User!Manual!
TL-C-HDCP!
HDCP!Converter!
!
!
!
!
!
!
!
!
!
All!Rights!Reserved!
Version:!TL-C-HDCP_160624!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
Preface!
Read!this!user!manual!carefully!before!using!this!product.!Pictures!shown!in!this!manual!are!for!
reference!only,!slight!differences!may!be!evident!on!the!real!product.!
This!manual!is!only!for!operation!instruction!only,!not!for!any!maintenance!usage.! !
!
Trademarks!
Product!model!and!logo!are!trademarks.!Any!other!trademarks!mentioned!in!this!manual!are!
acknowledged!as!the!properties!of!the!trademark!owner.!No!part!of!this!publication!may!be!
copied!or!reproduced!without!prior!written!consent.!
!
FCC!Statement!
This!equipment!generates,!uses!and!can!radiate!radio!frequency!energy!and,!if!not!installed!and!
used!in!accordance!with!the!instructions,!may!cause!harmful!interference!to!radio!
communications.!It!has!been!tested!and!found!to!comply!with!the!limits!for!a!Class!B!digital!
device,!pursuant!to!part!15!of!the!FCC!Rules.!These!limits!are!designed!to!provide!reasonable!
protection!against!harmful!interference!in!a!commercial!installation.! !
Operation!of!this!equipment!in!a!residential!area!is!likely!to!cause!interference,!in!which!case!
the!user!at!their!own!expense!will!be!required!to!take!whatever!measures!may!be!necessary!to!
correct!the!interference!
Any!changes!or!modifications!not!expressly!approved!by!the!manufacture!would!void!the!user’s!
authority!to!operate!the!equipment.!
! !!!!!!!!! !!!!!!!!!!!! !
!
! !
TL-C-HDCP!User!Manual
www.tlnetworx.com,
SAFETY!PRECAUTIONS!
To!in s ure! t he!be st!experience!from!the!product,!please!read!all!instructions!carefully!befo re!
using!the!device.!Save!this!manual!for!further!reference.!
l Unpack!the!equipment!carefully!and!save!the!original!box!and!packing!material!for!possible!
future!shipment!
l Follow!basic!saf ety!precautions!to!reduce!the!risk!of!fire,!electrical!shock!and!injury!to!
persons.!
l Do!not!dismantle!the!housing!or!modify!the!module.!It!may!result!in!electrical!shock!or!
burns.!
l Using!supplies!or!parts!not!meeting!the!products’!specifications!may!cause!damage,!
deterioration!or!malfunction.!
l Refer!all!servicing!to!qualified!service!personnel.!
l To!pr even t !fir e!or! s hock! hazar d,!d o !not! expos e !the! unit! to!ra in,! m oistu re!o r !install! t his!
product!near!water.!
l Do!not!put!any!heavy!items!on!the!extension!cable!in!case!of!damage.!
l Do!not!remove!the!housing!of!the!device!as!opening!or!removing!housing!may!expose!you!
to!dangerous!voltage!or!other!hazards.!
l Install!the!device!in!a!place!with!proper!ventilation!to!avoid!damage!caused!by!overheat.!
l Keep!the!module!away!from!liquids.!
l Spillage!into!the!housing!may!result!in!fire,!electrical!shock,!or!equipment!damage.!If!an!
object!or!liquid!falls!or!spills!on!to!the!housing,!unplug!the!module!immediately.!
l Do!not!use!liquid!or!aerosol!cleaners!to!clean!this!unit.!Always!unplug!the!power!to!the!
device!before!cleaning.!
l Unplug!the!power!cord!when!left!unused!for!a!long!period!of!time.!
l Information!on!disposal!for!scrapped!devices:!do!not!burn!or!m ix !w it h!gen eral!househ o ld !
waste,!please!treat!them!as!normal!electrical!wastes.!
1!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
1. Introduction!
TL-C-HDCP!is!an!HDCP!Converter!supports!HDMI2.0!&!HDCP2.2.!It!is!designed!to!enhance!the!
compatibility!between!HDMI!source!and!display!by!converting!HDCP!2.2!signa l !to!H DCP!1.4.! !
The!high-definition!HDMI!signal!can!be!transmitted!from!HDMI!source!to!match!all!kinds!of!
display!devices.! !
The!transmission!distan ce!of!4k*2k@60Hz!(max)!signal!can!be!up!to!15m.!Besides!straightthrough!HDMI!transmission,!the!EDID!bypass!function!ensures!the!best!resolution.!
!
1.1 Features!
l Supports!HDMI2.0!&!HDCP2.2!
l EDID!bypass!
l Auto!input!resolution!detection!
l Easy!to!install!and!simple!to!operate!
!
1.2 Package!List!
ü 1!x!TL-C-HDCP!
ü 2!x!Mounting!ears!
ü 2!x!Screws!
ü 4!x!Plastic!cushions!
ü 1!x!Power!Adapter!(DC!5V!1A)!
ü 1!x!User!manual!
&
Check!whether!all!the!items!listed!above!are!included!in!your!package.!If!not,!contact!
your!dealer.!
!
! !
2!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
2. Appearance!
!
No.!
Name!
Description!
① !
Power!Indicator!
Illuminated!red!when!powered!on!
② !
IN!
Connect!with!HDMI/!DVI!source!
③ !
DC!5V!
Micro!USB!power!port,!insert!DC!5V!1A!power!adapter!
④ !
OUT!
Connect!with!HDMI/!DVI!display!
&
Pictures!shown!in!this!manual!are!for!reference!only.!
!
3. System!Connection!
The!figure!below!illustrates!a!typical!connection!that!can!be!utilized!with!TL-C-HDCP:!
!
Step1. Connect!a!HDMI!source!(e.g.!a!Blu-ray!DVD)!to!IN!port!of!TL-C-HDCP;!
Step2. Connect!a!HDMI!display!(e.g.!a!LCD!TV)!to!OUT!port!of!TL-C-HDCP;!
Step3. Plug!DC!5V!1A!power!adapter!into!the!power!port!of!TL-C-HDCP.!
&
!
1) System!should!be!installed!in!a!clean!environment!with!proper!temperature!and!
humidity.!
2) All!of!the!power!switches,!plugs,!sockets!and!power!cords!should!be!insulated.!
3) All!devices!should!be!connected!before!power!on.! !
DVD
HDTV
DC 5V
HDMI Signa l:
3!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
4. Specification!
Input!
Output!
Input!
1!HDMI!IN!
Output!
1!HDMI!OUT!
Connector!
19-pin! type-A! female!
HDMI!
Connector!
19-pin! type-A! female!
HDMI!
Audio!
HDMI!embedded!audio!
Audio!
HDMI!embedded!audio!
General!
Transmission!
Distance!
4K*2K@60Hz≤15m!
1080P≤20m!
Bandwidth!
18!Gbps!
Audio!
Supports!PCM（2.0,!2.1,!5.1,!6.1,!7.1）,!Dolby!Digital（5.1）、DTS-HD（5.1,!
7.1,!DD+/True!HD（2.0,!5.1,!7.1)!DTS-ES!6.1!
Audio!Sampling!
Rate!
32k,!44.1k,!48k,!88.2k,!96k,!176.4k,!192k!
Power!Supply!
DC!5V!1A!
Power!
Consumption!
0.5W!
Dimensions!
(W*H*D)!
45.5*12*75!mm!
Weight!
49g!
Work!
Tempe ratu re!
0~50℃!
Reference!
Humility!
10%-90%!
EDID!
Management!
Support!pass-through!EDID!
!
4.1 Supported!Resolution!
4K!
3840*2160,!4096*2160（30H z/60Hz）!
16:9!
1920*1080,!1600*900,!1366*768,!1280*720,!1024*576（60Hz）!
16:10!
1920*1200,!1680*1050,!1440*900,!1360*768,!1280*800（60Hz）!
4:3!
1600*1200,!1400*1050,!1280*1204,!1024*768,!800*600,!640*480
（60Hz）!
21:9!
2560*1080（30Hz/60Hz）!
&
Use!quality!HDMI!cable!to!connect!the!devices!to!ensure!preferred!transmission!effect.!
! !
4!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
5. Panel!Drawing!
!
!
6. Troubleshooting!&!Maintenance!
Problems!
Causes!
Solutions!
Color!loss!or!blurry/!double!
image!on!HDMI!display!
Poor!quality!of!the!HDMI!
cable!
Change!for!qualified!HDMI!
cable.!
Power!led!is!off,!operations!
don’t!work!
No!power!
Power!up!the!unit!
Poor!contact!of!power!port!
Make!sure!power!adapter!is!
properly!seated!
No!output!on!the!display!
Source/!Display!is!off!
Turn!on!the!source/!display!
Poor!contact!of!HDMI!ports!
Check!the!HDMI!ports!one!
by!one!to!make!sure!they’re!
properly!seated.!
&
If!your!problem!persists!after!following!the!above!troubleshooting!steps,!seek!further!
help!from!authorized!dealer!or!our!technical!support.! !
45 .5 mm
12 m m
75 m m
5!
TL-C-HDCP!User!Manual
www.tlnetworx.com,
7. After-sales!Service!
If!there!appear!some!problems!when !r unning!the!device,!pl ease!check!and!deal!with!the!
problems!referenced!in!this!user!manual.!
1) Product!Limited!Warranty:!We!warrant!that!our!products!will!be!free!from!defects!in!
materials!and!workmanship!for!three!years.!Please!see!warranty!page!posted!on!
www.tlnetworx.com!for!more!info.!
2) What!the!warranty!does!not!cover:!
l Warranty!expiration.!
l Factory!applied!serial!number!has!been!altered!or!removed!from!the!product.!
l Damage,!deterioration!or!malfunction!caused!by:!
l Normal!wear!and!tear!
l Use!of!supplies!or!parts!not!meeting!our!specifications!
l No!certificate!or!invoice!as!the!proof!of!warranty.!
l The!product!model!showed!on!the!warranty!card!does!not!match!with!the!model!of!
the!product!for!repairing!or!had!been!altered.!
l Damage!caused!by!force!majeure.!
l Non-authorized!service!
l Other!causes!which!does!not!relate!to!a!product!defect!
l Delivery,!installation!or!labor!charges!for!installation!or!setup!of!the!product!
3) Techn i cal! Suppo rt:!Email!to!our!after-sales!department!or!make!a!call,!please!inform!us!the!
following!information!about!your!cases.!
l Product!version!and!name.!
l Detailed!failure!situations.!
l The!formation!of!the!cases.!
!
Remarks:!For!any!questions!or!problems,!please!try!to!get!help!from!your!local!distributor.!
!
