Technaxx Musicman BT-X7 User guide

MusicMan

®

NANO Bluetooth Soundstation BT–X7

User Manual

Declaration of Conformity is under: www.technaxx.de (in bottom bar “Konformitätserklärung”)

Probably the smallest speaker in the world!

Wireless mini speaker with Bluetooth function in a unique design, a nice accessory for a
Smartphone, Tablet PC, computer, etc.

Features

 Easy conection with Bluetooth compatible devices (= Pairing)
 Built-in hands-free function with built-in microphone
 Built-in rechargable Lithium-Polymer 300mAh battery
 Playing time approx. 4 hours by medium volume
 Bluetooth Version 3.0 with 2W output power
 Volume control buttons and ON/OFF button
 Ideal for traveling, easy installation, crystal clear sound quality

Charging of the battery

Plug in the MicroUSB cable* (* included) MicroUSB slot of the speaker. Then connect the
USB port to the USB slot of PC or USB 5V 500mAh charging adapter** (**not included).
Charging time is approximately 1.5 hours. While loading, the red LED lights continously.
When the speaker is fully loaded, the red LED turns off. Always fully upload battery, please.

Power ON / OFF:

Press the button at least for 3 seconds.

Bluetooth Connection:

(1) When the speaker is powered on, the red and the blue LEDs are flickering. The speaker
is now ready to pairing (= connect to Bluetooth).

(2) Scan in your Bluetooth compatible devices under Bluetooth settings and you find the
Bluetooth device with the name “MusicMan NANO”. Select and connect to your smart
phone. After connected successfully, you will head a short sound, the Blue LED blinks
slowly.

There are two ways of navigation:

Either you can navigate the speaker through it’s buttons, or you also can navigate the
speaker directly through your Bluetooth connected device.

 Short press of the button to pause and play.

 Short press of the button to go to the next song.

 Short press of the button to go to the last song.

 Long press of the button to increase the volume.

 Long press of the button to decrease the volume.

Hands-free Function

When a call is coming in, make a short press of the button for hands-free
microphone function and to except the call. To finish the call, you either can press the

button again, or you finish the call through the Bluetooth connected device, e.g. a

smart phone.

 The speaker can play music when linked to a mobile phone, MP3, MP4, PC, iPOD or to
another audio device, which must have a 3.5mm socket or Bluetooth.

Line–IN

Connect your Smartphone or audio device with the 3.5mm socket of the speaker. Use the

3.5mm cable** (**not included). First turn ON your Smartphone or audio device and the
speaker. Start the audio playback from your Smartphone or audio device. You can listen to
the audio playback over the speaker. To stop the audio playback, unplug the 3.5mm cable
from the speaker.

The buttons and and have no function!
