Technicolor - Thomson ROC2206 User Manual

ROC2206

User manual

ROC2206

ABC

Respect the environment and the law!

Respectez l’environnement et la loi !

Schützen Sie die Umwelt und halten Sie die geltenden Entsorgungsbestimmungen ein!

Rispettate l’ambiente e la legge!

¡Respete el medio ambiente y la ley!

The ROC 2206 is a universal remote control (2 in 1). It can replace 2 remote controls thanks to its 2 mode keys TV, VCR/DVD... It is compatible with the majority of television sets, video cassette recorders, DVD players, satellite and cable receivers as well as terrestrial digital television (DVBT), amplifiers and other audio equipment provided they are controlled by infra red signals. This remote control has been factory programmed to allow you to use it immediately with the majority of Thomson Group devices.We therefore advise you to try it before beginning to program it. If programming is necessary, follow one of the methods A, B, C, D or E that are given in this manual. But before anything else, fit the two batteries into the remote control handset and peel off the tab as shown on the diagram on the inside of the cover. Keep these instructions and the separate list of codes in a safe place so that you can later reprogram your remote control.

1 - Description of keys

1 Indicator lamp: the indicator lamp lights up when any

key is pressed.

2 B: On / Standby. 3 Remote control mode

Selects device to control TV, DVD,VCR,... 4 S: programmes the remote control. SHIFT: activates the secondary key features

(indications in blue).

5 I (EXIT): teletext Off in TV mode.

SHIFT and EXIT: turns off the menu of the

selected product. 6 c: switches the TV sound off. SHIFT and OK: confirms a selection. 7 VOL-/VOL+ increases (+) or decreases (-) the

volume of the TV set. SHIFT and VOL-/VOL+ also allows you to

navigate the menus horizontally.

8 M (RECORD): to record (VCR/DVD). 9 F (FF): fast forward *. 10 B (Play): play*. 11 K (Pause): stops on an image*. 12 Number keys 0 to 9: these keys have the same

functions as those of your original remote and are

also used to enter the codes for different products.

13 AV: for selecting an external source (SCART). 14 Press this key first before you type in the 2-digit

channel number (except for Thomson group

products).

15 L (STOP): stop playback*. 16 G (REW): goes backward or advances forward*. 17 "Info" key.

Videotext inlay on TV picture.

18 PROG+,PROG-: programmes zapping button

(received by the television set or the satellite

receiver); use to scroll vertically through menus

SHIFT and PROG+/PROG- also allow you to

navigate the menus vertically. 19 a (MENU): teletext On/Off in TV mode. SHIFT and MENU: turns on the menu of the

selected products. * The coloured buttons can be used to select categories

when teletext is activated, and specific functions depending on the make.

2 - Testing the remote control

before programming

1. Turn on the device that you wish to control.

2. Press the key corresponding (3) to the type of device

to control: TV: television set, VCR/DVD: video cassette recorder, DVD player.

3. Point the remote control at the device you wish to

control and try to turn it off using theB (2) key. If the device does not turn off, you must program the

remote control using one of the methods A, B, C or

D as described below.

Before you start programming, you must find the subcode of

the set to be controlled.

Refer to the list provided with these instructions, page I of the

codes.

1 Switch on the set you want to control.

2. Hold down the S (4) key until the indicator lamp (1) remains lit (the indicator light remains on for a few seconds to give you the time to proceed with the following steps. The indicator lamp flashes when this time is almost up, and then goes off).

3. Press the key (3) that corresponds to the type of equipment you want to control:

TV: television set, VCR/DVD: video cassette recorder, DVD player.

4. While the indicator is lit, type in the subcode (example: 1 for Thomson).

5. Direct the remote control towards the set and try to switch it off by pressing the B (2) key.

6. If the set you want to control switches off, press c (6) to memorise the subcode.

7. If the product doesn’t turn off, press the B (2) key repeatedly until the set switches off. Wait approximately one second between key presses to give the indicator lamp (1) enough time to go off and light up again. This will allow you to see whether the product responds or not.

8. Immediately upon the switching-off of the set to be controlled, press c (6) to store the subcode.

Note:

If you want to assign another type of product than those

mentioned on the remote control (with the exception of the TV button which can only be used to control a television set),

begin by entering the code that corresponds to the product you

want to programme (a 3-digit code that you will find in the code booklet – see method B).

Example: if you want to control a satellite receiver with the VCR/DVD key, begin by entering a satellite code (any

satellite, for example: 603 for a Thomson satellite receiver) then

begin the procedure.

Check of the programming:

In principle, your set is ready for receiving the remote control

commands. Check your remote control for proper functioning by

performing the test described on page 3.

3 - Programming

the remote control

Method A – Fast programming with

1-digit subcode

Method B – 3-digit codes Programming

Before you start programming, you must find the code of the set to be controlled. Refer to the list provided with these instructions, page II of the codes.

1. Switch on the set you want to control.

2. Hold down the S (4) until the indicator lamp (1) remains lit (the indicator light remains on for a few seconds to give you the time to proceed with the following steps. The indicator lamp flashes when this time is almost up, and then goes off).

3. Press the key (3) that corresponds to the type of equipment you want to control:

TV: television set, VCR/DVD: video cassette recorder, DVD player.

4. While the indicator is lit, enter the first digit of the 3-digit code proposed for the set to be controlled (example: 036 for Thomson). The red indicator then goes off if the code is correct or flashes, if the code is not on the list.

5. Direct the remote control towards the set and try to switch it off by pressing the B (2) key.

6. Should the set not switch off, repeat step 2. Then type in the next 3-digit code. Try to switch off the set by pressing B (2) key once. Repeat this procedure by trying out each of the 3-digit codes.

Check of the programming:

In principle, your set is ready for receiving the remote control commands.Check your remote control for proper functioning by performing the test described on page 3.

Method C – Programming by means of

code retriever

Should none of the codes work, you still have the possibility

of retrieving the appropriate code without having to perform

any input.

1. Switch on the set you want to control.

3. Press the key (3) that corresponds to the type of equipment you want to control:

TV: television set, VCR/DVD: video cassette recorder, DVD player.

4. Direct the remote control towards the set and try to switch it off by pressing the B (2) key.

5. If the set you want to control switches off, press c (6) to memorise the subcode.

6. Should the set not switch off, press B (2) key, as many times as required (up to 200 times), until the set switches off. Wait approximately one second between key presses to give the indicator lamp (1) enough time to go off and light up again. Proceeding this way will enable you to see whether the set responds or not.

7. Immediately upon the switching-off of the set to be controlled, press c (6) to store the subcode.

Note:

If you want to assign another type of product than those mentioned on the remote control, begin by entering a code that corresponds to the product you want to programme (a 3-digit code that you will find in the code booklet – see method B). Example: if you want to control a satellite receiver with the VCR/DVD key, begin by entering a satellite code (any satellite, for example: 603 for a Thomson satellite receiver) then begin the procedure.

Check of the programming:

In principle, your set is ready for receiving the remote control commands.Check your remote control for proper functioning by performing the test described on page 3.

Method D - Automatic code search

With this method, the remote control scrolls through the full

code list by sending an IR signal to the set to be controlled

remotely. Proceed as follows:

1. Check that your equipment is on. If not, switch it on manually.

3. Release the S (4) key.

4. Press the key corresponding to the type of equipment (for example TV).

5. Press the PROG+ (18) key once. After a few seconds the remote control begins to list all the codes included in the library (around 1 code per second). Press PROG+ (18) a second time to reduce the speed of the test (1 code every 3 seconds). As soon as the device changes channel you must immediately press c (6) to record the code and stop the listing. If you have gone past the code, you can go back to the previous code by pressing PROG- (18) as many times as necessary (you can go forward by pressing

(2) or PROG+ (18). As soon as the device reacts

again, press c (16) to record the code.

Note:

If you want to assign another type of product than those

mentioned on the remote control, begin by entering a code that

corresponds to the product you want to programme (a 3-digit code that you will find in the code booklet – see method B).

Example: if you want to control a satellite receiver with the VCR/DVD key, begin by entering a satellite code (any

satellite, for example: 603 for a Thomson satellite receiver) then

begin the procedure.

Method E – Programming for control of a COMBO

(combined TV-VCR, TV/DVD, VCR/DVD, ... set)

Depending on the COMBO group (TV/VCR, VCR/DVD, etc.) and

the make, you will be required to enter a single code for both

devices in the COMBO, or to enter two codes, one code per

device. Consult the separate list to discover this. Before you start

programming, you must find the subcode or code of the

subset to be controlled (television or video recorder).

Refer to the list supplied with this user manual (see page

subcodes or codes).

1. Switch on the COMBO you want to control.

3. Press the TV (3) key, then follow one of the programming methods (A, B, C or D) described earlier.

4. If a second code programming is required, then repeat steps 2 and 3 above.

4 - How to retrieve

a programmed code

It may be useful to retrieve the code programmed in the

remote control.

1. Hold down the S (4) key until the indicator lamp (1) remains lit (the indicator light remains on

for a few seconds to give you the time to proceed with the following steps. The indicator lamp flashes when this time is almost up, and then goes off).

2. Press the key (3) that corresponds to the type of equipment you want to control:

TV: television set, VCR/DVD: video cassette recorder, DVD player.

3. Press S (4) again briefly. The indicator lamp (1) flashes once.

4. Press the number keys (0 to 9) in ascending order until the indicator lamp (1) flashes once.

5. The digit which made the indicator lamp (1) flash, is the first number of the 3-digit code. Please make note of it.

6. Repeat step 4 to find out the two other numbers of the code.

7. When the third number is found, the red indicator lamp (1) goes off.

5 - Check of the programming

- For a television or a satellite receiver: switch on and, for

example, press (18) to change channels.

- DVD player: load a DVD and then press PLAY (10).

Try other remote control keys to find out the range of

functions you can control. If you think that not all of the

keys are active, try the programming Method B or C.

When you have retrieved the code of your set, jot

it down so that you can use it whenever needed.

After battery replacement, you may have to

programme the remote control again.

6 - Other functions

Adjustment of ALL volume controls under a specific mode.

You can allocate the volume control to one of the modes of the remote control on condition that the volume control exists on the corresponding device (e.g. control of TV sound in VCR/TV mode).

1. Hold down the S (4) key until the indicator lamp (1) remains lit.

2. Release the S (4) key.

3. Press the c (6) key. The indicator lamp (1) flashes once.

4. Press once on the mode key (TV, VCR/DVD…) corresponding to the device whose volume will always be controlled by the VOL (7) and c (6) keys.

5. Press the c (6) key once.

Adjustment of the volume controls for EACH mode.

You can decide that the volume control is functional for each mode selected on condition that the volume control exists on the corresponding device (e.g. control of the television set sound in TV mode, the control of the sound of the SAT receiver in SAT mode, ...).

1. Hold down the S (4) key until the indicator lamp (1) remains lit.

2. Release the S (4) key.

3. Press the c (6) key. The indicator lamp (1) flashes once.

4. Press once on the mode key (TV, VCR/DVD…) corresponding to the device whose volume will always be controlled by the VOL (7) and c (6) keys.

5. Press the VOL - (7) key once.

6. Press the

c (6) key once.

7 - The NAVILIGHT system

The THOMSON NAVILIGHT navigation system allows you easy access to the settings of your television set (TV) or your video recorder (VCR) fitted with the THOMSON NAVILIGHT system provided that you have allocated the VCR/DVD key to the video recorder.

1. Switch on the set you want to control.

2. Press the key corresponding to the type of set you want to use (TV or VCR/DVD). In the VCR/DVD position, make sure that the AV mode is activated for the TV set (the SCART socket must be selected).

3. Press the S (4) key once and then press the a (19) key.

4. Navigate through the setting menus with the play keys p, q, t and u (18 and 7).

5. Validate with OK (6).

6. To leave the menus, press key EXIT (5) once.

Note: The S (4) key remains on as long as light I is lit. If this light goes out, you have to press the S (4) key again before using the navigation keys. To exit this mode, press S (4) a second time.

TV CODE

VCR/DVD CODE

You can contact THOMSON by dialling:

(For Great-Britain, all calls will be charged £0.10/min)

0871 712 1312

www.thomson-europe.com

ROC 2206 / EN / epheme - rst / 04-2006

ENGLISH

- Do not mix different types of batteries or new and old

batteries. Do not use rechargeable batteries. In order to avoid any risk of explosion, observe polarities indicated inside the battery compartment. Replace only with the type of batteries specified above. Do not throw them into fire, do not recharge them. If you are not using the remote control for a long period of time, remove the batteries. Please respect the environment and prevailing regulations. Before you dispose of batteries or accumulators, ask your dealer whether they are subject to special recycling and if they will accept them for disposal.

FRANÇAIS

- Ne mélangez pas différents types de piles ou des piles

neuves et usagées. N'utilisez pas de piles rechargeables. Afin d'éviter tout risque d'explosion, respectez les polarités indiquées au fond du compartiment à piles. Utilisez uniquement des piles du type spécifié. Ne les jetez pas au feu, ne les rechargez pas. Si vous n'utilisez pas la télécommande pendant une période prolongée, retirez les piles. Respectez l’environnement et la loi ! Avant de jeter des piles (ou des accumulateurs), informez-vous auprès de votre distributeur pour savoir si elles (ou ils) font l’objet d’un recyclage spécial, et s’il peut se charger de les récupérer.

DEUTSCH

- Verwenden Sie nie Batterien unterschiedlicher

Marken bzw. verbrauchte und neue Batterien. Keine wiederaufladbaren Batterien einsetzen. Achten Sie stets beim Einlegen der Batterien auf die Angabe der Polarisierungsrichtung. Batterien dürfen nicht in offenes Feuer geworfen werden. Wenn Sie Ihre Fernbedienung über längere Zeit nicht benutzen, nehmen Sie bitte die Batterien heraus. Batterien gehören nicht in den Hausmüll. Als Verbraucher sind Sie gesetzlich verpflichtet, gebrauchte Batterien zurückzugeben. Sie können Ihre alten Batterien bei den öffentlichen Sammelstellen in ihrer Gemeinde oder überall dort abgeben, wo Batterien der betreffenden Art verkauft werden.

ITALIANO

- Non mescolate diversi tipi di batterie e non utilizzate

batterie vecchie e nuove allo stesso tempo. Non utilizzate batterie ricaricabili. Al fine di evitare qualsiasi rischio di esplosione, rispettate le polarità indicate all'interno del vano batterie. Sostituitele solo con il tipo di batterie sopra specificato. Non gettatele nel fuoco, non r icaricatele. Se non utilizzate il telecomando per un lungo periodio, togliete le batterie. Rispettate l’ambiente e la legge! Prima di gettar via le pile (o gli accumulatori) informatevi presso il vostro distributore per sapere se sono o no oggetto di riciclaggio speciale e se può incaricarsi di recuperarli.

ESPAÑOL

- No mezcle diferentes tipos de pilas, nuevas y antiguas.

No utilice pilas recargables. Para evitar riesgos de explosión, respete las polaridades indicadas en el compartimento de las pilas. Sustituya las pilas por otras iguales a las especificadas anteriormente. No las queme y no las recarge. Si no tiene que utilizar el mando a distancia durante un periodo prolongado de tiempo, retire las pilas. ¡Respete el medio ambiente y la ley! Antes de tirar las pilas o acumuladores, pregunte a su distribuidor si éstos son objeto de algún reciclaje especial y si él puede encargarse de su recuperación.

NEDERLANDS

nieuwe batterijen. Gebruik geen oplaadbare batterijen. Respecteer de polariteit zoals aangegeven in het batterij compartiment om de kans op een eventuele explosie te voorkomen. Alleen vervangen met het batterijtype zoals hierboven aangegeven. Gooi batterijen nooit in het vuur, niet herladen. Indien u de afstandsbediening langere tijd niet gebruikt, verwijder dan de batterijen. Eerbiedig de natuur en de wetgeving! Alvorens de batterijen (of de accumulators) weg te werpen, vraag aan uw dealer of deze het voorwerp uitmaken van een bijzondere recycling en of hij belast is met de ophaling ervan.

PORTUGUÊS

novas e antigas. Não utilize pilhas recarregáveis. Para evitar qualquer risco de explosão, respeite as polaridades indicadas no compartimento das pilhas. Substitua as pilhas por outras iguais às especificadas anteriormente. Não as queime nem as recarregue. Se não utilizar o telecomando durante um longo período de tempo, retire as pilhas. Respeite o ambiente e a lei! Antes de deitar fora as pilhas (ou os acumuladores) informe-se junto do seu distribuidor para saber se elas (ou eles) estão sujeita (o)s a uma reciclagem especial e se ele pode encarregar-se de as(os) recuperar.

EΛΛHNIKA

καινούργιες και παλιές µπαταρίες. Mην χρησιµοποι είτε επαναφορτιζµενες µπαταρίες γ ια να αποφύγετε τoν κίνδυνο έκρηξης. Σεβασθείτε την πολικτητα στην τοποθέτηση των µπαταριών. Επανατοποθετήστε µνο µε τον ίδιο τύπο µπαταριών πoυ αναγράφονται παραπάνω. Mην πετάτε της µπαταρίες στην φωτιά. Mην τις επαναφορτίζετε. Αν δεν χρησιµοποιείτε τo τηλεχειριστήριο για πολύ καιρ βγάλτε τις µπαταρίες. Προστατεύετε το περιβάλλον και τηρείτε το νµο ! Πριν πετάξετε µπαταρίες µιας χρήσης (ή επαναφορτιζµενες), επικοινωνείστε µε το διανοµέα σας και ρωτήστε τον αν οι µπαταρίες υφίστανται ειδική ανακύκλωση και αν ο ίδιος αναλαµβάνει να τις πάρει πίσω.

- Mix geen verschillende batterijen of oude en

- Não misture diferentes tipos de pilhas ou pilhas

- Mην χρησιµοποιείτε µαζί

PУCCКИЙ

стаpые батаpейки, не использyйте батаpейки pазлчных типов и подзаpяжаемые батаpейки. Bо избежание взpыва соблюдайте поляpность, yказаннyю внyтpи отсека для батаpей. 3аменяйте батаpейки только батаpейками yказанного выше типа. Hе выбpасывайте иx в огонь, не заpяжайте иx. Eсли вы не намеpены пользоваться пyльтом дистанционного yпpавления в течение длительного вpемени, выньте батаpейки из отсека для батаpей. Бережно относитесь к окружающей среде и соблюдайте законы! Перед тем, как избавиться от старых батареек (или аккумуляторов) свяжитесь с торговой организацией, чтобы узнать, не принимает ли она их для переработки и утилизации.

POLSKI

nowych baterii razem ze starymi. Nie używaj akumulatorków. Aby uniknąć ryzyka wybuchu, wkładaj baterie zgodnie ze znakami biegunów wewnątrz kieszeni na baterie. Wymieniaj jedynie na baterie podanego wyżej typu. Nie wrzucaj baterii do ognia, ani nie ładuj ich ponownie. Jeżeli przez długi okres nie używasz pilota, wyjmij baterie. Szanuj środowisko naturalne i przestrzegaj prawa! Zanim wyrzucisz zużyte ogniwa (lub akumulatorki), dowiedz się u dystrybutora, czy podlegają one recyklingowi i czy może on je od Ciebie w tym celu odebrać.

âEŠTINA

staré baterie s novými. Nepoužívejte dobíjecí baterie. Pﬁi vkládání baterií dbejte na správnou polaritu, vyznaãenou uvnitﬁ bateriového pouzdra, pﬁi nedodržení polarity hrozí nebezpeãí exploze. Baterie nahrazujte pouze výše specifikovaným typem. Baterie nevhazujte do ohnû a nedobíjejte je. Pokud nebudete dálkový ovládaã delší dobu používat, baterie vyjmûte. ChraÀte životní prostﬁedí a dodržujte zákon! Než vyhodíte ãlánkové (nebo akumulátorové) baterie do odpadu, informujte se u prodejce pﬁístroje, zda není organizován sbûr použitých baterií a jejich speciální recyklace v souladû s právní ùpravou na ochranu životního prostﬁedí.

MAGYAR

és az ùj elemket. Ne használjon ùjratölthetŒ elemeket sem. A tartóban jelölt polarítás szerint helyezze be a megfelelŒ elemeket. A kimerült elemeket tilos t¦zbe dobni és ùjratölteni. Ha hosszabb ideig nem hasznalja a távirányítót vegye ki belŒle az elemeket. Tartsa tiszteletben a környezetet és a törvényt! Az elemek (vagy az akkumulátorok) szemétbe történŒ kidobása elŒtt kérdezze meg eladójától, hogy azok részt vesznek-e egy speciális ùjrafeldolgozási programban, illetve foglalkozik-e a kimerült elemek (akkumulátorok) összegy¦jtésével.

SVENSKA

gamla batterier. Använd inte uppladdningsbara batterier. Det är viktigt att batterierna sätts i på rätt sätt och att den rekommenderade typen av batterier används. Utsätt aldrig batterierna för eld. Om fjärrkontrollen inte används under lång tid rekommenderar vi att batterierna tas ur. Tänk på miljön! Förbrukade batterier (eller uppladdningsbara batterier) läggs i de speciella uppsamlingslådor som finns uppsatta i din kommun, eller återlämnas till en återförsäljare av batterier för återvinning.

NORSK

Bruk ikke oppladbare batterier. Det er viktig at batteriene settes I på riktig måte og at den anbefalte typen batterier benyttes. Utsett aldri batteriene for ild. Om fjernkontrollen ikke benyttes over lang tid anbefaler vi at batteriene tas ut. Tenk på miljøet. Oppbrukte batterier (eller oppladbare batterier ) legges I spesielle oppsamlingsspann som du blant annet finner hos de fleste forhandlere av forbrukerelektronikk.

DANSK

gamle og nye batterier. Benyt ikke genopladelige batterier. For at undgå en eksplosion bør de respektere pol indikationerne som er mærket på indersiden af produktet, hvor batterierne skal sætte i. Erstat kun batterierne med de ovennævnte typer. Batterier må ikke kastes ind i ild, og må ikke genoplades. Hvis De over en længere periode ikke benytter fjernbetjeningen, skal batterierne tages ud. Respekter miljøet og lovgivningen! Inden De smider batterier (eller akkumulatorer) ud, bør De henvende Dem til Deres forhandler for at få at vide, om disse indgår i en speciel genbrugsordning, og om de således kan afleveres hos forhandleren.

SUOMI

Räjähdysvaaran välttämiseksi laita paristot oikein päin paristokoteloon. Ohjeet löydät paristokotelon pohjasta. Käytä vain yllä mainitun tyyppisiä paristoja. Älä heitä vanhoja paristoja tuleen äläkä lataa niitä uudelleen. Mikäli et käytä kaukosäädintä pitkään aikaan, poista paristot kaukosäätimestä. Noudata lakia ja kunnioita luontoa! Ennen kuin heität kuluneet paristot (tai akut) jätteisiin, niin kysy jälleenmyyjältä kuuluvatko ne mahdollisesti erikoiskierrätykseen ja kerääkö hän ne talteen.

- Hе yстанавливайте вместе новые и

- Nie mieszaj różnych typów baterii ani nie używaj

Nepoužívejte baterie rÛzných typÛ, nemíchejte

Ne keverje a különbözŒ típusù illetve a régi

- Blanda inte olika sorters batterier eller nya med

- Bland ikke ulike typer batterier eller nye og gamle batterier.

- Forskellige typer af batterier bør ikke blandes så som

- Älä käytä sekaisin erilaisia paristoja, esim. uusia ja vanhoja.

+ 14 hidden pages

Technicolor - Thomson ROC2206 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
