Table of Contents
Safety Information
Before you begin . . . . . . . . . . . . . .2
CD Player
General Control . . . . . . . . . . . . . . . . . . . . . .3
Power Supply . . . . . . . . . . . . . . . . . . . . . . . .4
AC Outlet Power Supply . . . . . . . . . . . . .4
Battery Power Supply . . . . . . . . . . . . . . .4
Recharge function . . . . . . . . . . . . . . . . . .4
The Display . . . . . . . . . . . . . . . . . . . . . . . . . .5
Listening to Compact Disc . . . . . . . . . . . . . .5
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Resume . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Skip/Search . . . . . . . . . . . . . . . . . . . . . . . . . .6
Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
View the playlist . . . . . . . . . . . . . . . . . . . . . .7
Clear the playlist . . . . . . . . . . . . . . . . . . . . . .7
EQ. setting . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Listening to a mp3 disc . . . . . . . . . . . . . . . .8
Folder selection . . . . . . . . . . . . . . . . . . . . . .8
Skip/Search . . . . . . . . . . . . . . . . . . . . . . . . . .8
Smart sort . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Playmode . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SmartTrax
Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
View the playlist . . . . . . . . . . . . . . . . . . . . . .9
Clear the playlist . . . . . . . . . . . . . . . . . . . . . .9
Navigation chart . . . . . . . . . . . . . . . . . . . . .10
FM radio
Listening to FM Radio . . . . . . . . . . . . . . . .11
Auto Search . . . . . . . . . . . . . . . . . . . . . . . . .11
Setting Presets . . . . . . . . . . . . . . . . . . . . . .11
Using Presets . . . . . . . . . . . . . . . . . . . . . . . .11
Clearing Presets . . . . . . . . . . . . . . . . . . . . .11
More Information
Useful Advice . . . . . . . . . . . . . . . . . . . . . . .12
Notes on CD-R/RW Discs . . . . . . . . . . . . . .12
Please Respect The Environment . . . . . . .13
Headset Safety . . . . . . . . . . . . . . . . . . . . . .13
Technical Specification . . . . . . . . . . . . . . .13
2
1
Unpacking Your Unit
You should have the following:
• one main unit
• one remote control
• AC/DC power adapter
• one set of clip phones
• one user’s guide
• batteries
How to Use Your Clip Phones
(The e.clipz)
The right ear clip phone is labeled R while
the left ear clip phone is labeled L.
1. Pull the ear hook away from the ear
pad slightly. You will hear a click sound.
2. Slide the ear hook behind the ear with
the ear pad on the front of the ear.
Rotate the clip phone so the ear pad fits
closely with the ear.
3. Lock the clip phone in place by
pushing down on the top of the ear hook
until it locks.
4. For best sound quality, make sure the
earpad fits closely with your ear.
Before you begin
PDP2075 EN 4/28/04 2:19 PM Page 6
L
CLICK
R
EN
EN
AC Outlet Power Supply
You can power your CD player with an
AC/DC adapter. Refer to the table for
details of the operating voltage.
AC/DC adapter is purposed for indoor use
in dry rooms only. Remove the jack from
the device to use it with the batteries.
Battery Power Supply
Refer to the table for details of the
batteries required to operate your unit.
Recharge function
To charge Ni-Cd / Ni-MH batteries:
1. Insert 2 rechargeable batteries into
the battery compartment on the main
unit.
2. Connect the main adapter.
3. Press and hold stop on the unit to
start recharging. An battery indicator will
be displayed when recharging is in
progress.
4. Unplug the AC/DC adapter to stop
recharge, or press play to stop recharge
and enter playback mode directly.
CD Player
Model Number
PDP2075
AC/DC adapter
5-4079A
(Included)
(230V 50Hz)
Batteries
2 x 1.5V IEC R6 (UM3)
(Included)
Power Supply
4
3
Note:
Power is fed to the unit even
when it is not functioning. To
cut the power supply off, the AC/DC
adapter must be unplugged.
1. controls switch - To lock or unlock the
buttons.
2. DC jack - You can insert the adapter instead
of batteries for indoor use.
3. Remote Jack - Insert your remote here.
4. Volume buttons - To adjust the volume.
5. tune up - Skip / search forward track;
search up radio frequency.
6. tune down - Skip / search backward
track; search down radio frequency.
7. stop button - Press to stop CD playback,
press and hold to turn off the unit. In stop
mode, press and hold to activate recharge
function.
8. play/pause button - Press to play or
pause CD.
9. Directions button - access different option
in the option menu; enter / exit a folder.
10. menu•lock button - press to enter / exit
option menu, press and hold to activate key
lock function.
11. sel button - select the highlighted option.
12. DSP button - For different EQ selection.
13. open switch - Slide to open CD door.
CD Player
General Control
OPEN
8
4
7
10911
12
PDP2075 EN 4/28/04 2:19 PM Page 8
2
O
P
E
N
CONTROLS
HOLD • • ON
3
OPEN
13
O
N
CD/FM
S
E
E
K
8
R
E
C
H
A
R
G
E
OFF
7
TUNE
U
P
TUNE
D
6
O
W
N
1
5
4
4
3
EN
EN
5
CD Player
CD Player
6
Resume
When you power off the unit, resume is
automatically activated. It stores settings
concerning playmode and EQ. When the
unit is on again,it resumes to the original
settings.
Skip / Search
Press to skip to the previous track.
Press and hold to search backward in a
track.
Press to skip to the next track.
Press and hold to search forward in a
track.
Pause
During playback, press play/pause
on the main unit to pause playback. The
minutes and seconds flash when the playback is paused.
Stop
Press stop on the main unit.
Note:
To prevent excessive bat-
tery consumption, when finished all tracks or in stop state, the
unit switches off automatically in all
modes after no key has been activated
for 30s.
The display
1. Random playback
2. Repeat
3. SmartTrax disc is detected
4. Time display
5. Battery Indicator
6 Key lock (remote control)
7. Key lock (main unit)
* For different playmode icons, please
refer to the playmode section.
Listening to a Compact Disc
Slide the open switch to the right to open
the door. Insert a disc and press lightly on
the centre to lock. Close the door.
Playback
Press play/pause on the main unit
or remote to start playback.
Reading DISC will appear on the display.
Then, the total number of tracks and time
of the CD will be displayed. If the disc
compartment is empty or the disc cannot
be read, No Disc will appear on the display.
The Electronic Shock Protection (ESP)
system prevents sound interruptions when
impacts or vibrations occur. Electronic antishock consumes less power and increases
the battery life. Therefore, the ESP function is always on.
After many successive impacts, the buffer
might be emptied causing a brief sound
interruption for the memory to reload.
1 4 62 3 5 7
PDP2075 EN 4/28/04 2:19 PM Page 10
1
PLAYLIST
YEARRFOLDER
ARTIS ALBUM GENRE
EN
EN
7
CD Player
Playlist
Folders and tracks can be bookmarked
and placed into the playlist.
1. Press or to select the folder
to enter.
2. Press or to enter / exit the
folder.
3. Press sel to select the whole folder or
individual title to place into the playlist.
View the playlist
1. Press or to select the playlist.
2. Press sel to enter and view the
playlist.
Clear the playlist
1. Press menu•lock to enter the option
menu.
2. Press or to select “Clr
Playlist”.
3. Follow the instructions to clear the
playlist.
EQ setting
Press DSP on the remote repeatedly to
select among Flat, Bass Boost, Rock, Jazz
and Classic.
Lock
Slide controls switch on the main unit
to the HOLD position, or press and hold
menu•lock on the remote for 2 second
to lock the button to avoid accidental
activation of unwanted functions.
“HOLd” will show on the display when
the control is locked.
CD Player
Listening to a mp3 Disc
Press play/pause on the main unit
to start playback.
“Reading file system...” will appear on
the display. If the disc compartment is
empty or the disc cannot be read, No
Disc will appear on the display.
Category selection
Press or to select a category.
Press or to enter / exit the select-
ed category.
Skip / Search
During playback, press to skip to
the previous file.
Press and hold to search backward in a
file.
Press to skip to the next file.
Press and hold to search forward in a file.
Smart Sort
This function enables the user to sort all
the songs according to their artist,
album, genre, year, folder, etc.
1. When the unit is in stop mode, press
stop repeatedly to sort songs in different methods.
2. When the unit is in play mode, press
the
Directions button repeatedly to sort
songs in different methods.
Playmode
You can play the tracks in a random
order, play the entire CD or one track as
many times as you wish, as well as listen
to the beginning of each track for 10 seconds.
In the option menu, select “Shuffle”,
“Repeat” or “Intro”, then press sel to
toggle ON / OFF. There are various combinations which you can try them out, here
are some examples.
Play the current track repeatedly.
Play all tracks within the current
layer repeatedly.
Play tracks randomly.
8
1
PDP2075 EN 4/28/04 2:19 PM Page 12
EN
EN
Smart Resume Plus
The unit is equipped with Smart resume
plus features, if the newly inserted CD is
considered as the same as the former
one, the Smart Resume Plus feature will
automatically activate. The last playback
song and playmode will be restored.
SmartTrax is a music navigation system
that allows for the organization of mp3
or WMA files into various standardized
categories. The categories include Artist,
Title, Genre, Album, Year and CD Playlist.
This systematic arrangement makes the
navigation easier and faster as songs are
placed into categories (e.g. Artist, Album,
Genre, etc.)
To enjoy SmartTrax navigation experience, please make sure your mp3 disc is
burnt with SmartTrax feature switched
ON.
SmartTrax
Note:
When reading a SmartTrax
disc which is different from
the former one, the unit will automatically enter the Artist Category.
SmartTrax
Navigation chart (SmartTrax mode)
Playlist
Selected categories and tracks can be
bookmarked and placed into the playlist.
1. Press or to select a category
to enter.
2. Press or to enter / exit the
category.
3. Press sel to select the whole category
or individual title to place into the
playlist.
View the playlist
1. Press or to select the playlist.
2. Press sel to enter and view the playlist.
Clear the playlist
1. Press menu•lock to enter the option
menu.
2. Press or to select “Clr
Playlist”.
3. Follow the instructions to clear the
playlist.
9
10
PDP2075 EN 4/28/04 2:19 PM Page 14
SMART TRAX
HOME DIRECTORY
Artist
Album
Genre
Artist
Album
Genre
Genre
Y ear
Folder
Genre
Y ear
Folder
Folder
T itle
Playlist
Folder
T itle
Playlist
Playlist
Artist
Artist1
Artist2
Artist3
Album
Album1
Album2
Album3
Genre1
Genre2
Genre3
Year
1999
2000
2001
Folder1
Folder2
Folder3
T itle1
T itle2
T itle3
Default
Artist-Album-T
Artist-song
Genre
Folder
Title
Playlist
Artist
Artist1 Song1
Artist1 Song2
Artist1 Song3
Album
Album1 Song1
Album1 Song2
Album1 Song3
Genre1 Song1
Genre1 Song2
Genre1 Song3
Year
Song1
Song2
Song3
Folder
Folder1 Song1
Folder1 Song2
Folder1 Song3
Title
T itle1 Song1
T itle1 Song2
T itle1 Song3
Song1
Song2
Song3
Genre
Playlist
EN
EN
Clean the player with a soft cloth, or a
damp chamois leather. Never use
solvents.
Useful advice
• Do not store CDs in damp areas.
• Do not expose CDs to high
temperatures.
• Do not put any tape or adhesives on
either side of the disc.
• You should avoid leaving the CD
door open. Dust is liable to impair
performance of the laser optical unit.
• Do not use your set immediately
after transport from a cold place to a
warm place: there may be
condensation problems.
• Do not touch the playing surface.
Make sure that you keep your set
away from water and high
temperatures.
• If you do not use your set on battery
power for more than one month, we
advise you to take out all the batteries.
• To prevent personal injury, do not
reverse any battery and do not mix
battery types.
• Discard leaking batteries immediately.
Leaking batteries can cause skin burns
or other personal injury.
• This apparatus shall not be exposed to
dripping and splashing.
• Prolonged use of the CD player at full
volume can damage the user’s ear.
SPC: Sound Pressure Control at 100dB
maximum (only for Thomson models)
Notes on CD-R/RW Discs
• Do not affix any type of labels to
either side (recordable or labeled side)
of a CD-R/RW disc as this may result in
the unit malfunctioning.
• To avoid damages to the CD-R/RW disc,
do not open the disc compartment
door while the disc is being read.
• Do not load an unrecorded CD-R/RW
disc into the unit. This may take a
longer time to read the disc.
• Playback capability for CD-RW discs
may vary due to variations in the
quality of the CD-RW disc and the
recorder used to create the disc.
More Information
11
Listening to FM Radio
1. Enter the option menu and choose
“Go to radio”, or press and hold
play/pause for 2 seconds to select FM
radio.
2. Press the directions button to search
for the desired station.
Auto Search
1. In radio mode, press play/pause to
turn on the Seek feature, then press the
directions button to auto search up or
down in FM frequency.
Search will stop when a station is found.
To turn off the Seek feature, press
play/pause.
Setting Presets
Your player has 20 preset stations for
easy access to your favorite FM radio
stations.
You can save a radio frequency as a preset station:
1. Press sel on the remote control.
2. You can change the preset destination by pressing and .
3. Press sel to confirm saving.
Using Presets
1. Enter the option menu and choose
“Go to radio”, or press and hold
play/pause for 2 seconds to select FM
radio.
2. Press and to access the previous or next preset station.
The display will show the frequency and
the preset number.
Clearing Presets
1. In radio mode, enter the option
menu and choose “Clr Preset”.
2. Press and to access the previous or next preset station.
3. Press sel to confirm clearing.
FM Radio
12
PDP2075 EN 4/28/04 2:19 PM Page 16
EN
13
More Information
Please respect the environment !
Before throwing any
batteries away, consult
your distributor who may
be able to take them back
for specific recycling.
Headset Safety
Have a Blast- Just Not in
Your Eardrums
Make sure you turn down
the volume on the unit
before you put on
headphones. Increase the volume to the
desired level only after headphone is in
place.
• Do not play your headset at high
volume. Hearing experts warn against
extended high-volume play.
• If you experience ringing in your ears,
reduce volume or discontinue use.
• You should use with extreme caution or
temporarily discontinue use in
potentially hazardous situations.
Even if your headset is an open-air
designed to let you to hear outside
sounds, do not turn up the volume so
high that you are unable to hear what is
around you.
Technical specifications
* Frequency response: 20Hz to 20kHz
Power Supply
• 4.5V DC through AC/DC adapter
• 2 “AA” batteries
• 2 “AA” rechargeable Ni-cd / Ni-MH batteries
• 4.5V DC (through car DC adapter)
The descriptions and characteristics given in this document are given as a general indication and not
as a guarantee. In order to provide the highest quality product possible, we reserve the right to make
any improvement or modification without prior notice. The English version serves as the final reference on all products and operational details should any discrepancies arise in other languages.
PDP2075 EN 4/28/04 2:19 PM Page 18
Loading...
