PDP2225 IB-EN new 7/4/02 2:44 PM Page 1
usermanual
PDP2225
THOMSON multimedia
46/47 quai A. Le Gallo
92648 Boulogne Cedex
FRANCE
RCS nanterre
B 322 019 464
55522540
www.thomson-multimedia.com
PDP2225 IB-EN new 7/4/02 2:44 PM Page 2
EN
Important Information
Warning
• Do not play your headset at a high volume. Hearing experts warn against extended
high-volume play.
• If you experience a ringing in your ears, reduce volume or discontinue use.
• You should use extreme caution or temporarily discontinue use in potentially
hazardous situations.
Even if your headset is an open-air type designed to let you hear outside sounds, don’t
turn up the volume so high that you are unable to hear what is around you.
Precautions for the Unit
• Do not use the unit immediately after transportation from a cold place to a warm
place; condensation problem may result.
• Avoid shock to the unit especially during recording. Recorded data may be damaged.
• Do not store the unit near fire, places with high temperature or in direct sunlight.
• Do not operate or store unit in places with frequent static electricity or electrical
noise (e.g. speaker, TV set).
• Clean the unit with a soft cloth or a damp chamois leather. Never use solvents.
• The unit must only be opened by qualified personnel.
Warning: Use of this product is for your personal use only. Copying CDs
or downloading music files for sale or other business purposes is a violation of copyright law. It is also a violation of copyright law to download
files without permission of the copyright owner.
Caution While Driving: Use of headphones while operating an automobile or moving vehicle is not recommended and is unlawful in some states
and areas. Be careful and attentive on the road. Stop operation of the
unit if you find it disruptive or distracting while driving.
Care of Memory Cards (Not Included)
• Do not touch the golden electrodes. Use a soft dry cloth to clean any dirt.
• Do not bend memory card.
• Do not operate or store memory card in places with frequent static electricity or
electrical noise (e.g. speaker, TV set). Recorded data may be damaged.
• It is normal for memory card to get warm after being used for a long time.
• Always put it in storage case after removing from the unit.
• Do not store memory card near fire, places with high temperature/ humidity or in
direct sunlight.
• We recommend that you make a copy of your recorded contents into another media
(e.g. floppy disc, tape) as back-up.
Power supply
• Battery power: AAA (LR03) x 2.
Battery Precautions
• When storing the unit , be sure to remove the batteries because they may leak and
damage the unit.
• Batteries may leak electrolyte if inserted incorrectly, if disposed of in fire, or if an
attempt is made to charge a battery not intended to be recharged.
• Never mix new batteries with old ones. Do not mix battery types.
• Discard leaky batteries immediately. Leaking batteries may cause skin burns or other
personal injury.
• Do not charge batteries which are not intended to be recharged.
• Dispose of batteries, according to federal, state and local regulations.
Wyrób importowany przez
Thomson multimedia Polska Sp. z o.o.
Oddzia Consumer Products Marketing & Sales.
The descriptions and characteristics given in this document are given as a general indication and not as a guarantee. In
order to provide the highest quality product possible, we reserve the right to make any improvement or modification
without prior notice. The English version serves as the final reference on all product and operational details should any
discrepancies arise in other languages.
Important Information
PDP2225 IB-EN new 7/4/02 2:44 PM Page 4
EN
Table of Content
Important Information
Important Safety Information
Before You Begin . . . . . . . . . . . .1
1. Unpacking the player and
accessories . . . . . . . . . . . . . . . . . . . . . .1
2. What’s so special about this MP3
player . . . . . . . . . . . . . . . . . . . . . . . . . .1
3. Insert batteries into the player . . .2
4. Inserting a MultiMediaCard
(optional) . . . . . . . . . . . . . . . . . . . . . . .2
5. Using Headphones . . . . . . . . . . . .3
6. Connecting the lyra Player to your
Computer . . . . . . . . . . . . . . . . . . . . . . .3
General Controls . . . . . . . . . . . .4
Radio controls . . . . . . . . . . . . . .5
Digital music Operation . . . . . .6
Playback . . . . . . . . . . . . . . . . . . . . . . . .6
Stop Playback . . . . . . . . . . . . . . . . . . . .6
Skip / Search . . . . . . . . . . . . . . . . . . . . .6
Advanced Operation . . . . . . . . .7
DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Play Modes . . . . . . . . . . . . . . . . . . . . .7
Programming Tracks . . . . . . . . . . . . . .7
Editing Program . . . . . . . . . . . . . . . . . .7
Key Lock . . . . . . . . . . . . . . . . . . . . . . . .8
File Download . . . . . . . . . . . . . . . . . . .8
Adjust volume Level . . . . . . . . . . . . . .8
Troubleshooting Tips . . . . . . . . .9
RISK OF ELECTRIC
SHOCK
RISQUE DE CHOC ELEC-
TRIQUE
Sound Pressure Control
Les articles de loi L44.5 et 44.6 du code de la santé publique,
modifiés par l’article 2 de la loi du 28 Mai 1996 imposent
une puissance acoustique maximale de 100 décibels. Le
casque livré ( code 55110130 ) et votre appareil respectent
la législation en vigueur.
A pleine puissance, l’écoute prolongée du baladeur peut
endommager l’oreille de l’utilisateur.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER
(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING
TO THE QUALIFIED SERVICE PERSONNEL.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
elecrtric shock or personal injury.
This symbol indicates important
instructions accompanying the product.
IMPORTANT NOTE: To reduce the risk of fire or shock hazard, do not expose this
player to rain or moisture.
Important Safety Information
PDP2225 IB-EN new 7/4/02 2:44 PM Page 6
EN
Before You Begin
Before you Begin
1
2
1. Unpack the player and accessories
When you unpack your new player, be sure you have removed all the accessories and
information papers. The items shown below are packed with your player.
1. The Player
2. Batteries
3. Software CD
4. Digital X-Phone
5. Connection Cable
6. Neck Strap
7. Carry Case
2. What’s so special about this MP3 player?
This player is meant to play MP3 files encoded on a memory card or recorded in the
built-in flash memory.
To do so, you need the use of a Windows computer with USB port , connection cable
(included) and a music management software (MusicMatch Jukebox).
Compressed music internet sites
www.rca.com
www.musicmatch.com, www.emusic.com
CDs
Compression and transfer
Connection cable
Playback
and/or
MP3 music
built-in flash
memory
Optional:
MemoryCard
(not included)
3. Insert batteries into the
player
A. To insert batteries, lift open the
battery compartment door.
B. Insert 2 “AAA”(LR03) batteries with
polarities corresponding to indications
on the compartment. (Refer to “More
information” for battery precautions.)
C. Close the door to the battery
compartment
Note: Refer to the power level indicator
on display for battery level.
Replace with new batteries when the
indicator is empty.
4. Inserting a SD card /
MultiMediaCard (Optional)
The player has built-in flash memory. To
extend the playtime, you can use the
optional Memory Card slot.
A. Insert a Memory Card into the card
slot when the player is off as the
diagram shows:
B. To remove card, push the Memory
Card to eject.
Push the battery
compartment door
up to open
Caution: Do not remove Memory
Card during playback or when
power is on. It may stop unit from
playing immediately.
PDP2225 IB-EN new 7/4/02 2:44 PM Page 8
VOL
MusicMatch
Jukebox
S
T
Y
O
A
P
L
P
L
A
T
S
X
T
E
N
General Controls
3
4
Before You Begin
5. Using Headphones
Insert phone jack into PHONES on the side
of player for listening.
6. Connecting the Lyra Player
to your Computer
1. Lift the rubber cover on the player.
2. Insert the smaller end of the connection
cable into the socket tightly.
3. Insert the opposite end of the connecting cable to the
USB socket on the
back of the computer.
Note: Have a Blast- Just Not in Your
Eardrums. Make sure you turn down
the volume on the unit before you put
on headphones. Increase the volume
to the desired level
only after headphones are in
place.
Note: Refer to the Software
Instruction manual for procedures in
setting up USB drivers and
transferring files to the player.
3
1. DISPLAY
2. STOP - Stops playback and turn unit
off .
3. LAST - Skips back to last track. Press
and hold to search backward through
the track.
4. NEXT - Skips to next track. Press and
hold to search forward through the
tracks.
5. PLAY - Turns unit on, start playback
and pause, mute operation in Radio
mode.
6. DSP - Selects among DSP modes.
(Flat, Bass, Pop, Rock, Jazz,Tone)
7. MODE - Selects between repeat
one, repeat all, random playback, random shuffle, program and program
repeat all modes.
8. RADIO - Selects radio mode.
9. MUSIC - Selects Digital music play-
back mode.
10. ENTER - Presses to confirm selection.
11. USB - Connects USB cable.
12. MEMORY CARD - Slot for insert-
ing Memory Card.
13. PHONES - Inserts headphones
14. VOLUME - Adjusts sound volume.
EN
PDP2225 IB-EN new 7/4/02 2:45 PM Page 10
PHONES
12
13
11
OPEN
1
8
6
3
2
7
4
10
5
9
14
OPEN
EN
5
Radio Controls
6
Digital music Operation
Listening to the radio(FM only)
Manual search
1. Press PLAY to turn on the unit.
2. Push the ENTER knob upward to enter
radio mode.
3. You may tune up or tune down the
frequency by pushing the ENTER knob
to the left/right.
Auto search / Preset a station
1. In radio mode, keep pushing the
ENTER knob to the left/right for 2 seconds, the unit will start searching for a
station.
2. The unit will stop searching when a
station is found.
3. You may save the station by pressing
ENTER, then push the ENTER knob to
the left/right to select the location you
want to store the station in (0-9).
4. Press ENTER to confirm. A preset station is stored.
Select a preset station
1. In radio mode, press MODE button.
2. You may recall your previously saved
preset station (0-9)
3. Push the ENTER knob to the left/right
to select your desired preset station.
4. Press ENTER to confirm selection.
Mono / Stereo selection
1. In radio mode, press DSP button to
toggle between ST / Mono.
Adjust Volume Level
Press + or - to adjust sound volume.
Refer to the volume level on display for
sound level.
Playback
1. In OFF mode, press PLAY to turn the
unit on.
2. Select music by pushing the ENTER
key downward, then the total number of
tracks will show on display. Playback
then starts automatically from the first
track.
3. You can press PLAY button during
playback to pause and press again to
resume playback.
4. During playback , you can press ENTER
to display complete song title and artist
information.
Stop Playback
1.During playback, press STOP to stop
playback (Stop mode) with total number
of tracks will show on display.
2.Press STOP again to exit to the WELCOME screen. (The unit will turn itself
off automatically after idle for about 1
minute.)
Skip / Search (Scan)
1.In stop mode, push or to
select desired tracks.
2.Push once to skip to next track.
Push and hold for quick forward scan of
playing track.
3.Push once to return to previous
track. Push and hold for quick backward
scan of playing track.
PDP2225 IB-EN new 7/4/02 2:45 PM Page 12
EN
Advanced Operation
7
Advanced Operation
8
DSP
• In Music mode, press DSP button
repeatedly to select among the DSP
modes:
FLAT > BASS > POP
TONE > JAZZ > ROCK
• In TONE mode, you may further adjust
BASS and TREBLE level.
Play modes
• In music mode, press MODE button
repeatedly during playback for the following playback modes:
Off (Normal playback) > Repeat One
> Repeat All > Shuffle > Repeat
Shuffle > All Program > Repeat program > Normal.
Note: All program and Repeat program
only appears if there are programmed
tracks.
Programming Tracks
1. Press ENTER in stop mode to enter
program mode. You will see ‘P’ icon
flashes on display, flashing ‘ - -’ for
track selection and ‘P01’ for program
list position.
2. Press or to select a track.
Selected track number will flash.
3. Press ENTER key upward/downward
to skip to the previous / next programming position.
4. Press ENTER to confirm selection.
5. Repeat steps 2-4 for further selections. Maximum 20 selections can be
made.
6. Press STOP to exit programming
mode or unit returns to stop mode
automatically after 30 seconds if no
keys are activated.
Note: The player will enter Intro Play
mode and play the beginning of each
track as you scroll through tracks for
programming .
Editing program
Overwriting Programmed Tracks
1. In stop mode, press ENTER to enter
programming mode.
2. Push or to select the programmed track you want to overwrite.
3. Push or to select the new
track you want to store.
4. Press ENTER to confirm selection.
5. Repeat steps 2 to 4 to overwrite additional programmed tracks.
Key Lock
To avoid accidental key activation, press
and hold the MODE button to lock keys.
“Locked” can be seen on display. press
and hold the MODE button again to
unlock keys.
File Download
This unit can be connected to the computer. Please see Software Instruction
Manual for instructions to install USB
driver , music management software and
to transfer tracks to player and/or memory card.
Adjust Volume Level
Press + or - to adjust sound volume.
Refer to the volume level on display for
sound level.
>
>
PDP2225 IB-EN new 7/4/02 2:45 PM Page 14
9
The player does not turn on when PLAY button pressed.
• Batteries may be inserted incorrectly.
• Batteries may be empty.
Skipping tracks or bad sound quality?
• Repeat, random or program function may be activated.
• There may be strong magnetic fields (e.g. too close to TV) near the unit.
• Low Battery level. Replace with new ones.
Cannot perform playback?
• LOCK function may be activated.
• There may be no MP3 tracks in the card or internal memory.
• Memory Card may be damaged.
USB display does not appear when connected to computer.
• Check connection between your unit and the computer. (Refer to Software
Instruction Manual)
• Check if USB drivers are properly installed (Refer to Software Instruction Manual)
The player does not respond to key operations?
• Turn the player off by removing the batteries. Reinsert the batteries properly and
turn the player on again to resume normal operations.
Troubleshooting Tips
EN
Lyra Helpline
Wyrób importowany
Przez Thomson Consumer
Electronics Poland
More help is available on www.thomson-lyra.com and phone numbers of the Lyra
helpline per countries are listed below.
PDP2225 IB-EN new 7/4/02 2:45 PM Page 16
HELPLINE
Votre Contact THOMSON: 0 810 810 891, de le 16.10.2000
(pour la France, prix d'un appel local)
Ihr Kontakt zu THOMSON: 0180 1000 390, ab 16.10.2000.
(für Deutschland, Kosten zum Ortstarif)
You can contact THOMSON by dialling: 0845 601 3093, from16 October 2000
(For Great-Britain, all calls will be charged at local rate)
Para contactar con THOMSON marque: 901 900 410, a partir del 16.10.2000
(las llamadas serán cargadas al precio de la tarifa local)
Il vostro contatto THOMSON: 8488 10 168, dal 16.10.2000
(tariffa chiamata urbana)
www.thomson-europe.com
Loading...
