Technaxx
®
Fittypet TX-46
User Manual
This device complies with the requirements of the standards referred to the Directive
R&TTE 1999/5/EC. The Declaration of Conformity you find here: www.technaxx.de/ (in
bar at the bottom “Konformitätserklärung”). Before using the device the first time, read the
user manual carefully.
Turn OFF nearby Bluetooth devices to avoid signal interference!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German
fixed-line and 42 cent/minute from mobile networks). Free Email: support@technaxx.de
Features
Connection via Bluetooth 4.0 with transmission distance of ~10m
Taxable via free iOS and Android APP, easy to install the APP and to use it
Track your dog’s activity, sleep rhythm and physical condition
Reminder function of deworm and vaccinum schedule
Enter your dog’s medical records
Supports Apple devices: iPhone 4s and higher, iPod touch 5, iPad 3/4, iPad Air / mini /
mini2 and later version of Apple devices with iOS 7.0
Supports Android devices: Samsung S3 / S4 / S5 / Galaxy Note 2 / Galaxy Note 3
Pleasant fitting on your dog’s collar
No risk for your dog of getting stuck
Compete and share your success with friends via Facebook & Twitter
Protection class IP67
Ideal for making friends with other dog lovers
Technical Specifications
Bluetooth version Bluetooth 4.0 / BLE technic / transmission distance ~10m
Storage One week data storage
LED indicator light Shows the status of synchronization
Battery Replacable cell battery CR2032 with 220mAh
Weight / Dimensions 9 g / (L) 40 x (W) 33 x (H) 4 mm
Weight / Dimensions of the
rubber band
1 g / (L) 40 x (W) 15 x (H) 1 mm
Package Contents
Fittypet TX-46, Opener, Cell battery CR2032, 2 rubber
bands, User Manual
1. Installation
2. Put the FITTYPET (= P1) on the collar
3. Software
3.1. Download and install Fittypet APP
Download Fittypet APP from App store for iOS devices or Google Play Store for android
devices.
3.2. Register a new account
3.2.1. Open the application, click on the “Register”’
button, if you have no Account to login. If you forgot
your password then click on “Forget my password” and
a temporarily password will be sent to your email
account automatically. Check your email account
which you already registered for Fittypet. Input the
temporarily password to login and then you can insert
your new password.
3.2.2. Fill in Email account and
password, and then click on “Register”.
3.2.3. Continue to fill in your data like
First Name, Last Name, Picture Profile,
Gender, and then click on “Done”.
4. Binding
4.1. Click on “Fittypet Setup” and then on “Fittypet conection”. Then fill in the
relevant information of your dog.
4.2. Click on “Done” to proceed.
4.3. Searching the devices around
you, all what you see on the pictuer
as “orange dot’s” are all Fittypet in
your area.
4.4. Choose one to bind. During
binding process, you will see at first
the red light of the device flashes 3
times. Click on “Bind” to complete the
binding. Then you will see this picture.
5. Synchronize data
5.1. Make sure your Fittypet is nearby
your mobile phone. Then click on
“Synch” to start synchronizing data
from your Fittypet. When finished, you
see the last synchronizing time.
5.2. When synchronizing your phone, it will scan your Fittypet, then connect it. The LED
in the Fittypet will blink twice times RED when the connection was successfully.
6. Add one more dog (optional)
5.3. After synchronizing successfully, the data will be analyzed in the cloud and then
you can see the result like in the picture below.
6.1. “My Profile” “My Dog”
Click on the icon to add one more dog.
NOTE that the first time you use this device, the index data about “Mood” will come
out after approx. 3 hour later. Because this device has to collect enough activity
information from your dog to analyse it, and after that the index will come out.
6.2. HOME: After Login was successfully,
you will see the main page (see picture)
with the following sub pages:
(a) Fittypet setting
(b) Deworm
(c) Medical record
(d) Vaccinum
Read the detailed explainations of these
sub pages now in the below text.
(a) Fittypet: Press the button “Fittypet” to
enter to Fittypet setting. In this menu you
can add dogs and bind or unbind the
Fittypet. When you click on the button
“Bind now” your mobile device starts
automatically searching for the Fittypet
near to you. If the Fittypet is not belonging
to somebody, then you can bind to your
Fittypet. If founded Fittypet is already
registered under other person, then you
must unbind the Fittypet from this person
and register or unbind to the Fittypet.
(b) Deworm: Here you can set a reminder time for Deworming your dog. You will be
informed via Email and PIP tone 2 hours before your appointment.
(c) Medical record: Under this menu you can add the medical record or see the
medical history of your dog.
(d) Vaacinum: Here you can set a reminder time for vaacination of your dog. You will
be informed via Email and PIP tone 2 hours before your appointment.
6.3. DISCOVER = COMMUNITY: Here
you can comment or LIKE the posts from
your friends, or chat with your friends of
the community. Before you do this, you
must add some friends.
This sub menu is almost the same as
chatting under Facebook or WeChat.
6.4. MESSAGES: Here you can see
posts from yourself or from your added
friends.
The message can be edited or
commented.
My Pets: Here you can edit the profile of your dog like Nickname, Category, Birthday,
Gender and Weight of the dog or you can add a new pet. Fill all the data of your new pet.
My Followers: Here will be collected the persons you are following. You can comment or
send a new message. You can also chat with persons following you.
My Fans: These are persons which are following you. You can chat with these people
when they are online or leave a message.
My Posts: Here you can see your own posts & edit them, comment, like or chat with this
groups.
My Collects: Your favorite posts can be collected here. You can comment, like or chat with
the person you collect.
System settings: Here you can change the password, delete the cache or read the
information about the company.
Security and Disposal Hints for Batteries: Hold children off batteries. When a child
swallowed a battery go to a doctors place or bring the child into a hospital promptly! Look
for the right polarity (+) and (–) of batteries! Always change all batteries. Never use old and
new batteries or batteries of different types together. Never short, open, deform or load up
batteries! Risk of injury! Never throw batteries into fire! Risk of explosion!
Hints for Environment Protection: Packages materials are raw materials
and can be recycled. Do not disposal old devices or batteries into the
domestic waste. Cleaning: Protect the device from contamination and
pollution (use a clean drapery). Avoid using rough, coarse-grained
materials or solvents or aggressive cleaner. Wipe the cleaned device
accurately. Important Notice: Should battery fluid leak from a battery, wipe
the battery case with a soft cloth dry. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
6.5. PROFILE: Here you find 6 Sub
menus:
(a) My Pets = My Dogs
(b) My Followers
(c) My Fans
(d) My Posts
(e) My Collects
(f) System Settings
