User Manual
TL-INCT-01
HDMI In-line Controller
All Rights Reserved
Versi on: TL-INCT-01_160711
1
TL-INCT-01 User Manual
www.tlnetworx.com
Preface
Read this user manual carefully before using this product. Pictures shown in this manual
are for reference only, slight differences may be evident on the real product.
This manual is only for operation instruction only, not for any maintenance usage.
Trademarks
Product model and logo are trademarks. Any other trademarks mentioned in this manual
are acknowledged as the properties of the trademark owner. No part of this publication
may be copied or reproduced without prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void the
user’s authority to operate the equipment.
2
TL-INCT-01 User Manual
www.tlnetworx.com
SAFETY PRECAUTIONS
To i ns u re t he b e st experience from the product, please read all instructions carefully
before using the device. Save this manual for further reference.
l Unpack the equipment carefully and save the original box and packing material for
possible future shipment
l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
l Do not dismantle the housing or modify the module. It may result in electrical shock
or burns.
l Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
l Refer all servicing to qualified service personnel.
l To p re v e n t fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
l Do not put any heavy items on the extension cable in case of damage.
l Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
l Install the device in a place with proper ventilation to avoid damage caused by
overheat.
l Keep the module away from liquids.
l Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
l Unplug the power cord when left unused for a long period of time.
l Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.
3
TL-INCT-01 User Manual
www.tlnetworx.com
1. Introduction
The TL-INCT-01 is a HDMI In-line Controller, with resolutions up to 4K@60Hz (chroma
sub-sampling 4:4:4 8-bit only) and HDCP 2.2.
Its digital or analog audio output allows audio to de-embed from HDMI input and send
to an audio distribution system, such as an AVR or Zone Amplifier. Its rotary EDID switch
has 15 EDID presets to help negotiate the HDMI handshake in certain situations, such as
an old HDMI display with bad DDC channel, or a DVI display with audio reinforcement.
By auto-detecting input signal status, it automatically triggers CEC commands to turn on
or off a TV with CEC support, pre-loaded RS232 commands to power on or standby
projector, and relay control to trigger up and down for a projection screen.
1.1 Features
l Supports video sources up to HDMI 2.0(4K@60Hz 4:4:4 8-bit) and HDCP 2.2
l HDMI audio de-embedded out with Digital Coaxial and Analog Stereo
l Rotary switch for EDID Management with 15 EDID presets
l Built in CEC controller from HDMI out
l Built in RS232 controller, to pre-load and store RS232 command of sink device
l Automatic CEC/RS232 command to Power ON/Standby display device, by detecting
input signal status
l Built in RELAY control to automatically turn Projector Screen ON/OFF, by detecting
input signal status
l Automatic input cable equalization and signal regeneration compensation
1.2 Package List
ü 1 x TL-INCT-01
ü 2 x Mounting ears
ü 3 x Phoenix Male Connector (3.5 mm,
3 pins)
ü 1 x Power Adapter (DC 5V 1A)
ü 1 x User manual
&
Check whether all the items listed above are included in your package. If not,
contact your dealer.
4
TL-INCT-01 User Manual
www.tlnetworx.com
2. Appearance
Front Panel
No.
Name
Description
1.
DC 12V
12V DC power input, threaded port for standard or
locking connection
2.
POWER LED
ON: The unit is powered on.
OFF: The unit is powered off.
3.
HDMI IN
Connects to an HDMI source
4.
EDID
Switch for EDID Management with 15 EDID presets
5.
S/PDIF OUT
HDMI audio de-embedded out with Digital Coaxial,
connects to an amplifier
6.
AUDIO OUT
HDMI audio de-embedded out with Analog Stereo,
connects to an amplifier
Rear Panel
No.
Name
Description
1.
RELAY1
Tu rn on projection screen automatically
2.
RELAY2
Tu rn off projection screen automatically
3.
HDMI OUT
Connects to an HDMI display
4.
RS232
Pre-load and store RS232 command of sink device
5
TL-INCT-01 User Manual
www.tlnetworx.com
3. EDID Management
Switch for EDID Management with 16 presets as follows:
Position
Description
0(default)
Copy EDID from HDMI Out
1
3840x2160@60Hz 2CH
2
3840x2160@30Hz 2CH
3
1920x1080@60Hz 2CH
4
1280x720@60Hz 2CH
5
1920x1200@60Hz 2CH
6
1680x1050@60Hz 2CH
7
1600x1200@60Hz 2CH
8
1600x900@60Hz 2CH
9
1440x900@60Hz 2CH
A
1400x1050@60Hz 2CH
B
1360x768@60Hz 2CH
C
1280x1024@60Hz 2CH
D
1280x960@60Hz 2CH
E
1280x768@60Hz 2CH
F
1024x768@60Hz 2CH
Note: If EDID Copy failed, a fixed 1080P@60Hz Stereo EDID will be provided to the
source device.
&
Pictures shown in this manual are for reference only.
6
TL-INCT-01 User Manual
www.tlnetworx.com
4. RS232 Control Tool
RS232 port configuration tool is a control tool running on PC for pre-loading RS232
commands for the TL-INCT-01 to control the sink device. Connect a PC to the
TL-INCT-01 via an RS232 cable. Run the configuration tool to set the connection
parameters correctly before sending the pre-loaded commands to the TL-INCT-01. The
baud rate for the TL-INCT-01 is 57600.
See the display model’s manual for the RS232 settings and commands.
Baud rate: Choose the correct baud rate according to the sink device.
Power on: Enter the command to power on the sink device.
Power off: Enter the command to power off the sink device.
See below picture:
7
TL-INCT-01 User Manual
www.tlnetworx.com
5. System Connection
The figure below illustrates a typical connection that can be utilized with TL-INCT-01:
1) Using quality HDMI cables, connect an HDMI source (such as PC, Blu-ray, games
console, satellite/cable TV, media server etc.) to HDMI IN of the TL-INCT-01.
2) Connect the HDMI display device (Such as projector) to the HDMI OUT of
TL-INCT-01.
3) Connect audio system to the S/PDIF OUT and AUDIO OUT port of TL-INCT-01.
4) Connect RS232 to the projector for pass-through the commands to control the
projector.
8
TL-INCT-01 User Manual
www.tlnetworx.com
5) Connect RELAY1 and RELAY2 to the projection screen for control the projection
screen ON/OFF.
6) Connect the included 12v power supply to the TL-INCT-01. Power on the devices.
&
1) System should be installed in a clean environment with proper temperature and
humidity.
2) All of the power switches, plugs, sockets and power cords should be insulated.
3) All devices should be connected before power on.
6. Specification
Te c h n i ca l
Input
1 x HDMI IN
Input Signal Type
HDMI 2.0 with HDCP 2.2
Input Resolution Support
VESA:
800x600@60Hz, 1024x768@60Hz,
1280x768@60Hz, 1280x800@60Hz,
1280x960@60Hz, 1280x1024@60Hz,
1360x768@60Hz, 1366x768@60Hz,
1440x900@60Hz, 1600x900@60Hz,
1600x1200@60Hz, 1680x1050@60Hz,
1920x1200@60Hz;
SMPTE:
4096x2160@24/25/30/50/60Hz,
3840x2160@24/25/30/50/60Hz,
1080P@24/25/30/50/60Hz, 1080I@50/60Hz,
720P@50/60Hz, 576P@50Hz, 480P@60Hz
Input Video Level
0.5-1.2 V p-p
Input DDC Signal
5V p-p
Maximum Pixel Clock
297MHz
Output
1 x HDMI OUT
Output Signal Type
HDMI 2.0 up to 4K@60Hz(4:2:0 10-bit) and
HDCP 2.2.
9
TL-INCT-01 User Manual
www.tlnetworx.com
Output Resolution Support
VESA:
800x600@60Hz, 1024x768@60Hz,
1280x768@60Hz, 1280x800@60Hz,
1280x960@60Hz, 1280x1024@60Hz,
1360x768@60Hz, 1366x768@60Hz,
1440x900@60Hz, 1600x900@60Hz,
1600x1200@60Hz, 1680x1050@60Hz,
1920x1200@60Hz;
SMPTE:
4096x2160@24/25/30/50/60Hz,
3840x2160@24/25/30/50/60Hz,
1080P@24/25/30/50/60Hz, 1080I@50/60Hz,
720P@50/60Hz, 576P@50Hz, 480P@60Hz
Video Impedance
100 Ω
General
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity
10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV(Air-gap discharge)/
±4kV(Contact discharge)
Surge Protection
Voltage: ±1 kV
(Ten times respectively for the positive and
negative voltage)
Electrical Fast
Tr an si en t/ Bu rs t
Data communication cord: 1 kV
Power cord : 2 kV
Power Supply
DC 12V 0.5A
Power Consumption
(Maximum)
≤2 W
Device Dimension
(W x H x D)
120mm x 20mm x 80mm /
4.72’’ x 0.79’’ x 3.15’’
Product Weight
0.23kg
Certification
CE, FCC, RoHS
&
Use quality HDMI cable to connect the devices to ensure system stability.
10
TL-INCT-01 User Manual
www.tlnetworx.com
7. Panel Drawing
8. Troubleshooting & Maintenance
Problems
Causes
Solutions
Color loss or blurry/ double
image on HDMI display
Poor quality of HDMI cable
Change for qualified HDMI
cable.
Power led is off, operations
don’t work
No power
Power up the unit
Poor contact of power port
Make sure power adapter is
properly seated
No output on the display
Source/ Display is off
Tu rn o n th e source/ display
Poor contact of HDMI
ports
Check the HDMI ports one
by one to make sure they’re
properly seated.
&
If your problem persists after following the above troubleshooting steps, seek
further help from authorized dealer or our technical support.
11
TL-INCT-01 User Manual
www.tlnetworx.com
9. After-sales Service
If there appear some problems when running the device, please check and deal with the
problems referenced in this user manual.
4) Product Limited Warranty: We warrant that our products will be free from defects in
materials and workmanship for three years. Please see warranty page posted on
www.tlnetworx.com for more info.
5) What the warranty does not cover:
l Warranty expiration.
l Factory applied s erial numb er has been altered or removed f rom the produc t.
l Damage, deterioration or malfunction caused by:
l Normal wear and tear
l Use of supplies or parts not meeting our specifications
l No certificate or invoice as the proof of warranty.
l The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
l Damage caused by force majeure.
l Non-authorized service
l Other causes which does not relate to a product defect
l Delivery, installation or labor charges for installation or setup of the product
6) Te c h n i c a l S u p p o rt : Email to our after-sales department or make a call, please inform
us the following information about your cases.
l Product version and name.
l Detailed failure situations.
l The formation of the cases.
Remarks: For any questions or problems, please try to get help from your local
distributor.
Loading...
