Technicolor Connected Home USA DCI401XXXX, DCI401COM2 Users Manual

Important Safety Instructions

 Read these instructions.
 Keep these instructions.
 Heed all warnings.
 Follow all instructions.
 Do not use this apparatus near water.
 Clean only with dry cloth.
 Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

 Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

 Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

 Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

 Only use attachments/accessories specified by the manufacturer.
 Unplug this apparatus during lightning storms or when unused for long periods of

time.

 Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

 If an outside antenna or cable system is connected to the product, be sure the

antenna or cable system is grounded so as to provide some protection against
voltage surges and built-up static charges.

 To reduce the risk of fire or electric shock, do not expose this apparatus to rain or

moisture.

 Batteries (battery pack or batteries installed) shall not be exposed to excessive heat

such as sunshine, fire or the like.

 Warning: Use only the power supply that came with your unit. If the power supply

needs to be replaced, contact your service operator or dealer to obtain an authorized
replacement.

 Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Note

 This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.

2

 This equipment generates, uses and can radiate radio frequency energy and, if not

Model type

DCI401xxxx

Operating voltage

120V AC / 60 Hz / 0.5A

Typical Power
consumption

5.0W (typical)max

6.0W (max)

Weight

0.42 Lb

Dimensions (W x H x
D)

4.33 x 0.96 x 3.19
Inches

Operating
temperature range

59 to 104° F / 15 to
40°C

Storage temperature
range

-4 to 158°F / -20 to
70°C

installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.

 If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

Ensuring optimum performance

 Disconnect the product from the power before you connect the product to (or

disconnect it from) any other equipment. Avoid any contact with the power, which
can be lethal or cause severe electric shock.

 Do not insert anything into any opening of the case.
 Leave the power socket accessible so that you can unplug the set quickly.
 Leave 2 to 3 inches around the product to ensure proper ventilation to it.
 To clean the product, use a dry clean soft cloth with no cleaning solvent or abrasive

products. Clean the ventilation openings regularly.

Environmental information

 The batteries use some hazardous substances which pollute the environment. Do not

dispose of them with other articles. Take care to dispose them at special collecting
points.

Technical specifications

Manufactured under license from Dolby Laboratories.
