Technaxx
®
FMT600BT Transmitter
User Manual
Transfer of music and calls directly from your Bluetooth device
to your car radio
This device complies with the requirements of the standards referred to the Directive R&TTE 1999/5/EC.
The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom
“Konformitätserklärung”). Before using the device the first time, read the user manual carefully.
Turn OFF nearby Bluetooth devices to avoid signal interference!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line
and 42 cent/minute from mobile networks). Free Email: support@technaxx.de
Features
Wirelessly transmit phone calls from Bluetooth mobile phones to the car FM stereo
system, for every car type without modification Take convenient phone calls and still drive
safely and transmit wirelessly your MP3 music to the car radio via UKW Built-in
Microphone for hands-free handling (switchs to hands-free mode automatically from music
playing status when receiving calls) USB port for charging a mobile device, e.g. iPad
(Output 5V/2.1A) USB port to plug in an USB flash drive (up to 32GB) with MP3 music
tracks Bluetooth chip is compatible with a wide range of Bluetooth enabled devices (=
Pairing) Last saved UKW frequency stays saved Steaming music in MP3/WMA format
from a USB flash drive 3.5mm AUX jack: music playback from external audio devices
(iPod, MP3 player, etc.) Remote control (included) for more convenient operation
“Voice prompts” (means: spoken announcement) Easy handling and installation (just plug
it into the 12V/24V socket of a vehicle)
Technical Specifications
Bluetooth module / BT version CSR BC8635 / Bluetooth version 4.0
Bluetooth operating distance max. 10m
LCD display size 20 x 25.5 mm (1.1“)
Frequency range 87.6 – 107.9 MHz, max. 3m
Frequency stability ±10ppml
Audio input 3.5mm stereo jack
Music format MP3, WMA
Memory USB up to 32GB
FM transmitter input DC 12V – 24V
Charger output 5V / 2.1A
Weight / Dimensions 45 g / (L) 7,5 x (W) 3,4 x (H) 10,5 cm
Package Contents
FMT600BT Transmitter, AUX–IN cable, Remote
control, User Manual
View of device
AUX-IN port
SD Card Slot
Volume + / Volume –
USB Reader
Previous button / Next button
Frequency modulation “M”
Output 5V / 2.1 A
Answer / Hang off
Play / Pause
Using FM Transmitter function
(a) Plug the FM transmitter into the cigarette lighter port or power port of your vehicle.
(b) First tune your radio to a free FM frequency, then match the same frequency to the FM
transmitter.
(c) Insert a USB flash drive, which contains MP3 files, into the USB port. It will play and
transmit the MP3 files automatically. Attention: only the inward USB Port can serve as a
USB Reader!
(d) Line-IN function: Use the provided audio cable to connect a MP3/MP4 player or
another external device to the AUX–IN port of this FM transmitter. When using this function,
you have to stop playback from the USB flash drive, and all functions will be controlled by
the external device.
Using Bluetooth function
Using Bluetooth for the first time, you need to pair your mobile device with this FM
transmitter.
(a) Activate the Bluetooth function on your mobile device. Then search the NEW device.
When the mobile device has detected this FM transmitter with the name "TECHNAXX", pair
the devices by using the original password "0000".
(b) In the music playback mode this FM transmitter will automatically switch to the
telephone mode, when there is an incoming call.
Bluetooth calling
Answer the incoming call
Hang off a call
Dial the last number
When making a call, you can only dial the phone number by your mobile phone, but once
the call is connected, you can use the hands-free function.
Press the blue knob
Press the blue knob
Press 2x the blue knob
Using USB charger function
When this FM transmitter is powered from car lighter socket, connect the USB output port
5V/2.1A of this FM transmitter to your mobile device with a special USB cable** (**not
included). This FM transmitter can be used as charger for mobile devices. ATTENTION:
The USB output port with 5V/2.1A is for charging an external device (e.g. iPad).
Get access to Menu Lists
(a) “Play” mode
While music is playing, press the “M” button for more then 3 seconds to see this menu:
Language select the language you prefer
Contrast change the contrast of the display
Firmware version see the firmware version of the FM transmitter
Tx-Power
Exit select to finish the configuration
(b) “Pause” mode:
Music will pause when you press the button. Then press the “M” button for more then
3 seconds to see this menu list:
U-disk Dir select the file to play
Delete file select the file to delete
Delete all select to delete all the file
Language select the language you prefer
Contrast change the contrast of the display
Firmware version see the firmware version of the FM transmitter
Exit select to finish the configuration
change the transmission power depending on the region
(Europe, ROW)
ATTENTION (see remote control)
(a) Conversion between regional configurations
This product also supports various regional configurations. Press the “M” button for more
then 3 seconds till the menu appears. Choose “Tx-Power” and then press the “M” button
on the FM transmitter to choose “Europe” (in Europe) or “ROW” ( in the rest of the world).
Then press the “M” button on the FM transmitter to confirm. [The sound quality under
“ROW” is better than under “Europe” mode.]
(b) Conversion from Bluetooth to USB flash drive
When the FM transmitter is playing the music from your mobile phone via Bluetooth, press
the “Pause” button on the FM transmitter. After ~ 10 seconds it appears on the screen the
following: “Press M key”. Then press the “M” button. The FM transmitter then will play the
music from USB flash drive.
View of remote control
Most of the function can be fulfilled by the remote control.
Folder Switch
Loop mode Selector
EQ Selector
Number Selector
Answer / Hang off
Play / Pause
Channel + / –
Volume + / –
Prev. / Next
(Previous Song / Next Song)
Quick Using Guide
Operation
Guide
Answer / Hang
up a call
Play music /
Pause music
Increase the
volume
FM transmitter Remote Control
Press button to answer a call
Press button to hang off a call
Press button to play music
Press button again to pause
music playback
Rotate clockwise to increase the
volume.
Press button
Press button
Press
Volume.
VOL+
to increase the
Decrease the
volume
Set Frequency
Rotate anticlockwise to decrease the
volume.
Press
press to increase the
frequency.
Press to decrease the
frequency.
Press to play the next song.
“M”
button first. Then
Press
volume.
Press
by 0.1MHz. Press
to decrease by 0.1MHz
Or press the numbers of the
frequency what you desired, then
press CH+ button to confirm.
Press to play the next
song.
Press to play the previous
VOL–
CH+
button to increase
to decrease the
CH–
button
Choose Music
Press to play the previous
song.
song.
Or press the number of the song
and then press
to confirm.
Choose EQ
” option by pressing
d
Support by remote control only
Press
favorite EQ.
EQ
button to choose your
Change
Loop Mode
Change
Language
Support by remote control only
Press
seconds first. Then choose
“Language
“Language” to choose the desired
language by pressing an
Press
seconds first. Then choose
“M”
button for more then 3
and . Short press
. Then press “M” to confirm.
“M”
button for more then 3
Press
loop mode.
Support by FM transmitter only
button to change to
Change
Contrast
Switch Folder
“Contrast” option by pressing
and . Short press “Contrast” to
choose a contrast setting by
pressing and . Then
press “M” to confirm.
Press
MODE for more then 3 seconds first.
Then choose “USB-disk Dir” or
“Card Folder” and press “M” button
to confirm. Choose your desired
folder and then press “M” button to
confirm this folder.
“M”
button under PAUSE
Support by FM transmitter only
Press
switch the folder.
Folder+
or
Folder–
How to solve problems
The FM transmitter does not start: Check the fuse first. Exact handling see at the
beginning of the user manual (How to replace the fuse).
The fuse thread is blown: The fuse has to be exchanged by an equal fuse. Exact handling
see at the beginning of the user manual (How to replace the fuse).
The device does not switches on again: Check the function of the cigarette lighter.
The cigarette lighter has no function: Contact your car garage.
Problem when operating: First switch off the FM transmitter and then switch it on again.
Warnings
Do not attempt to disassemble the device, it may result in short-circuit or even damage.
Do not drop or shake the device, it may break internal circuit boards or mechanics.
Keep the device in dry and ventilated environment. Avoid high humidity and high
temperature. Also batteries should not be exposed to excessive heat or direct sunlight.
Keep the surface of the device clean, but do not use organic solvents.
Keep the device away from little children.
Hints for Environment Protection: Packages materials are raw materials
and can be recycled. Do not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from contamination and
pollution (use a clean drapery). Avoid using rough, coarse-grained
materials or solvents/aggressive cleaner. Wipe the cleaned device
accurately. Important Notice: Should battery fluid leak from a battery, wipe
the battery case with a soft cloth dry. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
