MS2200
It is important to read this instruction book prior to using your new product for the first time.
user
manual
MS2200 EN 11/17/03 1:59 PM Page 3
Safety Information
For UK Only
CONNECT THE MAIN LEAD INTO A MAINS
POWER SOCKET
POWER SUPPLY 230V. It must not be
connected to D.C. mains.
Note: The mains lead of the set is fitted with a
molded plug. If the mains socket are not
compatible or if for any reason the plug is
removed please follow the directions below. The
molded plug cannot be rewired and if removed
must be
disposed of safely.
DO NOT under any circumstances plug the
severed plug into any mains socket as this could
result in electric shock.
Important: If the plug is removed, rewire the
new plug as follow:
The wires in the mains plug are colored in
accordance to the following code:
BLUE = NEUTRAL / BROWN = LIVE
If the colors of the wires in the mains lead of this
apparatus may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows:
BLUE wire to the terminal coded N (Neutral) or
colored black.
BROWN wire to the terminal coded L (Live) or
colored red.
DO NOT make any connection to
the terminal in the plug which is
marked by the letter E or by the
earth symbol or colored green or
green and yellow.
A fused plug must be fitted
with a 3A fuse approved by
ASTA or BS1362 and fuse covers must be always be securely
replaced. If you set does not
work, the fuse may be blown.
EN
The descriptions and characteristics given in this document are given as a general indication and not as a guarantee.
In order to provide the highest quality product possible, we reserve the right to make any improvement or
modification without prior notice. The English version serves as the final reference on all products and operational
details should any discrepancies arise in other languages.
MS2200 EN 11/17/03 1:59 PM Page 4
Safety Information
CAUTION!
Invisible laser radiation when open. Avoid exposure to beam. Class 1 laser product. This system
must be opened only by qualified technicians to
prevent accidents caused by the laser beam.
LASER λ = 780 nm, P max = 5 mW
Rating Information: At bottom/rear of the unit.
This unit comply with the existing requirements
In accordance with the rating plate of
the unit, this unit complies with
current standards concerning electrical
safety and electromagnetic
compatibility.
Please respect the environment Before
throwing any batteries away, consult
your distributor who may be able to
take them back for specific recycling.
Have a Blast- Just Not in Your Eardrums
Make sure you turn down the volume
on the unit before you put on headphones. Increase the volume to the
desired level only after headphone are
in place.
CAUTION – INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS FAILED OR
DEFEATED. AVOID EXPOSURE TO BEAM.
ATTENTION –
RAYONNEMENT LASER INVISIBLE
DANGEREUX EN CAS D'OUVERTURE ET LORSQUE
LA SECURITE EST NEUTRALISEE.
EXPOSITION DANGEREUSE AU FAISCEAU.
EN
MS2200 EN 11/17/03 1:59 PM Page 5
ADVARSEL!
USYNLIG LASERSTRÅLNING VED ÅBNING NAR
SIKKERHEDSAFBR
UNGDÅ UDSAETTELSE FOR STRÅLNING.
VORSICHT!
UNSICHTBARE LASERSTRALUNG
WENN ABDECKUNG GEÖFFNET UND SICHERHEITS–
VERRIEGELUNG ÜBERBRÜCKT.
NICHT DEM LASERSTRAHL AUSSETZEN!
YDERE ER UDE AF FUNKTION.
CLASS 1 LASER PRODUCT
LASER KLASSE 1
AREIL
APP
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
VARNING–
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD OCH SPÄRRAN ÄR URKOPPLADE.
BETRAKTA EJ STRÅLEN.
VARO!
AVAT TAESSA JA SOUJALUKITUS OHITETT
OLET AL
TTIINA NÄKYMÄTTÖMÄLLE.
LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
A LASER
DE CLASSE 1
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
AESSA
WARNING: TO PREVENT FIRE
SHOCK HAZARD,
TO RAIN OR MOISTURE.
DO NOT EXPOSE THIS PR ODUCT
OR ELECTRICAL
Safety Information
Getting Started . . . . . . . . . . . . . . . .2
Unpacking the system . . . . . . . . . . . . . . . . . . . .2
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Using the FM and Am Antennas . . . . . . . . .2
Connecting the Speakers . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General Controls . . . . . . . . . . . . . . .3
Main Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing Batteries . . . . . . . . . . . . . . . . . . . . .4
Settings . . . . . . . . . . . . . . . . . . . . . .5
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Showing Demonstration . . . . . . . . . . . . . . . . . .5
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . .5
Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . .5
Activating the Timer . . . . . . . . . . . . . . . . . . .5
Adjusting the Display Brightness . . . . . . . . . . .5
Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Sound Features . . . . . . . . . . . . . . . .6
Preset Equalizer Curves . . . . . . . . . . . . . . . . . . .6
Creating Custom curves . . . . . . . . . . . . . . . . .6
Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Muting Audio . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CD Player . . . . . . . . . . . . . . . . . . . . .7
Notes on CD-R/RW Disc . . . . . . . . . . . . . . . . . . .7
Loading Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Play and Load Simultaneously . . . . . . . . . . .7
Skipping a Disc . . . . . . . . . . . . . . . . . . . . . . . .7
Skipping Tracks . . . . . . . . . . . . . . . . . . . . . . . .7
Searching Through a CD . . . . . . . . . . . . . . . .7
Random Playback . . . . . . . . . . . . . . . . . . . . . .7
Sampling Tracks . . . . . . . . . . . . . . . . . . . . . . .8
Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Setting Up a CD Program . . . . . . . . . . . . . . .8
Playing a Program List . . . . . . . . . . . . . . . . .8
Displaying the Program List . . . . . . . . . . . .8
Deleting Program List . . . . . . . . . . . . . . . . .8
Radio . . . . . . . . . . . . . . . . . . . . . . . .9
Selecting Tuner Band . . . . . . . . . . . . . . . . . . . . .9
Tuning to a Station . . . . . . . . . . . . . . . . . . . . . . .9
Using Presets . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Auto Preset Programming (FM only) . . . . . . . .9
Manually Setting Presets . . . . . . . . . . . . . . . . . .9
Suppressing Stereo Signal . . . . . . . . . . . . . . . . .9
Tuning to an RDS Station . . . . . . . . . . . . . . . . .10
Displaying RDS Station Information . . . . .10
Searching by Program Type (PTY) . . . . . . . . . .10
Tape Player . . . . . . . . . . . . . . . . . . .11
Playing a Tape . . . . . . . . . . . . . . . . . . . . . . . . . .11
Tape Counter . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
From Tuner . . . . . . . . . . . . . . . . . . . . . . . . . .11
From CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
From an Auxiliary Input . . . . . . . . . . . . . . .11
Troubleshooting Tips . . . . . . . . . . .12
Maintenance . . . . . . . . . . . . . . . . .13
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CD Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Tape Player . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Handling CDs . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning CDs . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CD Lens Care . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Important Information . . . . . . . . .14
Safety Precautions . . . . . . . . . . . . . . . . . . . .14
Headset Safety . . . . . . . . . . . . . . . . . . . . . . . . .14
Important Battery Information . . . . . . . . . . .14
Don’t Infringe . . . . . . . . . . . . . . . . . . . . . . . . . .14
Technical Specification . . . . . . . . . . . . . . . . . . .14
1
EN
Table of Content
MS2200 EN 11/17/03 1:59 PM Page 6
Unpacking the system
You should have the following:
• one main unit (with 2 main speakers);
• one remote control;
• one AM loop antenna;
• one user’s guide;
• one Thomson Warranty Card
Back View
1. FM Pigtail Antenna
2. AM Loop Antenna Connector
3. Main Speaker Jacks
Using the FM and AM Antennas
Before you use your audio system, you’ll want to
make sure both the FM and AM antennas are
positioned properly. Uncoil the FM antenna at
the back of the unit, making sure it is fully
extended (you may even want to tape it to the
wall behind the unit if possible. The higher the
better.) You’ll also need to connect the AM
antenna loop to the back of the unit if you listen
to AM stations. Rotate the AM loop antenna for
better reception.
Connecting the Speakers
Match the red wire (on the left speaker) to red
terminal for the left speaker (L) on the back of
the unit and the black wire (on the left speaker )
to the black terminal for left speaker (L). Follow
the same procedure to connect the right (R)
speaker.
Installation
To ensure sufficient ventilation, keep the spacings
shown below free from other surfaces:
2
EN
Getting Started
10 cm
10 cm
Front View
10 cm
10 cm
5 cm
Side View
1
2
3
MS2200 EN 11/17/03 1:59 PM Page 7
Speaker
Wire Connection
Push Speaker terminal tab
down to insert wire.
NOTE: Make sure the insulation
speaker wires at all connection
ends of the
Release tab to lock wire in
the terminal.
is completely removed from the
points.
FM ANTENNA
AM LOOP
+
__
RL
MAIN SPEAKERS 6
+
5 DISC CHANGER
SIMULTANEOUS PLAY AND LOAD SYSTEM
•
N
C
E
L
O
P
S
O
E
ON
IR SENSOR
ECO
ECO
L
SOURCE
GAME
•mp3•
R
CD INFO
CD-R / RW COMPATIBLE
DISC
SKIP
TUNE•PRESET
PRESET EQ
DIGITAL TUNING
TIMER
BANDDIMMER•DEMO
RECORDPROG•SET
CLOCK
RDS
AUTO PROG
B. BOOST
PUSH
CASSETTE DECK
DIGITAL LOGIC DECK
PLAYBACK/ RECORD
Loading...
