tracks randomly

CLOSE – push to close the disc compartment door

BAND – selects between MW/FM band

< TUNING > – rotate to search for radio stations

Cassette Player

PAUSE STOP/EJ. F.FWD REW PLAY REC.

PAUSE – pauses tape playback or recording

STOP/ EJ. – stops tape playback, winding or recording, opens cassette door

F. FWD/ REW – winds tape forward or backward

PLAY – starts tape playback

REC – starts tape recording

TM9237 EN 6/24/05, 5:36 PM2-3
