1
User Manual
Dear customer:
Thank you for choosing this mobile phone. This mobile phone incorporates
the latest world advanced functions, enabling simple and convenient
operation satisfying your special requirements.
The mobile phone supports T-FLASH (memory) card and Dual SIM standby. It
integrates the following available functions: SMS, MP3, MP4, Camera, FM
radio, Alarm, Video recorder and Calendar, enabling you arranging your work,
study and life freely; with long standby duration, as well as service and
calculator, your communication will be easier and smoother; powerful File
manager allows you to manage the files conveniently. In addition, the chord
ringtone allows you selecting music to set as ringtone; the personalized
appearance also can satisfy your selection.
Note: User Manual is used to guide the user about the functionality of the
phone. Some functions may vary due to modifications and up gradations of
software or due to print mistakes.
2
Contents
Safety precautions......................................................................... 5
About the phone............................................................................ 7
Display settings................................................................................................................7
Keys functions................................................................................................................. 7
Status icons.....................................................................................................................8
Getting started............................................................................... 8
First call........................................................................................................................... 8
Installing SIM cards......................................................................................................... 9
Installing memory card.................................................................................................... 9
Battery and charging..................................................................................................... 10
Installing the battery.......................................................................................................... 10
Charging the battery.......................................................................................................... 10
Battery status.................................................................................................................... 10
Using battery..................................................................................................................... 10
Switching on/off............................................................................................................. 11
Password........................................................................................................................... 12
Phone password................................................................................................................ 12
SIM1 PIN........................................................................................................................... 12
SIM2 PIN........................................................................................................................... 12
Disabling password........................................................................................................... 13
Using hands free kit.......................................................................................................13
Keypad lock...................................................................................................................13
Specified keys................................................................................................................13
Language and input methods........................................................................................13
Noun..............................................................................................................................14
Making a DDD................................................................................................................... 14
Making an IDD................................................................................................................... 14
Calling extension............................................................................................................... 14
Emergency call.................................................................................................................. 14
IMEI................................................................................................................................... 15
Calling........................................................................................... 15
Making Calls..................................................................................................................15
Making an International Call.............................................................................................. 15
Dialing extension............................................................................................................... 15
Making a call from the phonebook.................................................................................... 15
Latest numbers redial........................................................................................................ 15
Receiving Calls..............................................................................................................16
Rejecting Calls...............................................................................................................16
Options in a Call............................................................................................................ 16
Adjust volume................................................................................................................16
Menu guide................................................................................... 17
Phonebook.....................................................................................................................17
3
Messages...................................................................................................................... 17
Write message.................................................................................................................. 18
Inbox.................................................................................................................................. 18
Drafts................................................................................................................................. 19
Outbox............................................................................................................................... 19
Sent messages.................................................................................................................. 19
SMS settings..................................................................................................................... 19
Call center......................................................................................................................20
Call logs............................................................................................................................. 20
Call settings....................................................................................................................... 20
Multimedia..................................................................................................................... 22
Camera.............................................................................................................................. 22
Image viewer..................................................................................................................... 22
Video recorder................................................................................................................... 23
Video player...................................................................................................................... 23
Audio player...................................................................................................................... 23
Sound recorder.................................................................................................................. 23
FM radio............................................................................................................................ 24
Games...........................................................................................................................24
Organizer.......................................................................................................................24
File manager..................................................................................................................... 24
Calculator.......................................................................................................................... 25
Ebook reader..................................................................................................................... 26
Calendar............................................................................................................................ 26
Alarm................................................................................................................................. 26
World clock........................................................................................................................ 26
Torch................................................................................................................................. 26
User profiles...................................................................................................................26
Settings..........................................................................................................................27
Shortcuts........................................................................................................................... 27
Multi SIM settings.............................................................................................................. 27
Phone settings................................................................................................................... 28
Network settings................................................................................................................ 28
Security settings................................................................................................................ 28
Connectivity....................................................................................................................... 29
Restore factory settings.................................................................................................... 29
Services.........................................................................................................................29
Appendix....................................................................................... 30
Appendix A: Please take care of your mobile phone.....................................................30
Maintenance...................................................................................................................... 30
Appendix B: Troubleshooting........................................................................................ 30
Appendix C: Abbreviation and explanation................................................................... 31
Appendix D: Optional parts............................................................................................31
4
Safety precautions
Please read and follow these concise rules carefully to prevent danger or breaking laws.
Driving safety
Do not use mobile phone when driving. Use the hands-free accessories if you have to use the phone.
Put the mobile phone in the holder, instead of the passenger seat or any place that the phone will fall
off.
Power off in aircraft
The interference of mobile phone will affect the flight safety and it is illegal to use mobile phone in
aircraft. Please switch off you mobile phone before boarding.
Power off in the operation area of explosion
Please follow the regulations or rules and switch off your mobile phone in or near operation area of
explosion.
Power off near dangerous articles
Please turn off your mobile phone at gas station or places near fuels and chemicals.
In hospitals
Please follow the regulations or rules of hospitals when you use mobile phone there. Switch the device
off near medical equipment. Any wireless device, including mobile phone, will interfere with the medical
devices which are not fully protected. Other electronic devices also may be affected. If you have any
question, please consult your doctor or the manufacturer.
Interference
Any mobile phone might be interfered with and its performance will be affected thereby.
Professional service
Only qualified maintenance personnel can install or maintain this mobile phone. It may cause serious
danger and also violates warranty clauses if you install or maintain the mobile phone by yourself.
5
Accessories and battery
Use manufacturer approved accessories and batteries only.
Rational application
Use the mobile phone in normal way. Do not put your mobile phone in the environment with too high
temperature (higher than 60 ), for example, put it under the window which is irradiated by sunshine
directly. Please use wet or antistatic cloth to clean your phone. Do not use the cloth with static to wipe
the phone.
Emergency call
Make sure that the mobile phone is switched on and in service area, enter the emergency number (e.g.
110) and press the Call key to call the number. Report your position and explain your condition briefly.
Do not end the call without permission.
Note: Like other mobile phones, the characteristics of this phone may be not supported because of
the network coverage or wireless signals transmission. Certain networks even don’t support
emergency call. Therefore, do not depend on mobile phone only for very important communication
(e.g. medical emergency). Please consult your local network operator.
6
About the phone
The mobile phone has 21 keys, one display, one earphone, charger/data cable port
and one external memory card (T-FLASH card) interface.
Display settings
The display area consists of three parts:
1> the top line displays icons, indicating the signal intensity and battery status.
2> the center area displays the text and figures, including numbers, words and dynamic icons.
3> the bottom line displays different options for operating, such as menu, names, ok and back.
Keys f unctions
Keys Functions
Left soft key Press this key to enter the main menu under standby mode;
Press this key to confirm the function you choose;
Press this key to answer a call
Right soft key Press this key to enter phonebook list under standby mode;
Press this key to go back to previous menu;
Press this key to reject a call.
Call key Press this key to call out;
Press to pick up phone when there is an incoming call;
Press to enter call logs under standby mode.
End key Power Off: Long press to power off under standby mode;
Power On: Long press to power on if the phone is power off;
Press this key to go back to standby screen.
Navigation keys Press them to scroll the options when browsing a function list. In edit
state, press direction keys to navigate. Under standby mode, press a
direction key to enter the specified function page. You can also
customize direction keys to match the desired functions. In conversation
status, press up or down direction key to tune the sound volume.
OK key Press OK key to confirm and enter main menu.
Number keys Dial numbers under standby mode and enter numbers and characters in
7
editing mode. Under standby mode, long press 0 key to open/close the
torch.
* key Under standby mode, press * key twice to display “+” to call international
numbers;”P” and “W” to call extension numbers. Help to lock the keypad
with pressing left soft key first. Under players and FM mode, press * key
to decrease volume.
# key Under standby mode, press and hold this key to switch between current
profile and silent profile. Under players and FM mode, press # key to
increase volume.
Status icons
Icons might be displayed on screen.
Getting started
First call
1> Insert the SIM cards (switch off the phone at first). For detailed installation guide, please refer to
“Installing the SIM card”.
2> Charge the battery. Refer to “Battery and charging”.
3> Press and hold the End key to switch on the mobile phone.
4> If the display prompts, enter the four-digit password and press “OK “key.
Icons Introductions
Signal intensity
New message
Missed calls
Keypad lock
Battery status
Alarm clock activated
Silent
Ring only
Vib. only
Vib. and ring
Vib. then ring
8
5> If the display prompts, enter the PIN code (provided together with the SIM card) and press” OK”
key.
6> Enter area code and telephone number and then press the Call key or left soft key to dial out by
SIM1 or SIM2 .
Note: Before using the mobile phone, please insert valid SIM cards and charge the battery.
Installing SIM card s
When you register mobile phone, you can apply for two different telephone numbers and two SIM
cards (Subscriber Identity Module). With the two cards, you can use the functions of the mobile
phone. The SIM card saves the parameters required by the communication, and personal information,
including PIN code (personal identity number), contacts, short messages and other system services.
Warning: Do not bend or scratch the SIM card, or contact static, dust or water; if the SIM card is lost,
please contact your network operator. Please switch off the mobile phone before installing the SIM
card. The SIM card is inserted into the rear side of the mobile phone.
Note: The T-flash card is tiny. Please keep it away from children to avoid swallowed. If the SIM card
is invalid or damaged, the phone displays “Insert SIM card”. Switch off the phone and take out the
SIM card, and then re-insert it into the slot properly. If the SIM card is damaged, please contact
your network operator. If the SIM card is locked, please contact your network operator.
Installing memory card
Since the mobile phone doesn’t have enough space, you may need to install a memory card (TFLASH card).
To install the T-FLASH card: open the rear cover, take out the battery, insert the T-FLASH card into
the slot, install the battery and then turn on the mobile phone.
To remove the T-FLASH card: open the buckle and take out the T-FLASH card, and then lock the
buckle.
Note: T-Flash card is tiny. Please keep it away from children. Please select qualified T-FLASH
cards, such as SANDISK, V-DATA, and Transcend. Please match with the mobile phone when you
purchase the card.
9
Battery and charging
Installing the battery
Only use qualified battery and accessories. When the battery isn’t used, put it in the protective case.
Note: Please operate according to the figure to avoid damaging the battery contact.
Charging the battery
The new battery will reach its optimized performance after complete charging and discharging for
several times.
Please charge in time when the battery voltage is low. Over discharging will damage the battery.
Disconnect the charger from the AC power supply and the mobile phone after charging. While
charging, the battery status icon flashes from right to left, and stops flashing after charging. It is
normal that the battery becomes warm in the charging process.
Battery status
Your mobile phone can monitor and display the battery status.
1> You can check the battery status from the icon in the upper right corner of the screen.
2>If the electricity is insufficient, the “Low Battery” prompt shows up. The mobile phone sends
warning tone if the “System alert” in Profiles is activated.
3> During charging, the icon of battery status blinks until the charging completes.
Note: The actual standby time and call time depend on the operation, local network, and settings of
the SIM card and mobile phone.
Using battery
The performance of the battery is affected by various factors, including wireless network settings,
signal intensity, environment temperature, the function or settings that you select, accessories and the
mode of voice, data or other applications that you select.
To keep the battery in optimum performance, please follow the rules below:
The charging of new battery or batteries which haven’t been used for long time may be longer;
Keep the battery in room temperature when it is being charged;
It is normal that the charging time becomes longer after long time using. If the call time becomes
shorter and charging time becomes longer after normal charging, you need to change a qualified
battery. Unqualified battery may damage your phone and cause danger.
If the battery is left unused for too long time or the battery voltage is too low, it takes certain period
of time to display the charging interface normally when the charger is connected.
Note: To protect your safety and the environment, do not dispose the battery randomly.
Warning: The short circuit of battery may cause explosion, fire or body hurt.
10
Precautions of using battery
1>Switch off the phone before removing the battery.
2> Use the battery carefully. It will cause short circuit to connect the anode (+) and cathode (-) of the
battery with metal objects (coin, clip, etc.), and damage the battery and metal objects. When the
battery is removed and put in the bag, do not contact the anode and cathode of the battery with
metal objects (e.g. keys).
3>Do not put the battery in fire, or use in any place with high temperature.
4>Do not disassemble or refit the battery.
5>Do not put the battery in the place with strong mechanical impact or break through with hard
object.
6>Store the battery in cool and dry place, and avoid high temperature (> 60°C) and direct sunlight.
7>Stop using if there is any particular smell or overheating.
8>Stop using the battery if there is any crack, distortion or electrolyte leakage.
9>If the electrolyte stains the skin or clothes, please wash with soap and clean water immediately; the
electrolyte enters the eyes, wash with clean water immediately and go to see the doctor.
10>Do not use the battery in low temperature, in which the battery can’t get the maximum standby/call
time.
11> Do not wash the battery with water or organic solvent, or put it in water.
12> Fully charge the battery if it won't be used for a long time.
13> You are recommended to return wasted batteries to the manufacturer of mobile phone or put
them in the specified public recovery area of wasted batteries. Do not put them together with other
garbage or dispose casually.
Using 3-in-1 charger (charger + data cable + earphone port)
The 3-in-1 charger may charge the battery through the mobile phone.
1>Connect the data cable and charger
2>Connect the data cable of the 3-in-1 charger to the I/O slot of the mobile phone.
3>Connect the charger plug of the 3-in-1 charger to the appropriate power outlet.
4>During charging, the icon of battery status blinks until the charging completes.
5>After charging, the battery icon stops flashing, and you can pull out the 3-in-1 charger.
Note: If the battery voltage is too low and can’t turn on the mobile phone, the charging icon may
appear on the screen after several minutes. The mobile phone may be turned on or off during
charging.
Warning: Make sure that the local voltage and power match the rated voltage and power of the 3in-1 charger.
Switching on/off
1>Press and hold the End key to switch on the mobile phone. The screen shows the power on video.
2>If the phone lock is activated, please input the password and press “OK” key. The default password
is 1122.
3> If the PIN code is activated, please input the code and press “OK” key. The PIN code is provided
11
by the network operator.
4>Access to standby interface.
5>Press and hold the End key to switch off the mobile phone.
Password
The mobile phone and SIM cards have several passwords, which will prevent your mobile phone and
SIM cards from illegal operation. Press “OK” key after inputting the valid password (expressed in *). If
there is misinput; please press the “Clear” key to delete the error and then input the correct numbers.
You can change the PIN code, PIN2 code and phone password in “Settings – Security settings –
SIM1/SIM2/ phone security”.
Phone password
The phone password is the phone lock, which can prevent your mobile phone from illegal operation.
The phone password is provided together with the mobile phone by the manufacturer. The default
password is 1122. If the mobile phone is locked, you need to enter the password to turn on the mobile
phone.
SIM1 PIN
PIN code: The PIN (Personal Identity Number) code is provided with the SIM card and will prevent
your SIM card from illegal operation. If the PIN lock is activated, the screen displays “Enter PIN” when
you turn on the mobile phone. While entering PIN code, the screen shows * instead. You can get the
PIN code when you get the SIM card from the network operator.
PIN2: the personal identity number required by certain functions such as call expense.
PUK and PUK2 (8-digit)
You also need to input PUK (personal unblocking key) code to change locked PIN code. To change
the locked PIN2, use PUK2. If the codes are not provided with the SIM card, please contact local
service provider.
Warning: If you enter invalid PIN code for three times consecutively, the SIM card will be locked. In
this case, please contact the local network operator. The SIM card may be damaged permanently if
you try to decode by yourself.
SIM2 PIN
PIN code: The PIN (Personal Identity Number) code is provided with the SIM2 card and will prevent
your SIM2 card from illegal operation. If the PIN lock is activated, the screen displays “Enter SIM PIN”
when you turn on the mobile phone. While entering SIM2 PIN code, the screen shows * instead. You
can get the PIN code when you get the SIM card from the network operator.
PIN2: the personal identity number required by certain functions such as call expense.
PUK and PUK2 (8-digit)
You also need to input PUK (personal unblocking key) code to change locked SIM PIN code. To
change the locked PIN2, use PUK2. If the codes are not provided with the SIM card, please contact
local service provider.
12
Warning: If you enter invalid PIN code for three times consecutively, the SIM card will be locked. In
this case, please contact the local network operator. The SIM card may be damaged permanently if
you try to decode by yourself.
Disabling password
Disabling password is necessary to enable call barring. You can get this password from your network
operator when you subscribe for this function.
Using hands free kit
With the hands free kit, you can make or answer calls without holding the mobile phone. When you
inert the hands free kit into the earphone port, the hands free kit can be used as the handset and the
microphone of the mobile phone.
Keypad lock
When the keypad is locked, the mobile phone will be locked automatically if there is no operation in
certain period of time. To unlock: Press the left soft key and * key.
Note: When the keypad is locked, it will be invalid. If there is new call, you can answer as usual,
and the mobile phone will resume the locked status after the call
Specified keys
1> Under standby mode, press * key/# key to decrease/increase the volume of players and FM.
2> In the dial interface, press and hold the # key to activate/deactivate the silent profile
3> In dialing interface, press and hold * key to input “+”, “P” or “W”; “+” is used to call international
numbers and “P” and “W” are used to call extension numbers.
Note: The difference between W and P: if P is pressed, it pauses for three seconds and then sends
DTMF; if W is pressed, a window pops up and asks if “Send DTMF?”
Language and input method s
13
The mobile phone provides English and Hindi languages. And the phone provides
ABC/abc/DI/di/Numeric input methods. You may need to input text when you use the phone. For
example: store a name in the phonebook or write a short message. In edit state, press # key to switch
input methods of body text. And you can press * key to enter symbol selection screen.
Noun
Making a DDD
To make a call with SIM1, enter a number and press the call key to call out by SIM1; the “SIM1
calling” characters appear in front of the number; to make a call with SIM2, enter a number and press
the call key to call out by SIM2; the “SIM2 calling” characters appear in front of the number. Once the
other party answers, the screen displays the call status.
Press the End key to end the call.
To make a DDD: area code + telephone number + call key
Making an IDD
If you need to make an international call, press and hold the * key until the prefix symbol “+” of
international long distance call appears on the screen , and you can make a call in any country (for
example, +86 in China).
Enter the prefix number, and then enter the country code and full phone number. The country codes
are according to the international tradition, and Germany is 49, UK 44, Sweden 46, etc.
To make an IDD: “+” country code + area code +telephone number + call key
Calling extension
Some extensions of fixed telephone can’t be dialed through directly and you need to dial through
the exchange before dialing the extension. If you insert the pause symbol P between the exchange
number and the extension number when you input the phone number, the mobile phone will
complete the dialing and dial extension automatically. To enter “P”: press and hold the stylus, or
press * for three times (the symbol “P” appears on the screen).
To call an extension of fixed telephone (excluding +): telephone number + P + extension number +
call key
Emergency call
You can always make an emergency call when you are in the coverage area of the network (you can
know by checking the indicating stripe of network signal intensity on the upper left corner of the
screen). If your network operator doesn’t provide roaming service in your area, you can only make
emergency calls. If you are located in a service area of the network, emergency calls can also be
made without a SIM card.
14
Note: In certain areas, 112 (emergency call) is provided by the network operator; if it is abnormal,
please contact the network operator.
IMEI
IMEI is International Mobile Equipment Identity. Turn off the mobile phone and take out the battery,
and you can find the label printed with this bar code in the rear side. This number is also saved in the
mobile phone. When the phone is turned on, enter “*#06#” to display the number.
Calling
When the marks of network providers to appear on screen, you can call or answer
the call. The signal strength is showing on the top left corner.
Making Calls
Enter area code and phone number and press call key to dial out by SIM1/SIM2.
Use the right soft key to delete if there is wrong input. Press and hold right soft key to clear all
characters.
Note: Obstacles give lots of effects on calling quality; moving around in a small range will improve
signal strength effectively.
Making an International Call
Please refer to “Making an IDD”.
Dialing extension
Please refer to “Calling extension”.
Making a call from the phonebook
Open the phonebook list, scroll to search the desired number, press call key to dial out by SIM1/SIM2.
Latest numbers redial
Under standby mode, press call key to access the call history.
Press the up/down key to reach the desired number or name and press call key to dial out by
SIM1/SIM2.
15
Receiving Call s
Press call key to receive an incoming call.
During a call, you can operate by pressing Left soft key: Hold, End single call, Phonebook and so
on; and you can also set Mute on/off.
Press end key to end a call.
Reject ing Call s
Press end key to reject an incoming call.
Options in a Call
During a call, press left soft key to enter options to select Hold, End single call, Phonebook, Call history,
Messaging, Sound recorder, Mute and Volume.
Hold: This function supports two calls at the same time. You can dial another number during a call.
Dial another number during a call (You can only dial by SIM1 when your first call is from SIM1, to
dial by SIM2 is the same to SIM1).
Press options and select a number from Phonebook or Call history and press call key to dial.
Type in another number you want to dial and press call key to dial.
Mute on/off: If you set Mute function, then you can hear what that side is speaking but your voice
couldn’t be heard at that side.
Note: If the caller can be identified, the caller’s name and phone number will display. If the caller
can’t be identified, the screen will only display the caller’s number. When you use the function list or
Phonebook, you can also answer a call.
Adjust volume
You can press Up/Down navigation keys to adjust volume during a call.
16
Menu guide
Phonebook
Contacts saved in the mobile phone contain the following information: the telephone name and
number. You can add new contacts to phone or SIM1/SIM2.
You can perform the following operations in this mode:
View: View detailed information of the contact.
Send text message: Send a message from SIM1/SIM2.
Call: Make a call from SIM1/SIM2.
Edit: Edit name and number of the contact.
Delete: Delete the contact.
Copy: Copy the contact to phone or SIM1/SIM2.
Move: Move the contact to phone or SIM1/SIM2.
Send vCard: Send vCard as text message or via Bluetooth.
Add to Blacklist: Add the contact to blacklist.
Mark several or mark all to operate.
Caller groups: You can create new group.
Phonebook settings: You can perform the following operations in this mode.
Preferred storage: Add a new contact to the SIM1/SIM2, Phone or All.
Speed dial: Set on/off, you can edit and alter speed dial list.
My number: To add owner’s number and other detailed information.
Extra numbers: To set owner numbers and Fixed dial of SIM1/SIM2.
Memory status: To check phonebook memory status of SIM1/SIM2 and phone.
Copy contacts: To copy contacts from SIM1/SIM2 and phone to other paths respectively.
Move contacts: To move contacts from SIM1/SIM2 and phone to other paths respectively.
Delete all contacts: Delete all contacts from SIM1/SIM2 and phone.
Enter the Contacts interface to perform the following operations:
Quick search:
In the input area where the cursor locates, enter the first letter to locate the first qualified entry in the
contacts list. For example, to search for “Lisa”, enter letter “L”.
Search name:
Enter the desired name, and search the matched entry in the Contacts.
Messag es
Enter this menu, you can view: Write message, Inbox, Drafts, Outbox, Sent messages and SMS
settings.
17
Write message
You can enter this function menu to write short messages.
Short message is a network service. To send or receive short messages, you may need to
subscribe for this service from your network operator. The short messages are sent to the
message center and then to the recipients (GSM subscribers). The short messages are saved in
the network if the mobile phone of recipient isn’t switched on or can’t receive short messages
(memory is full). The validity depends on user’s settings and network operator. With SMS, you can
send and receive chain text messages, which may affect the charge of messaging. Please contact
your network operator for details.
Each message may contain 160 characters. While editing the message, select the “Input method”
option.
Press # key to switch the input method.
Press the right soft key to delete one character before the cursor, or hold right soft key long to clear
all characters; press the End key to return to standby mode; When writing messages, you can
insert number, name and bookmark in editing message.
When the editing message is finished, you can press direction up/down key to option: enter
recipient or select contacts from phonebook or call history to send.
This mobile phone supports group messages with more than 600 characters each (the characters
limit of common text message). If the message contains more than limited characters, the phone
sends it in two or more messages.
If the memory is full, an icon will flash in the top line of the screen; since the mobile phone supports
dual SIM cards, the messages are saved in SIM1 and SIM2 separately, and the prompts appear
separately. To receive new messages normally, delete the short messages in corresponding SIM
cards. If the recipient has received the message, the mobile phone sends an alert tone of message
report (report is enabled)
Note: When you send message via SMS service, the mobile phone may display “Sent”. It indicates
that the message has been sent to the SMS center. But it doesn’t mean that the recipient has
received the message. Contact your network operator for more information.
Inbox
You can read the received short messages in the Inbox, including SIM1 messages and SIM2
messages. Press left soft key of options in messages list interface, you can perform the following
operations:
View: View the info of the message.
Reply: Reply in text message by SIM1 or SIM2.
Call sender: Call the sender by SIM1 or SIM2.
Forward: Forward the message to another contact by SIM1 or SIM2.
Delete: Delete the message.
Delete all: Delete all the messages in the Inbox of corresponding SIM cards; if SIM1 is selected.
Save to Phonebook: Save the sender’s number to phonebook of SIM1/SIM2/phone.
18
Filter by: Filter by SIM1/SIM2/All messages.
Drafts
Save the edited text message and perform operations respectively. You can perform the following
operations to the short messages saved in Drafts: View, send, Edit, Delete and Delete all.
Outbox
Turn on “Save sent message” in SMS settings, messages will be saved in Sent messages; if the
message isn’t sent successfully, the message will be saved in the Outbox. You can perform the
following operations to the short messages saved in Outbox: View, Resend, Edit, Delete and Delete
all.
Sent messages
Turn on “Save sent message” in SMS settings, messages will be saved in Sent messages; you can
perform the following operations to the short messages saved in sent messages: View, Forward,
Delete and Delete all.
SMS settings
You can set the SIM1/SIM2 SMS parameters in this menu.
SMSC address: Check and edit SMS center address.
Validity period: Set validity period as 1hour/6hours/12hours/1day/3days/1week/Maximum.
Message type: Set message type as Text/Fax group3/Fax group4/Page/Email.
Delivery report: The network notifies whether the recipient has received the message or not.
Reply path: Transfer the replay path to the network and this function requires the support of SMS
center.
Voicemail server: Add and call the voice mail number saved in the list.
Note: The number of SMS center is provided by the network operator.
Memory status: You can check the memory status of SIM1/SIM2 and phone in this menu.
Save sent message: Turn on/off save sent message.
Preferred storage: Set preferred storage as Phone/SIM.
19
Call center
Call logs
This mobile phone can register the missed calls, answered calls and dialed numbers of SIM, as well
as the time and expense of all calls. When the mobile phone is turned on in network service area and
supported by the network, it can register the missed calls and received calls. In the lists of missed
calls, received calls and dialed numbers, you can check the date and time of the calls, edit or delete
the telephone numbers in the list, save the numbers in Contacts.
Missed calls
This menu displays the missed calls that you did not answer. In the missed calls list, you can view the
details of the record by pressing the Left soft key.
In the lists of missed calls, you can check the date and time of the calls, call, send message, save to
phonebook, edit before call and delete.
Note: When the mobile phone prompts missed call, you can press “View” to access the list of
missed calls. Select the desired number and press the Call key to call this number.
Dialed calls
This menu displays the recent calls you have dialed. In the dialed calls list, you can view the details of
the record by pressing left soft key.
In the lists of dialed calls, you can check the date and time of the calls, call, send message, save to
phonebook, edit before call or delete.
Received calls
This menu displays the calls you have received. In the list of received calls, you can view the details of
the record.
In the lists of received calls, you can check the date and time of the calls, call, send message, save to
phonebook, edit before call or delete.
Delete call logs
Delete call logs. You can select dialed calls, missed calls and received calls to clear. Or you can
directly select all calls to delete.
Call settings
Call waiting: Set to activate or deactivate the call waiting. For call holding and multi-party
conference, you need to activate this function first. It requires network support.
Call divert: This function is a network service and you need to subscribe from the network operator
first. This function can divert the qualified calls to specified telephone number.
Name Description
Divert all voice calls Divert all incoming calls
Divert if If the network can’t connect to your mobile phone (power off or out
20
unreachable of service area), it will divert the incoming calls for you.
Divert if no answer If you don’t answer the calls in specified time, the network diverts
the call for you.
Divert if busy When you are calling, the network diverts the incoming call.
Divert all data calls Need network support, divert all coming data calls.
Cancel all diverts Cancel all diverting settings.
Call barring:
Outgoing calls:
1.
All voice calls: Set call barring for all outgoing calls of SIM.
2.
International voice calls: Set call barring for international calls of SIM;
3.
International voice calls except to home: When you are abroad, you can only call the
numbers from the country you locate and home country (i.e. the country where your network
operator locates).
Incoming calls:
1.
All voice calls: Set call barring for all incoming calls of SIM.
2.
Voice calls when roaming calls: Set call barring for all calls of SIM except the calls from the
numbers in local service area.
Cancel all: Cancel call barring settings of SIM. In this case, you can make and answer calls
normally.
Change barring password: Change the password of call barring for SIM.
Line switching: You can set Line1 or Line2. The default setting is Lin1.
Advanced settings
Blacklist: Set On/Off for blacklist and add blacklist numbers.
Auto redial: Select On or Off for auto redial in this option. If the first call isn’t connected
successfully, the mobile phone will redial for ten times at most automatically.
Auto call record: Set on/off auto call record.
Call time display: Set On/Off for call time display.
Call time reminder: Select single or periodic alert tone in the calling process so that you can know
the call time. You can also disable the alert tone.
Reject by SMS: Set on/off auto call record.
Answer mode: Turn on/off press any key to answer the phone and auto answer when headset
mode.
Note: Some settings need network support. Call barring needs local network support and you need to
apply this service first.
21
Multimedia
Camera
In this menu, you can take pictures with the embedded camera and adjust the camera settings. The
camera lens is in the rear side of the mobile phone and the screen is the viewfinder window. The
pictures are taken in JPG format. After downloading to PC, please view with appropriate software. If
the mobile phone memory is insufficient, please delete certain pictures or other files in “File manager”.
In the camera interface, you can perform the following operations:
Descriptions of Camera options
Options Description
Switch to video
recorder
Switch Camera to video recorder.
Photos View the saved pictures.
Camera settings LED highlight: Set LED highlight on/off.
Anti-flicker: 60Hz (default), 50Hz.
Delay timer: 5sec, 10sec, 15sec or Off.
Image settings Image size: 128* 160, 160*120, 640*480.
Image quality: Low, Normal, Good.
White balance Set Auto, Daylight, Tungsten, Fluorescent, Cloudy, Incandescent.
Scene mode Set Auto or Night.
Storage Choose Phone or Memory.
Restore default Restore the default settings.
Note: After replacing the T-Flash card, it is necessary to create Photos menu before using the
camera.
Image viewer
Image: All the pictures are saved in Album.
Description of image list options:
Options Description
View View selected image.
Image information Check detailed information of selected image.
Browse style Choose List/Matrix style.
Send Send via Bluetooth.
Use as Use as Wallpaper/Screen saver.
Rename Change the name of selected image.
Delete Delete the selected image.
Delete all files Delete all the images in the Album.
Storage Phone or Memory card.
22
Video recorder
Press OK key to start video recording. The recording time depends on the time limit and the capacity
of the memory card. Enter options to perform the following settings.
Description of video recorder options:
Options Description
Switch to Camera Switch to Camera.
Camcorder
settings
Anti-flicker: 60Hz (default), 50Hz.
Video settings Video quality: Set Normal; Good; Fine; Low.
Storage Phone or Memory card.
Video player
In this mode, you can also perform the following operations.
Description of video player options:
Options Description
Play Support playing video files in 3gp, MP4 format.
Send Send via Bluetooth.
Rename Change the name of selected video file.
Delete Delete the selected video file.
Delete all files Delete all the files in video player folder.
Storage Phone or Memory card.
Audio player
Audio Player supports MP3, wav and AMR audio format files and so on. In the list of audio files, you
can perform the following operations:
Play: Play the selected audio file.
Details: Check Size/Time/Title/Artist/Album of the selected audio file.
Refresh list: Refresh the playlist.
Settings: In setting interface, you can perform the following operations.
Pre. playlist: Set as Phone or Memory card.
List auto gen.: Select on/off for List auto gen.
Repeat: Turn off repeat play, repeat play the selected audio file, or repeat all the audio files in
the list.
Shuffle: Play audio files randomly.
Background play: Play audio files at background.
Sound recorder
In this mode, you can perform the following operations.
New record: Record audio file.
23
List: View the recorder list.
Settings: Select the memory card or phone for storage; set audio quality with low/high.
FM radio
In this mode, you can perform the following operations.
Channel list: Edit the channel name and frequency in the list.
Manual input: Input a frequency as your need.
Auto search: Scan channels automatically.
Settings: Set background play on/off.
Games
Puzzle: This phone provides a Puzzle game. You can choose start game/Best grades/Help.
Games settings: You can Activate/deactivate BGM, Sound effect, Vibration and set volume level as
your need.
O rganizer
File manager
Open
In this menu, you can manage the pictures, MP3 files and folders in this menu.
Note: Open files in the memory card.
Audio – Audio folder
Open audio files, you can perform the following operations:
Play: Play the selected file.
Send: Send the selected audio file via Bluetooth.
New folder: Create a new folder in the directory.
Rename: Change the name.
Delete: Delete the selected file.
Mark several: Mark several files to copy, move or send via Bluetooth.
Copy: Copy files to phone or memory card.
Move: Move files to phone or memory card.
Delete all files: Delete all files in the current folder.
Details: View the date and size of selected file.
Photos – Photo folder
View: View the selected image.
Image information: Check the File name, Date, Size, Image width and Image height.
Send: Send the selected photo via Bluetooth.
Use as: Use the selected image as wallpaper or Screen saver.
24
New folder: Create a new folder in the directory.
Rename: Change the name.
Delete: Delete the selected file.
Mark several: Mark several files to copy, move or send via Bluetooth.
Copy: Copy files to phone or memory card.
Move: Move files to phone or memory card.
Delete all files: Delete all files in the current folder.
Details: View the date and size of selected file.
Videos – Video folder
Play: Play the selected file.
Send: Send the selected video file via Bluetooth.
New folder: Create a new folder in the directory.
Rename: Change the name.
Delete: Delete the selected file.
Mark several: Mark several files to copy, move or send via Bluetooth.
Copy: Copy files to phone or memory card.
Move: Move files to phone or memory card.
Delete all files: Delete all files in the current folder.
Details: View the date and size of selected file.
My Music – MP3 folder
Play: Play the selected music.
Send: Send the selected music file via Bluetooth.
New folder: Create a new folder in the directory.
Rename: Change the name.
Delete: Delete the selected file.
Mark several: Mark several files to copy, move or send via Bluetooth.
Copy: Copy files to phone or memory card.
Move: Move files to phone or memory card.
Delete all files: Delete all files in the current folder.
Details: View the date and size of selected file.
Format
Format the memory card.
Rename
Change the name of memory card.
Details
Check Name, Total size and Free size of the memory card.
Calculator
Press number keys 0-9 to enter the figures you need to calculate and press the # key to enter radix
point; you can also enter operators such as +, -, ×, ÷; press left soft key to clear last input or result,
press and hold left soft key to clear all the contents or results. Press OK key to get the result.
Note: The precision of the calculator is limited and there are errors, especially when it is indivisible.
25
Ebook reader
You can watch ebook with this function and you can set it as your need in global settings options.
Calendar
In the camera interface, you can perform the following operations:
Jump to date: Skip to the specified date.
Go to today: Skip to the date of today.
Go to weekly/monthly view: You can select weekly view or monthly view of calendar.
Alarm
The time format of alarm clock is the same to clock. When the mobile phone is turned off, the alarm
clock is still valid only if the battery voltage isn’t low. The mobile phone allows setting 5 alarm clocks
and the default option is Off. You can customize the alarm time and date for every alarm clock
separately. When the alarm time arrives, the mobile phone rings and displays current time and date on
the screen. Press “Stop” to stop the alarm; press “Snooze”, the alarm stops and rings again after a few
minutes according to your settings.
If the mobile phone is still power off till the alarm time, the phone switches on and alarms
automatically. If you press “Stop”, the phone displays whether switch on the mobile phone or not.
Press “No” to switch off, or press “Yes” to switch on.
World clock
Press left/right navigation key to browse every city’s time zones in the world map. The related date
and time will display in the phone’s screen.
Torch
You can set on/off for torch.
U ser profiles
This mobile phone provided several profiles. You can customize the ringtone according to events and
environment. You can customize a profile and activate it. Available options are: General, Silent,
Meeting, Outdoor and My style.
General
You can customize the following items in General profile:
Alert type: Set Ring only, Vib only, Vib and ring and Vib then ring as your need.
26
Ring type: Repeat and Beep once.
SIM1/SIM2 incoming call: Set up the tone of incoming call of SIM1/SIM2.
Ringtone volume: Set the volume of ringtone.
SIM1/SIM2 message: You can set silent or tone1 as the message tone of SIM1/SIM2.
Message volume: Set the volume of message.
Keypad: Set Click, Tone or Silent.
Keypad volume: Set the keypad volume.
Power on/off: Set tone of power on/off.
System alert: Set On/Off.
After customized, select “Save” in “Options”.
Silent
Ring, Volume and Alert type mustn’t be set. You select “Activate” in “Options”.
Meeting
Please refer to “General” for more details.
Outdoor
Please refer to “General” for more details.
My style
Please refer to “General” for more details.
If the earphone is connected in Silent profile, the headset profile switches on, and the Silent profile
resumes when the earphone is disconnected.
In standby mode, press and hold the # key to switch to Silent mode, and press and hold this key
again to resume original profile.
Note: The Headset profile is activated automatically when the earphone is inserted and the original
profile resumes when the earphone is removed.
Settings
Shortcuts
The system default several shortcut menu, can be manually add to ten, select one menu, press the
left soft key into the “Options”, can undertake the following operation:
Add: to add other menu.
Edit: edit the current menu.
Delete: delete selected shortcut menu.
Delete all: delete the entire shortcut menu.
Change order: rearrange menu.
Multi SIM settings
You can set the dual SIM mobile phone accordingly:
Multi SIM open;
Only SIM1 open;
Only SIM2 open;
27
Phone settings
Time and date:
Set home city: You can set home city as your need.
Set time/date: Set current time and date and turn on/off Daylight saving.
Set format: Set the displaying format of time and date and Date separator with “.” “:” “/” and
“–”.
Update with time zone: Set on/off for this function.
Auto power on/off:
Set the time of schedule power on/off.
Language:
Select the phone language (Available options are English and Vietnamese). The default language
is English.
Pref. input method: ABC/abc/Abc/VI/Vi/vi/Numeric.
Display:
Wallpaper: Select wallpaper from System or User defined in Phone/Memory card.
Screen saver: Set on/off and select image from System or User defined in Phone/Memory
card.
Show date and time: Turn on/off
Dedicated key:
You can configure short cut functions for the direction Up, Down, Left, and Right key respectively.
In the standby mode, press any one of them to access the appointed function.
Auto update time: you can set On/Off or first confirm.
Flight mode: Phone cannot receive any signal at Flight mode. You can set Normal mode or Flight
mode in this menu.
UART settings: Set SIM1/SIM2.
Misc. settings: LCD backlight: In this function, you can set the time of LCD backlight and the
brightness.
Press Vib setting: Set press Vib setting on/off.
Network settings
In this menu, you can set SIM1/SIM2 network and preferred networks.
Names Descriptions
Network
selection
New search: The phone searches new network.
Select network: The phone selects available network.
Selection mode:
Automatic: The phone selects available network automatically.
Manual: Only register specified network. If this network is unavailable, the phone
won’t register other networks.
Security settings
SIM1/SIM2 security
28
PIN lock: Activate/deactivate PIN lock.
Change PIN: You can change the SIM1/SIM2 PIN to your private password in 4-8 digits.
Change PIN2: You can change the SIM1/SIM2 PIN2 to your private password in 4-8 digits.
Phone security
Phone lock: You can activate or deactivate phone lock. The phone lock is a 4-8 digit password
(default: 1122),
Change password: Change the phone lock password.
Auto keypad lock
You can activate or deactivate keypad lock. The keypad locks in certain time automatically (5sec,
30sec, 1 min and 5mins).
M Tracker
Input phone password to set mobile tracker.
Connectivity
In the Bluetooth interface, you can perform the following operations:
Power: Activate/deactivate the Bluetooth.
Visibility: Set on/off.
My device: Support search new device and so on.
Search audio device: Search devices like headset. Activate the Bluetooth wireless function before
searching.
My name: Display my Bluetooth name and you can edit name as your needs.
Advanced: Set audio path, the preferred storage and view my address.
Restore factory settings
Access the setting, select Reset, enter the password, and follow the prompt to reset and restart the
mobile phone. This operation will restore all default settings.
Note: The default password is 1122. The phone will auto power on after shutdown.
Services
With this function, you can access the services on the Internet, including weather, news, financial info,
etc. This service is provided by network operator. New menus appear according to SIM cards. It is
invalid if the SIM card and your network operator don’t support this function. Please contact your
network operator for more information.
29
Appendix
Appendix A: Please take care of your mobile phone
Maintenance
The mobile phone is made in exquisite process. Please be careful while using. The suggestions below
will help to extend the service life of the mobile phone.
1> Keep the mobile phone and all its parts and accessories away from children.
2> Keep the mobile phone dry. Keep it away from the substances such as rain, moisture and liquids
that may erode the circuits. Do not use the mobile phone at places with too much dirt or put it at
these places to avoid damaging the activate parts.
3> Do not put the mobile phone at the place with high temperature; otherwise, it will shorten the life of
the circuit, and damage the battery and plastic parts.
4> Do not put the mobile phone at cold place. When it becomes warm (normal temperature),
moisture will generate in the mobile phone and damage the circuit board.
5> Do not wash the mobile phone with corrosive chemical agent, cleaner or strong detergent. Dip
soap water with soft cloth to wipe the mobile phone.
6> If the mobile phone or any accessory can’t work normally, please send it to qualified service
center.
Note: Please dispose the used products according to local regulations.
Appendix B: Troubleshooting
Failure Reason
Can’t switch on 1 The battery has been run out;
2 The battery isn’t installed properly.
SIM card error 1 SIM card is dirty. Clean the SIM card.
2 Re-install the SIM card.
3 SIM card is damaged. Please change a new one.
4 (SIM2 is same)
Weak signal Check the icon of signal strength, where four strips indicate the
strongest signal and two or less strips indicate weak signal.
(SIM2 is same)
30
Can’t make calls (I) You have set to hide your own number, but the network operator
doesn’t support this service.
(II). The ambient has strong interference.
(III). You have enabled call barring.
(IV). You have activated Line 2, but the network operator doesn’t
support this service.
Can’t charge the
battery
(I). The battery may be over discharged and it takes a while to charge
after connected to the charger.
(II) Battery performance has decreased.
Can’t connect to
network
(I). The signal is too weak, or there is radio interference.
(II). Check whether the SIM card is installed properly, whether the
contact is poor or whether the card is damaged? Please contact your
network operator if the SIM card is damaged.
The photos taken are
too dark
(I) The brightness is too low;
(II) The environment is too dark
The photos taken are
blurry
(I) The object is moving;
(II) Your hand shakes when you press the shutter
The photos taken are
distorted
The object is too close
Can’t access service
menu
The SIM card doesn’t support
Appendix C: Abbreviation and explanation
SMS Short Message Service
EMS Enhanced Message Service
SIM Subscriber Identity Module
GSM Global System for Mobile Communication
PIN Personal Identity Number
PUK PIN Unblocking Key
IMEI International Mobile Equipment Identity
CB Cell Broadcast
GPRS General Packet Radio Service
MMS Multimedia Message service
Appendix D: Optional parts
T-FLASH card
This is also called as memory card, which is used to save data.
Hands free kits
31
The hands free kits include earphone and mini microphone, which are used for hands free call.
USB data cable
In power off state, connect the mobile phone to PC with the USB data cable to access files and
charge the battery. In power on state, connect the mobile phone to PC with the USB data cable to
access the storage device.
Travel charger
Used for travel charging
Note: Please use qualified accessories.
32
Declaration of conformity
Model: PM280 Description: Mobile Phone
We, Techmade s.r.l. declare under your sole responsibility that our Mobile Phone to which this
document refers, complies with the following standards and / or other normative documents.
Health EN 50566:2013 / EN 50360:2001/A1:2012 / EN 62209-1:2006 / EN 62209-2:2010 /
EN 62479:2010
EMC EN 50332-1:2000 / EN 50332-2:2003 / EN 301 489-1 V1.9.2 / EN 301 489-7 V1.3.1 /
EN 301 489-17 V2.2.1 / EN 301 511 V9.0.2
Radio EN 300 328 V1.9.1
Safety EN 60950-1:2006+A11:2009+ A1:2010+A12:2011+A2:2013
We declare that all essential set of tests were performed, and that the above named product complies
with the essential requirements of the R&TTE 1999/5/EC, EMC 2004/108/EC, LVD 2006/95/EC, RoHS
2011/65/EU.
Notified Body:
PHOENIX TESTLAB GmbH
Konigswinkel 10
D-32825 Blomberg, Germany
29/05/2015
Made in China
TECHMADE products are guaranteed for 2 years for all manufacturing defects and malfunctions.
For any questions please talk to your dealer or visit www.techmade.eu
Imported by TECHMADE Srl – Via Libertà 25 – 80055 Portici (NA).
Tel. +39 0823 609112 PBX Fax +39 0823 2
33
Loading...
