Techfaith Wireless Technology Group 09438T Users Manual

TECHFAITH

Perai-H

User Manual Version 1.0

Please Read Before Proceeding

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, ActiveSync, Excel, Internet Explorer, MSN, Outlook, PowerPoint, and Word are either registered trademarks or trademarks of Microsoft Corporation in the United

States or other countries.

THIS DEVICE IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX. DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your Pocket PC Phone.

When using this product, the safety precautions below must be taken to offset possible legal liabilities and damages.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the battery. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY IN AIRCRAFTS

Due to the possible interference caused by this product to an aircraft's navigation system and its communications network, using this product on board an airplane is against the law in most countries.

ENVIRONMENT RESTRICTIONS

Do not use this product at gas or refueling stations. The use of this product is also prohibited in fuel storehouses, chemical plants, and locations containing explosives.

SAFETY FOR ENVIRONMENTS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using hand-free devices as an alternative is allowed.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

NONIONIZING RADIATION

This product should be operated in the suggested normal condition only to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

TECHFAITH..........................................................................................................................................1

Perai-H.................................................................................................................................................1

User Manual Version 1.0....................................................................................................................1

Getting Started....................................................................................................................................10

1.1 Getting to Know your Device and its Accessories.............................................................12

Front, top, and left-side view..............................................................................................................12

Back and right-side view ....................................................................................................................14

The QWERTY keyboard....................................................................................................................14

Accessories...........................................................................................................................................15

1.2 Insert the SIM Card......................................................................................................................15

1.3 Battery Information......................................................................................................................16

Check the battery power ....................................................................................................................17

Charge the battery..............................................................................................................................17

Low battery..........................................................................................................................................17

1.4 Start Up..........................................................................................................................................17

Turn the device on and off..................................................................................................................17

Calibrate the Device............................................................................................................................ 17

Manage screen settings....................................................................................................................... 18

1.5 The Today Screen.......................................................................................................................... 18

Indicators.............................................................................................................................................19

1.6 Use the Start Menu........................................................................................................................20

Program Indicators............................................................................................................................. 20

Enter and Search Information...........................................................................................................21

2.1 Introduction ...................................................................................................................................23

Show or hide Input Panel...................................................................................................................23

Example:.............................................................................................................................................. 23

2.2 Use the Keyboard..........................................................................................................................24

Use the standard on-screen Keyboard..............................................................................................24

Enter text using the on-screen Keyboard..........................................................................................24

Enlarge the on-screen Keyboard.......................................................................................................24

2.3 Use Letter Recognizer...................................................................................................................24

Us Letter Recognizer ..........................................................................................................................24

2.4 Use Block Recognizer....................................................................................................................25

Use Block Recognizer..........................................................................................................................25

2.5 Use Transcriber.............................................................................................................................25

Start Transcriber.................................................................................................................................25

Write using Transcriber ..................................................................................................................... 25

Enter punctuation and symbols......................................................................................................... 25

Edit text................................................................................................................................................ 26

Transcriber Gestures .......................................................................................................................... 26

The T ranscri ber toolbar.....................................................................................................................27

2.6 Draw and Write on the Screen.....................................................................................................27

Set the input mode for Notes..............................................................................................................28

Write a note ...............................................................................................................................

Draw in a note .....................................................................................................................................28

2.7 Recording a Note...........................................................................................................................28

Create a voice note..............................................................................................................................28

Change recording formats..................................................................................................................29

2.8 Search Information.......................................................................................................................29

Search for a ﬁle or an item .................................................................................................................29

Use Phone Features.............................................................................................................................29

3.1 Use the Phone ................................................................................................................................ 30

The Phone screen ................................................................................................................................ 31

TALK button ....................................................................................................................................... 31

Enter your PIN....................................................................................................................................31

Turn on and off flight mode ...............................................................................................................31

Adjust the device volume....................................................................................................................31

..........28

3.2 Make a Call....................................................................................................................................32

Make a call from Phone......................................................................................................................32

Phone Screen ....................................................................................................................................... 32

Make a call from Contacts.................................................................................................................32

Specify the number to dial..................................................................................................................33

Make a call from Call History............................................................................................................33

Make a call from Speed Dial..............................................................................................................33

Create a Speed Dial entry...................................................................................................................33

Make a call from SIM Manager ........................................................................................................33

3.3 Receiving a Call............................................................................................................................. 33

Answer or reject an incoming call .....................................................................................................34

End a call .............................................................................................................................................34

3.4 In-call Options...............................................................................................................................34

Put a call on hold................................................................................................................................. 34

Switch between two calls .................................................................................................................... 34

Set up a conference call.......................................................................................................................34

Turn on and off the Speakerphone....................................................................................................34

Mute a call ...........................................................................................................................................34

3.5 Additional Dialing Information ...................................................................................................34

Make an emergency call.....................................................................................................................35

Make an international call .................................................................................................................35

SIM TkUI (STK).................................................................................................................................35

Synchronize Your Device.................................................................................................................... 35

Install and set up ActiveSync.............................................................................................................37

4.2 Synchronize Information..............................................................................................................37

Synchronize Outlook information.....................................................................................................37

Start and stop synchronization .......................................................................................................... 38

Change which information is synchronized...................................................................................... 38

Synchronize directly with Exchange Server .....................................................................................38

4.3 Synchronize via Infrared and Bluetooth.....................................................................................39

Synchronize with a PC via infrared...................................................................................................39

Synchronize with a PC via Bluetooth................................................................................................39

4.4 Synchronize Music, Video, and Pictures.....................................................................................39

Change Media synchronization settings............................................................................................40

Set up a sync relationship with a storage card.................................................................................40

Manage Your Pocket PC Phone............................................................................................................40

5.1 Personalize Your Pocket PC Phone ............................................................................................. 41

Today screen settings ..........................................................................................................................41

Customize the Today screen............................................................................................................... 41

Add a custom background image......................................................................................................41

Set options for displaying tasks on the Today screen.......................................................................42

Customize the Start menu.................................................................................................................. 42

Set Date / Time / Language / Regional Options................................................................................42

Set the time and date...........................................................................................................................43

Set an alarm......................................................................................................................................... 43

Set the time and date for a different location

Change language and regional settings.............................................................................................43

Personal and system settings..............................................................................................................43

Reassign programs or shortcuts to program buttons ......................................................................43

Increase or decrease the size of text on the screen............................................................................44

Enter owner information.................................................................................................................... 44

Choose how to be notiﬁed by events or actions ................................................................................ 44

Adjust the speed for scrolling.............................................................................................................44

...................................................................................43

Find the operating system version number.......................................................................................44

Get detailed device information......................................................................................................... 44

Change the device name.....................................................................................................................44

Why is the device name important?..................................................................................................45

Make the battery last longer..............................................................................................................45

Adjust the brightness of the backlight ..............................................................................................45

Set the backlight to dim after a time delay.......................................................................................45

Phone settings...................................................................................................................................... 45

Change the ring tone...........................................................................................................................45

Change the ring type...........................................................................................................................45

Change the keypad tone .....................................................................................................................46

Phone services......................................................................................................................................46

Choose the services..............................................................................................................................46

Networks..............................................................................................................................................46

Change phone network settings.........................................................................................................46

Set preferred networks.......................................................................................................................46

5.2 Add and Remove Programs..........................................................................................................46

Add programs......................................................................................................................................47

Remove programs...............................................................................................................................47

5.3 Manage Memory...........................................................................................................................47

See how much memory is available................................................................................................... 47

See available storage card memory...................................................................................................47

Free up program memory.................................................................................................................. 48

Close a program..................................................................................................................................48

5.4 Back Up Files................................................................................................................................. 48

Copy ﬁles to a storage card ................................................................................................................48

Copy a ﬁle using ActiveSync ..............................................................................................................48

Save ﬁles on a storage card automatically........................................................................................49

5.5 Protect Your Device.......................................................................................................................49

Protect your phone with a PIN...........................................................................................................49

Protect your device with a password.................................................................................................49

Change your password.......................................................................................................................50

Display owner information on the Today screen..............................................................................50

5.6 Reset Your Pocket PC Phone........................................................................................................50

Perform a soft reset.............................................................................................................................50

Perform a hard reset...........................................................................................................................51

Getting Connected ..............................................................................................................................51

6.1 Connect to the Internet.................................................................................................................53

Connect to the Internet via ISP..........................................................................................................53

Connect to a private network.............................................................................................................54

Reset or modify the network card settings on your device..............................................................54

6.2 Internet Explorer Mobile

Start Internet Explorer Mobile.......................................................................................................... 55

Choose a Home page...........................................................................................................................55

Transfer favorites from your PC ....................................................................................................... 55

Add a favorite......................................................................................................................................55

Delete a favorite or folder................................................................................................................... 55

Change the size of text on Web pages................................................................................................55

Show or hide pictures on Web pages.................................................................................................56

Change how Web pages ﬁll the screen............................................................................................... 56

Clear the History list...........................................................................................................................56

Save a picture from a Web page ........................................................................................................56

Change cookies and security settings................................................................................................56

..............................................................................................................55

Delete temporary Internet ﬁles..........................................................................................................56

6.3 Using Bluetooth............................................................................................................................. 57

Turn on or off Bluetooth on your device........................................................................................... 57

Bluetooth modes.................................................................................................................................. 57

Make your device discoverable..........................................................................................................57

Bluetooth partnerships.......................................................................................................................57

Create a Bluetooth partnership ......................................................................................................... 58

Accept a Bluetooth partnership......................................................................................................... 58

Rename a Bluetooth partnership.......................................................................................................58

Delete a Bluetooth partnership..........................................................................................................58

Beam information using Bluetooth....................................................................................................58

Use a Bluetooth device as a modem...................................................................................................59

Conﬁgure and use a Bluetooth device as a modem..........................................................................59

6.4 Use Wireless Manager ..................................................................................................................59

Connect to a Wi-Fi network...............................................................................................................59

Check the Wireless LAN status..........................................................................................................60

6.5 Use Terminal Services Client........................................................................................................60

Connect to a Terminal Server............................................................................................................60

Navigate within Terminal Services Client.........................................................................................61

Disconnect without ending a session..................................................................................................61

Disconnect after ending a session.......................................................................................................61

Exchanging Messages and Using Outlook ........................................................................................61

7.1 E-mail and Text Messages ............................................................................................................62

Set up an e-mail account.....................................................................................................................62

Compose and send a message.............................................................................................................64

Reply to or forward a message...........................................................................................................64

Add an attachment to a message........................................................................................................64

Receive attachments............................................................................................................................65

Downloading messages ....................................................................................................................... 65

Download messages from the server..................................................................................................65

Managing folders ................................................................................................................................66

7.2 MMS Messages..............................................................................................................................66

Set up MMS......................................................................................................................................... 67

Access MMS ........................................................................................................................................67

Set up a MMS account........................................................................................................................ 67

Manage MMS messages......................................................................................................................67

Start composing a MMS message ......................................................................................................67

Create a MMS message from a template..........................................................................................68

Add predeﬁned text strings to a MMS message...............................................................................68

Add an audio clip to a MMS message ............................................................................................... 68

Reply to a MMS message....................................................................................................................69

View a MMS message.........................................................................................................................69

Set advanced options for a MMS message........................................................................................69

Change MMS settings.........................................................................................................................69

ﬁgure MMS settings.....................................................................................................................69

Con

7.3 Windows Live Messenger.............................................................................................................70

Start Windows Live Messenger..........................................................................................................70

Sign in or out ....................................................................................................................................... 70

Add or delete contacts.........................................................................................................................71

Send an instant message.....................................................................................................................71

Block or unblock contacts ..................................................................................................................71

Check your own Messenger status.....................................................................................................71

Change your display name.................................................................................................................71

Get more help about Windows Live Messenger...............................................................................71

7.4 Calendar.........................................................................................................................................71

Schedule an appointment ................................................................................................................... 71

Send a meeting request.......................................................................................................................72

Set a default reminder for all new appointments............................................................................. 72

7.5 Contacts .........................................................................................................................................72

Create a contact...................................................................................................................................72

Change contact information...............................................................................................................73

Work with the contact list..................................................................................................................73

Copy SIM contact to Contacts...........................................................................................................73

Find a contact......................................................................................................................................73

7.6 Tasks............................................................................................................................................... 73

Create a task........................................................................................................................................74

Change the priority of a task .............................................................................................................74

Set a default reminder for all new tasks............................................................................................74

Show start and due dates in the task list........................................................................................... 74

Locate a task........................................................................................................................................74

7.7 Notes...............................................................................................................................................74

Entering information in Notes...........................................................................................................75

Set the default input mode for Notes.................................................................................................75

Create a note........................................................................................................................................ 75

Experiencing Multimedia...................................................................................................................75

8.1 Use Camera....................................................................................................................................76

Switch to any of the Camera modes..................................................................................................76

Exit the Camera .................................................................................................................................. 77

Use the camera .................................................................................................................................... 77

Use shortcuts in Camera mode..........................................................................................................77

The ENTER button.............................................................................................................................77

The NAVIGATION control ................................................................................................................77

The CAMERA button.........................................................................................................................77

Use Still Image capture modes ........................................................................................................... 77

Use Video capture mode .....................................................................................................................77

Use zooming .........................................................................................................................................78

Use the Camera Settings screen.........................................................................................................78

8.2 Use Picture & Videos ....................................................................................................................78

Copy a picture or video clip to your device.......................................................................................79

View pictures.......................................................................................................................................79

Play videos with audio........................................................................................................................79

View slide shows..................................................................................................................................79

Sort pictures and video clips..............................................................................................................80

Delete a picture or video clip..............................................................................................................80

Edit a picture or video clip

Set a picture as the Today screen background..................................................................................80

Send pictures and video clips via e-mail............................................................................................80

Beam a picture.....................................................................................................................................81

Assign pictures to contacts.................................................................................................................81

Use advance options............................................................................................................................81

8.3 Use Windows Media Player..........................................................................................................81

About the controls...............................................................................................................................82

About the screens and menus............................................................................................................. 82

Playback screen menu.........................................................................................................................82

Now Playing screen menu...................................................................................................................83

Library screen menu...........................................................................................................................83

.................................................................................................................80

About licenses and protected files......................................................................................................83

Play items on your device...................................................................................................................84

Play an item on a network..................................................................................................................84

Copy files to your device.....................................................................................................................84

Accessibility for people with disabilities............................................................................................85

Troubleshooting...................................................................................................................................85

Using Other Applications ...................................................................................................................85

9.1 Word Mobile..................................................................................................................................87

Create a ﬁle..........................................................................................................................................87

Unsupported features in Word Mobile..............................................................................................88

Get more help about Word Mobile....................................................................................................88

9.2 Excel Mobile..................................................................................................................................88

Unsupported features in Excel Mobile..............................................................................................89

9.3 View Slide Shows with PowerPoint Mobile.................................................................................89

Start a slide show presentation...........................................................................................................90

Stop a slide show.................................................................................................................................. 90

Navigate between slides......................................................................................................................90

9.4 Use Java .........................................................................................................................................90

Install MIDlets from the Internet...................................................................................................... 90

Install MIDlets from a PC..................................................................................................................91

Install a MIDlet/MIDlet suite.............................................................................................................91

Run MIDlets on your device...............................................................................................................91

Manage MIDlets..................................................................................................................................91

Change the name of a MIDlet............................................................................................................ 91

Uninstall a MIDlet...............................................................................................................................92

Conﬁgure MIDlet security..................................................................................................................92

A.1 Regulatory Notices.......................................................................................................................93

Regulatory Agency IDs ....................................................................................................................... 93

European Union Notice.......................................................................................................................93

Modifications.......................................................................................................................................94

Important Health and Safety Information .......................................................................................94

Safety Precautions for RF Exposure..................................................................................................95

General Precautions............................................................................................................................95

Safety Precautions for Power Supply Unit........................................................................................96

Exposure to Radio Frequency (RF) Signals......................................................................................96

SAR Information................................................................................................................................. 97

A.2 PC Requirement to Run ActiveSync4.0......................................................................................98

A.3 Troubleshooting............................................................................................................................98

Power & Battery..................................................................................................................................98

ActiveSync ...........................................................................................................................................99

Problem...............................................................................................................................

Display & Sound .................................................................................................................................99

Connection & Bluetooth.....................................................................................................................99

Operating...........................................................................................................................................100

Memory..............................................................................................................................................100

Media Player......................................................................................................................................100

Phone..................................................................................................................................................101

A.4 Specifications..............................................................................................................................101

System Information...........................................................................................................................101

Display................................................................................................................................................101

GSM/EDGE Module.........................................................................................................................102

Camera Module................................................................................................................................. 102

Physical .............................................................................................................................................. 102

.................99

Controls and Lights ..........................................................................................................................102

Audio.................................................................................................................................................. 102

Connection.........................................................................................................................................103

Expansion Slots ................................................................................................................................. 103

Chapter 1

Getting Started

1.1 Getting to Know your Device and its Accessories

1.2 Install the SIM Card

1.3 Battery Information

1.4 Start Up

1.5 The Today Screen

1.6 Use the Start Menu

1.1 Getting to Know your Device and its Accessories

Front, top, and left-side view

No. Item Function

Press this button to turn off your device temporarily and switches the device to sleep mode; press and hold (about 5 seconds) this button to turn off your device completely. When

1 POWER Button

your device is in sleep mode, you can still receive calls; however, the phone function is off when you turn off the device completely.

2 Power LED 3 Front Camera Lens 4 Speaker 5 Touch Screen 6 START menu KEY

7 Left SOFT KEY

8 Right SOFT KEY

9 OK Button

10 END Button

11 Internet Explore

12 Navigation Pad

13 Video phone 14 TALK Button

15 Microphone

Bi-color LED Power indicator, battery charging status. Use this front built-in camera to take photos or video clips Listen to audio media or phone call. Use to write, draw, or make a selection with the stylus. Press this button to active your START menu.

Performs the command shown in the label above the button.

Press this button to perform the command highlighted. Press this button to end a call or silence the ring from an

incoming call. Also, press this button to return to the Start screen from any location.. Press this button to launch Internet Explorer.

Press the navigation pad to scroll left, right, up or down on the display; press the center button to enter a selection.

Press this button to access the video phone Press this button to make a call to the name or number shown

on the screen or to answer a call. Do not cover the microphone with your hand during phone call

16 Sync Connector

Use this connector for synchronizing data or recharging the battery.

17 Earphone Jack 18 Volume Keys

19 Side OK Button 20 CAMERA Button

Connect a compatible headset to the connector of your device Scroll volume keys to adjust the volume/ press to confirm the

operation Press this button to perform the command highlighted.

Press to launch the camera. Press again to take a picture.

Back and right-side view

No. Item Function

MiniSD Card Slot

22 Zoom buuton 23 Camera Lens

24 External Speaker 25 Cover Latch

26 Stylus

Insert a storage card (miniSD) for storing data. Use this key to adjust the zoom of Microspur mode

Use this built-in camera to take photos or video clips Allows you to listen audio media or hands-free calls

Slide this latch to release the battery cover. Use the stylus to write, draw, or select items on the touch

screen.

The QWERTY keyboard

Your device provides you with a QWERTY keyboard, which is similar to a standard keyboard of PC.

The QWERTY keyboard

You can do the following actions with the QWERTY keyboard: . • To type lowercase letters, press the keys using your thumbs or fingers.

. • To use all uppercase letters, press twice.

. • To type a single uppercase letter, press

, and then press the corresponding

key. . • To enter a number or symbol (labeled in blue color), press

and then press

the corresponding key.

. • Press the Left/Right SOFT KEY (

/ ) to perform the command

shown in the label above the key.

. • Press OK key to verify your data entries or exit the program in use.

• Press to open the Start menu.

. • Press the arrow keys (

/ ) for directional movement.

Accessories

The following accessories are provided with the device:

No. Item Function

1 AC adapter 2 USB cable

3 Stereo headset

Recharge the device battery. Connect your device to PC and synchronize data.

Provide a Send/End button. You can use the button to pick up and hang up incoming and outgoing calls. To use it, plug into Earphone Jack.

1.2 Insert the SIM Card

Follow these steps to insert a GSM SIM (Subscriber Identity Module) card which is provided by your local network service provider. The SIM card may contain your phone number, service details, and phonebook/message memory.

Your device supports both 1.8V and 3V SIM cards. Some legacy SIM cards will not

function within this device. The customer should consult with their service provider for a replacement SIM card. There may be a fee for this service.

1. Always switch the device off, and disconnect the charger before removing the

battery

2. Slide the back cover to remove it from the phone

3. If the battery is installed, user the finger grip to lift the battery from the battery

compartment.. Then, insert the SIM card into the SIM card slot with its gold contacts facing down (the cutoff corner of the SIM card should match the cut-off corner in the

4. Replace the battery and gently push down to snap it into place.

5. Replace the battery cover.

1.3 Battery Information

This device is intended for use with Li-ion polymer battery. Use only batteries, chargers and enhancements approve by manufacturer. Battery performance depends on many factors, including wireless service provider’s network configuration, signal strength, temperature of the environment in which you operate your device, the features and/or settings you select and use, items attached to your device’s connecting ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

. • Standby time: 150 ~ 200 hours . • Talk time (Screen off): 3.5 ~ 5 hours

Warning! To reduce risk of fire or burns.

. • Do not attempt to open, disassemble, or service the battery pack. . •Do not crush, puncture, short external contacts, or dispose of in fire or water.

. • Do not expose to temperatures above 60oC (140oF). . • Replace only with the battery pack designated for this product. . • Recycle or dispose of used battery as stipulated by local regulation.

Check the battery power

• Tap the battery level icon ( ) on the Today screen.

• Select Start > Settings > System tab > Power.

Charge the battery

New batteries are shipped partially charged. Install and charge the battery before use with this device. The full performance of a new battery is achieved only after several complete charge and discharge cycles.To charge the battery:

. • Connect your device directly to an external power source. . • Plug the device sync cable into the USB port on your PC.

Low battery

When the low-battery warning appears, following actions are suggested:

. • Immediately save your current data. . • Recharge the battery. . • Turn off the device.

1.4 Start Up

Turn the device on and off

To turn on the device, press the POWER button. When you turn on the device for the first time, you are asked to complete a calibration process. For more information, see “Calibrate the device” on page 18.

To turn off the device, press POWER again.

Note Press POWER key to turn off your device temporarily and switches the device to

sleep mode. However, messages and calls can still be received while the device is in the sleep mode.

Calibrate the Device

Calibrating the device screen involves tapping with the stylus the centre of a cross as it moves around the screen.

If the device does not accurately respond to screen taps, follow these steps to

re-calibrate it:

1. Select Start > Settings > System tab > Screen.

2. On the General tab, select Align Screen, and follow the instructions on the

screen.

Manage screen settings

The device touch screen has three orientation modes: Portrait and Landscape (right-handed).Portrait mode allows you to get a better view or a better operation of certain programs on your device, while Landscape mode may be optimal for viewing longer text files.

1.5 The Today Screen

The Today screen displays important information, such as upcoming

appointments and status indicators. To open the program, tap the associated section on the screen.

. •To access the Today screen, tap Start > Today. . •To customize the Today screen display, which includes the background image, select Start > Settings > Personal tab > Today.

7 8

9 10

12 13

1 Tap to open the Start menu.

2 Tap to view connectivity status. 3 Indicates the radio signal strength.

Tap to configuration the phone settings.

4 Tap to control device/ringer volume level.

5 Indicates the battery status. Tap to enter the Power Settings screen

6 Displays the current time.

7 Displays the current date. Tap to setup date, time, alarm, and more. 8 Tap to start Comm Manager

9 Tap to set owner information 10 Your day at a glance with reminders. Tap to open the related program:

messages, tasks, and appointments.

11 Tap to lock or unlock the device.

: locked; : unlocked.

12 Tap to open the Phone screen. 13 Tap to open the Contacts screen.

Indicators

Following are some of the status icons that you may see on your device.

Icon Description

Indicates the battery is fully charged. Indicates the battery is very low. Battery charging. Sound on.

Sound off. Ringer in vibration mode.

Connection is active. Connection is not active. Synchronization in progress. Synchronization error. Indicates maximum signal strength.

No signal. Phone is turned off. No phone service. Searching for phone service. Voice call in progress. Calls are forwarded. Call on hold. Missed call. GPRS is in use

New e-mail or text messages. There are more notifications. Tap the icon to view all. Indicates Wi-Fi is turned on.

Indicates the device is locked. : Device unlocked. WiFi is connected

WiFi data call

1.6 Use the Start Menu

The Start menu which is located at the top left corner of the Today screen displays a list of programs. It lets you close a screen and switch from one program to another. To start a program, scroll through the programs list and then press ENTER button, or tap a program with the stylus.

3 1

4 5 6

1 Tap to open the Today screen. 2 Tap to start a program. The items displayed in Start menu can be customized by

tapping Start> Settings > Personal tab >Menus.

3 Tap to start a recently-used program. 4 Tap to view and select more programs that are installed in your device. 5 Tap to change device settings. 6 Tap to see a Help topic for the current screen.

Program Indicators

Following indicators are some of the icons for the programs that are already installed on your device.

Icon Description

ActiveSync Synchronizes information between your device and a PC. Calculator Performs basic arithmetic and calculations, such as addition, subtraction,

multiplication, and division.

Calendar Keeps track of your appointments and creates meeting requests.

Camera Snaps photos or shoots video clips with accompanying audio.

Comm Manager Allows you to manage the device’s connection (including W i-Fi,

Bluetooth, and ActiveSync), and switch the ringer/ vibration mode.

Contacts Keeps track of your friends and colleagues. Excel Mobile Creates new workbooks or lets you view and edit Excel workbooks.

File Explorer Enables you to organize and manage files on your device.

Games Lets you play two pre-installed games: Bubble Breaker and Solitaire.

Help Enables you to see Help topics for a program on your device.

Internet Explorer Internet Explorer browses Web and WAP sites, and downloads

new programs and files from the Internet.

JAVA Enables you to download and install Java applications, such as games and

tools, on your device.

Messaging Sends and receives e-mail and text messages. Notes Creates handwritten or typed notes, drawings, and recordings.

Phone Makes and receives calls, switches between calls and sets

up conference calling.

Pictures & Videos Collects, organizes, and sorts picture and video

files in the My Pictures folder of your device or on a storage card.

Pocket MSN Sends and receives instant messages with your MSN

Messenger contacts.

PowerPoint Mobile Lets you view and edit PowerPoint slides and

presentations.

Search Enables you to search contacts, data, and other information

on your device.

SIM Manager Collects, organizes and sorts the contact list stored

in your SIM card.

Tasks Keeps track of your tasks.

Windows Media Enables the multimedia function on your device.

Word Mobile Creates new documents or lets you view and edit

Word documents.

Voice Speed Dial You can record voice tags so that you can dial.

Chapter 2

Enter and Search Information

2.1 Introduction

2.2 Use the Keyboard

2.3 Use Letter Recognizer

2.4 Use Block Recognizer

2.5 Use Transcriber

2.6 Draw and Writing on the Screen

2.7 Record a Note

2.8 Search Information

2.1 Introduction

When you start a program or select a field that requires text or numbers, Input Panel becomes available automatically. Input Panel provides various input methods which is available on your device, including Block Recognizer, Keyboard, Letter Recognizer, and Transcriber. By default, the Input Panel icon appears on the menu bar to indicate which input method is currently selected. The Input Selector arrow (shown at the right side of the Input Panel icon) opens a list of available input methods.

Show or hide Input Panel

• Tap the Input Panel icon on the menu bar.

Example:

Input Panel icon

Icon Input method

Input Panel (Keyboard)

Input Selector arrow

The on-screen keyboard. Letter Recognizer or Block Recognizer. Transcriber

2.2 Use the Keyboard

To enter text, symbols, and numbers, you can either type using the QWERTY Keyboard or the standard on-screen Keyboard. To use QWERTY keyboard, see the instruction in Chapter 1.

Use the standard on-screen Keyboard

The on-screen Keyboard is available when text entry is possible. You can enter text by tapping keys on the keyboard that are displayed on the screen.

Enter text using the on-screen Keyboard

1. In a program, tap the Input Selector arrow, and tap Keyboard.

2. Enter text by tapping keys on the on-screen Keyboard. Enlarge the on-screen Keyboard

1. Tap the Input Selector arrow, then tap Options.

2. In the Input method list, select Keyboard.

3. Tap Large Keys.

2.3 Use Letter Recognizer

With using Letter Recognizer, you can write individual letters, numbers, and punctuation, which can be converted into typed text.

Us Letter Recognizer

1. In a program, tap the Input Selector arrow, and then tap Letter Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

. • Enter capital letters by writing in the ABC (left) area of the box. . • Enter lower case letters by writing in the abc (middle) area of the box. . • Enter numbers by writing in the 123 (right) area of the box. .

then writing the desired character.

. . Note Letter Recognizer is available only when text entry is possible.

Tip For help with writing characters with Letter Recognizer, tap the question mark near

the writing area.

2.4 Use Block Recognizer

1. In a program, tap the Input Selector arrow, and then tap Block Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

. • Enter letters by writing in the abc (left) area of the box. . • Enter numbers by writing in the 123 (right) area of the box. .

• Enter punctuation and symbols by tapping in either area of the box and

With Block Recognizer, single stroke can be used to write letters, numbers, symbols, and punctuation, which can be converted into typed text.

Use Block Recognizer

• Enter symbols and punctuation by tapping in either area of the box and

then writing the desired character.

. . Note Block Recognizer is available only when text entry is possible.

Tip For help with writing characters with Block Recognizer, tap the question mark near

the writing area.

2.5 Use Transcriber

Transcriber is a handwriting recognition program that allows you to write in cursive,

print, or a combination of both. Transcriber works transparently in the background of programs, recognizing words with its integrated dictionary. When Transcriber is turned on, it interprets stylus movement anywhere on the screen as handwriting input. For more information about using Transcriber, see Help on your device.

Start Transcriber

1. Start a program that accepts user input, such as Word Mobile.

2. Tap the Input Selector arrow, and tap Transcriber. The Transcriber introductory

screen appears.

Write using Transcriber

1. In a program, position the cursor where the text should be appeared.

2. Use the stylus to write anywhere on the screen. The handwriting will be converted to

text shortly after you lift the stylus from the screen.

Enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to add punctuation or a special symbol to existing text.

• In a program, tap on the Transcriber toolbar. The keyboard remains

visible the button is tapped again.

Tips To reposition the keyboard, tap and hold the title bar, then drag to the desired

location. When no text is selected, you can also open the keyboard by doing the

gesture.

Edit text

1. In a program, draw a line across the text which is desired to edit.

2. After you lift the stylus from the screen, the line will disappear and the selected text

will be highlighted.

3. Do either of the following actions:

. • Rewrite the text. . • Use gestures to capitalize letters, insert a space, and so on. For information about using gestures, see “Transcriber Gestures” in this chapter.

Transcriber Gestures

Use quick strokes of the stylus to edit your text or to insert returns, spaces, or tabs.

Tip Enter, Space, and Backspace buttons can also be used with the Transcriber

toolbar.

Do To

Insert a paragraph return at the cursor. The horizontal portion of the gesture must be at least two times longer than the vertical portion.

Insert a space at the cursor. The horizontal portion of the gesture must be at least two times longer than the vertical portion.

Move the cursor one space back and erase any text. Do the gesture by drawing a line from right to left.

Open the menu of alternate words if a word is selected or the onscreen Transcriber keyboard if no text is selected. Do the gesture by drawing a line straight down and back up.

Change the capitalization of a selected letter, word, or block of text. Do the gesture by drawing a line straight up.

Undo the last action. Do the gesture by drawing a line straight up and back down.

Copy the selected text. Do the gesture by drawing a line from left to right and back.

Cut the selected text. Do the gesture by drawing a line from right to left and back.

Paste copied or cut text. Do the gesture by drawing a line from the lower left of the screen diagonally up toward the right and back down to the right.

Insert a tab. The horizontal portion of the gesture must be at least two times longer than the vertical portion.

The Transcriber toolbar

The Transcriber toolbar, which appears at the bottom of the screen when Transcriber is open, provides easy access to several tools, Enter, Space, Backspace buttons, Left and Right arrow buttons.

Tap To

Open the Options dialog box, where you can set options such as writing direction, text entry, and shorthand. Open Letter Shapes, where you can set your personal writing st yles to maximize recognition. Use the miniature keyboard to quickly enter numbers, punctuation, and other symbols. Change the character recognition mode.

• a mode. This is the default for optimum handwriting recognition.

• 123 mode. Numbers and some letters are allowed and the calculator is activated.

• A mode. All letters are automatically capitalized. If you are in A or 123 mode, recognition returns automatically to the default mode once you lift the stylus.

Insert a space at the cursor. Insert a paragraph return at the cursor.

Move the cursor one space to the left. Move the cursor one space to the right. Move the cursor one space back and erase any text. Open Transcriber Help.

2.6 Draw and Write on the Screen

With your device, you can draw directly on the screen, or write on the screen and save notes in your own handwriting. To do

this, input mode should be set to Writing in Notes. If you prefer to use handwriting or frequently add drawings to your notes, you may find it helpful to set Writing as the default input mode. If you prefer typed text, set Typing as the default input mode.

For more information on what you can do with Notes, see “Notes” in Chapter 7.

Drawing on the Screen

Set the input mode for Notes

1. Tap Start > Programs > Notes.

2. In the note list, tap Menu > Options….

3. In the Default mode box, select one of the following:

. • Writing if you want to draw or enter handwritten text in a note. . • Typing if you want to create a typed note.

4. Tap OK. Write a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. Write your text on the screen.

4. Tap OK to return to the note list if finished. Notes To select handwritten text, tap and hold next to the writing. As soon as dots

appear, quickly drag across the writing before they form a complete circle. If a letter crosses three ruled lines, it is treated as a drawing rather than text.

Draw in a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. To draw on the screen, use the stylus

4. A selection box appears around your drawing.

5. Tap OK to return to the note list if finished. Note, Tap and hold the drawing briefly to select a drawing. When you lift the stylus, the

drawing is selected.

2.7 Recording a Note

You can create a stand-alone recording (voice note) or you can add a recording to a note. For more information about creating, changing, or saving notes, see “Notes” in Chapter 7.

Create a voice note

1. Tap Start > Programs > Notes.

2. Do one of the following:

. • To create a stand-alone recording, record from the note list. . • To add a recording to a note, create or open a note.

3. If you do not see the Recording toolbar, tap Menu > View Recording Toolbar.

4. Tap the record icon (

5. Hold your device’s microphone near your mouth or other source of sound.

6. Tap the stop icon (

7. If you add a recording to a note, tap OK to return to the note list if ﬁnished.

8. An icon will appear in the note when recording in an open note,.

9. The recording will appear in the note list when creating a stand-alone recording,.

) to begin recording.

) when ﬁnished recording.

Tip To quickly create a recording, press the RECORD button. When you hear the beep,

begin your recording. Release the button when you are finished.

Change recording formats

1. Tap Start > Settings > Personal tab > Input.

2. Tap the Options tab, select the format you want in the Voice recording format list.

3. Tap OK. Note Recording formats can also be changed within Notes. In the note list, tap Menu >

Options > Global Input Options link (at the bottom of the page).

2.8 Search Information

You can search for files and other items stored on your device in the My Documents folder or on a storage card. You can search by file name or by words located in the item. For example, you can search in e-mail messages, notes, appointments, contacts, and tasks, as well as in online Help.

Search for a ﬁle or an item

1. Tap Start > Programs > Search.

2. In Search for, enter the ﬁle name, word, or other information you want to search for.

3. If you have looked for this item before, tap the Search for arrow and select the item

from the list.

4. In Type, select a data type to help narrow your search.

5. Tap Search.

6. The My Documents folder and subfolders are searched.

7. In the Results list, tap the item you want to open. Note The storage card symbol

on a storage card.

is displayed which is next to the names of files saved

3.1 Use the Phone

3.2 Make a Call

3.3 Receive a Call

3.4 In-call Options

Chapter 3

Use Phone Features

3.5 Additional Dialing Information

3.1 Use the Phone

+ 73 hidden pages

Techfaith Wireless Technology Group 09438T Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
