Technicolor - Thomson PDP2842, PDP2845 User Manual

Download

Thomson

Lyra Jukebox

User’s Guide

PDP2842 / PDP2845

It is important to read this instruction book prior to using your new product for the first time.

Important Information

CAUTION

RISK OF ELECTRIC

SHOCK DO NOT

OPEN

This symbol indicates "dangerous voltage" inside the product that presents a risk of electric shock or personal injury.

To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

Battery can only be repaired or replaced by qualified service personnel.

This symbol indicates important instructions accompanying the product.

WARNING

To reduce the risk of fire or electric shock, do not expose this product or AC charger to rain or moisture.

To reduce risk of injury, charge only rechargeable batteries recommended by the manufacturer for this product. Other types of batteries may burst causing damage and personal injury.

Sound Pressure Control

Les articles de loi L44.5 et 44.6 du code de la santé publique, modifiés par l’article 2 de la loi du 28 Mai 1996 imposent une puissance acoustique maximale de 100 décibels. Le casque livré ( code 55700930 ) et votre appareil respectent la législation en vigueur.

A pleine puissance, l’écoute prolongée du baladeur peut endommager l’oreille de l’utilisateur.

Important Information

Service

This product should be serviced only by those specially trained in appropriate servicing techniques. For instructions on how to obtain service, refer to the warranty in this guide.

Product Registration

Please fill out the product registration card and return it immediately. Returning this card allows us to contact you if needed.

Product Information

Keep your sales receipt for proof of purchase to obtain warranty parts and service and attach it here. Record the serial number and model numbers — both numbers are located on the product.

Model No. ________________________

Serial No. _________________________

Purchase Date ______________________

Place of purchase ____________________

End User License Agreement

IMPORTANT-READ CAREFULLY: This End User License Agreement (“Agreement”) is a legal agreement between you and Thomson Inc. (“Thomson”) for the Thomson Lyra device application/driver software program and associated documentation, if any (“Program”).

ACKNOWLEDGMENT

BY INSTALLING THE SOFTWARE OR CLICKING ON THE ACCEPTANCE BUTTON OF THE SOFTWARE, COPYING OR OTHERWISE USING THE PROGRAM, YOU ACKNOWLEDGE AND AGREE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT, AND AGREE TO BE BOUND BY ITS TERMS AND CONDITIONS. IF YOU DO NOT AGREE TO THE TERMS OF THIS LICENSE AGREEMENT, CLICK ON THE REJECTION BUTTON AND/OR DO NOT INSTALL THE SOFTWARE AND/ OR DO NOT USE THE PROGRAM.

LICENSE

a) You are granted the license (i) to use the Program on a single workstation and (ii) to make one (1) copy of the Program into any machine-readable form for backup of the Program, provided the copy contains all of the original Program’s proprietary notices.

b) You may transfer the Program and license, only as part of the Thomson Lyra device, to another party if the other party agrees to accept the terms and conditions of this Agreement. If you transfer the Program, you must at the same time either transfer all copies to the same party or destroy any copies not transferred.

End User License Agreement

LICENSE RESTRICTIONS

a) Except for the licenses expressly granted to you in this Agreement, no other licenses are implied.

b) You may not (i) modify, translate, reverse engineer, decompile, disassemble (except to the extent that this restriction is expressly prohibited by law) or create derivative works based upon the Program or (ii) copy the Program, except as expressly permitted herein. You agree that you shall only use the Program in a manner that complies with all applicable laws in the jurisdictions in which you use the Program, including, but not limited to, applicable restrictions concerning copyright and other intellectual property rights.

c) The Program may contain prerelease code that does not perform at the level of a final code release. In this case, the Program may not operate properly. Updated versions of the Program can be downloaded from www.thomson-lyra.com.

d) Thomson is not obligated to provide support services for the Program.

e) The Program is provided with “RESTRICTED RIGHTS”. Use, duplication, or disclosure by the U.S. Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of DFARS

252.227-7013, or FAR 52.227-19, or in FAR 52.227-14 Alt. III, as applicable.

TERM AND TERMINATION

a) The license is effective on the date you accept this Agreement, and remains in effect until terminated by either party.

b) You may terminate this license without any notice or delay, by destroying or permanently erasing the Program and all copies thereof.

c) If you use, copy, modify, or transfer the Program, or any copy, in whole or part, except as expressly provided for in this license, your license is automatically terminated.

d) When the license is terminated, you must destroy or permanently erase the Program and all copies thereof.

End User License Agreement

WARRANTY DISCLAIMER

THE PROGRAM IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE OR NON-INFRINGEMENT. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU (AND NOT THOMSON, ITS SUPPLIERS, ITS AFFILIATES OR ITS DEALERS) ASSUME THE ENTIRE COST FOR ALL NECESSARY REPAIR OR CORRECTION.

This exclusion of warranty may not be allowed under some applicable laws. As a result, the above exclusion may not apply to you, and you may have other rights depending on the law that applies to you

OWNERSHIP RIGHTS

All title and intellectual property rights in and to the Program and any copies thereof are owned by Thomson or its suppliers. All title and intellectual property rights in and to the content which may be

accessed through use of the Program is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This license grants you no rights to use such content.

LIMITATION OF LIABILITY

a) TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THOMSON, ITS AFFILIATES, OR ITS DEALERS BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, CORRUPTION OF FILES, LOSS OF BUSINESS INFORMATION OR ANY OTHER PECUNIARY LOSS) REGARDLESS OF CAUSE OR FORM OF ACTION, INCLUDING CONTRACT, TORT OR NEGLIGENCE, ARISING OUT OF THE USE OF OR INABILITY TO USE THE PROGRAM, EVEN IF THOMSON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

End User License Agreement

b) YOU ASSUME RESPONSIBILITY FOR THE SELECTION OF THE APPROPRIATE PROGRAM TO ACHIEVE YOUR INTENDED RESULTS, AND FOR THE INSTALLATION, USE, AND RESULTS OBTAINED.

WINDOWS MEDIA

This version of the Lyra Personal Digital Player (“Lyra Player”) contains software licensed from Microsoft that enables you to play Windows Media Audio (WMA) files (“WMA Software”). The WMA Software is licensed to you for use with the RCA/THOMSON Portable Audio Device digital music player under the following conditions. By installing and using this version of the Lyra Player, you are agreeing to these conditions. IF YOU DO NOT AGREE TO THE CONDITIONS OF THIS END USER LICENSE AGREEMENT, DO NOT INSTALL OR USE THIS VERSION OF THE Lyra Player.

GRANT OF LICENSE. The WMA Software is only licensed to you as follows:

You may use this version of the Lyra Player containing the WMA Software only with the Portable Audio Device player.

You may not reverse engineer, decompile, or disassemble the WMA Software, except and only to the extent that such activity is expressly permitted by applicable law in spite of this limitation.

You may transfer your right to use this version of the Lyra Player only as part of a sale or transfer of your Portable Audio Device player, on the condition that the recipient agrees to the conditions in this End User License Agreement. If the version of the Lyra Player that you are transferring is an upgrade, you must also transfer all prior versions of the Lyra Player that you have which include the WMA Software.

The WMA Software is protected by copyright and other intellectual property laws. This protection also extends to documentation for the WMA Software, whether in written or electronic form.

End User License Agreement

MICROSOFT IS NOT PROVIDING ANY WARRANTY OF ANY KIND TO YOU FOR THE WMA SOFTWARE, AND MICROSOFT MAKES NO REPRESENTATION CONCERNING THE OPERABILITY OF THE WMA SOFTWARE.

The WMA Software is of U.S. origin. Any export of this version of the Lyra Player must comply with all applicable international and national laws, including the U.S. Export Administration Regulations, that apply to the WMA Software incorporated in the Lyra Player.

THIRD PARTY SOFTWARE

ANY THIRD PARTY SOFTWARE THAT MAY BE PROVIDED WITH THE PROGRAM IS INCLUDED FOR USE AT YOUR OPTION. IF YOU CHOOSE TO USE SUCH THIRD PARTY SOFTWARE, THEN SUCH USE SHALL BE GOVERNED BY SUCH THIRD PARTY’S LICENSE AGREEMENT, AN ELECTRONIC COPY OF WHICH WILL BE INSTALLED IN THE APPROPRIATE FOLDER ON YOUR COMPUTER UPON INSTALLATION OF THE SOFTWARE. THOMSON IS NOT RESPONSIBLE FOR ANY THIRD PARTY’S SOFTWARE AND SHALL HAVE NO LIABILITY FOR YOUR USE OF THIRD PARTY SOFTWARE.

GOVERNING LAW

This Agreement is governed by the laws of France, without regard to its conflict of laws.

GENERAL TERMS

This Agreement can only be modified by a written agreement signed by you and Thomson, and changes from the terms and conditions of this Agreement made in any other manner will be of no effect. If any portion of this Agreement shall be held invalid, illegal, or unenforceable, the validity, legality, and enforceability of the remainder of the Agreement shall not in any way be affected or impaired thereby. This Agreement is the complete and exclusive statement of the agreement between you and Thomson, which supersedes all proposals or prior agreements, oral or written, and all other communications between you and Thomson, relating to the subject matter of this Agreement.

Table of Contents

Important Information .............................................................2

Warning .................................................................................................... 2

End User License Agreement ................................................... 4

Table of Contents ...................................................................... 9

Before You Begin .................................................................... 12

Unpacking Your Unit ............................................................................. 12

Things to consider before you get started... ....................................... 13

Computer System Requirements ................................................... 13

Warning .......................................................................................... 13

Caution ............................................................................................ 13

Caution While Driving .................................................................... 13

Back up your data ........................................................................... 14

Important Battery Information ...................................................... 14

Getting Started : Software Setup.......................................... 15

Inserting the Included CD-ROM into CD-ROM Drive ........................... 15

Installing Software Components .......................................................... 16

Install the USB Driver (Windows 98SE and Me Only) ................... 16

Install System Applications ............................................................. 17

Install MusicMatch Jukebox ........................................................... 18

Install Additional Services .............................................................. 19

Launch the MusicMatch software ................................................. 19

Install MusicMatch Plug-in ............................................................. 19

The MusicMatch icon found in your computer’s system tray ............ 19

Connecting Thomson Lyra to the Computer ................................. 20

Transferring Files to Thomson Lyra Jukebox ....................................... 21

Transfer Files via MusicMatch Jukebox ......................................... 21

Transfer Files via W indows Explor er (Drag and Drop) ................. 22

Create Pre-defined Playlists and T ransferring them to the

Jukebox ........................................................................................... 23

Table of Contents

Disconnecting Your Lyra from the Computer ...................................... 24

System Tray Applications ...................................................................... 25

Profile .............................................................................................. 25

Verify User Playlists ......................................................................... 26

Updating System File ...................................................................... 26

LyraSync ........................................................................................... 27

MyDislikes ....................................................................................... 28

Lyra•Jukebox .......................................................................... 29

Overview of General Controls .............................................................. 29

Front View ....................................................................................... 29

Navigation Controls ................................................................ 29

Left View ......................................................................................... 30

Right View ....................................................................................... 31

Top View .......................................................................................... 31

Display Overview .................................................................................. 32

Menu Navigation ............................................................................ 33

Basic Operation ...................................................................................... 33

Selecting Music Mode .................................................................... 34

Music Playback Display ................................................................... 34

Music Playback Operation .............................................................. 35

Step-by-Step Example ..................................................................... 36

Navigation Menu ............................................................................ 38

Playlists ................................................................................................... 40

My Selections .................................................................................. 40

My Dislikes ...................................................................................... 42

View User Playlists .......................................................................... 43

Pre-defined Playlists ....................................................................... 44

Save MySelections or MyDislikes as a Playlist ............................... 44

Clear Playlists .................................................................................. 45

All Files ................................................................................................... 46

Additional Features ............................................................................... 47

Repeat ............................................................................................. 47

Shuffle ............................................................................................. 48

Profiler ............................................................................................. 51

Table of Contents

Selecting Radio Mode ........................................................................... 52

Preset Station ......................................................................................... 52

Tuning to a Station ................................................................................ 52

Setting Preset ......................................................................................... 53

Selecting Preset Station .................................................................. 54

Clearing Preset ................................................................................ 54

Suppressing Stereo Signal .............................................................. 54

Record FM Radio .................................................................................... 55

View FM Recording ........................................................................ 56

Selecting Recording Duration ........................................................ 56

Selecting Recording Quality ........................................................... 56

Delete FM Recording ...................................................................... 57

System Settings ..................................................................................... 58

Customize Music Menu .................................................................. 59

System Info ............................................................................................ 60

Connecting your Thomson Lyra Jukebox to your Car Stereo............. 61

Connecting Your Thomson Lyra Jukebox on your stereo system ...... 62

Check for Updates ................................................................................. 63

Portable Hard Drive Capability ............................................................. 63

Tips and Troubleshooting ..................................................................... 64

FAQ (Frequently Asked Questions) ...................................................... 66

Specifications & System Requirements ................................................ 66

Hardware ........................................................................................ 66

Hard Disc ......................................................................................... 67

Software .......................................................................................... 67

PC Hardware Requirements ........................................................... 68

Accessories ...................................................................................... 68

Miscellaneous Specifications .......................................................... 68

Repair Centers - Hungary ...................................................................... 69

Repair Centers - Poland ......................................................................... 70

Repair Centers - Russia .......................................................................... 71

Repair Centers - Czech Republic ........................................................... 73

Before You Begin

Unpacking Your Unit

Your Lyra Jukebox came with ever ything you need to make music portable — all of the items shown below should have been packed in the box with your Lyra Jukebox.

Thomson Lyra Jukebox



Music Management CD Contains the Lyra Jukebox applications & MusicMatch Jukebox software

AC/DC adapter charger

Mini USB cable Plug the small end into the USB on your Lyra Jukebox, and plug the other end into your computer’s USB port. Go to page 20 for connection details.

Line out cable Connects Lyra Jukebox to your audio system.

For details, go to page 62.

Car adapter kit Car cord adapter / cassette adapter

Go to page 61 for instructions.

Clip Phones Go to page 37 for instructions.

Illustrations contained within this publication are for representation only and subject to change.

Before You Begin

Things to consider before you get started...

Computer System Requirements

• Pentium III 500MHz or higher recommended

Macintosh iMac G3 or higher

•Windows ®98SE, Me, 2000, or XP

Mac OS X Version 10.1.5 or higher

• Internet Explorer 4.0 or higher

• Internet access

• 100MB free hard disk space for the software

• 64MB RAM (128 MB recommended)

• CD-ROM drive capable of digital audio extraction

• USB port (2.0 recommended)

• Installed sound card

• 16- bit color video card

Warning

Use of this product is for your personal use only . Unauthorized recording or duplication of copyrighted material may infringe upon the rights of third parties and may be contrary to copyright laws.

Caution

• Keep product out of direct sunlight. Exposure to direct sunlight or extreme heat (such as inside a parked car) may cause damage or malfunction.

• Do not expose to rain or moisture.

Caution While Driving

Use of headphones while operating an automobile or moving vehicle is not recommended and is unlawful in some states and areas. Be careful and attentive on the road. Stop operation of the unit if you find it disruptive or distracting while driving.

Before You Begin

Back up your data

As with any portable device that has a hard drive, you must back up the drive regularly. RCA and Thomson are not responsible for lost data.

Important Battery Information

• The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not separately recharge, disassemble, heat above 100C (212F), or incinerate.

• Battery replacement should only be made by trained technicians. Refer to Thomson Warranty for details.

• Do not attempt to open the unit. No user servicable parts inside.

•To reduce risk of injury, charge only rechargeable batteries recommended by the manufacturer for this product. Other types of batteries may burst causing damage and personal injury.

• Keep the unit away from children. Do not disassemble or dispose product in fire.

• Use only the specified chargers which were packaged with the product. Use of another charger may present a risk of fire or explosion.

Getting Started: Software Setup

The Music Management CD that came with your L yra Jukebox contains all of the necessary softwar e components you need to make your L yra Jukebox work properly.

These components do the following:

• install USB driver for Windows 98SE/Me users (Refer to page 16)

• enable you to transfer files fr om your computer to your Lyra Jukebox

• profile, format and sort the contents, update the system files (Refer to page 25)

• use the MusicMatch Jukebox software to organize your music collection and transfer the music to your Lyra Jukebox

The MusicMatch Jukebox™ software compresses audio files (from music CDs) to the mp3, mp3PRO or Windows Media Audio (WMA) format so you can play them on your Lyra Jukebox. The MusicMatch softwar e also enables you to download files from the internet that are already compressed and then transfer those files to your L yra Jukebox (or play the music on your computer).

Inserting the Included CD-ROM into CD-ROM Drive

Note: Do not connect your Lyra Jukebox to your computer before you have installed the required drivers. (Windows 98SE/Me only)

1. Turn on your computer and place the Music Management CD that came with your Lyra Jukebox into your computer.

IMPORTANT: Don’t connect the USB cable to the PC or Lyra Jukebox before or during the driver installation.

If you’re running Windows 2000, no additional drivers are required. If you’re running Windows 98SE/Me, you must install the USB drivers from the CD-ROM in order for the Lyra Personal Jukebox to function properly.

Getting Started: Software Setup

2. If the setup screen does not appear, double click My Computer, double click your CD-ROM drive icon, and double click Install to run the installer.

The Lyra Jukebox and MusicMatch Jukebox quick start program runs.

3. Select your Thomson L yra model on the startup screen and click Install to access installation programs corresponding to your Lyra device.

4. Click on the software component you want to install. See next Section for details.

Installing Software Components

Install the USB Driver (Windows 98SE and Me Only)

For Windows 98SE and Me systems, you need to install a USB driver before your computer can recognize your Lyra Jukebox.

1. Click Install USB Driver/System Applications to install the required driver for your Lyra Jukebox.

2. Follow the on-screen instructions to install all necessary files.

3. Click Finish to complete installation and return to the startup screen.

Getting Started: Software Setup

Install System Applications

1. Click Install System Application to install

2. Follow the on-screen instructions to

3. Click Finish to complete installation and

applications that will help you better manage your Lyra Jukebox.

Note: The installation program will detect whether your system requires a USB driver. If you see the Install USB driver/System Applications option, click it to install the USB driver. (Refer to the previous section for details). The program will install the USB driver first, restart the computer, and then begin to install the System Application software.

install all necessary files.

return to the startup screen.

(Refer to page 25 for further system application details)

Getting Started: Software Setup

Install MusicMatch Jukebox

MusicMatch Jukebox is a music management software used to organize and manage digital audio files and can be used to transfer the music to your Lyra Jukebox.

1. Click Install MusicMatch Jukebox to run the MusicMatch setup program.

Wait while the installation program begins. It may take up to 20 seconds for the installer to start.

Note: It is recommended to uninstall any previous installations of the MusicMatch Jukebox software before proceeding. After the uninstall process has been completed, delete the MusicMatch folder found under C:\Program Files. If you do not wish to uninstall the previous MusicMatch Jukebox software, go to “Install MusicMatch Plug-in” on page 19.

2. Follow the on-screen instructions to complete MusicMatch installation.

For more information on MusicMatch Jukebox, click Tutorials on the CD or go to www.musicmatch.com.

Getting Started: Software Setup

Install MusicMatch Plug-in

MusicMatch requires a plug-in for your particular device in order to transfer files from your computer to your Lyra Jukebox.

1. Click Install MusicMatch Plug-in.

2. Follow the on-screen instructions to install all necessary files.

3. Click Finish to complete installation and return to startup screen.

Install Additional Services

Click on Install ID3man by Auditude, Get 100 Free mp3 Tracks from eMusic, Moodlogic or Try Rhapsody Music services for additional digital music

services provided by our partners.

Launch the MusicMatch software

The MusicMatch icon found in your computer’s system tray.

The MusicMatch software converts audio files to the mp3, mp3PRO and WMA format so you can play them on your L yra Jukebox.

1. Remove the Music Management CD from your computer.

2. Start the MusicMatch Jukebox software (double click on the MusicMatch icon in your system tray or on your desktop).

Getting Started: Software Setup

Connecting Thomson Lyra to the Computer

Connect the Lyra Jukebox to your computer with the mini USB cable provided. Turn on the unit by pressing the ON button. Press and hold the Play button to start USB transfer. The Lyra Jukebox will appear as a Removal Disk drive letter.

Note: It might take several seconds for the device (the Lyra Jukebox) to be detected, especially in Windows 2000/XP. Click Refresh in My Computer or Explorer to make sure the device has been detected.

Note: The Lyra Jukebox is capable of transferring files at hi-speed mode of USB 2.0. This is up to 40 times faster than USB 1.1. If USB

2.0 port is available on your computer, use it to connect to your Lyra Jukebox. The Lyra Jukebox is still backward compatible with the older USB 1.1 ports. However, you will not be able to take full advantage of the potential speed increase.

Getting Started: Software Setup

Transferring Files to Thomson Lyra Jukebox

You can transfer files to your L yra Jukebox via MusicMatch Jukebox or via Windows Explor er.

If your Lyra Jukebox isn’ t already connected to your computer, connect the Lyra Jukebox to the computer using the provided USB cable as illustrated above.

Note: The USB port acts as a power source for your Lyra Jukebox.

Note: Do not disconnect the USB cable during music download.

Doing so may corrupt system files or the files being downloaded.

Transfer Files via MusicMatch Jukebox

1. Drag and drop desired tracks from the Music Library to the Playlist display and save the playlist.

Note : Be sure to save the playlist or it will not be displayed on the playlist window of the Portable Device Manager screen.

2. From the menu area, select Files/Send to Portable Device or click Send to Portable under the copy item on the left side of the MusicMatch

Jukebox screen to display the Portable Device Manager screen.

3. Click on Options and select your portable device under Select Device. Click OK. Your device should be listed under Portable Device.

4. Select the playlist item and drag it to the active device listed under Portable Device. Only those playlists saved in step 1 are displayed on the playlist window . The songs in the playlist will now be automatically transferred to your Lyra Player.

USB 2.0 Hi-speed capable

During transfer a progress indicator appears in the Portable Device Manager screen, and

connected...

Do not unplug

“Do not unplug” flashes in the Lyra Jukebox’s LCD.

Getting Started: Software Setup

When the transfer is finished, the Lyra Personal Jukebox Profiler application may

automatically run so it can sort/profile the newly transferred files.

You can run the profiler manually by right clicking on the Lyra icon on the System Tray Area. Refer to page 25 for details.

Caution: Make sure all data are transferred to the Lyra Jukebox before unplugging the USB cable.

If you’re running Windows 2000 you must stop the device before unplugging it. Click the icon (the Unplug or Eject hardware icon) from the system tray and select the USB Mass Storage device for the drive letter associated with the Lyra Jukebox, and select the device you want to stop. See the Windows Help for details about the Unplug or Eject Hardware topic.

Transfer Files via Windows Explorer (Drag and Drop)

If your Lyra Jukebox isn’ t already connected to your computer, connect the Lyra Jukebox to the computer using the provided USB cable as illustrated on page 20 and turn on the unit.

From Windows Explor er, highlight all the files/folders you want to transfer to your Lyra Jukebox and drag them to the drive letter that is associated with it.

Note: You must profile your contents after file transfer in order for the new files to appear in the Navigation Menus. Refer to page 25 for profiling details.

Getting Started: Software Setup

Create Pre-defined Playlists and Transferring them to the Jukebox

Pre-defined playlists can be created on your PC using MusicMatch Jukebox. Refer to the MusicMatch Jukebox User Manual for details. Note that only playlists cr eated with songs stor ed on the Lyra Jukebox will work on the Lyra. Use Windows Explorer to transfer pre-defined playlists to your L yra Jukebox.

If your Lyra Jukebox isn’ t already connected to your computer, connect it using the provided USB cable and turn the unit on.

From Windows Explor er, highlight the predefined playlists that you have created in MusicMatch Jukebox and drag them to the lyra_playlists directory in the drive letter associated with your L yra Jukebox.

Note: You must profile your contents after file transfer in order for the new files to appear in the Navigation Menus. Refer to page 25 for profiling details.

Getting Started: Software Setup

Disconnecting Your Lyra from the Computer

USB 2.0 Hi-speed capable

connected...

Safe to unplug

Note: Before disconnecting the USB cable from the computer or the Lyra Jukebox, be sure the “Safe to unplug” message is displayed.

From the System Tray, double click the left mouse button on the icon and select Unplug or eject hardware. Select the drive corresponding to your Lyra player.

The Stop a Hardware device screen appears. Select the device to be stopped again for confirmation and click OK.

You can also stop your L yra Jukebox by right clicking on the icon from the system tray and selecting the drive corresponding to your player.

Getting Started: Software Setup

System Tray Applications

Profile

New files that are transferred to your Lyra Jukebox using W indows Explorer (drag and drop) will not appear in the Navigation Menus until you profile the contents. If MusicMatch Jukebox was used to transfer files, profiling will be done automatically.

1. Connect your Lyra Jukebox to the computer using the pr ovided USB cable if it is not already connected and turn the unit on.

2. Right click on the Lyra icon in the System tray (bottom right hand corner of the computer screen.

3. Select the Profile Device Content... item to start the profiling and sorting contents.

4. Click Done when profiling is complete.

Caution: Make sure all data are transferred to the Lyra Jukebox before unplugging the USB cable.

Note: The Lyra Jukebox can also perform profiling. Refer to page 51 for details.

Getting Started: Software Setup

Updating System File

You can upgrade your Lyra Jukebox or repair damaged system files on your device by downloading the latest firmware from http://www.thomson-lyra.com. After you have downloaded the latest firmware, follow the steps below to update your system files.

1. Connect your Lyra Jukebox to the computer using the pr ovided USB cable if it is not already connected and turn the unit on.

2. Right click on the Lyra icon in the System tray (bottom right hand corner of the computer screen and select the Update System File... item to start updating your system with the latest firmware.

Possible cause of system file damage:

• System files and/or folders were accidentally deleted from the device,

•You have formatted your Jukebox.

Verify User Playlists

Verify items in the User Playlists under the lyra_playlist system folder exists on the Lyra Jukebox.

1. Connect your Lyra Jukebox to the computer using the pr ovided USB cable if it is not already connected and turn the unit on.

2. Right click on the Lyra icon in the System tray (bottom right hand corner of the computer screen) and select the Verify User Playlists... item.

Getting Started: Software Setup

LyraSync

Files and folders can be synchr onized between your PC and your Lyra Jukebox.

1. Connect your Lyra Jukebox to the computer using the pr ovided USB cable if it is not already connected and turn the unit on.

2. Right click on the Lyra icon in the System tray (bottom right hand corner of the computer screen and select

LyraSync.

3. The LyraSync Options screen appears.

4. Click Insert to select the paths of files and folders to synchronize between your PC and the Device. Click OK.

5. Select the desired LyraSync direction.

• PC overwrites Device

• Device overwrites PC

• Synchronize PC and Device

6. Click Synchronize to start.

Getting Started: Software Setup

MyDislikes

Items in the MyDislikes playlist can be viewed and deleted in MyDislikes.

1. Connect your Lyra Jukebox to the computer using the pr ovided USB cable if it is not already connected and turn the unit on.

2. Right click on the Lyra icon in the System tray (bottom right hand corner of the computer screen and select

MyDislikes....

3. Files tagged as dislike on the unit will show on the Lyra Jukebox MyDislikes screen. Highlight files to remove from the MyDislikes playlist and click Remove Dislikes.

Note: Files will be removed from your Lyra Jukebox, playlist and MyDislikes playlist permanently.

4. Press Done to close the MyDislikes screen.

Overview of General Controls

Lyra • jukebox

2 4

Front View

1. LCD (Liquid Crystal Display) - This is where the Lyra’s user interface appears (go to page 34 for an explanation of the items that appear on the LCD during playback).

Navigation Controls

2. SELECT - Selects a highlighted item in navigation mode. During music menu navigation, press SELECT to tag any item to be included in the MySelections playlist. These items can be individual songs, or a group of songs under an artist, album, etc. Press SELECT on a tagged item to remove it from MySelections playlist. During music playback, press SELECT to add the current song to the MySelections or MyDislikes playlist. In radio mode - Saves the current radio station as a preset station.

Lyra • jukebox

3.Up ( ) - Scrolls up Lyra Jukebox menu and moves the highlight up. During music and radio playback - Increases volume level.

4. Down ( ) - Scrolls down Lyra Jukebox menu and moves the highlight down. During music and radio playback - Decreases volume level.

5. Enter / Next ( ) - Enters the highlighted item.

- Views the content of the highlighted item.

- Shows info screen during menu navigation when the item selected is a song. In music mode - press and release to skip forward to the next song. To scan forward in the current song, press and hold. During preset tuning in radio mode - Selects the next preset station. During manual tuning in radio mode - Tunes up radio frequency.

6. Back / Previous ( ) - Returns to the previous menu. In music mode - Press and release to skip back to the beginning of the song or the previous song. To scan backwards in the song that’s playing, press and hold. During preset tuning in radio mode - Selects the previous preset station. During manual tuning in radio mode - Tunes down radio frequency.

Left View

7. USB port - Attach the small end (Type mini-B) of the mini-USB cable here. Attach the large end (Type A) to your computer. The Lyra Jukebox will also get power from the USB port when connected. Plug in the AC power adapter here. When you plug in the AC adapter, the battery inside the Lyra Jukebox automatically starts charging.

Lyra • jukebox

Right View

8. Headphones jack ( ) - Insert the headphones plug here.

9. ON / Play / Pause ( ) - When the power is off, press to turn on the

unit. When the unit is on in music mode, press to play or pause music. In radio mode, press to select between tune and preset mode. Press and hold to switch between music and radio mode.

10. OFF / Stop ( ) / Reset - When the unit is in stop mode, press to turn the power off. When music is playing, press to stop playback. During radio recording, press to stop recording. When the unit does not respond, press and hold for more than 10 seconds to reset the unit.

11. MENU / Lock ( ) - Accesses the Menu.

- Press and hold to activate and deactivate key lock.

Top View

12. FM REC - Starts or pauses radio recording.

Lyra • jukebox

Display Overview

MUSIC

Artist

Artist/Album Album Title Genre Year Playlists All Files

1. The relative icon lights to show the sorting method of the current folder.

2. The menu level you are currently at.

3. The items in the current menu level.

4. The lock icon is displayed when the key lock function is activated. This

can be activated by pressing and holding the MENU/ Lock button until the lock icon is displayed. To unlock, press and hold again until the lock icon is turned off.

5. Charger is connected.

6. The battery indicator shows battery level.

- Battery full

- Battery empty

7. The current position you are at among all other items in the current menu level.

Lyra • jukebox

Basic Operation

The information in this section presumes you’ve successfully transferred files to your Lyra Jukebox, and you’re ready to play some music.

If you need specific set-up information (downloading music, transferring files, installing software), go to “Getting Started: Software Setup” on page 15-28.

If you want more detailed information about the Lyra Jukebox’s features, go to page 29.

Understanding how to navigate through the Lyra Jukebox’s menu system, combine with how the buttons operate, will give you information you need for basic functionality.

Menu Navigation

1. To scroll up and down and highlight items on screen, press the Up ( ) or Down ( ) arrow.

2. To enter and view the submenu, press the Enter / Next ( ) arrow button.

3. To go back to the previous menu level, press the Back / Previous ( ) arrow button.

4. To view the menu at any given time, press the MENU button.

Music Menu Radio Menu

Go to Radio Repeat Off Shuffle Off DSP Flat Profile Content Settings System Info

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

Lyra • jukebox

√

Selecting Music Mode

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

Music Playback Display

1. If the unit is in radio mode, press the MENU / Lock ( ) button to view the Radio menu.

2. Use the Up ( ) or Down ( ) arrows to select Go to Music and press SELECT for music mode.

2 3

1223 / 1921

0:34

Title

Artist

Album

Genre

Year

128kbps

Bass

√

1223 / 1921

0:34

Title

Artist

Album

Genre

Year

128kbps

1. Displays song information.

2. The current song number out of the total number of songs on the unit.

3. Song elapse time.

4. Random icon.

5. The repeat icon is displayed when the repeat feature is activated.

- Indicates repeat one song

- Indicates repeat all songs in the current play mode.

6. Shows mp3 Bitrate and song format (mp3 / mp3PRO / wma).

7. √ - Indicates the song is included in the MySelections playlist.

x - Indicates the song is included in the MyDislikes playlist.

8. Current DSP selection (Flat / Bass / Rock / Pop / Jazz / Graphic EQ).

9. The volume bar shows on the display for a few seconds when the

volume is adjusted.

Lyra • jukebox

Music Playback Operation

• Once the item that you want to play is on the screen, press Play / Pause ( ) to begin playback. This item can be an artist, an album, a playlist, or a song. Press again to pause playback. The unit will automatically power off after remaining in pause mode for more than the Power Save interval (length of this Power Save interval can be modified in the Setting menu).

•To scan backwards in the track that’s playing, press and hold the Back / Previous ( ) button.

•To scan forward in the track that is playing, press and hold the Enter / Next ( ) button.

•To go to the next track, press and release the Enter / Next ( ) button.

•To go to the previous track, press and release the Back / Previous ( ) button.

•To stop playback, press the Stop ( ) button on the side of the unit. The display returns to the previous menu level.

•To turn up the volume, press VOL ( ) . The volume bar updates to show the increase in volume level.

•To turn down the volume, press VOL ( ) . The volume bar updates to show the decrease in volume level.

•To add an item to MySelections list, press SELECT to tag it (in navigation mode or during playback). You can add an album, an artist, or individual songs. Songs saved in this list can be played and viewed through the Playlists menu.

•To add a song to the MyDislikes list, press the SELECT button to tag the song. (only active during playback).

•To access the song information screen, press Enter / Next ( ) in navigation mode.

Lyra • jukebox

Step-by-Step Example

The following example illustrates (with more detail than the previous information) how you find the song you want to play .

1. These instructions presume you’ve already done the following:

• Installed the MusicMatch Jukebox softwar e and the Lyra Jukebox profiler application (go to page 25 for detailed instructions).

•Transferred music from your computer to the Lyra Jukebox (page 18 has detailed instructions) and profiled the contents of the Lyra Jukebox through MusicMatch Jukebox or the Profiler software.

Note: The music you’re transferring could be from a CD you put in your computer, the internet, or music you already had loaded onto your computer.

2. If you haven’t already unplugged the Lyra Jukebox from your computer, disconnect the USB cable from the Lyra Jukebox.

Note: If you’re running Windows 2000, you must stop the device before unplugging it. Click the icon (the Unplug or Eject hardware icon) from the system tray and select the USB Mass Storage device for the drive letter associated with the Lyra Jukebox, and click STOP. See the Windows Help for details about the Unplug or Eject Hardware topic.

3. If you’ve fully char ged the battery (the Lyra Jukebox needs to be plugged in for about 4 hours before the battery is fully charged), the display shows “Batteries fully charged.”. Disconnect the AC adapter from the outlet and then from your Lyra Jukebox.

Note: If the battery isn’t fully charged, keep the Lyra Jukebox plugged in while you listen to the music you’ve transferred from your computer.

Lyra • jukebox

4. Connect the clip phones to your Lyra Jukebox (inser t the end of the clip phones connector into the phones jack on the side of the Lyra).

How to Use Your Clip Phones (The e.clipz)

The right ear clip phone is labeled R while the left ear clip phone is labeled L.

a. Pull the ear hook away from the ear pad

slightly. You will hear a click sound.

CLICK

b. Slide the ear hook behind the ear with

the ear pad on the front of the ear. Rotate the clip phone so the ear pad fits closely with the ear.

c. Lock the clip phone in place by pushing

down on the top of the ear hook until it locks.

d. For best sound quality, make sure the

earpad fits closely with your ear .

5. If your Lyra Jukebox isn’ t already on, turn it on (press the ON / Play / Pause ( ) button). The Thomson Lyra logo flashes on the scr een, and then the main Menu appears.

Lyra • jukebox

Playlists

Lyra Jukebox has 2 System Playlist selections: MySelections and MyDislikes.

My Selections

You can create a MySelections temporary playlist using the Lyra Jukebox.

- The song is included in MySelections.

- If the item is a folder, all the songs in the folder is included in MySelections.

- If the item is a folder, some of the songs in the folder is included in MySelections.

ALBUM 1

Song 1 Song 2 Song 3 Song 4 Song 5 Song 6

1. In navigation mode, move the cursor to highlight the item to be selected.

• To scroll up and down the display,

press the Up ( ) or Down ( ) button.

• To enter the highlighted folder, press

the Enter / Next ( ) button.

• To go back to the previous folder,

press the Back / Previous ( ) button.

• To view music sub-menu, press the

MENU button.

Lyra • jukebox

ALBUM

Album 1 Album 2 Album 3 Album 4

Title 1

Artist 1

Album 2

Genre

Year

11/100 128kbps

0:10

√

ALBUM 1

Song 1 Song 2 Song 3 Song 4 Song 5 Song 6

2. If the item is an item (artist, album, etc.), press SELECT to tag all the songs belonging to the selected item and place them into the MySelections playlist.

If the item is a song, press SELECT to tag the song and place it into the MySelections playlist.

The relative icon ( or )will show beside any folder or song that has been tagged.

During playback, a √ icon is displayed

to show the song is included in MySelections playlist.

3. To de-select a selected item, use the navigation buttons to highlight the selected item and press SELECT.

Refer to “View User Playlist” on page 43 to view items in the MySelections playlist.

To clear MySelections playlist, refer to “Clear Playlists” on page 45.

Note: MySelections is not active in All Files mode.

Lyra • jukebox

My Dislikes

In playback mode, you can tag songs you don’t like and place them into the MyDislikes playlist.

SELECT A SONG

MySelections MyDislikes

Title

Artist

Album

Genre

Year 1/100 128kpbs 0:55 x

1. When a song is playing, press the SELECT button.

2. Press Up ( ) or Down ( ) to select MyDislikes.

Press SELECT to tag the song and add it to the MyDislikes playlist.

The x icon will show on the bottom right corner of the display to show the song has been tagged as a “dislike” song.

3. To de-select a song from the MyDislikes playlist, press the SELECT button again while the song is playing.

Note: To clear the MyDislikes playlist, refer to “Clear Playlist” on page 45.

Note: You can also view the MyDislikes playlist on your computer where songs that have been marked can be viewed or deleted. (Refer to System Tray Applications on page 25)

View User Playlists

Lyra • jukebox

MUSIC

Artist Artist/Album Album Title Genre Year Playlists All Files Radio Recordings

PLAYLISTS

MySelections MyDislikes Playlist1 Playlist2 Playlist3

MYSELECTIONS

Song 1 Song 2 Song 3 Song 4

1. Use the Up ( ) or Down ( ) button to scroll and highlight Playlists from the Music menu.

2. Press Enter / Next ( ) to show predefined and system playlists.

3. Scroll up and down the Playlists menu to select the desired playlist to be viewed using the Up ( ) or Down ( ) button.

4. Press Enter / Next ( ) to view tagged items in the selected playlist.

Lyra • jukebox

Pre-defined Playlists

Pre-defined playlists are those playlists created on the PC and transferred to the Lyra Jukebox. Refer to page 23 for details on creating Pre-defined Playlists and transferring them to your Lyra Jukebox.

PLAYLISTS

MySelections MyDislikes Playlists1 Playlists2

Follow the steps under “View System Playlists” to enter the Playlists menu.

All playlists except for MySelections and MyDislikes playlists are pre-defined playlists

Note: Pre-defind Playlists can not be edited on the device.

Save MySelections or MyDislikes as a Playlist

Go to Radio Clear Playlist Save as Playlist Repeat Off Shuffle Off DSP Flat Profile Content Settings

1. Press MENU when the cursor is pointing to MySelections or MyDislikes.

2. Press Up ( ) or Down ( ) to select Save as Playlist and press SELECT.

Lyra • jukebox

SAVE AS PLAYLIST

Save MySelections as :

Playlist3

PLAYLISTS

MySelections MyDislikes Playlists1 Playlists2 Playlists3

Clear Playlists

PLAYLISTS

MySelections MyDislikes Playlist1 Playlist2 Playlist3

3. Name the playlist using the arrow buttons. Press Enter / Next ( ) to move the cursor to the right. Press Back / Previous ( ) to move the cursor to the left. Press Up ( ) or Down ( ) to select a number or a letter.

4. Press SELECT to save.

1. Press MENU when the cursor is pointing to the system playlist to be cleared (MySelections or MyDislikes).

Go to Radio Clear Playlist Save as Playlist Repeat Off Shuffle Off DSP Flat Profile Content Settings

2. Press Up ( ) or Down ( ) to select Clear Playlist and press SELECT.

Lyra • jukebox

All Files

Your Lyra Jukebox is a USB mass storage device that can be used to store any files. To see all of the files that are stored on your Lyra Jukebox:

Artist/Album

MUSIC

Album Title Genre Year Playlists All Files Radio Recordings

ALL FILES

Folder 1 Folder 2 Folder 3 Song 1 Song 2

1. Highlight All Files (press the Up ( ) or Down ( ) arrow button) from the Music menu.

2. Press Enter / Next ( ) (the All Files menu appears). Folders are listed first and individual files are listed next.

Note: The folders and files are sorted in the order they were transferred to the Lyra Jukebox (the folder you transferred most recently appears last in the list of folders and the file you transferred most recently would be the last on the list since file names follow folder names.

Lyra • jukebox

Additional Features

Go to Radio

Clear Playlist Save as Playlist Repeat One Shuffle Off DSP Flat Profile Contents Settings System Info

Repeat

Three repeat options are available on the Lyra Jukebox.

• Repeat Off - No repeat option selected.

• Repeat One - Plays the current song repeatedly. The repeat one icon

will show on the display.

• Repeat All - Plays all songs in the current view repeatedly. The repeat all icon will show on the display.

Press MENU to access music sub-menu.

Go to Radio Clear Playlist Save as Playlist Repeat One Shuffle Off DSP Flat Profile Contents Settings System Info

1. From the music sub-menu, highlight Repeat. (Press the Up ( ) or Down ( ) button).

2. Press SELECT to toggle and select repeat options.

The corresponding repeat icon appears on the display.

Lyra • jukebox

3. Press the Back / Previous ( ) button or the MENU / Lock ( ) button to return to the main Menu.

4. Select the item you wish to play and press the Play / Pause ( ).

If Repeat All is activated, the songs in the folder where playback begins will be repeated

If Repeat One is activated, the selected song where playback begins will be repeated.

5. To de-select the repeat option, repeat steps 1 and 2 and select Repeat Off.

Shuffle

When Shuffle is On, songs are played in random order.

If shuffle is activated, the songs in the view where playback begins are played randomly. After all the songs have been played, the unit will randomly select another folder and shuffle all the songs in the newly selected folder.

Go to Radio Clear Playlist Save as Playlist Repeat One Shuffle Off DSP Flat Profile Contents Settings System Info

1. From the music sub-menu, highlight Shuffle (Press the Up ( ) or Down ( ) button).

Lyra • jukebox

2. Press the SELECT button repeatedly to toggle between Shuffle on and off.

The Shuffle icon will show on the display when shuffle is on.

3. Use the Back / Previous ( ) button or the MENU / Lock ( ) button to return to the main menu.

4. Use the Navigation buttons to select the folder where you want shuffle playback to begin.

Press Play / Pause ( ) to begin playback.

All songs/folders in the folder where playback begins will be played randomly.

5. To de-select the shuffle option, repeat steps 1 and 2 to select Shuffle Off.

Lyra • jukebox

Adjusting DSP Settings

DSP Settings (Digital Signal Processor settings) adjust the various levels of the audio output for different types of songs. For example, the DSP setting for BASS makes the bass sounds more prominent. You can also personalize the levels via the Graphic EQ menu item. The default DSP setting for your Lyra Jukebox is FLAT.

Go to Radio

Clear Playlist Save as Playlist Repeat One Shuffle Off DSP Flat Profile Contents Settings System Info

1. From the music sub-menu, select DSP

using the Up ( ) or Down ( )button.

2. Press SELECT to toggle and select the

DSP setting you want to use.

•FLAT

• BASS

• ROCK

• POP

•JAZZ

• Graphic EQ

Personalizing DSP Output (Graphic EQ menu item)

Graphic EQ: enables you to personalize audio output settings.

DSP

Flat Bass Rock Pop Jazz Graphic EQ

1. From the music sub-menu, select DSP using the Up ( ) or Down ( )button.

2. Press Enter / NEXT ( ) to show a list of DSP options.

3. Select Graphic EQ using the Up ( ) or Down ( ) button.

Lyra • jukebox

GRAPHIC EQ

FREQ=60HZ +8dB

4. Press Enter / Next ( ) to show the Graphic EQ display.

5. Press Enter / Next ( ) to move among frequency adjustments (60Hz, 250Hz, 1kHz, 4kHz and 12 kHz).

Press the Up ( ) or Down ( ) button to adjust levels between +15 and -15.

6. Press the Back / Previous ( ) button to return to the previous menu or the MENU / Lock ( ) button to return to the main Music menu.

Profiler

The application will profile and sort supported audio files on your Lyra Jukebox so you can sort and play them properly.

Note: It is best to profile your contents on your PC after each transfer of music files. Profiling on the unit will take longer and may use up battery power.

Note: Approximately 3500 songs can be profiled on the Lyra Jukebox. If the number of audio files exceed this limit, use your PC for profiling (Refer to page 25).

Go to Radio Clear Playlist Save as Playlist Repeat One Shuffle Off DSP Flat Profile Contents Settings System Info

1. Highlight Profile Contents from the music sub-menu. (Use the Up ( ) or Down ( ) button).

2. Press SELECT to start profiling contents on the Lyra Jukebox or press Back / Previous ( ) to cancel and return to the previous menu level.

Lyra • jukebox

Selecting Radio Mode

Go to Radio

Clear Playlist Save as Playlist Repeat Off Shuffle Off DSP Flat Profile Contents Settings System Info

1. If the unit is in music mode, press the MENU / Lock ( ) button to view the music sub-menu.

2. Use the Up ( ) or Down ( ) button to select Go to Radio and press SELECT for radio mode.

Preset Station

Press the PLAY / PAUSE ( ) button to select between Preset mode and Tune mode.

Tuning to a Station

RADIO

FM 106.1 MHz

Manual Stereo

•Press the Back / Previous ( ) arrow button to tune down radio frequency.

• Press the Enter / Next ( ) arrow button to tune up radio frequency.

Setting Preset

Lyra • jukebox

RADIO

FM 106.1 MHz

Manual Stereo

SAVE AS PRESET

Save FM 106M.1 MHz as

Preset: 1

Name:

SAVE AS PRESET

Save FM 106.1 MHz as

Preset: 1

Name:

SAVE AS PRESET

Save FM 106.1 MHz as

Preset: 1

Name: KMEL Hip-Hop

1. Tune to the station to be saved as a preset station.

2. Press SELECT.

3. Press the Up ( ) or Down ( ) arrow button to select a preset location

4. Press SELECT.

5. Create a name for the preset location using the Up ( ) or Down ( ) arrow button to select an alphabet or number.

Press Back / Previous ( ) to move the cursor to the left.

RADIO

FM 106.1 MHz

Preset 1

KMEL Hip-Hop

Preset Stereo

Press Enter / Next ( ) to move the cursor to the right.

6. Press SELECT to confirm your selection.

Lyra • jukebox

Selecting Preset Station

In preset mode, press Back / Previous ( ) to select the previous preset station and press Enter / Next ( ) to select the next preset station.

Clearing Preset

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

CLEAR PRESET

Clear preset 5?

Change Preset: /

Confirm: SELECT

Cancel:

Suppressing Stereo Signal

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

1. In radio mode, press MENU/ Lock ( ) to view radio sub-menu.

2. Use the Up ( ) or Down ( ) arrow button to select Clear Preset.

3. Press the Enter / Next ( ) button or the SELECT button.

4. Press the Up ( ) or Down ( ) arrow buttons to select the preset location to clear.

5. Press SELECT to confirm.

1. From the radio submenu, use the Up ( ) or Down ( ) arrow buttons to select Mode.

2. Press SELECT to select between Stereo and Mono sound.

Record FM Radio

Lyra • jukebox

RADIO

FM 106.1 MHz

Preset 1

KMEL Hip-Hop

Preset Stereo

RECORD RADIO

Recording...

00:55:34

FM 106.1MHz

RECORD RADIO

Paused...

00:55:34

FM 106.1MHz

1. Tune to the Station to be recorded by following steps under “Tune to a Station” or “Selecting Preset Station”.

2. Press FM REC to start recording.

Press FM REC to pause recording. Press again to resume.

RECORD RADIO

Recording as: FM106.1 [001].mp3

3. Press OFF / STOP ( ) to stop recording.

Lyra • jukebox

Selecting Recording Duration

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

1. From the radio sub-menu, use the Up

2. Press the SELECT button to select

Selecting Recording Quality

Go to Music

Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

1. From the radio sub-menu, press the Up

2. Press the SELECT button to select

View FM Recording

MUSIC

Artist Artist/Album Album Title Genre Year Playlists All Files Radio Recordings

1. From the main Music menu, use the Up

( ) or Down ( ) arrow button to select RecDur.

among 30min, 60min, 90min, 120min and Max.

( ) or Down ( ) arrow button to select RecQua.

between Standard (48k), High (96k) and Max (128k).

( ) or Down ( ) arrow button to select Radio Recordings.

RADIO RECS

FM87.5 [001] FM106.1 [001] FM106.1 [002] FM102.5 [001] FM106.1 [003]

2. Press the Enter / Next ( ) arrow button to view the list of radio recordings in the order they were recorded.

Delete FM Recording

Lyra • jukebox

RADIO RECS

FM87.5 [001] FM106.1 [001] FM106.1 [002] FM102.5 [001] FM106.1 [003]

Go to Radio Clear / Delete Repeat Off Shuffle Off DSP Flat Profile Contents Settings System Info

DELETE

After deleting,

please profile

contents!

Please confirm ! [ < ]: Cancel [ SELECT ] : Delete

1. With the arrow at the radio recording to be deleted, press the MENU / Lock ( ) button to view the radio submenu.

2. Use the Up ( ) or Down ( ) arrow button to select Clear / Delete.

3. Press the SELECT button.

4. Press Back / Previous ( ) to cancel or SELECT to confirm and delete selected radio recording.

Lyra • jukebox

System Settings

You can personalize the display settings for your Lyra Jukebox.

1. Press MENU to view music or radio sub-menus.

2. From the sub-menu, use the Up ( ) or Down ( ) arrow button to select Settings.

Music Menu Radio Menu

Go to Radio Repeat Off Shuffle Off DSP Flat Profile Contents Settings System Info

Go to Music Clear Preset Mode Stereo RecDur 30min RecQua High Settings System Info

SETTINGS

Customize Menu Contrast 0 Backlight 5sec PowerSave min AutoResume Off

3. Press the SELECT button to show setting options.

4. Highlight the display setting (Customize

Menu, Contrast, Backlight, PowerSave or AutoResume) you want to adjust using

the Up ( ) or Down ( ) arrow button.

5. Press SELECT repeatedly to select among options in the following settings.

Contrast (between -5 to +5)

Backlight (Off, 5 sec, 10 sec or 30 sec)

PowerSave (30 sec, 1 min, 2 min or 3min)

AutoResume (Off, On)

6. Press the Back / Previous ( ) button to return to the previous menu or the MENU button to return to the submenu.

Lyra • jukebox

Customize Music Menu

You can set the music menu on the Lyra Jukebox to show and hide certain menu items.

Go to Radio Repeat Off Shuffle Off DSP Flat Profile Contents Settings System Info

1. From the Settings menu, select

Customize Menu. (Press the Up ( ) or Down ( ) button).

SETTINGS

Customize Menu Contrast 0 Backlight Off PowerSave 1min AutoResume Off

Artist On Artist/Album On Album Off Title On Genre On Year On

MUSIC

Artist Artist/Album Title Genre Year Playlists All Files Radio Recordings

2. Press Enter / Next ( ) to view Customize Menu options.

3. Use the Up ( ) or Down ( ) button to select the music menu item to hide or show.

Press SELECT to toggle between On and OFF.

Select On to show the item on the music menu. Select Off to hide the item from the music menu.

4. Press the Back / Previous ( ) button to return to the previous menu or the MENU button to return to the submenu.

Those items that are set to Off will not show on the music menu.

Lyra • jukebox

System Info

System Information shows Lyra Jukebox system details which includes the number of songs you have on your Jukebox, the amount of free space available and your firmware version.

SYSTEM INFO

No of Song : 4627 Free Space :1630.54M Used Space 2370.46M Firmware Info

FIRMWARE INFO

1. For Lyra Jukebox information, select System Info in the music or radio submenu using the Up ( ) or Down ( ) button.

2. Press Enter / Next ( ) to show hardware information.

3. To see firmware information, select

Firmware Info and press Enter / Next ( ).

4. Press the Back / Previous ( ) button or the MENU button to return to the sub-menu.

Lyra • jukebox

Connecting your Thomson Lyra Jukebox to your Car Stereo

The cassette adapter lets you listen to the Lyra in an automobile or RV safely without having to wear headphones.

The car kit is included with your Lyra Jukebox. This accessory kit includes a car cord adapter and a cassette adapter. The car cord adapter lets you power your Lyra from the cigarette lighter socket of a car, truck, or RV. It converts 12-volts to a 5 volt output.

1. Insert the plug on the cassette adapter into the lineout jack on the player. If the headphones are attached, remove them.

2. Insert the cassette (Side A up) into your cassette player making sure the cord is placed in the correct position for your type of player.

3. Remove the cigarette lighter from the socket, and insert the car cord adaptor into the socket.

4. Attach the end of the car cord adapter to the DC IN jack on your Lyra Jukebox (the POWER light comes on).

5. Turn on your Lyra Jukebox, and operate the Lyra Jukebox to play music as described on page 35.

6. Control the volume with the car cassette player.

7. When you’re finished,

A.Remove the cassette adapter from the car cassette player.

B. Turn off the Lyra Jukebox.

C. Remove the car cord’s plug from the cigarette lighter socket.

Cautions: Make sure to place the cassette securely into the slot with the correct direction for the type of player you have. The car cord adapter is designed to be used only with vehicles having negative ground electrical systems. Use of any other car cord adapter may damage your Lyra Jukebox and void your warranty.

Lyra • jukebox

Connecting Your Thomson Lyra Jukebox on your stereo system

Your Lyra Jukebox came with a Line Out Cable that you can use to connect your Lyra to your audio system.

1. Make sure your Lyra Jukebox is off.

2. Connect the black end of the cable to the Headphones jack on your Lyra Jukebox player.

3. Connect the red (audio left) and white (audio right) cables to the corresponding left and right audio jacks on your stereo system.

4. Turn on the power to your audio system, and select the proper input setting on the audio system that corresponds with the way you’ve connected the Lyra Jukebox to the audio system.

5. Turn on your Lyra Jukebox – press the ON / Play / Pause ( ) button.

6. Operate the Lyra Jukebox to play music as described on page 35.

Lyra • jukebox

Portable Hard Drive Capability

Since Lyra Jukebox has a 20-gigabyte (PDP2842) or 40-gigabyte (PDP2845) hard drive, you can use it to transport files - any files, not just music files. Some possible uses for this feature are as follows:

• Create back-ups/archive files.

• Connect to other computers - at work, for example.

•Transport digital photo albums.

•Transport files from one computer to another computer. For example, instead of putting files at work on a zip or accessing them on your home computer via e-mail or remote access, you can put the files on your Lyra Jukebox.

• Capture internet downloads.

• Share information.

Check for Updates

Visit http://www.thomson-lyra.com for the latest news and firmware upgrades for our Lyra Jukebox. You must update your system after new downloads have been made in order for the new applications to be executed (Refer to page 26).

Additional Information

Tips and Troubleshooting

Problem: Player repeats same tracks or all tracks.

• Repeat play is turned on. Press the MENU button to change the play mode.

Problem: Audio distorted at high volume.

• Select another DSP setting.

•Turn down the volume.

Problem: The audio tracks on my Lyra keep skipping or popping.

•You’ll need to re-record the audio track – make sure you close all other applications on your PC when you record.

•Try recording with Error Correction setting turned on.

Problem: Player turns itself off.

•Your Lyra Jukebox turns itself off if you leave it in pause mode or navigation mode for the duration specified in PowerSave.

Problem: Songs aren’t listed in any of the sort modes (Artist, Album, etc.)

• The contents of the Lyra Jukebox haven’t been profiled (sorted) since the last file transfer. Select the Profile Device Contents... menu item from the Lyra Jukebox profiler system tray application on your PC to profile (sort) the contents of the device. The icon in the system tray looks like this .

Problem: Bad or missing file error message displayed on the Lyra Jukebox.

• The Lyra Jukebox system files are corrupted or missing. Select the Update System Files... menu item from the Lyra Jukebox profiler system tray application on your PC to update the necessary system files.

Additional Information

Problem: Lyra Jukebox Profiler application icon – . – doesn’t appear in the system tray.

•You can restart Windows to auto-launch the application, or you can double-click or run the Lyra Jukebox Profiler executable file that’s in the Profiler sub-folder of the installation directory that was specified during the setup process – (Example Directory: C:\Program Files\Thomson\Lyra Jukebox\LyraHDTrayApp\LYRAHD2TrayApp.exe)

If the problem persists, you might need to reinstall the Lyra Jukebox software.

Problem: Lyra Jukebox does not respond to key presses.

• If your Lyra stops responding to key presses, you can reset it by pressing the “OFF” button for about 10 seconds. Most of your settings will be preserved; only the settings that you have changed after your last power off will be lost.

Additional Information

FAQ (Frequently Asked Questions)

Question: What is mp3?

mp3 is an abbreviation for MPEG-1, Layer 3 Audio (MPEG = Motion Picture Experts Group). This is a digital sound encoding and compression process that was developed by the Fraunhofer Institut fur Integrierte Schaltungen and Thomson. mp3 is an international standard and is well suited for the transfer of high quality audio files over telephone or ISDN lines, and over the internet.

Specifications & System Requirements

Hardware

• Dimensions: 23mm D, 70mm W, 85mm H

• Unit Weight: 146grams

• PDP2842 - 20 Giga Byte Storage

PDP2845 - 40 Giga Byte Storage

• Stereo Headphones Jack

•Mini USB Connection Jack

• Battery Operated: Up to 12 hours of playback with internal rechargeable lithium polymer battery.

Additional Information

Hard Disc

• External Hard Disc Drive: When connected to a computer via USB, the Lyra Hard Disc player is capable of storing any file type allowing the user a fast, convenient method of storing, retrieving, and transferring files. Including word processing files, presentations, spreadsheets and any other computer files.

• Capacity: PDP2842 - 20 GB / PDP2845 - 40 GB

• Rotational Speed: 4200 RPM

•Average Access Time: 12 MS

• Connection: USB 2.0, Hi-speed capable

Software

• Includes Music Management software with the Lyra Jukebox applications and the MusicMatch Jukebox software.

MusicMatch Jukebox software lets the user organize all tracks in a digital music library, create custom playlists through drag and drop interface.

– Encodes mp3, mp3PRO and Windows Media Audio (WMA) files.

– Integrated CD Player.

– Export to WAV

– mp3 Equalizer

Additional Information

PC Hardware Requirements

• Pentium III 500MHz or higher recommended

Macintosh iMac G3 or higher

•Windows ®98SE, Me, 2000, or XP

Mac OS X Version 10.1.5 or higher

• Internet Explorer 4.0 or higher

• Internet access

• 100MB free hard disk space for the software

• 64MB RAM (128 MB recommended)

• CD-ROM drive capable of digital audio extraction

• USB port (2.0 recommended)

• Sound card

• 16- bit color video card

Accessories

• CD-ROM Music Management Software

• USB Connection Cable

• AC/DC Adapter

• Clipphone™ Stereo Headphones

• Audio Line-Out Cable

• Car DC Adapter: Supplies power to Lyra Jukebox player from car battery via cigarette lighter plug.

• Car Cassette Audio Output Adapter

Miscellaneous Specifications

• Signal to Noise Ratio (>85dB)

• THD (<0.1%)

1 MusicMatch and MusicMatch Jukebox are registered trademarks of MusicMatch Corp.

2 Warning – This product is not intended for the unauthorized recording or duplication of copyrighted material.

Additional Information

Repair Centers - Hungary

THOMSON SZERVÍZLISTA

Szerviz Helység Cím Telefon és fax

Major Ferenc e.váll. Baja Bara u. 4/D. 79/424-627 T/F Belka Kft. Baja Jelky tér 1. 79/322-333 HIFI-TV-VIDEO Barcs Köztársaság u. 7. (82) 461-680 Infra-Vízió Kft. Békéscsab Luther u. 18. 66/441-665 T/F JUHÁSZ Elektronika Békéscsab Kölcsey u. 17. (66) 324-419 Vidi-Vill Kft. Budapest Akácfa u. 6. 1/3229-698T, 3420-530 Kordován Tv. Kft. Budapest Kordován tér 2. 1/3806-223T, 3806-965 TV-Video Mester Sz. Budapest Rétköz u. 18. 1/2466-000 T/F SERELCO Szerviz Budapest Diószeghy. u. 18. 333-9575, 477-2070, Camcorder Kft. Budapest Budafoki u.35 466-8684, 209-2462/F Speciál Hírad. Tech. Budapest Keleti Károlyu.13 315-0306 SZIGNÁL Szerviz Dabas Bem u. 28. 29/362055 Szigi-Vill Bt. Debrecen Darabos u. 18. 52/413-406T, 319-810F CIVIS Kft. Debrecen Eötvös u.70 52/555-800 LASSIE Bt. Diósd Balatoni út 28. (23) 380-382 MCSB Bt. Dunaújváros Petőfi u.2/a 25/287-074 T/F SZERVÍZ 96 Kft. Eger Reményik u. 18. (36) 313-333 R-NI 98 Bt. Gyöngyös Csokonai u. 2. (37) 500-180 Video-Quadró Kft. Győr Lajta u. 2. 96/418-736T, 415-798F SERELCO Győr Nagy i. U.61 96/ 527-517 TRANS-SAT 2000 Nagykanizsa Csengery u. 33. (93) 318-416 K.SZ.K. Kft. Kalocsa Obermayer tér 7. (78) 462-480 TV-Video Kft. Kaposvár Nádor u. 51. 82/321-526T, 421-526F KAPOS Enter Kft. Kaposvár Zárda u. 18. (82) 429-306 Electro Record Sz Kecskemét Arany J. u. 6. (76) 484-939 Video-Foton Bt. Keszthely Kossuth u. 45. 83/312-867 T/F Krausz és Tsa. Kiskunhalas Táncsics M. u. 6 77/421-972 T/F Video-Phone Kft. Kikunfélgyh. Kossuth u.6 76/461 984 ZELKA Rt. Lenti Dózsa Gy. út 1. (92) 351-160 Rádió-Tv. Kft. Miskolc Kis-Hunyad u. 52. 46/506-129 T, 340-293 Kisjós István e.váll. Nagykanizsa Őrház u. 4. 93/322-507T, 314-104F CLANETT Bt. Nyergesújfal Diófa u. 15. (33) 356-633 Mihalkó György Nyíregyháza Hősök tere 15/a 42/411-358T, 314-521F TECHNO-SAT Kft. Nyíregyháza Pacsirta u.36 (42) 504-432 MŰSZAKI Bolt Orosháza (68) 411-551 Video Klinika Pápa Törökbálint u. 7. 89/310-150 T/F SIGNÁL TV Bt. Pápa Eötvös u. 6. (89) 324-950 T+T TV Szerviz Pécs Hungária u. 13. 72/314-044T, 213-941 SERELCO Pécs Szabadság u.33 72/212-354 TV-SZER Bt. Salgótarján Kassai sor 4. 32/311-750T, 311-021 Javító Karban Salgótarján Úttörők útja 31/A (32) 310-027 Primvill Kft. Soltvadkert Kossuth u.15 78/482-349 Serelco Szeged Berlini Krt.6 62/420019 Ekron Bt. Szekszárd Rákóczi u. 31. 74/316-723T, 316-864 MIKRO-VIDEO Kkt. Szekszárd Kossuth L. u. 3. (74) 312-214 Motesiczky Pál Szentendre Janicsár u. 1. (26) 313-915 Commission Bt. Szentes Kossuth u. 11. 63/313-151 T/F ELEKTRONIKA Szentes Honvéd u. 10. (63) 400-184 Mega-Mikro Kft Székesfehérvár Bátky Zs. U.1 (22) 505-245,246 Videoton Kft Székesfehérvár Berényi út. 72-100 22/ 533-680 INFOTECH Szolnok Ostor u. 2. (56) 343-185 Rátel Kft. Szombathely Kőszegi u. 2-6. 94/312-345T, 328-919 H & K Elektronika Szombathely Puskás Tivadar u 7 (94) 322-203 Elka Kft. Tatabánya Komáromi u. 27. 34/316-188,311-777 Pajor & Tsa. Bt. Vác Radnóti tér 6 (27) 314-274 Vermes András Veszprém Templom u. 3. 88/425-405 T/F Zsámboki TV. Szer Vitnyéd Szent István u. 18. 96/242-395 T/F ZELKA Rt. Zalaegerszeg Mártírok útja 9. (92) 550-629

Additional Information

Repair Centers - Poland

Miasto Nazwa firmy Adres Tel.Kier Telefon

Biała Podlaska SERWIS THOMSON ul. Chełmońskiego 1 0-83 3420461 Białystok P.P.U.H. PERFEKT ul. Brukowa 7 0-85 7420628 Bielsko-Biała ELEKTRONIK SERVICE ul. Legionów 50 0-33 8166065 Bydgoszcz TV COLOR-SERWIS ul. B. Zaleskiego 12 0-52 3795597 Bydgoszcz NOWA TECHNIKA ul. Kijowska 90 0-52 3424822 Chełm ZAKŁAD RADIOWO-TELEWIZYJNY ul. Różana 18 0-82 5633500 Częstochowa VALVO Al. Niepodległości 30 0-34 3632868 Elbląg SERVICE AB - FILIA ul. Leszno 6 0-55 2362154 Gdańsk SERVICE AB - FILIA ul. Grunwaldzka 132 0-58 3413531 Gdynia SERVICE AB ul. Indyjska 15 0-58 6218344 Gliwice FIRMA HANDLOWO-USŁUGOWA ul. Chorzowska 1 0-32 2315814 Gorzów Wlkp. UNITRONIX-SERWIS ul. Słoneczna 3 0-95 7227806 Grudziądz AUDIO VIDEO THOMSON SERWIS ul. Pańska 25 0-56 4623228 Jelenia Góra "FELIX" ZAKŁAD USŁUGOWO-HANDLOWY RTV Pl. Ratuszowy 5/6 0-75 7523062 Katowice ELEKTRONIK SERWIS PLUS ul. Gliwicka 65 0-32 2543560 Katowice ZAKŁ. USŁUG RTV I AGD ul. Kujawska 1C 0-32 2589472 Kielce ELECTRONIC SERVICE ul. Mickiewicza 10 0-41 3445539 Kielce MDS ELEKTRONIK ul. Manifestu Lipcowego 73 0-41 3623936 Konin SERVICE WMW ul. Legionów 23 0-63 2493704 Koszalin TELSERWIS ul. Małopolska 1c/3 0-94 3461629 Kraków MIX-SERWIS ul. Wadowicka 8A 0-12 2690942 Kraków ASTEL S.C. ul. Bałuckiego 9 0-12 2660999 Kraków ASTEL S.C. ul. więtokrzyska 10 0-12 6324018 Krasnystaw ZAKŁAD USŁUG RTV ul. Poniatowskiego 19 0-82 5763007 Krosno RAGZ - FILIA ul. Wojska Polskiego 40 0-13 4362959 Leszno EURO ELEKTRONIK ul. Złotnicza 44 0-65 5287323 Lubin MULTISYSTEM SERWIS ul. Paderewskiego 10 0-76 8444711 Lublin UNITRA ELTRON SERWIS ul. Braci Wieniawskich 5 0-81 7422999 Lublin DUCAT SERWIS ul. Choiny 1 0-81 741 30 81 Łódź W & W ul. Organizacji " WiN " 52 0-42 6576267 Łódź W & W ul. Piotrkowska 235/241 0-42 6370337 Łódź RAGZ ul. Piłsudskiego 143 0-42 6763038 Mława AUTORYZOWANY SERWIS RTV-SAT ul. Piłsudskiego 42 0-23 6544972 Nowy Sącz EURO SERWIS ul. Wiejska 6 0-18 4430335 Nowy Targ SERVIS RTV i AGD ul. Szaflarska 93d 0-18 2665013 Olsztyn ZBYSZKO ul. Gałczyńskiego 1/19 0-89 5277566 Opole SYNCHRO ul. Sz. Szeregów 23 0-77 4559254 Ostrołęka TELE AUDIO VIDEO ul. Bogusławskiego 13 0-29 7643781 Ostrów Wielkopolski SERWIS RTV ul. Kompały 3 0-62 7367644 Piaseczno BWM-ELEKTRONICS - FILIA ul. Jana Pawła II 24 lok.2 0-22 7368757 Piła TELS ul. Ojca M. Kolbe 13 0-67 2126292 Piotrków Tryb. RAGZ - FILIA ul. Kostromskiej 24 0-44 6476870 Poznań NIKU SERWIS ul.Składowa 5 0-61 8523078 Poznań AKWA ELECTRONIC ul.Otwocka 8 0-61 8708049 Radom METRO ul. Focha 12,pawilon 26 0-48 3634820 Rybnik ELEKTRONIK SERWIS PLUS - FILIA ul. Zamkowa 6 0-32 4235413 Rzeszów VIDEO-SERVICE ul. Leszczyńskiego 6 0-17 8534668 Siedlce TOP-SERVICE ul. Czerwonego Krzyża 14/11 0-25 6339826 Siemianowice Sląskie KMA ELECTRONICS ul. Fojkisa 8 0-32 2201400 Sieradz SOKAL S.C. Al. Pokoju 11 0-43 8224050 Słupsk VIDEOSONIC ul. Dmowskiego 10 0-59 8455563 Suwałki TELE-VIDEO SERWIS ul. Gen. Andersa 7 0-87 5671518 Szczecin ZURIT SERWIS ul. Chopina 22 0-91 4525399 Szczecin PHU HIT-SERVICE ul. Szwoleżerów 22 0-91 4333741 Tarnobrzeg SERVIS TV-VIDEO ul. Wyspiańskiego 9 paw.1 0-15 8221075 Tarnów TEKIELAND-ELECTRONIC ul. Kopernika 4 0-14 6223812 Toruń FHU OMPEX ul. Hallera 65/3 0-56 6520696 Wałbrzych NAREL ul. Mickiewicza 18 0-74 8426216 Warszawa ASEL ul. Gen.Abrahama 2b 0-22 6710958 Warszawa AST ul.Obozowa 82a 0-22 8361870 Warszawa BWM-ELEKTRONICS ul. I. Gandhi 17 0-22 6446156 Warszawa NOWA TECHNIKA Pl. Inwalidów 10 0-22 8398379 Warszawa NOWA TECHNIKA ul. Białostocka 5 0-22 6185270 Warszawa NOWA TECHNIKA ul. Żelazna 58/62 0-22 6243970 Włocławek FC TRONIK ul. Wiejska 24 0-54 4118788 Wrocław THOM-SERWIS ul. Szczytnicka 30 0-71 3277981 Wrocław SERWIS ELEKTRONICZNY ul. Hauke-Bossaka 6 0-71 3429296 Zamość TELERADIOMECHANIKA ul. Piłsudskiego 31 0-84 6395000 Zielona Góra JANCOL ul. Dąbrowskiego 35 0-68 3245137

Additional Information

Repair Centers - Russia

Страна Город Сервисный Центр Адрес Телефон

Белоруссия Минск ЦТИ ул. Короля, 26 (017) 2105678, 2893944 Молдавия Кишинев ACO-SERVICE-ELECTRON S.R.L. ул. Банулеску Бодони 45 (373) 222-40-35 Россия Абакан Кристалл ул.Пушкина, д.54 (39022) 6-85-81, 4-34-21 Россия Алметьевск Эль-Мастер ул. Р. Фахретдина, 24 (85512) 51919 Россия Архангельск Двина-Сервис ул. Урицкого, 54 (8182) 265355 Россия Балаково ЧП Дунаев ул. Н. Леонова, д. 1а Д/К Химиков (845-70) 2-33-06 Россия Балашиха Кан-Сервис ул. Калинина, д.1 (095) 523 3313 Россия Барнаул Ремикс ул. Пушкина, 37 (3852) 231241 Россия Белгород Видео-Плюс ул. Богдана Хмельницкого, 86 (0722) 268896 Россия Березники ЧП Меркулов Советский проспект 50 (242) 6-21-21 Россия Владивосток Диапазон-Сервис ул. Баляева, 58 (4232) 215287 Россия Владимир Ромашка ул. Горького, 32 (0922) 330798, 331391 Россия Волгоград Про-Сервис ул. Рабоче-Крестьянская, 14 (8442) 445281 Россия Воронеж Орбита-Сервис ул. Донбасская, 1 (0732) 774329, 776625 Россия Воронеж Эль-Сервис Ленинский проспект, 172 (0732) 54-32-91 Россия Екатеринбург Сентри пр-т Космонавтов, 45 (3432) 310336, 32 05 71 Россия Екатеринбург Сентри ул. Орджоникидзе, 26 (3432) 310336, 32 05 71 Россия Ижевск Лэсси ул. Пушкинская, 216 (3412) 438805 Россия Иркутск ТИС ул. 5-ой Армии, 12 (3952) 333859 Россия Иркутск ТИС ул.Партизанская, 149 (3952) 51-31-09 Россия Йошкар-Ола Эль-Мастер ул. Советская, 116 (8362) 120912 Россия Казань ТВС ул. Шамиля Усманова, 32а (8432)44-10-51 Россия Казань ЭЛЬДОРАДО-СЕРВИС ул. Р.Зорге, д.95 (8432) 685005 Россия Калининград Вестер-Сервис ул. Горького, 50 (0112) 273432, 273151 Россия Кемерово Вайд Сервис ул. Коммунистическая 122 (3842) 258523 Россия Комсомольск-на-Амуре Инсайт-Сервис Мира пр-т, 9 (42172) 4 60 58 Россия Красноярск Интернационал Сервис ул. Вильского, 3 (3912) 453305 Россия Красноярск Интернационал Сервис ул. Карла Маркса, 44 (3912) 453305 Россия Курск Экран-Сервис Добролюбова ул., 17 (0712) 22 33 80, 56 0053 Россия Липецк Владон Меркулова ул., 8 (0742) 41 06 94 Россия Магадан Центр-Видео-Сервис Колымское шоссе, д.4 (413-22) 4-11-74 Россия Магадан Центр-Видео-Сервис ул. Карла Маркса, 33/15 (41322) 23322 Россия Магнитогорск Эль-Мастер ул. Ленинградская, 34 (3511) 227878 Россия Москва Авакс Хорошевское шоссе, 33/1 (095) 195 4113, 195 2593 Россия Москва Интеррадиоприбор проезд завода “Серп и молот”, 5 (095) 3614933, 2733173 Россия Москва Интеррадиоприбор ул. Мневники, 7 корп. 2 (095) 946 4604, 946 4504 Россия Москва КДС - Технический центр Шелепихинская наб., 18 (095) 7973434 Россия Москва Лит-Сервис Жулебинский б-р,9 (095)705-4688, 705-0899 Россия Москва Лит-Сервис б-р Дмитрия Донского, 2а (095)711-8336, 711-5827 Россия Москва Лит-Сервис ул. Братиславская,14 (095)346-8744 Россия Москва Лит-Сервис ул. Краснобогатырская 75 (095)269-2310, 966-3511 Россия Москва Мир и Сервис Пролетарский пр. 23 (095) 3250305, 3253437 Россия Москва Партия-Сервис ул. Академика Королева, д.5 913-33-88 Россия Москва Партия-Сервис ул. Викторенко, д. 3 742-50-20 Россия Москва Партия-Сервис ул. Исаковского, д. 33, корп. 4 757-50-00, 758-40-51 Россия Москва Партия-Сервис ул. Марксистская, д.34 912-00-08, 911-67-80, 911-68-89/73 Россия Москва Партия-Сервис ул. Народного Ополчения, д. 22, корп 2 787-70-21 Россия Москва Партия-Сервис ул. Новопеределкинская, д. 9А 731-11-00 Россия Москва Партия-Сервис ул. Обручева 30 (095) 9133939 Россия Москва Партия-Сервис ул. Уральская, д. 1а 462-0041 Россия Москва Партия-Сервис ул. Ярцевская, д. 30 149-23-31, 149-24-19 Россия Москва Экс-Сервис ул. Врубеля, д.12 (095)742-9081 Россия Москва Эль-Мастер ул. Кулакова, д.20 (095) 7547007 Россия Мурманск CPS Мурманск ул. Софьи Перовской, 37 (8152) 458701, 45 09 49 Россия Н. Новгород Электроника ул. Алексеевская, 9 (8312) 19-41-08, 19-41-10 Россия Н. Новгород Электроника ул. Лескова, 8 (8312) 59-46-20, 54-68-18 Россия Набережные Челны РАФТ Новый Город, 28/08 (8552) 549823 Россия Нефтеюганск Эфир 13 микрорайон, 56 (34612) 54223 Россия Новгород ТКТ (Орбита) ул. Кочетова 23а (81622) 611200 Россия Новокузнецк Стратас ул.Транспортная 49а (3843) 78-71-95 Россия Новосибирск ЭЛЬ-СЕРВИС ул.1-я Ельцовка, д.1 (3832) 285246 Россия Новосибирск Юса Красный пр-т, 50 (3832) 180995, 181755 Россия Омск Телетекст-Сервис пр-т Маркса, 18 (3812) 312530 Россия Оренбург Коминком Брестская ул., 7 (3532) 626888, 627701

Россия Орск Коминком Школьная ул. 13 (35372) 62631

Additional Information

Repair Centers - Russia

Страна Город Сервисный Центр Адрес Телефон

Россия Пенза ПТС Московская ул., 18 (8412)662222 Россия Пермь ЛЭБТ Бульвар Гагарина, 58а (3422) 619400, 619480 Россия Пермь ЭЛЬДОРАДО-СЕРВИС б-р Гагарина, д.32 (3422) 484477 Россия Петрозаводск ЛАНС наб. Ла-Рошель, 17 (8142) 765150 Россия Россия Ростов-на-Дону ААА-Сервис ул. Горького 136 (8632) 907900 Россия Ростов-на-Дону ЭЛЬСЕРВИС ул. Красноармейская, д.206 (8632) 618066 Россия Рязань Фонограф пл. 50-летия Октября, д.1 (0912) 721712 Россия Самара CЕРВИС-ЦЕНТР ул. Республиканская, д.62 (8462) 538199 Россия Самара Энон-Сервис ул. Советской Армии, 148 (8462) 240740 Россия Саранск Видео-Сервис ул.В.Терешковой 18а (834-22)4-54-85 Россия Саратов Скарт пр-т 50 лет Октября, 110а (845-2) 48-41-31,32-09-11,34-00-39 Россия Сергиев Посад Эль-Мастер пр-т Красной Армии, 4 (09654) 60533 Россия Сочи Союз-Сервис ул. Московская, 5 (8622) 920225 Россия Ст.-Петербург Орбис Витебский пр-т 33 кор.2 (812) 379-5655 Россия Ст.-Петербург Орбис Ланское шоссе 65 (812) 246-3793 Россия Ст.-Петербург Орбис Октябрьская наб. 60 (812) 446-6171 Россия Стерлитамак Импорт - Сервис ул. Коммунистическая, 61 (3473) 24 42 85 Россия Тверь Голубой Экран пр. Победы, 2/2 (0822) 36 05 20 Россия Тольятти Мастер-Класс ул. Карбышева, 6 (8482) 260595, 260065 Россия Томск Командор-Сервис ул. Беленца, 14 (3822) 516-333 Россия Тула Омегамет ул. Доватора, 1 (0872) 436158, 462466 Россия Тюмень Тюмень Импорт-Сервис ул. Мельникайте, 97 (3452) 224596, 22 45 96 Россия Тюмень Тюмень трейд ул. Герцена, д.101 (3452) 46-41-06 Россия Улан-Уде МВ-Маркет Гостиные ряды, “МВ-Маркет” (3012) 211661 Россия Уссурийск Вега-Гарант ул. Советская, 29 (42341) 21035 Россия Усть-Илимск Питон Офис 4, ул. Мечтателей д. 21 (39535) 57147 Россия Уфа Техно ул. Чернышевского, 88 (3472) 377303, 377344 Россия Уфа ЭЛЬДОРАДО-ЛЕНД ул. Чернышевского, д.100 (3472) 222448 Россия Челябинск Импорт-Сервис ул. Энтузиастов, 16 (3512) 340505 Россия Челябинск ЭЛЬ-СЕРВИС ул. Володарского, 32 (3512) 65-31-09 Россия Энгельс ЭПКСЦ “Гарант” ул.Петровского,57 (845-11)6-42-37 Украина Винница СКОРМАГ-СЕРВИС пр-т Юности, 16, к. 104 (0432) 46-43-93 Украина Днепропетровск MTI ул. Ленина, 21а (0562) 37-13-60 Украина Днепропетровск СЕРВИСЦЕНТР пл. Октябрьская, 2, офис 6. (0562) 37-78-30 Украина Донецк Импорт-Сервис пр-т Мира,13 (062) 335-06-70 Украина Житомир ВЫБОР ул. Победы, 32 (0412) 41-88-26 Украина Запорожье ТТП-94 ул.Грязнова, 71 (0612) 13-80-49 Украина Ивано-Франковск ООО “Мегастайл” ул. Вовчинецкая, 172а (03422) 6-15-30 Украина Киев Крок ТТЦ пр-т Владимира Маяковского, 26 (044) 5450897 Украина Кировоград ДП “Инэк-Кировоград” пр-т Коммунистический, 22/12 (0522) 22-06-21 Украина Краматорск Астрон ул.Дворцовая, 6 (0626) 41-97-34 Украина Кременчуг ИНЭК-КРЕМЕНЬ ул. Победы, 17/6 (05366) 3-11-21 Украина Кривой Рог ДОМТЕХСЕРВИС ул. Волгоградская, 4 (0564) 74-36-15 Украина Луганск КОРСАК ул. Коцюбинского, 27 (0642) 34-56-06 Украина Луцк ООО “Каскад-Интекс” ул. Гулака Артемовского, 15а (0332) 77-99-55 Украина Львов МАРКЕТ-ЛЬВОВ ул. Стороженко, 12 (0322) 33-70-63 Украина Мариуполь ООО “Нейтрон” пр-т Металлургов, 94 (0629) 529282 Украина Николаев СЦ АЛЛАДИН ул. Никольская, 46 (0512) 47-04-96 Украина Николаев ЧП Осипенко (Транзит) пр. Ленина, 184 (0512) 57-52-35 Украина Одесса Профессионал ул.Успенская д.24/26 0482) 42-91-52 Украина Одесса ЮГ СЕРВИС ул. Лейтенанта Шмидта, 21 (0482) 37-54-66 Украина Полтава НПО “Промэлектроника” ул.Фрунзе, 66 (05322) 7-81-55 Украина Ровно ОПАЛ ул. С. Бандеры, 55 (0362) 62-04-01 Украина Севастополь ПАНОРАМА-С ул. Генерала Петрова, 3 офис 1 (0692) 45-39-00 Украина Северодонецк Северодонецкрадиотехника ул. Маяковского, 13 (06452) 4-30-30 Украина Симферополь ГАРАНТ ул. Павленко, 54 (0652) 52-15-08 Украина Сумы СЕРВИСЦЕНТР ул. Героев Сталинграда, 3 (0542) 21-06-79 Украина Тернополь ТЕРНАВА-СЕРВИС ул. Злуки, 39 (0352) 43-30-22 Украина Ужгород ПРОФИ-СЕРВИС пл. Ш.Петефи, 47 (0312) 23-44-63 Украина Харьков БЕСТ ул. Полтавский Шлях, 30 (0572) 12-38-60 Украина Херсон РАДИО ул. Советская, 23 (0552) 22-57-30 Украина Черкассы ЕВРАЗИЯ-С ул. Одесская, 8 (0472) 66-36-53 Украина Чернигов ЛАГРОС LTD пр-т Мира, 80 (0462) 17-78-99 Украина Черновцы ЗДАМЕКС-ПЛЮС ул. Русская, 198 (03722) 6-09-23 Украина Ялта Ави-Электроникс ул.Жадановского, 3 (0654) 38-60-18

Петропавловск-Камчатский

Мастерская №1 ул. Ключевская, 56, каб. 203 415-37-6-37

Additional Information

Repair Centers - Czech Republic

Seznam servisních partnerů - Česká republika

Servisní partner Město Ulice Telefon PSČ

Prague

NOVOTNÝ elektronik Praha 4 Hvězdoslavova 1599 272 937 184, 272 942 516 NOVOTNÝ elektronik Praha 8 Zenklova 81 283 840 523, 284 840 158 NOVOTNÝ elektronik Praha 6 - Řepy Makovského 1144 235,321,277 NOVOTNÝ elektronik Praha 4 - Chodov Hráského 1909 271,913,629 NOVOTNÝ elektronik Vlašim Poděbradova 358 317,844,844 BELS CZ s.r.o. - Praha Praha 4 Bělehradská 18 261,218,480 DI servis Praha 8 Pernerova 35 221 897 233-5 AV Kovoslužba Praha 4 Cílkova 9/796 241,714,442

Central Bohemia

BELS CZ s.r.o. - Benešov Benešov Zapova 525 317,725,060 TV-VIDEO centrum Nymburk Palackého 119 325,514,891 ELECTRONIC SERVICE NOVÁK Příbram Prokopská 4 318,625,052

East Bohemia

Jozef Ondruš - Radiotechnika Pardubice Tepleho 1398 466,303,951 Jozef Ondruš - Radiotechnika Hradec Kralové Nerudova155 495,530,073

West Bohemia

NELIN spol. s r.o. Karlovy Vary Krymská 47 353,222,028 Televizní servis Ladislav Juppa Plzeň Lobezská 62 377 456 356, 377 443 545 TOP Elektronik Karlovy Vary Moskevská 64 353224056, 353 230 337

North Bohemia

Horák electronics s.r.o. Jablonec n. Nisou Sadova 8 483,312,550 Jiří Suchý servis video - televize Česká Lípa Kolarova 2059 487,832,064 Jan Murga MJ* electronic - Stráž nad Nisou Stráž nad Nisou Myslbekova 485,159,301 Jan Murga MJ* electronic - Liberec Liberec Na Perstyne 378/42 485,104,628 RAMI Elektronic Ústí n. Labem Novosedlické nám. 1239/2 47 55 33 166 TV servis - Vlček Lubomir Chomutov Kadanska 3259/3 474,629,223 TV*VIDEO*SAT - V.Bloudek Most Moskevská 1/14 476,206,709 VIDCOM ELEKTRONIK Teplice - Prosetice Plynarenská 280 417,531,555

South Bohemia

ELEKTRO STELA Tábor Údolni 2908 381,256,600 ELEKTRO STELA Malšice Táborská 200 381,277,304 Milan Čepl - ELEKTRONIKA Humpolec Rasinova 466 565 532 363, 565 532 021 Video TV servis České Budějovice Na zlate stoce 14 385,310,165 VOBUKO spol. s r.o. Písek Havlíčkovo nám. 92 382 215 356, 382 219 130

South Moravia

KNK servis Brno Bubeníčkova 12/14 548 210 713, 548 213 870 TEVIS BRNO s.r.o. Brno Blatného 2 541 240 003, 541 211 112 i fax Miroslav Drda - TELES RTS Otrokovice Olbrachtova 1621 577,922,677 VIKI spol. s r.o. Jihlava Fritzova 12 567,303,546 Rates s.r.o. Hodonín Havlíčkova 2 518,341,300 Belvis elektronika Uherský Brod Dlní valy 507 572,633,417

North Moravia

TELEVIZE VIDEO SERVIS Ostrava - Poruba U oblouku 501/5 596,912,602 KATEX s.r.o. Šumperk Nam. Republiky 8 583,212,807 MONTAN RTS s.r.o. OIomouc Sokolská 8 585,220,312 MONTAN RTS s.r.o. Dolany 376 Dolany 376 585,396,512 SOPRA s.r.o. Opava Komárovská 2 553 711 395, 553 620 207

Additional Information

ИНФОРМАЦИЯ ДЛЯ ПОТРЕБИТЕЛЯ

visit us at www.thomson-europe.com or www.thomson-lyra.com

Please do not send any products to the address listed in this manual or on the carton. This will only add delays in service for your product.

THOMSON

46, quai Alphonse Le Gallo

92648 Boulogne Cedex

FRANCE

5594468B (EN)

Technicolor - Thomson PDP2842, PDP2845 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Important Information

WARNING

Important Information

Unpacking Your Unit

Things to consider before you get started...

Computer System Requirements

Warning

Caution

Caution While Driving

Back up your data

Important Battery Information

Inserting the Included CD-ROM into CD-ROM Drive

Installing Software Components

Install the USB Driver (Windows 98SE and Me Only)

Install System Applications

Install MusicMatch Jukebox

Install MusicMatch Plug-in

Install Additional Services

Launch the MusicMatch software

The MusicMatch icon found in your computer’s system tray.

Connecting Thomson Lyra to the Computer

Transferring Files to Thomson Lyra Jukebox

Transfer Files via MusicMatch Jukebox

Transfer Files via Windows Explorer (Drag and Drop)

Create Pre-defined Playlists and Transferring them to the Jukebox

Disconnecting Your Lyra from the Computer

System Tray Applications

Profile

Updating System File

Verify User Playlists

LyraSync

MyDislikes

Overview of General Controls

Front View

Navigation Controls

Left View

Right View

Top View

Display Overview

Basic Operation

Menu Navigation

Selecting Music Mode

Music Playback Display

Music Playback Operation

Step-by-Step Example

Navigation Menu

Playlists

My Selections

My Dislikes

View User Playlists

Pre-defined Playlists

Save MySelections or MyDislikes as a Playlist

Clear Playlists

All Files

Additional Features

Repeat

Shuffle

Profiler

Selecting Radio Mode

Preset Station

Tuning to a Station

Setting Preset

Selecting Preset Station

Clearing Preset

Suppressing Stereo Signal

Record FM Radio

Selecting Recording Duration

Selecting Recording Quality

View FM Recording

Delete FM Recording

System Settings

Customize Music Menu

System Info

Connecting your Thomson Lyra Jukebox to your Car Stereo

Connecting Your Thomson Lyra Jukebox on your stereo system

Portable Hard Drive Capability
