Features

This air conditioner is equipped with cooling, heating, and drying functions. Details on these functions are
provided below; refer to these descriptions when using the air conditioner.

• Microprocessor Controlled Operation

The interior compartment of the remote control
unit contains several features to facilitate
automatic operation, easy logically displayed
for easy use.

• Simple One-touch Wireless Remote Control

The remote control unit has several features to
facilitate automatic operation.

• 24-Hour ON or OFF Timer

This timer can be set to automatically turn the
unit on or off at 10 minutes intervals within a
24 hour period.

• 1-Hour OFF Timer

This timer can be set to automatically turn off
the unit at any time after one hour.

• ECONOMY Mode

Pressing this button changes the setting of the
room temperature thermostat, allowing you to
set the temperature at whatever level that you
find comfortable.

• Automatic and 3-step Fan Speed

Auto/High/Medium/Low

• Air Sweep Control

This function moves a flap up and down in the
air outlet, directing air in a sweeping motion
around the room and providing comfort in
every corner.

• High Power Cooling

When a cooling or drying operation is to be
performed, the air conditioner operates for
15 minutes in the high power mode.

• Odor Reduction Mode

When a cooling or drying operation is to
commence, the indoor fan motor is shut down
for 40 seconds to minimize the odors which are
produced when operation starts up.

• Mold Inhibiting Mode

Upon completion of a cooling or drying
operation, the indoor fan motor operates in the
fan mode for 30 seconds to prevent
condensation inside the indoor unit and inhibit
the growth of mold.

• Anti-Mold Filter

This unit is equipped with an anti-mold filter
that inhibits the growth of mold and bacteria.

• Air Clean Filter

An air filter that uses antibacterial filter to
eliminate unpleasant odors and clean the air.

3

Contents

Page

Features ........................................................................................................... 2

Product Information ........................................................................................ 3

Alert Symbols .................................................................................................. 3

Installation Location ........................................................................................4

Electrical Requirements .................................................................................. 4

Safety Instructions .......................................................................................... 4

Names of Parts ................................................................................................ 5

Using the Remote Control Unit .................................................................... 11

Operation with the Remote Control Unit .................................................... 12

1. Automatic Operation ....................................................................... 12

2. Manual Operation ............................................................................ 13

3. Adjusting the Fan Speed ................................................................. 15

4. ECONOMY Mode ............................................................................. 15

Special Remarks ............................................................................................ 17

Setting the Timer ........................................................................................... 18

Setting the 1-Hour OFF Timer ....................................................................... 21

Setting the HIGH POWER Operation............................................................ 21

Tips for Energy Saving ................................................................................. 22

Adjusting the Airflow Direction.................................................................... 23

Operation without the Remote Control Unit ............................................... 24

Care and Cleaning ......................................................................................... 24

Troubleshooting ............................................................................................ 27

Operating Range ........................................................................................... 27

Product Information

If you have problems or questions concerning your Air Conditioner, you
will need the following information. Model and serial numbers are on the
nameplate on the bottom of the cabinet.

Model No. ______________________ Serial No. _________________________

Date of purchase ____________________________________________________

Dealer’s address ____________________________________________________

Phone number_____________________

DECLARATION OF CONFORMITY

This product is marked « » as it satisfies EEC Directive No. 89/336/
EEC, 73/23/EEC and 93/68/EEC.
This declaration will become void in case of mis-usage and/or from non
observance though partial of Manufacturer’s installation and/or
operating instructions.

Alert Symbols

The following symbols used in this manual, alert you to potentially
dangerous conditions to users, service personnel or the appliance:

This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.

This symbol refers to a hazard or unsafe
practice which can result in personal
injury or product or property damage.

CAUTION

4

Installation Location

• We recommend that this air conditioner be installed properly by

qualified installation technicians in accordance with the Installation
Instructions provided with the unit.

• Before installation, check that the voltage of the electric supply in your

home or office is the same as the voltage shown on the nameplate.

• Do not install this air conditioner where there are fumes or
flammable gases, or in an extremely humid space such as a
greenhouse.

• Do not install the air conditioner where excessively high heat­generating objects are placed.

Avoid: To protect the air conditioner from heavy corrosion, avoid installing the

outdoor unit where salty sea water can splash directly onto it or in
sulphurous air near a spa.

Electrical Requirements

1. All wiring must conform to the local electrical codes. Consult your

dealer or a qualified electrician for details.

2. Each unit must be properly grounded with a ground (or earth) wire or

through the supply wiring.

3. Wiring must be done by a qualified electrician.

Safety Instructions

• Read this Instruction Manual carefully before using this air
conditioner. If you still have any difficulties or problems, consult your
dealer for help.

• This air conditioner is designed to give you comfortable room
conditions. Use this only for its intended purpose as described in this
Instruction Manual.

• Never use or store gasoline or other flammable vapor or liquid near
the air conditioner – it is very dangerous.

• This air conditioner has no ventilator for intaking fresh air from
outdoors. You must open doors or windows frequently when you
use gas or oil heating appliances in the same room, which consume
a lot of oxygen from the air. Otherwise there is a risk of suffocation
in an extreme case.

• Do not turn the air conditioner on and off from the power mains
switch. Use the ON/OFF operation button.

• Do not stick anything into the air outlet of the outdoor unit. This is
dangerous because the fan is rotating at high speed.

• Do not let children play with the air conditioner.

• Do not cool or heat the room too much if babies or invalids are

present.

CAUTION

5

Names of Parts

Air intakes

INDOOR UNIT

Air outlet

Remote control unit

Drain hose

Refrigerant tubes

OUTDOOR UNIT

Air outlet

NOTE

This illustration is based on the external view of a standard model.
Consequently, the shape may differ from that of the air conditioner which
you have selected.

This air conditioner consists of an indoor unit and an outdoor unit. You
can control the air conditioner with the remote control unit.

Air Intake Air from the room is drawn into this section and passes through air

filters which remove dust.

Air Outlet Conditioned air is blown out of the air conditioner through the air

outlet.

Remote Control Unit The wireless remote control unit controls power ON/OFF, operation

mode selection, temperature, fan speed, timer setting, and air
sweeping.

Refrigerant T ubes The indoor and outdoor units are connected by copper tubes

through which refrigerant gas flows.

Drain Hose Moisture in the room condenses and drains off through this hose.

Outdoor (Condensing) Unit The outdoor unit contains the compressor, fan motor, heat

exchanger coil, and other electrical components.

6

Unit Display and Operation Selector

IMPORTANT

Avoid using radio equipment such as mobile phone near
(within 1 m) the remote control receiver. Some radio
equipment may cause malfunction of the unit.

If the trouble happens, disconnect power and restart the
air conditioner after a few minutes.

REMOTE CONTROL This section picks up infrared signals from the remote control unit

receiver (transmitter).

Operation selector

ON position This position is for operating the air conditioner with the wireless

remote control unit.
Set the selector normally in this position.

OFF position Switch the selector to the OFF position if you are not going to use the

air conditioner for a few days or longer.

WARNING The OFF position does not disconnect the power. Use the main power

switch to turn off power completely.

TEST position This position is used only when servicing the air conditioner.

CAUTION Do not set at the TEST position for normal operation.

DEMO position This position is used only when setting address of the remote control

unit.

OPERATION lamp This lamp lights when the system is in the continuous AUTO (red,

orange or green), HEAT (red), DRY (orange) and COOL (green) mode.

TIMER lamp This lamp lights when the system is being controlled by the timer.

SERVICE lamp When a fault occurs in the air conditioner, this lamp turns on or flashes

in combination with the other two lamps to indicate the type of fault.

MCAF94/124/184

INDOOR UNIT

Operation
selector

SERVICE
lamp

TIMER
lamp

OPERATION
lamp

REMOTE CONTROL
recelver

TIMER
lamp

OPERATION
lamp

MCAF244

INDOOR UNIT

Operation selector

7

(5) ECONOMY ..............................

(6) High power operation ...........

(7) Flap indication

Auto. flap indication ..............

Flap angle indication .............

Sweep indication....................

(8) Fan speed

Automatic operation .............

HIGH .......................................

MEDIUM .................................

LOW ........................................

(1) Operation mode

AUTO ......................................

HEAT.......................................

DOUBLE SENSOR DRY .........

COOL ......................................

(2) Confirmation of

transmission ..........................

(3) Set temperature

16–30 °C

When set to 28 °C .........

Current temperature

indication ......................

(4) Timer

ON Timer ...............................

OFF Timer ..............................

1-hour OFF Timer ...................

Remote Control Unit (Display)

Displayed when indoor

unit sensor is in use

Displayed when setting

timer

Displayed when
transmitting data

Displayed when setting
temperature

Symbols

Displayed when setting temperature in
automatic operation

8

NOTE

The illustration above pictures the remote control unit after the cover has
been lowered and removed.

Transmitter When you press the buttons on the remote control unit, the mark

appears in the display to transmit the setting changes to the receiver in the
air conditioner.

Sensor A temperature sensor inside the remote control unit senses the room

temperature.

Display Information on the operating conditions is displayed while the remote

control unit is switched on. If the unit is turned off, only the mode that was
set previously is still displayed.

HIGH POWER button : When you press this button, the current operation mode is set to the

HIGH POWER mode, and the unit is operated in this mode for
15 minutes.

ON/OFF operation button

This button is for turning the air conditioner on and off.

: When you press this button, regardless of whether the unit is

operating or stopping, the unit operates for one hour and then
shuts down.

Press the button to increase the set temperature.
Press the button to reduce the set temperature.

For details, see Automatic operation and Manual operation.

Remote Control Unit

Temperature setting

buttons (TEMP.)

1 HR. TIMER button

(1-HOUR OFF TIMER)

Sensor

Transmitter

Display

1 HR. TIMER button

HIGH POWER button

OFF TIME setting button

ON TIME setting button

Return button

Advance button

SET button

CANCEL button

ACL button

Battery compartment (Pull off the
cover to expose the batteries.)

CLOCK button

ECONOMY button

MODE selector button

FLAP button

ADDRESS switch

(Cover closed)

ON/OFF operation button

Temperature setting buttons (TEMP.)

FAN SPEED selector button

A/C SENSOR button

Model No.: RCS-3MVHPN4E

9

(1) (2) (3) (4) (5) (6) (7) (8)

Remote Control Unit (continued)

No display : The timer does not operate.

: The air conditioner stops at the set time.

: The air conditioner starts at the set time.

: The air conditioner stops and starts, or starts and stops, at

the set times every day. For details, see “Setting the Timer”.

ECONOMY button For details, see “ECONOMY Mode”. When you press this button in the

HEAT, DRY or COOL mode, the mark appears in the display, and the
remote control unit will automatically adjust the set temperature to
save energy.

MODE selector button Use this button to select AUTO, HEAT, DRY or COOL mode.

(AUTO) : When this setting is selected, the air conditioner calculates the

difference between the outdoor temperature and the room
temperature and automatically switches to the “COOL”, “DRY”
or “HEAT” mode as appropriate.

(HEAT) : The air conditioner makes the room warmer.

(DRY) : The air conditioner reduces the humidity in the room.

(COOL) : The air conditioner makes the room cooler.

FLAP button Press this button either to select the setting of the airflow direction to

the auto. flap in each mode or one of the six possible positions
manually or to select the sweep function which moves the flap up and
down automatically.

: Auto flap setting: If selected in a heating operation, the flap is set

to position (3) in the following chart. If selected in a cooling or dry
operation, the flap is set at position (7) in the following chart.

: The airflow direction can be set manually. (six positions)

: The flap moves up and down automatically.

NOTE When you press the FLAP button, the air flow direction will be changed

one by one as follows.

FAN SPEED selector button : The air conditioner automatically decides the fan speeds.

: High fan speed

: Medium fan speed

: Low fan speed

ACL button (ALL CLEAR) Puts the remote control unit into pre-operation status. Always press this

button after replacing the batteries.

ON TIME/OFF TIME

setting buttons

Swing

10

ADDRESS switch • Change the address switch to prevent mixing of signals from remote

control units when two Sanyo air conditioners are installed next to each
other. Normally, the address switch is set to A. When switching the
adress, take the steps listed below. Contact your dealer where you made
the purchase if 3 or more Sanyo air conditioners are to be operated.

1 Break off the address switching tabs on the remote control unit, and

set the address switch to B.

2 Insert batteries into the remote control unit, press the ACL button,

and attach the cover.

3 Open the intake grille of the indoor unit, and set the operation knob

to the DEMO position.

4 Press the ON/OFF operation button on the remote control unit, and

check that a receiving tone (beep) is heard from the indoor unit.

5 Set the operation selector to the ON position, and close the intake

grille.

6 Operate the remote control unit, and check that a receiving tone

(beep) is heard from the indoor unit.

• Normally, the tabs on the remote control unit should not be bent.

A/C SENSOR button When you press this button (use a small-tipped object such as a

ballpoint pen), the

mark will appear at the display. And the room
temperature is detected by the sensor which is built into the indoor unit
and the air conditioner is controlled accordingly.

NOTE If the remote control is located near a heat source, such as a space heater

or in direct sunlight, press the A/C SENSOR button to switch to the sensor
on the indoor unit.

NOTE The remote control unit sends the temperature signal to the air conditioner regularly at five minute

intervals. If the signal from the remote control unit stops for more than ten minutes due to the loss of
the remote control unit or other trouble, the air conditioner will switch to the temperature sensor which
is built into the indoor unit and control the room temperature. In these cases, the temperature around
the remote control unit may differ from the temperature detected at the air conditioner’s position.

Remote Control Unit (continued)

11

ACL button

Using the Remote Control Unit

How to Install Batteries

1. Slide the cover in the direction indicated by the arrow

and remove it.

2. Install two AAA alkaline batteries. Make sure the

batteries point in the direction marked in the battery
compartment.

3. Use a thin object such as the tip of a pen to press the

ACL button.

NOTE • The batteries last about six months, depending on how much you

use the remote control unit. Replace the batteries when the remote
control unit’s display fails to indicate, or when the remote control
cannot be used to change the air conditioner’s settings.

• Use two fresh leak-proof type-AAA alkaline batteries.

• In replacing batteries, follow the instructions as mentioned in the
sub-section “How to Install Batteries”.

• If you do not use the remote control unit more than 1 month, take

out the batteries.

How to Use the Remote

Control Unit

When using the remote control unit, always point the unit’s transmitter
head directly at the air conditioner’s receiver.

Air conditioner
(Indoor unit)

Remote control
unit

Receiver

(Transmitter head)

Cover

12

STEP 1 Press the MODE selector button and select (AUTO).
STEP 2 Press the ON/OFF button and switch the air conditioner ON.
STEP 3 Press the temperature setting buttons (TEMP.).

The air conditioner starts operating after automatically selecting the type of operation
—whether heating, drying (dehumidifying) or cooling—that suits the conditions in the
room, and automatically adjusting the temperature, fan speed and airflow direction.

Each time one of the temperature setting buttons (TEMP.) is pressed, the temperature is
changed by 1 °C.

The temperature can be changed from +4 °C (higher) to
–4 °C (lower) from the standard temperature setting.
(The upper limit during cooling is 30 °C.)

Operation with the Remote Control
Unit

1. Automatic Operation

Standard temperature settings during automatic operation

Type of operation Standard temperature setting

Heating 24 °C

Drying 20 °C to 26 °C range

(The exact temperature depends on the prevailing temperature

when the unit starts operating.)

Cooling 27 °C

STEP 2

STEP 3

STEP 1

13

As shown in the figure below, the automatic selection of the operating modes

is determined by the indoor temperature and outside air temperature.

• When multiple indoor units are used and units in other rooms are already operating,
they will be set to the same type of operation as the operating indoor units.

• The temperature, airflow direction and fan speed are set automatically but the airflow
direction and fan speed can be changed to suit your individual preference. It will take
a few seconds for the fan speed to be switched.

2. Manual Operation

NOTE Check that the circuit breaker on the power panel is turned on and that

the operation selector of the indoor unit is in the ON position.

STEP 1

STEP 5

STEP 2

STEP 3

STEP 4

Indoor temperature

Outside air

temperature

Cooling

operation

Drying operation

Temperature setting

(standard)

Approx.

15°C

Heating operation

Approx.

22°C

Approx.

27°C

Approx.

22°C

Approx.

20°C

Approx.

18°C

27°C

20°C to 26°C

24°C

Operation with the Remote Control Unit (continued)

14

Operation with the Remote Control Unit (continued)

• After the cooling or drying operation has stopped, the indoor fan runs
for about 30 seconds to dry out the inside of the air conditioner. (The
operating lamps remain off.) The flap closes after the fan has
stopped.

• If the room temperature rises above the temperature setting during a
drying operation, the unit performs similar operation to cooling, and
when the room temperature approaches the temperature setting, it
performs the humidity-priority drying operation.

• The drying operation does not serve to raise the room temperature.
(When the outside air temperature is low or when the heat quantity
inside the room is low, the room temperature will not rise.)

• A change made to the temperature setting remains stored in the
memory even after operation has stopped.

• If the temperature setting is lowered during a drying operation so that
the unit has switched to a cooling operation, the outdoor unit shuts
down for 3 minutes. (This happens only when one indoor unit is
used.)

• When the unit is running in the drying operation mode while the
temperature setting is higher than the room temperature, the
humidity may not be reduced. In a case like this, select a temperature
setting which is lower than the current room temperature, and
perform the drying operation.

NOTE This appliance has a built-in 3-minute time delay circuit to ensure reliable

operation. When the operation button is pressed, the compressor will
start running within three minutes. In the event of power failure, the unit
will stop.

STEP 1 Press the MODE selector button and select the desired

mode.

For heating operation →
For dehumidifying operation →
For cooling operation →

STEP 2 To start the air conditioner, press the ON/OFF operation

button.

STEP 3 Press the temperature setting buttons to change the

temperature setting to the desired temperature.

Adjustable temperature range:

30 °C max.
16 °C min.

NOTE • Room temperature control works to ensure that the

temperature stabilizes within a range of ±2 °C of the
temperature setting. For this reason, the value displayed
on the remote control unit may differ from the actual
temperature setting. Before the temperature stabilizes,
this difference may exceed the ±2 °C range.

• The operating lamp of the indoor unit lights in one of the
colors shown below.

STEP 4 Set the FAN SPEED selector button to the setting you want.

(Refer to “Adjusting the Airflow Direction” on page 23.)

STEP 5 Press the FLAP button and set the airflow direction as

desired.
(Refer to “Adjusting the Airflow Direction” on page 23.)

To stop the air conditioner, press the ON/OFF operation button again.

Heating Red

Operating lamp Drying Orange

Cooling Green

15

3. Adjusting the Fan Speed

A. Aut omatic

Simply set the FAN SPEED selector button to the

position.

B. Manual If you want to adjust fan speed manually during operation, just set the

FAN SPEED selector button as desired. [ , , or ]

4. ECONOMY Mode

The ECONOMY Mode is used for saving energy.

Press the ECONOMY button while the air conditioner is operating.
The mark appears in the display.

To cancel the ECONOMY function, press the ECONOMY button again.

Operation with the Remote Control Unit (continued)

16

When the ECONOMY mode is selected, the air conditioner
automatically raises the temperature setting 1 °C when 60 minutes
have passed after the selection was made. This enables you to save
energy without sacrificing comfort. This function is convenient when
gentle cooling is needed.

When the ECONOMY mode is selected, the air conditioner
automatically lowers the temperature setting 3 °C when 60 minutes
have passed after the selection was made, and then another 4 °C after
another 2 hours have passed, regardless of the indoor temperature
when ECONOMY was selected. This enables you to save energy
without sacrificing comfort. This function is convenient when gentle
heating is needed.

NOTE The temperature does not shift in the Auto mode during ECONOMY

mode.

B. In Heating Mode:

( )

Operation with the Remote Control Unit (continued)

A. In Cooling and DRY

Mode: ( and )

Setting temperature

Room temperature

Time

1 °C

Setting temperature

Room temperature

Time

3 °C

4 °C

17

Special Remarks

Power failure

during operation

• In the event of power failure, the unit will stop. Though the power is
resumed, the unit will not restart automatically.
Press the ON/OFF operation button and restart the unit again.

Clicking Sound

Clicking sound is heard

from the air conditioner

• In heating or cooling operation, any plastic parts may expand or
shrink due to a sudden temperature change. In this event, a clicking
sound may occur. This is normal, and the sound will soon disappear.

Remote Control Unit • The remote control unit sends the setting condition to the air

conditioner regularly at five minute intervals.

18

1. How to set the present
time

Setting the Timer

(Example) To set to 10:30 pm.

Operation

1. Press the CLOCK button three
times.

2. Press the Advance, Return ( , )
button until PM 10:30 is
displayed.

3. Press the CLOCK button again.

Indication

The time indication alone blinks.

The time can be set in 1-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.

This completes the setting of the
current time.

2. How to set the OFF time (Example) To stop the air conditioner at 11:00 am.

1. Press the OFF TIME setting
button once.

2. Press the Advance, Return ( , )
button until AM 11:00 is
displayed.

3. Press the SET button.

The timer indication blinks
and present OFF time is shown.

The time can be set in 10-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.

The timer indication stops
blinking and the present time is
displayed.

19

3. How to set the ON time (Example) To start operation at 7:10 am.

Setting the Timer (continued)

NOTE • The timer can be programmed while the unit is operating or while it is

stopped.

• A timer program is canceled after the timer has operated. So the
timer should be set every time programming operation is to be
performed.

• The airflow direction, fan speed and temperature setting can be
changed after a timer program has been set even when the unit is
stopped. Even when operation is stopped during an ON timer
program, the unit will start operating when the set time is reached
provided that the program is not canceled.

• As a safeguard to prevent you forgetting to turn off the air
conditioner, the unit’s operation will be stopped if the remote control
unit has not been operated for at least 25 hours after the ON timer
starts.

• When the ON timer is used, the temperature setting may not be
reached by the set time depending on the size and conditions in the
room.

To cancel a timer program • Press the CANCEL button.

• When either an ON or OFF timer is to be canceled, press the button

corresponding to the timer whose program is to be canceled, and
then press the CANCEL button.

Operation

1. Press the ON TIME setting
button once.

2. Press the Advance, Return (

, )
button until AM 7:10 is
displayed.

3. Press the SET button.

Indication

The timer indication blinks
and present ON time is shown.

The time can be set in 10-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.

The timer indication stops
blinking and the present time is
displayed.

NOTE ON timer (comfort programming)

The unit starts operating automatically to attempt to change the
temperature to the desired level by the set time. (The unit operates at the
low fan speed from up to 60 minutes prior to the set time.)

OFF timer

The unit stops operating at the set time.

20

(Example) To start operation at 7:10 am. and stop the air conditioner at
11:00 am.

Setting the Timer (continued)

4. How to set DAILY ON/
OFF REPEAT timer

7:10 am. 11:00 am.

ON OFF

Operation

1. Set the timer ON/OFF times as
shown in 2-1, 2, 3 and 3-1, 2, 3.

Indication

The present time 10:30 pm. and

are displayed.

OFF
time

Present
time

ON
time

Daily
ON/OFF

NOTE • The ON/OFF combination timer uses the current time as the

reference, and it is activated starting from whichever set time
comes first.

• With the ON/OFF combination timer, the settings are repeated
every day.

• You can check the timer ON/OFF times after you have set them
by pressing the ON TIME and OFF TIME setting buttons.

21

Setting the 1-Hour OFF Timer

1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop,

regardless of whether the unit is on or off when this button is pressed.

The indicator in the display indicates that this function is operating.

Setting the 1-Hour OFF Timer:

Regardless of whether the unit is operating or stopped, press the 1 HR.
TIMER button.

appears in the display.

Cancelling the 1-Hour OFF Timer:

Press the ON/OFF operation button to turn the unit off, wait for the unit to
stop operating, and then press the ON/OFF operation button again. The 1­Hour Timer function is now cancelled and the unit operates normally.

NOTE If, while the 1-Hour Timer function is operating, the 1 HR. TIMER button is

pressed once to cancel the function and then again, the unit continues to
operate for one hour from that point in time and then stops.

• The 1 Hour OFF Timer setting is given priority over the DAILY ON/OFF
REPEAT setting.

• It is not possible to use the OFF Timer and 1-Hour OFF Timer together.
Whichever function is set last takes precedence. If the 1 HR. TIMER
button is pressed while the TIMER OFF function operates, the OFF
Timer is cancelled and the unit will stop operating one hour later.

2. Operation together
with the DAILY ON/
OFF REPEAT Timer

Setting the HIGH POWER Operation

1. HIGH POWER Operation This function causes the unit to operate at HIGH POWER in the present

mode of operation for 15 minutes when this button is pressed while the
unit is on. The indicator on the display indicates that this function is
operating.

Canceling the HIGH POWER operation

HIGH POWER operation is canceled by pressing the ON/OFF operation
button, HIGH POWER button (when it is pressed again) or MODE selector
button, when the OFF time or HIGH POWER time setting is reached or
when the ECONOMY mode operation is performed. The 15-minute timer
is also cleared.

It is not possible to use the HIGH POWER operation and ECONOMY mode
operation together. Whichever function is set last takes precedence.
If the HIGH POWER button is pressed while the ECONOMY mode is
operating, the ECONOMY mode operation is cancelled and the unit will
change to the HIGH POWER operation.

2. Operation together with
the ECONOMY mode

22

NOTE

During a heating operation

• The room is heated for 15 minutes by warm air which has a slightly
higher temperature than usual.

• When the HIGH POWER button is pressed during a defrosting
operation, the unit enters the HIGH POWER operating mode upon
completion of the defrosting operation.

Concerning HIGH POWER

operations

Setting the HIGH POWER Operation (continued)

When operating one

indoor unit

During a cooling operation

• The room is cooled down for 15 minutes by cooling at a slightly lower
temperature than usual, and the fan speed is set to the highest fan
speed setting.

During a drying operation

• If the room temperature is higher than the temperature setting, the
room is cooled down for 15 minutes by cooling at a slightly lower
temperature than usual, and if it is close to the temperature setting,
the drying operation is performed, and the fan speed is set to the
highest fan speed setting.

During a cooling or drying operation

• The room is cooled down for 15 minutes by cooling at a slightly lower
temperature than usual, and the fan speed is set to the highest fan
speed setting.

• When the unit is used continuously for 15 minutes, the temperature
setting has been reached during a cooling or heating operation or the
humidity setting has been reached during a drying operation (which is
only when one indoor unit is operated), operation will continue for
the next 5 minutes at a reduced power level, after which the regular
operation is restored.
If the setting is not reached in either case, regular operation is
restored immediately.

• After HIGH POWER operation has finished or when a HIGH POWER
operation has been canceled on the way and then reinstated, regular
operation is performed for about 5 minutes to protect the unit, and
then the HIGH POWER operation is performed.

• During HIGH POWER operations, the room temperature may not
coincide with the temperature setting.

When operating multiple

indoor units

Tips for Energy Saving

Do not • Block the air intake and outlet of the unit. If they are obstructed, the

unit will not work well, and may be damaged.

• Let direct sunlight into the room. Use sunshades, blinds or curtains. If
the walls and ceiling of the room are warmed by the sun, it will take
longer to cool the room.

Do • Always try to keep the air filter clean. (Refer to “Care and Cleaning”.)

A clogged filter will impair the performance of the unit.

• To prevent conditioned air from escaping, keep windows, doors and
any other openings closed.

23

Adjusting the Airflow Direction

1. Horizontal The horizontal airflow can be adjusted by moving the vertical vanes with

your hands to the left or right.

When the humidity is high, the vertical vanes should be in the front
position during the cooling or dehumidifying operation. If the vertical
vanes are positioned all of the way to the right or left, condensation may
begin to form around the air vent and drip down.

2. V ertical The vertical airflow can be adjusted by moving the flap with the remote

control unit. Do not move the flap with your hands. Confirm that the
remote control unit has been turned on. Use the FLAP button to set either
the sweep function or one of the six airflow direction settings.

CAUTION

A. Sweep function

The flap starts moving up and down to
deliver air over the sweep range.

B. Setting the airflow manually

Referring to the above illustration, use the
FLAP button to set the airflow direction
within the range used during the heating,
cooling, or dehumidifying operation.

NOTE • The flap automatically closes when the unit is off.

• During the heating operation, the fan speed will be very low and the

flap will be in the horizontal position (position 6) until the air being
blown out of the unit begins to warm. Once the air warms up, the flap
position and fan speed change to the settings specified with the
remote control.

• Use the FLAP button on the remote control to adjust the position of
the flap. If you move the flap by hand, the factual flap position and the
flap position on the remote control may no longer match. If this
should happen, shut off the unit, wait for the flap to close, and then
turn on the unit again; the flap position will now be normal again.

• Do not have the flap pointed down during cooling and drying
operation. Condensation may begin to form around the air vent and
drip down.

HEAT

SWEEP

SWEEP

COOL

and

DRY

CAUTION

24

Clean the casing and grille of the indoor unit with a vacuum cleaner
brush, or wipe them with a clean, soft cloth.

If these parts are stained, use a clean cloth moistened with a mild liquid
detergent. When cleaning the grille, be careful not to force the vanes out
of place.

1. Never use solvents, or harsh chemicals when cleaning the indoor
unit. Do not wipe the plastic casing using very hot water.

2. Some metal edges and the fins are sharp and may cause injury if
handled improperly; be especially careful when you clean these
parts.

3. The internal coil and other components of the outdoor unit must be
cleaned every year. Consult your dealer or service center.

Operation without the Remote
Control Unit

If you have lost the remote control unit or it has trouble, follow the steps
below.

1. When the air conditioner is not running
If you want to turn on the air conditioner, switch the operation selector to
the OFF position, and then to the ON position.

NOTE The set temperature and fan speed are automatically set at the

last selection before stopping.

2. When the air conditioner is running
If you want to turn off the air conditioner, switch the operation selector to
the OFF position.

Care and Cleaning

1. For safety, be sure to turn the air conditioner off and also to
disconnect the power before cleaning.

2. Do not pour water on the indoor unit to clean it. This will damage
the internal components and cause an electric shock hazard.

INDOOR UNIT

Operation

selector

CAUTION

Casing and Grille

(Indoor Unit)

25

Care and Cleaning (continued)

Anti-Mold Filter

The anti-mold filter behind the air intake grille should be checked and
cleaned at least once every two weeks.

How to remove the

anti-mold filter

1. Grasp both ends

of the air intake
grille and pull it
out and up.

2. Push the anti-

mold filter up
slightly, and then
pull it down.

Cleaning

Use a vacuum cleaner to remove light dust. If there is sticky dust on the
filter, wash the filter in lukewarm, soapy water, rinse it in clean water, and
dry it.

Air intake grille

Anti-mold filter

How to replace the

anti-mold filter

1. With the “FRONT” mark

facing you, slide the anti­mold filter up into the unit
and then lower the handle
into the groove on the unit.

2. After installing the anti-mold

filter, press the locations
marked by the arrows ( )
and close the air intake grille.

Air intake grille

Anti-mold
filter

Insert into the groove on the unit.

26

The air cleaning filter needs to be installed behind the anti-mold filter.

1. Remove the anti-mold

filter.

2. Install the air cleaning

filter in the position
shown in the figure.

3. Reinstall the anti-mold

filter.

NOTE • In general, the filter should be replaced once every three months.

• Dirty air clean filters cannot be washed and reused. Purchase a

replacement filter at your local dealer.

• Wipe clean using a soft, dry cloth.

• To remove stubborn dirt, moisten a cloth in warm water no hotter
than 40 °C, wring thoroughly, and then wipe.

• The air intake grille can be removed in order to wash it with water.

• With the air intake grille open all the way, grip both arms with your

hands and pull toward you to remove.
To remount, hold the air intake grille roughly horizontal and push it in
until the arm shafts fit into the indentations in the main unit, then fit
the grille into place.

Care and Cleaning (continued)

CAUTION

The air cleaning filter removes dust and dirt from the air, and reduces
odors and smoke from tobacco.

This air cleaning filter cannot remove harmful gases or vapors nor
ventilate air in the room. You must open doors or windows frequently
when you use gas or oil heating appliances. Otherwise there is a risk of
suffocation in extreme cases.

How to install the air

cleaning filter

Air
cleaning
filter

Cleaning the main unit and

remote control unit

Removing and remounting

the air intake grille

Air intake grille

Arm

When using a footstool or the like, be careful not to let it tip over.

Washing the grille

with water

• Clean the grille gently using a soft sponge, or the like. Then wipe
away any remaining moisture.

• Neutral detergent may be used to remove stubborn dirt. Then rinse
thoroughly with water and wipe away any remaining moisture.

Air Cleaning Filter

27

Troubleshooting

If your air conditioner does not work properly, first check the following points before requesting service. If it
still does not work properly, contact your dealer or service center.

Trouble Possible Cause Remedy

Air conditioner does not run
at all.

OPERATION lamp blinks and
air conditioner does not
operate.

Compressor runs but soon
stops.

Poor cooling (or heating)
performance.

Clicking sound is heard from
the air conditioner.

OPERATION lamp lights but
outdoor unit will not run.

Operating Range

The air conditioner is operable within the temperature ranges as listed below:

Temperature Indoor air temperature Outdoor air temperature

COOLING

Max. 32 °C DB / 23 °C WB 43 °C DB

Min. 19 °C DB / 14 °C WB 19 °C DB

HEATING

Max. 27 °C DB / 19 °C WB 24 °C DB / 18 °C WB

Min. 16 °C DB / –WB — / – 15 °C WB

1. Restore power.

2. Contact service center.

3. Consult your electrician or dealer.

4. Press the button again.

5. Replace batteries.

Contact service center.

Remove obstruction.

1. Clean air filter to improve airflow.

2. Eliminate heat source if possible.

3. Shut them to keep the heat (or
cold) out.

4. Remove it to ensure good airflow.

5. Set the temperature lower (or
higher).

6. (Consult your dealer or try to use
a back-up heater.)

This is normal, and the sound will
soon disappear.

1. Turn off the power then restart the
air conditioner after 1 minute.

2. Consult your dealer.

1. Power failure.

2. Leakage circuit breaker tripped.

3. Line voltage is too low.

4. Operation button is OFF.

5. Batteries in remote control unit
have run down.

Trouble in wiring system.

Obstruction in front of condenser coil.

1. Dirty or clogged air filter.

2. Heat source or many people in
room.

3. Doors and/or windows are open.

4. Obstacle near air intake or air
discharge port.

5. Thermostat is set too high for
cooling (or too low for heating).

6. (Outdoor temperature is too low
for heating.)

In heating or cooling operation, any
plastic parts may expand or shrink
due to a sudden temperature change.
In this event, a clicking sound may
occur.

1. The use of cellular phones near the
air conditioner may cause
disturbance to its normal
operation.

COP-INVERTER-ARGO.qxd 6-02-2004 16:07 Pagina 2

R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France

Tél. [phone] - Fax [phone]

R.C.S. Bourg-en-Bresse B 759 200 728

In order to carry on a constant improvement, our products can be modified without prior notice.

Per garantire un costante miglioramento dei nostri prodotti, ci riserviamo di modificarli senza preavviso.

Par souci d’amélioration constante, nos produits peuvent être modifiés sans préavis.

Unsere Produkte werden laufend verbessert und können Vorankündigung abgeändert Werden.

En el interés de mejoras constantes, nuestros productos pueden modificarse sin aviso prévio.
