Technaxx Easy IP-Cam HD wireless TX-55 User manual

Technaxx® * User Manual

Easy IP-Cam HD wireless TX-55

Security Camera HD powered by batteries for indoor and outdoor use

The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,

to which this user manual belongs, complies with the essential requirements of the

standards referred to the Directive R&TTE 2014/53/EU. The Declaration of Conformity you

find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before using

the device the first time, read the user manual carefully.

Service phone No. for technical support: 01805 012643 (14 cent/minute from German
fixed-line and 42 cent/minute from mobile networks). Free Email: [e-mail]

If you drill a hole in the wall, please make sure that power cables, electrical cords and/or

pipelines are not damaged. When using the supplied mounting material, we do not take the
liability for a professional installation. You are entirely responsible to ensure that the
mounting material is suitable for the particular masonry, and that the installation is done
properly. When working at higher altitudes, there is danger of falling! Therefore, use
suitable safeguards.

Content

Introduction .......................................................................................................................... 0

1. Features ....................................................................................................................... 1

2. Technical specifications ................................................................................................ 1

3. Product View................................................................................................................. 2

3.1 Front .......................................................................................................................... 2

3.2 Rear .......................................................................................................................... 2

4. Setup Device ................................................................................................................ 2

4.1 Install Device ............................................................................................................. 2

4.2 Install Easy IP Battery APP ....................................................................................... 3

4.3 Add Camera from AP Mode ...................................................................................... 3

4.4 Delete Camera ( Delete) ...................................................................................... 6

4.5 Resetting the device .................................................................................................. 6

4.6 MicroSD card and camera positioning ...................................................................... 6

4.7 Mounting ................................................................................................................... 6

5. Monitor Easy IP Battery Camera .................................................................................. 7

5.1 Monitor Camera ........................................................................................................ 7

5.2 Monitor Event Detection ............................................................................................ 8

5.3 Event record list (Camera Record Management) ...................................................... 8

6. Settings ......................................................................................................................... 9

6.1 Camera Setup ........................................................................................................... 9

6.2 Camera setting ........................................................................................................ 10

1. Features

 Ideal for monitoring indoor & outdoor locations, like rooms, garage, garden & areas

difficult to view

 No power connection required, working with batteries

 Standby time ~3–5 months (with 1–3 events/day)

 Push notificaton via the APP when motion is detected

 Video resolution HD 1280x720 (720P) @ 30fps max.

 1MP CMOS image sensor

 IR LED for clear night shots

 Motion detection: PIR-Sensor ~5–6m, triggering time ~1–1.5 sec.

 Easy to attach via magnet, 3M adhesive stripe or screws

 Easy setup by QR code scanning at iOS & Android device

 Free iOS & Android APP for live monitoring playback

 Built-in microphone for audio recordings  IPX4 protection class (splashproof)

2. Technical specifications

Video resolution HD 1280x720 (720P) @ 30fps max. for video and event recordings

Image sensor 1/4" CMOS OV9712, 1 megapixel

Lens F/NO=2.4, f=2.45mm, 120° viewing angle, fixed focus

Depth of field ~50cm to infinity

White balance / Exposure Automatically

WiFi / connection distance Built-in WiFi module IEEE 802.11b/g/n, ~20–30m distance

Audio encoder / Input AAC & AC3 mono / sample rate 48K & built-in microphone

Video encoder / File format H.264 / MP4

Picture resolution / Format 1280x800 / JPG

Night vision High power IR LED lights with removable IR filter

PIR detection range / PIR triggering time ~5–6m / ~1–1.5 seconds

Storage MicroSD card* up to 32GB (*not included)

Power 4x CR123A batteries** (**included)

Weight / Dimensions

150.5g (without batteries)

(L) 11.2 x (W) 6.5 x (H) 7.4cm (with stand)

Easy IP-Cam HD wireless TX-55, Camera chassis, 4x

Package Contents

Keep this manual for future reference or product sharing carefully. Do the same with the

original accessorie(s) for this product. In case of warranty, please contact the dealer or the

store where you bought this product

screws & 3M adhesive stripe, Powerful magnet with iron

plate, 4x CR123A batteries, User Manual

1

3. Product View

3.1 Front

3.2 Rear

1 PIR Sensor

2 IR LED’s

3 Status LED

4 Microphone

5 Lens

6 Light Sensor

7 Ready LED

1 Reset Button

2 MicroSD Slot

3 Battery Door

4 Battery Compartment

4. Setup Device

TX-55 has a built-in WiFi network and can connect to your WiFi router directly. Therefore,

for the first time of TX-55 use, you need to set up the WiFi network and assign to an

available network (WiFi router) which is linked to the internet.

4.1 Install Device

To open the battery compartment turn right the magnet chassis of the camera, open the

battery compartment and insert the included batteries. Make sure the battery polarities

match the (+ and -) sign indicated in the battery compartment. Close the battery cover and

the camera auto powers on. The RED Led of the camera is flashing slowly for about 3

seconds and turns off. After that the BLUE Led starts flashing slowly. Now the camera is in

Access Point Mode (AP Mode).

2

4.2 Install Easy IP Battery APP

Search and find the Easy IP Battery APP from the APP Store

for iOS or the Google Play Store for Android.

Then install it in your mobile device.

Press the Easy IP Battery icon to start it.

4.3 Add Camera from AP Mode

In the AP Mode, the Ready LED is flashing slowly in BLUE and the WiFi function is active.

iOS configuration steps:

1. Press the add camera icon

2. Press WiFi Setup.

3. Press “Next”.

4. Enter the WiFi password of the router your Smartphone is connected to.

5. Press “Next”

6. Enter a new camera password (for safety use a password with min. 6 characters)

7. Press “Next”

from the APP to add camera.

8. Enter camera name. (Camera name can be customized like office, hall, garden, etc.)

9. Press “Next”

10. Press the Home button and go to the WiFi settings of the iPhone. Then select and
connect with "Device_#####", no need to enter password. Wait around 60 sec. and

make sure you see

Battery APP.

appear. Press Home button again and go back to Easy IP

3

11. Press “Next” the device will be configured. After the TX-55 is set up, press “Finish” to

complete. The Ready LED turns off and reboots the camera. Status LED flashing in

Red within 10 sec. Then both the Ready and Status LED are on. If the configuration

couldn’t finish press “Retry” or start the configuration again. The camera is ready for

monitoring from your mobile device when camera is online.

12. Press “Finish”

Android configuration steps:

1. Press the Add Camera icon

2. Press the WiFi Setup.

3. Select the WiFi network. Press scan to find different WiFi network in your surroundings.

Default WiFi network is set as the network your Smartphone is connected with.

4. Press “Next”.

5. Enter the WiFi password of the router. You have selected.

6. Press “Next

from the APP to add camera.

4

7. The camera that should be connected will be found automatically. If you have more

than one camera in your network you can select the device from the menu next to the

device name or scan for devices with the button “Scan”.

8. Press “Next”

9. Enter a new camera password. (For safety use a password with minimum of 6

character)

10. Press “Next”

11. Enter camera name. (Camera name can be customized like office, hall, garden, etc.)

12. Press “Next”

13. Shows the device name that is going to be configured.

14. Press “Finish” the device will be configured. After the TX-55 is set up the Ready LED

turns off and reboots the camera. Status LED flashing in Red within 10 sec. Then both

the Ready and Status LED are on. If the configuration couldn’t finished press “Retry”

or start the configuration again. The camera is ready for monitoring from your mobile

device when camera is online.

Note:

1. If the assigned WiFi network of the camera has changed, the camera must use the AP

Mode to set the new assigned WiFi network again.

2. Make sure the assigned WiFi has enough bandwidth otherwise the camera is hard to

reach or needs longer waiting time to access the internet.

5
