Teac PCDV125L User Manual

Download

Page 1

Page 2

WARRANTY REGISTRATION

Please read this warranty card.

Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service.

Warranty Terms & Conditions

1. TEAC warrants to the original retail purchaser only, that this product is free from defects in material and

workmanship under normal domestic use and authorises free service during the warranty period at any TEAC Authorised Service Centre only. TEAC warranty only applies to products purchased, used and serviced in Australia.

2. Subject to the terms herein, this warranty effectively covers the equipment as specified in the Warranty Periods

Table below from the date of purchase.

TEAC PRODUCT

WARRANTY PERIOD

Plasma TV 106 cm and above 1 Year (In-Home Service/ Pick up Available)*

LCD Televisions 80 cm and above 1 Year (In-Home Service/Pick up Available)*

Televisions – 59cm and above 1 Year (In-Home Service/ Pick up Available)* All Televisions under 59 cm 1 Year (No In-Home Service) Digital Set Top Boxes & Module 1 Year (No In-Home Service) VCR 1 Year (No In-Home Service) DVD & Module 1 Year (No In-Home Service) DVD Recorder & PVR Module 1 Year (No In-Home Service) Audio Systems 1 Year (No In-Home Service)

3. In Home Service/Pick up* will only be provided as part of this warranty if all the following conditions are met; a) The product as indicated in the Warranty Period Table. b) The product is within the warranty period. c) The product is located within the normal service area of the local TEAC Authorised Service Centre.

In any other situation or circumstance, where an In Home Service/Pick up* call is made, a service fee will be charged by the Service Provider including a travel fee if outside normal service area.

If TEAC determines that the product is not repairable on site, TEAC can complete the repair by taking the product to a TEAC Authorised Service Centre.

Where In-Home service/Pick up* is not available, the purchaser is required to send the product to the nearest TEAC Authorised Service Centre for repair. In this event, a copy of this warranty card and a copy of your receipt of purchase must be enclosed to be a valid warranty. Such equipment or part must be sent freight prepaid to your nearest TEAC Authorised Service Centre. After the repair, the product will be available for collection by or return to the purchaser at purchaser’s cost. The warranty does not cover freight or insurance. In all cases of transit damage or lost, a claim must be filed against the carrier by the purchaser, even if shipment is arranged by TEAC. TEAC inhome service may also be available at a fee upon request.

4. Accessories, Remote, including power adaptors, AV box, TV tuners, etc, are warranted to be defect free for 1 year.

5. Replacement of spare parts under normal usage; except cabinet, front panel, knob, removable accessories, battery,

consumable, AC cord, connecting cord and other accessories, are warranted as specified in Warranty Periods Table, and will be repaired or replaced at the sole judgement of TEAC.

6. The warranties hereby conferred do not extend to, and exclude, any cost associated with the installation, de-

installation or re-installation of a product (be it in-home or otherwise), including costs related to the mounting, demounting or remounting of any screen, (and any other ancillary activities), delivery, handling, freighting, transportation or insurance of the product or any part thereof or replacement of and do not extend to, and exclude, any damage or loss occurring by reason of, during, associated with, or related to such installation, de-installation, re-installation or transit.

7. Normal customer maintenance as described in the owner’s manual is not covered by this warranty (such as cleaning

VCR heads etc.)

8. Service will be provided only during normal business hours and under safety conditions and circumstances.

Page 3

9. This warranty does not apply to equipment showing abuse, damage or that it may have been tampered with, altered

or repaired outside any TEAC Authorised Service Centre. If so, the warranty will be void.

*Your nearest Authorised TEAC Service Centre is listed in your Owner’s Manual, please refer to TEAC website for up to date list.

10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with

the sale of any equipment other than as stated in this warranty and outlined above.

11. In no event will TEAC be responsible or liable for indirect or consequential damages from interrupted operations or

other causes.

12. Warranty is not transferable to any subsequent purchaser if the product is sold during the warranty period.

13. LCD dead pixel policy, please contact TEAC Customer Care Centre on 1800 656 700 for assistance.

* Extended promotional warranty may apply to certain products (for more info please contact: [email protected])

In home service administration fee is applied after 1

year of warranty.

Page 4

WARRANTY PROCEDURES

Please keep this information for your own records.

Please refer to the owner’s manual to ensure that you have followed the correct installation and operating procedures.

1. Read owner’s manual carefully

2. If you require Warranty Service, please contact the TEAC Authorised Service Centre

3. Please have your purchase receipt as your proof of purchase and the following details completed for a valid

Warranty.

Owner’s Name

Owner’s Address

Postcode

Model Name/No. Serial No.

Dealer’s Name

Dealer’s Address

Postcode

4. Please ensure that your product is packed appropriately upon return to the service centre.

If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below:

[email protected]

www.teac.com.au

1800 656 700

Page 5

7. REPEAT BUTTON

9. DISPLAY BUTTON

10.

11.

12.

13.

15.

16.

17.

18.

19. AUDIO IN JACK

20. MIC JACK

21. MIC

22.

23. OPEN/CLOSE BUTTON

24. SD/MMC CARD SLOT

26.

27.

28.

29. AUDIO OUT JACK

31.

32.

TFT DISPLAY HANDLE PHONES JACK VOLUME CONTROL FUNCTION SWITCH

6. MENU BUTTON

AUDIO BUTTON

BUTTON SKIP/SEARCH DOWN BUTTON SKIP/SEARCH UP BUTTON PLAY/PAUSE BUTTON

14. BAND SWITCH TUNING CONTROL SPEAKERS POWER INDICATOR

FM ST. INDICATOR

LEVEL CONTROL

USB PORT

25. DISC TRAY REMOTE SENSOR BATTERY COMPARTMENT VIDEO JACK

RIGHT

30. AUDIO OUT LEFT JACK TELESCOPIC FM ANTENNA AC SOCKET

33. VOLTAGE SELECTOR(OPTIONAL)

STOP&USB/SD/MMC CARD

ILLUSTRATION OF THE CONTROLS/JACKS ON THE MAIN UNIT

1011121314

161817 19202122232425

272829

30 31

Page 6

ILLUSTRATION OF THE KEYS ON THE REMOTE CONTROLLER

820

1. SCREEN ON/OFF & BRI/COL BUTTON

2. TITLE BUTTON

3. PREV/F.BWD BUTTON

4. NEXT/F.FWD BUTTON

5. NAVIGATION BUTTONS

6. NUMERIC BUTTONS

7. PROGRAM/ANGLE BUTTON

8. MUTE BUTTON

9. OPEN/CLOSE BUTTON

10. SETUP BUTTON

11. MENU BUTTON

12. DISPLAY BUTTON

13. STOP BUTTON

14. OK(PLAY/PAUSE) BUTTON

15. SUBTITLE BUTTON

16. AUDIO BUTTON

17. SEARCH BUTTON

18. REPEAT BUTTON

19. ZOOM/SLOW BUTTON

20. USB/CARD BUTTON

BASIC CONNECTION

The mains plug is used as disconnect device, the disconnect device shall remain readily operable.



It is recommended to be connected to a multi-system TV. Ensure that this player and other equipment to be connected to the unit are in the standby or off mode and disconnect the AC power cords before commencing connection. Do not block ventilation holes of any piece of the equipment and arrange them so that air can circulate freely. Read through the instructions before connecting other equipment. Ensure that you observe the color coding when connecting audio, video cables.

Note:



During DVD play, the TV volume may be at a lower level than during TV broadcasts, etc. If this is the case, adjust the volume to the desired level. If the DVD/CD player is connected to the TV through a video cassette recorder, the picture may not be played back normally with some DVDs. If this is the case, do not connect the player via the VCR.

Connecting to TV set

To video input connector (yellow) To audio input connectors (red, white)

Video/audio cable

AC power cord

To power outlet

Page 7

PREPARATION

Power on the TV set and select video input mode.

GET STARTED

1. Turn on the player and slide the function switch to the DVD/USB/CARD position.

2. Press disc OPEN/CLOSE button on the front of main unit to Open the disc tray and lift the TFT screen ou.

3. Place a disc onto the disc tray.

4. Press OPEN/CLOSE button to close the disc tray and the playback starts automatically.

5. When a menu screen appears on the TV,move thenavigation buttons or press the numeric buttons to select a preferred track number, then press OK(PLAY/PAUSE) button to start playback.

yto face

SKIP

Press NEXT SKIP or PREV SKIP button once during play to skip a chapter(DVD) or a track (CD) ahead or backwards.

FORWARD OR BACKWARD

STOP PLAYBACK

Press STOP button during playback to stop playback; the player activates its resume function when STOP is pressed in STOP mode; press PLAY button again, playback resumes at the point it stopped previously; open the disc tray or press the STOP button one more time to clear the resume function.

ZOOM PLAY

Press the ZOOM key continuously to zoom in the picture by 2, 3, and 4 times, zoom out by 1/2, 1/3, 1/4 normal size. Press this key once more when the picture is at 1/4 size to return to the normal size display. Scroll to view the enlarged picture using Navigation buttons.

ON SCREEN DISPLAY INFORMATION

When the player is in operation, press DISPLAY button continuously on the remote control, the screen will display parts of information(current disc type, title number, chapter number, playtime, audio language, audio type, subtitle language and multi angle, etc) in a sequence.

CHANGING AUDIO SOUNDTRACK LANGUAGE (DVD)

NOTE: When no soundtrack languages are recorded, pressing this button will not work.

It is possible to change the audio soundtrack language to a different language from the one selected at the initial settings (This operation works only with discs on which multiple audio soundtrack languages are recorded). Press AUDIO button during DVD disc play, the sound track language changes with the current sound track number shown on the TV screen.

ADJUST THE VOLUME

Rotate the VOLUME CONTROL to increase or the volume.

reduce

Press MUTE button, the audio output of the main unit will be shut off; pressing this button again will resume the audio output.

MUTE

OPERATIONS

MULTI-ANGLE VIEWING (DVD ONLY)

Press and hold ANGLE button during playback to display the number of angles being played and then select a desired angle to view the scene. Note: only the DVDs shot with multi-angle scenes have this function.

RAPID ADVANCE/ REVERSE

During playback, press and hold F.FWD button or F. BWD button several times to scan the disc forward or backward at X2, X4, X8, X20 normal speed. Press PLAY button to resume normal play.

SEARCH FOR PREFERRED SCENE

1. Press SEARCH button during play and highlight the item to

be played (Title, Chapter, or Chapter time) by navigation buttons.

2. Input the desired number or time via the numeric buttons.

3. Press OK button to confirm and the playback from the

located scene starts.

4. To exit search menu, press SEARCH button .again

PLAY/ PAUSE

During playback, press PLAY/PAUSE button to pause; To resume normal play, press PLAY/PAUSE button again.

SLOW-MOTION PLAY (DVD)

Press and hold SLOW button on the remote control during playback, the disc will be played at 1/ 2 normal speed at first, each time this button is pressed, the play speed becomes slower (down to 1/7 normal speed.) Press PLAY button, normal play will resume.

REPEAT

Press REPEAT button during play, it will repeatedly playing one chapter, tittle and all for DVD disc, repeatedly playing a track and all tracks for CD or repeat the sections between two specific points (A-B).

PROGRAM PLAY(UP TO 16 MEMORIES)

1. Press PROGRAM during playback to display the program menu.

2. Select location(s) to be memorized via navigation buttons and then enter desired Titles/Chapters numbers via numeric buttons.

Note: Leading zero is not necessary. If the track number is more than 10, press the first unit digit and then another unit digit. Example: Track 3, press "3"

Track 12, press "1" and then "2" Track 21, press "2" and then "1"

3. To start program play, select PLAY on the menu or press

PROGRAM button again to exit without program play.

4. To change programmed items, scroll the navigation button

to the item to be changed and enter the desired track number, the selected Item will be changed.

5. You can also cancel program mode by clearing all the

items in the program menu.

CHANGING SUBTITLE LANGUAGE (DVD ONLY)

Press SUBTITLE button during playback, the subtitle language shown on the screen will change as a response to each press; When the desired language appears, release the button to view the subtitle in that language. Note: this function only works on the DVDs recorded with multi-language subtitles.

RETURN TO MAIN MENU

During DVD playback, press MENU button to return to main menu. Press Title button to play the title (DVD).

MP3/ PLAYBACK

1. Load the Mp3/ disc onto the disc tray and the TV screen will show all its folders after a few seconds.

2. Select the folder you want by the navigation buttons and

OK button to confirm.

3. The files in this folder are displayed and select your

song via navigation buttons and press OK button

to start playback. If MP3

XVID

then press

favourite

files are displayed on the screen, select a song via navigation buttons and press OK to start playback.

Page 8

4.5.Press NEXT and PREV button to select track directly. Press REPEAT button change play mode. REPEAT 1- repeat one file. REPEAT DIR- repeat all tracks in the current album REPEAT ALL- repeat all tracks in current disc. REPEAT OFF-cancel repeat modes.

KODAK PICTURE CD / JPEG CD PLAYBACK

Slide show of Kodak Picture CD after being loaded begins automatically; Folders of JPEG picture CD after being loaded are displayed on the TV screen; use the navigation buttons to select the desired folder and then press OK button to confirm. The files in this folder are displayed and you can select your

pictures using the up/down navigation buttons and press OK button to start playback. Preview of the picture will be displayed while you scroll across the filenames.

favourite

6. SLIDE SHOW TRANSITION MODES

During slide show playback, press the PROGRAM button cyclically to select one of the following modes to play.

WIPE TOP WIPE BOTTOM WIPE L WIPE R DIAGONAL WIPE L TOP DIAGONAL WIPE R TOP DIAGONAL WIPE L BOTTOM DIAGONAL WIPE R BOTTOM

KODAK PICTURE CD / JPEG CD OPERATIONS

1. PLAY MODES

Press REPEAT button during play to change the play modes. REPEAT 1- repeat one file REPEAT DIR- repeat all picture in the current album REPEAT ALL- repeat all pictures in current disc. REPEAT OFF- cancel repeat modes. During playback, press STOP to enter preview mode.

SKIP TO NEXT/PREVIOUS PICTURE

PICTURE ROTATIONS

PICTURE FLIPS

Press NEXT button to skip to the next picture or PREV button to the previous picture. If no key is pressed for a few seconds, it will skip to next picture automatically.

Press RIGHT and LEFT navigation buttons to rotate the picture Clockwise and anti-clockwise respectively.

Press UP navigation button to flip the picture vertically. Press DOWN navigation button to flip the picture horizontally.

COLOR AND BRIGHTNESS ADJUSTMENT(FOR THE LCD SCREEN)

Press the SCREEN ON/OFF&BRI/COL button on the remote control to adjust the colour intensity and brightness respectively. Press the button once to enter the Colour adjustment mode, and press the Navigation Left/Right buttons to adjust. Press the button twice to enter the Brightness mode; press and hold this button to close the screen.

EXTERNAL MEMORY MEDIA OPERATION (USB) Prepare the player for External Memory media operation

1. Make sure the power is connected; slide the FUNCTION switch to DVD/USB/CARD position, POWER indicator will light.

3. You may play the files stored in the storage media in the

same way as you do with MP3/XVID disc.

Press USB/CARD button on the remote control or press and hold STOP/USB/SD/MMC CARD button on the main unit continuously until the player enters USB mode.

An icon of READ USB shows on the LCD and after the

USB is successfully detected and read, the track number as a total shows in the LCD.

Insert an MMC/SD card into the card slot. Press USB/CARD button on the remote control or press and hold STOP/USB/SD/MMC CARD button on the main unit continuously until the player enters MMC/SD mode.

5. PICTURE ZOOM IN/OUT

Press ZOOM button continuously ,the picture zooms in by 2, 3, 4 times or zooms out by 1/2, 1/3, 1/4 the original size. Press this button once more when the picture getting 1/4 size to return to the normal play. If the picture is enlarged, you may use the navigation buttons to .pan through the rest of the picture

EXTEND FROM CENTER H EXTEND FROM CENTER V COMPRESS TO CENTER H COMPRESS TO CENTER V WINDOW H WINDOW V WIPE FROM EDGE TO CENTER RANDOM NONE

Page 9

1.SYSTEM SETUP

INITIAL SETTINGS

2. LANGUAGE SETUP

- it is used to select the TV mode. Options: Please select this option as per your TV set.

it is used to select the LCD mode.

Options: 4:3 16:9

it is used to select the TV scan mode, please

set as per your TV set.

Options: Normal Pan & scan mode

Normal Letter box mode

16:9 wide screen mode

Reset to factory settings.

Options: RESTORE

1.1 TV SYSTEM

1.2 LCD MODE-

1.3 TV TYPE-

4:3PS :

4:3LB :

16:9 :

1.4 DEFAULT -

NTSC, PAL, AUTO

LANGUAGE SETUPLANGUAGE SETUP

OSD LANGUAGE AUDIO LANG SUBTITLE LANG MENU LANG

EXIT SETUP

2.1 OSD LANGUAGE - It is used to select different On

Screen Display language for different user.

2.2 AUDIO LANG -

2.3 SUBTITLE LANG-

2.4 MENU LANG -

select audio language.

(DVD only, need disc software support)

Select subtitle language.

(DVD only, need disc software support)

Select disc menu language.

(DVD only, need disc software support)

prefered

SPEAKER SETUPSPEAKER SETUP

DOWNMIX

EXIT SETUP

4. SPEAKER SETUP

4.1 DOWNMIX

Options: Left/Right mix mode

Select this option if you don't

have a 5.1 channels amplifier.

LT/RT-

STEREO-

SYSTEM SETUPSYSTEM SETUP

TV SYSTEM

DEFAULT

EXIT SETUP

TV TYPE

LCD MODE

3. VIDEO SETUP

VIDEO SETUPVIDEO SETUP

BRIGHTNESS CONTRAST HUE SATURATION

EXIT SETUP

3.1 BRIGHTNESS-- to set the brightness of the display.

Options: 0/2/4/6/8/10/12

Options:

3.2 CONTRAST--to set the contrast effect of the display.

3.3 HUE--to set the colour impression of the display.

3.4 SATURATION--to set the saturation level of the display.

0/2/4/6/8/10/12

Options: -6/-4/-2/0/+2/+4/+6

Options: 0/2/4/6/8/10/12

Initial settings page is for you to make your preferred settings up for your player. Once the initial settings are done they are retained in the CPU of the player until otherwise modified.

1. Press SETUP button.

2. Use the

4. Press SETUP button to exit main setting page.

COMMON PROCEDURES FOR INITIAL SETTINGS

navigation buttons to select the item you want to

modify,

3. Use navigation buttons to switch to another on

the main setting page.

selected items will display a sub-menu. Again use navigation buttons to make changes. Press OK button to confirm.

sub-menu

Page 10

RADIO OPERATION

1. Slide the FUNCTION switch on the main unit to the RADIO position, .

2. Select the desired band with the BANDswitch.

Adjust the volume level to a comfortable listening level.

6. To turn off the radio, slide the FUNCTION switch to OFF

position.

the POWER Indicatorwill light up

he built-in AM antenna and external FM TELESCOPIC

ANTENNAare directional.

NOTE: When external headphones/earphones are connected,

the sound to theunit's main speakers will be muted.

Caution: Listening to headphones at high volume can result in

damage to users' hearing.

NOTES:

TO PLAY THE RADIO

STEREO HEADPHONE JACK

Astereo headphonejack has been provided at the top of the unit so that you can listen tothe unitwithout disturbing others. To use this jack, plug in the headphones/earphones (not included) and adjust the VOLUME controlto acomfortable listening level.

3. Tune

to the desired station by rotating the TUNING control (Move the control back and forth until you get the strongest clearest sound).

4. T

When

receiving an FM broadcast, fully extend the TELESCOPIC ANTENNA and position for the best reception. For AM broadcasts, rotate the whole set until the best reception is heard.

If a particular FM (STEREO) station is weak, or you hear too much background noise, try moving the position of the band selector switch to the FM (MONO) position. This can often result in a much clearer reception. When the band selector switch is set to FM STEREO and a stereo broadcast is being received, the FM STEREO indicator on the top of the unit will be lit.



AUDIO IN

Appliance:

1. Power the player on using the supplied AC Power Cord.

2. Slide Function Switch to DVD/USB/CARD position.

3. Connect the appliance into the player's AUDIO in socket with the supplied LINE OUT cable of the appliance.

4. Power on the appliance and begin play.

this input allows you to connect other audio playback devices (EG: portable radio, MP3, player, TV audio out.)

At this moment, music which is output from the appliance will be produced from the speaker

SPECIFICATIONS:

Power source

Operating Humidity Range:

: AC 240V /50Hz

NTSC / PAL / AUTO Operating Temperature Range: +5 C to +35 C Continuous playing time: 150 minutes

10%to75%

Specifications are subject to change without notice.

Receiving bands: Tuning range:

Power consumption:

TV system supportable:

Dimensions:

Disc supportable:

AM/FM

AM 540 - 1600 KHz

FM 88 -108 MHz

25W

446.5mm(L)x246mm(W)x166mm(H)

1. DVD-VIDEO disc

Output power: Speaker output: USB support up to 4GB SD/MS support up to 4GB

Audio signal output:

2.5W x 2

4 ohm 5W

12 cm single-sided, single-layer 12 cm single-sided, dual-layer 12 cm double-sided, single-layer 8 cm single-sided, single-layer 8 cm single-sided, dual-layer 8 cm double-sided, single-layer

2. VIDEO CD/CD-DA/CD-R/CD-RW/MP3 -CD

12cm disc 8cm disc

1.DVD (linear audio)

(1) Frequency response:20Hz-20KHz (48KHz

sampling)&20Hz-20KHz (96KHz sampling) (2) S/N ratio: >45dB (3) Wow and flutter: below measurable level

2.CD audio: (1) Frequency response: 20Hz-20KHz (2) S/N ratio: >45dB (3) Wow and flutter: below measurable level

DC 12V UM2/"C" x 8pcs

Remote control:

DC 3V UM4/"AAA" x 2pcs

Page 11

TROUBLESHOOTING



Hold the disc by the edge so the surface will not be soiled with finger prints. Finger prints, dirt and scratches can cause skipping and distortion.

Do not write on the label side with a ball-point pen or other writing utensils. Do not apply benzine, thinner, and liquid that prevents against static electricity. Be careful not to drop or bend the disc. Install only one disc on the disc tray. Do not try to close the disc tray when the disc is not installed properly. Be sure to store when not in use.

the disc in its case

DISC HANDLING PRECAUTIONS

If your DVD player does not seem to be functioning properly, check the items below before you contact an authorized service center

Symptom Check

Make sure the AC cord is securely plugged into an AC outlet.

Turn the power off and then back on.

Check that the battery is inserted in the

and direction properly.

The battery may be flat. Replace it with a new one.

Check that the signal transmission is directed at the remote control sensor on the DVD player.

Remove the obstacle between the remote controller and remote control sensor.

Check that the A/V cables are securely connected.

Check that the disc is a DVD (region number 4 or all), DVD-RW or AUDIO CD.

Do not use a disc that has scratches or dirt.

Check that the label-side of the disc is facing up.

The pick-up lens of the DVD player may be dirty. Contact the service center for lens cleaning.

Check that the TV channel is set to VIDEO or AV if viewing with a TV.

Power does not turn on or suddenly turns off.

Remote control won't work

No picture or sound

Check that the LCD display is turned on.

Check that the display panel is open. If it is closed, to the speakers.

audio will not output

Check the volume setting. If set to zero, turn up volume level. Check that the headphones are plugged into the PHONES socket. Speakers cannot be used with the headphones. Check that the battery is properly installed and AC Adapter is properly connected. Use a disc without scratches or dents.

No picture No sound

No picture and sound Distorted video or sound

Specifications are subject to change without notice.

Page 12

TEAC AUSTRALIA PTY.,LTD.

A.B.N.: 11 113 998 048

Service Providers in Australia

please contact one of the following service providers in your area if you require service for your product.

Name Address Phone Fax

Associated Electronics 7 Molonglo Mall FYSHWICK 2609 (02)62 80 4698 (02)62 80 5437

TEAC Perth Service Centre 273 Great Eastern Highway BELMONT 6104 (08)94 79 6499 (08)94 79 6544

Inpulse Electro nics 3 Sloane Street MARIBYRNONG 3032 (03)93 17 4000 (03)39 17 4040

Jav Electronics 65 Mackie Road BENTLEIGH EAST 3165 (03)95 70 4911 (03)95 63 8722

Watpace Electronics 62 Wingara Avenue KEILOR EAST 3033 (03)93 36 4042 (03)93 36 3768

QQ Electronics Pty Ltd Unit 5, 14-38 Bellona Avenue REGENTS PARK 2143 1300 883 229 (02)97 38 1311 Maxwell Electronics 106 Bath Road KIRRAWEE 2232 (02)95 42 3000 (02)95 42 3377

TCS (Total Care Services) 62 Leader Street FORESTVILLE 5035 (08)83 51 1044 (08)83 51 1043

NSW

Name Address Phone Fax B & H Electronics 466 David Street ALBURY 2640 (02)60 41 3911 (02)60 21 7455

Border Video & TV Service

Shop 3, 339 Urana Road LAVINGTON 2641 (02)60 40 2229 (02)60 40 2184

Bourkes Video & Tv Service 111 Danger Street ARIMDALE 2350 (02)67 71 1513 (02)67 71 1696

Nichols Electronics Shop 4/70 River Street BALLINA 2478 (02)66 86 9422 (02)66 81 4999 Baytech Electronics Shop 3, 270 Beach Road BATEHAVEN 2536 (02)44 72 7023 (02)44 72 7354

Sapphire Electronics

U5B/85 Bega Street BEGA 2550 (02)64 92 2522 (02)64 93 2062

Lawson Radio & TV 298 Great Western Highway LAWSON 2783 (02)47 59 1254 (02)47 59 2312 Iwac Repairs Pty Ltd Shop 8, 12 Statham Street BENNETTS GREEN 2290 (02)49 48 1067 (02)49 48 1069

Visual Audio Services 510 Chapple Street - PO BOX 76 BROKEN HILL 2880 (08)80 87 4055 (08)80 87 4055

T K Electronics Unit 2 10 O’Hart Close CHARMHAVEN 2263 (02) 43 92 0828 (02)43 93 1018

TV Technologies 20 Marcia Street COFFS HARBOUR 2450 (02)66 51 7366 (02)66 50 0152

Coogee Electronic Service 261 Arden Street COOGEE 2034 (02)93 15 8566 (02)66 50 0152

Electronics 2000 Shop 3/190 Sharp Street COOMA 2630 (02)64 52 4179 (02)64 52 4179 Lachlan Valley TV 49 Vaux Street COWRA 2794 (02)63 42 2189 (02)63 42 2189

Greg’s TV 2 Bingalong Street DALMENY 2546 (02)44 76 7544 (02)44 76 7544 Deniliquin Hi-Tech 44 Hardinge Street DENILIQUIN 2710 (03)58 81 1444 (03)58 81 1444

Western Electronic Service 437 Hopkins Parade DUBBO 2830 (02)68 82 3905 (02)68 82 3870

Con Carr Retravision 126-128 Murray Street FINLEY 2713 (03)58 83 1611 (03)58 83 2114

Forbes TV & Video Repairs 132 Rankin Street FORBES 2871 (02)68 52 2921 (02)68 52 2921 Forster Electronic Services Shop 15, Forster Tower, Wallis Street FORSTER 2428 (02)65 54 5352 (02)65 54 5352 V.J. & C.M. Davey TV & 137 Meade Street GLEN INNES 2370 (02)67 32 2260 (02)67 32 2260

Ray White Television Repairs 2 Taylor Street GOULBURN 2580 (02)48 22 4050

Repairs & Spares 140 Fitzroy Street GRAFTON 2460 (02)66 42 1911 (02)66 43 3961

Griffith Home Appliance 94-98 Yambil Street GRIFFITH 2680 (02)69 62 1826

S & K Electronics 111 Banna Avenue GRIFFITH 2680 (02)69 62 2847 (02)69 64 7774 Ron Burns Electrical 8 Hillcrest Road GUNNEDAH 2380 (02)67 42 3299

Tele – Fridge Electronics 82 Conadilly Street GUNNEDAH 2380 (02)67 42 0022 (02)67 42 3878

Page 13

Inverlec Electronics Shop 1,20 Glen Innes Road INVERELL 2360 (02)67 22 4522 (02)67 22 4522

Maxwell Electronics 106 Bath Road KIRRAWEE 2232 (02)95 42 3000 (02)95 42 3377

Jag Electronics 59 Tambourine Bay Road LANE COVE 2066 (02)94 27 5478 (02)94 28 2634

AVL Electronics 2/87 Bold Street LAURIETON 2443 (02)65 59 6330 (02)65 59 6330 Leeton Appliances 99 Grevillia Street LEETON 2705 (02)69 53 4151 (02)69 53 4151 Hans Electronic Services 147 Magellan Street LISMORE 2480 (02)66 21 9311 (02)66 21 9711 Robert Peatfield 2 West Street MACKSVILLE 2447 (02)65 68 2867 (02)65 68 2867 Mullumbimby TV Service Shop 3 97-99 Stuart Street MULLUMBIMBY 2482 (02)66 84 2335 (02)66 84 3554 John Rice TV Service 13 Park Avenue MURWILLUMBAH 2484 (02)66 72 3292 (02)66 72 3292

Spencer Electronics Unit 2, 26 Somerset Avenue NARELLAN 2567 (02)46 47 2046 (02)46 47 2046

Newcastle Quickfix/ J P Electronics Shop 5, 468 Pacific Hwy BELMONT 2280 (02)49 45 4699 (02)49 45 5696

NSW

Name Address Phone Fax

Videotel Unit 1/17 Quinns Lane SOUTH NOWRA 2541 (02)44 21 5250 (02)44 23 3280

Ideal Electronics 145 Woodward Street ORANGE 2800 (02)63 62 8270 (02)63 62 8270 Parkes Sight 'n' Sound 67 Clarinda Street PARKES 2870 (02)68 62 4475 (02)68 63 4209

Vickery Sound

171 Brisbane Water Drive POINT CLARE 2250 (02)43 23 3623 (02)43 23 1581

Quickfix Repairs 118 Stafford Street PENRITH 2750 (02)47 22 8550 (02)47 22 9949

BJRAE Electronics 2/199 Adelaide Street RAYMOND TERRACE 2324 (02)49 87 7032 (02)49 87 6194

QQ Electronics Pty Ltd Unit 5, 14-38 Bellona Avenue REGENTS PARK 2143 1300 883 229 (02)97 38 1311

Quickfix Repairs Shop 17 West Market Street RICHMOND 2754 (02)45 78 2111 (02)45 78 2021

Tech 1 Electronic Repairs Shop1/12 Sunset Ave WARILLA 2528 (02)42 97 5397 (02)42 97 5398 Cherries Electronics Unit 3, 8 Walter Street SINGLETON 2330 (02)65 71 2488 (02)65 71 2488 Videtel Video, TV & Monitor 232 Marius Street EAST TAMWORTH 2340 (02)67 61 3788 (02)67 61 3388 Peel Television Service 1 Macquarie Street TAMWORTH 2340 (02)67 66 3928 (02)67 66 9932 Colour Fix TV & Video Service 172 Bridge Street TAMWORTH WEST 2340 (02)67 65 5539 (02)65 62 0561 Hawkins Electronic Service 94 Manning Street TAREE 2430 (02)65 52 2288 (02)65 52 4059

Household Electronics 3/39 Shearwater Drive TAYLORS BEACH 2316 (02)49 19 0344 (02)49 19 0355 That Repair Shop 122 Fitzmaurice Street WAGGA WAGGA 2650 (02)69 21 5200 (02)69 25 9491

Schuberts Electronics 53 Hastings Street WAUCHOPE 2446 (02)65 85 1533 (02)65 85 3816

ILLAWARRA Electronics Solution Shop 3, 60 Lakeside Drive KANAHOOKA 2530 (02)42 61 9234 (02)42 61 9227 United Television Service Pty Ltd 390 Keira Street WOLLONGONG 2500 (02)42 28 4555 (02)42 26 3453

Vac Shak Pty Ltd 16 Lovell Street YOUNG 2594 (02)63 82 5700 (02)63 82 7366

Page 14

QLD

Name Address Phone Fax

McMahon Electrical Traders 23 Mabel Street ATHERTON 4883 (07)40 91 1788 (07)40 91 1741 Beerwah Electronics Peachester Road BEERWAH 4519 (07)54 94 0466 (07)54 94 0416 Bremer Television Service 36 Station Road BOOVAL 4304 (07)32 82 3593 (07)32 82 1214

Bowen Retravision (Northern Elect) 40 George Street BOWEN 4805 (07)47 86 1633 (07)47 86 2257 TV Doctor Unit 2, 11 Breene Place MORNINGSIDE 4170 (07)38 99 9644 (07)33 99 9019 Telefix Unit 9, 19 Lensworth Street COOPERS PLAINS 4108 (07)33 23 2700 (07)33 23 2730 Nielsons Radio & TV Service 68 Gavin Street BUNDABERG 4670 (07)41 53 1377 (07)41 53 1534 A1 Sound & TV Service 14 Gloucester Road BUDERIM 4556 (07)54 45 4777 (07)54 45 1311 Caboolture Video & Microwave 4/125 Morayfield Road CABOOLTURE 4510 (07)54 95 3477 (07)54 95 3477 Digital TV Service 197 Lyons Street WESTCOURT 4870 (07)40 51 1711 (07)40 51 1771

Garrows Video & TV Service 4/74 Omrah Avenue CALOUNDRA 4551 (07)54 91 3238 (07)54 91 7457

Charleville Radio & TV 14 Wills Street CHARLEVILLE 4470 (07)46 54 1633 (07)46 54 2266

Moss Electronics (form Caboolture Video) Unit 2, 25 Redcliffe Gardens Dr CLONTARF 4019 (07)3283 6749 (07)3283 6750

Precise Electronics 1 / 4 Northview Street MERMAID BEACH 4218 (07)55 75 1377 (07)55 72 4689 Ready Electronics Shop 3/1 Tibbing Street NERANG 4211 (07)55 96 6359 (07)55 02 2734 Tweed Television Shop 3/12 Machinery Drive SOUTH TWEED HEADS 2486 (07)55 24 4483 Bakers TV & Electronics Pty Ltd Unit 15, 388 Newman Road GEEBUNG 4185

(07)32 16 5495 (07)32 16 5598

Harbour Cit

y TV & Video Shop 3/1 Mellefont Street GLADSTONE 4680 (07)49 72 9495 (07)49 72 9495

Lloyd Lawrence Electronics Shop 8-9, 5 Torquay Road HERVEY BAY 4655 (07)41 24 3787 (07)41 24 3787

Professional VCR Sales Service 90 Mourilyan Road INNISFAIL 4860 (07)40 61 4720 (07)40 61 4720

Dunstans SBTV 37 Kingaroy Street KINGAROY 4619 (07)41 62 1547 (07)41 62 2343

Nev Robert Electronics 31 Hart Street MACKAY 4740 (07)49 57 6498 (07)49 51 3737

Sunland TV Service Unit 5 Centre One, Norval Court MAROOCHYDORE 4558 (07)54 43 6444 (07)54 43 6464

Telefix Unit 1, 96 Aerodr ome Road MAROOCH YDORE 4558 (07)33 23 2700 (07)33 23 2730 Noosa TV & Video Repairs Shop 2, 9 Commerce Court NOOSAVILLE 4566 (07)54 47 1752 (07)54 47 1753 Sunland TV Service Shop 4, 54 Rene Street NOOSAVILLE 4566 (07)54 74 2101

Cumners Electronics Shop 4, 131 Old Pacific Highway OXENFORD 4210 (07)55 73 5250 (07)55 73 5403 N & M TV & Video Service 47a Yandilla Street PITTSWORTH 4356 (07)46 93 2886 (07)46 93 2886

C.Q. Video & TV Service 227 Berserker Street ROCKHAMPTON 4701 (07)49 28 8811 (07)49 28 2698

Matthew's TV & Video Service 176 Main Street ROCKHAMPTON 4701 (07)49 28 5377 (07)49 28 5608

WSR Electronics 542 Sherwood Road SHERWOOD 4075 (07)33 79 5400 (07)32 78 5655

Top Beat Entertainment & Elec 97A Folkestone Street STANTHORPE 4380 (07)46 81 0681 (07)46 81 0682 T.I. TV Repairs 11 Summer Street THURSDAY ISLAND 4875 (07)40 90 2139 (07)40 69 2577 Clark & Webb TV & Radio 14 Grange Street TOOWOOMBA 4350 (07)46 32 7290 (07)46 32 9244 Downs Radio & TV Service (DR TV) 35 Dent Street TOOWOOMBA 4350 (07)46 32 1044 (07)46 32 1224

Townsville Electronics 197 Ingham Road WEST END 4810 (07)47 75 7774 (07)47 79 6867 Top Beat Entertainment & Electrical 46 Wood Street WARWICK 4370 (07)46 61 2690

Page 15

Name Address Phone Fax The Television Workshop Shop 4 Elder St Centre ALICE SPRINGS 0870 (08)89 52 8555 (08)89 52 5557

New Age Electronics Unit 1/21 Delatour Street COCONUT GROVE 0810 (08)89 48 1755 (08)89 48 1766

Eletech Service 13 Sandalwood Ave NHULUNBUY 0880 (08)89 87 3828 (08)89 87 3828

Name Address Phone Fax

TCS (Total Care Services) 62 Leader Street FORESTVILLE 5035 (08)83 51 1044 (08)83 51 1043

Haynes Electronic Service Shop 3, 7 Verrall Cresent BERRI 5343 (08)85 82 4677 (08)85 82 5294

E.K. Dunstan & Co 255 Main Street CLARE 5453 (08)88 42 2144 (08)88 42 3942

Peter's Electronics 25 Lorna Street LOXTON 5333 (08)85 84 6920 (08)85 84 6920

Gambier Sound& Vision Repairs 16-18 Watson Tce MT GAMBIER 5290 (08)87 23 3955 (08)87 23 3855 Portside Technologies 28 Hallet Place PORT LINCOLN 5606 (08)86 82 1500 Pirie Antenna & TV 283B Senate Road PORT PIRIE 5540 (08)86 32 2565 (08)86 33 0091 Riverland Electronics Services 113 Renmark Avenue RENMARK 5341 (08)85 86 5600 (08)85 86 5533 Victor Electronic Service 44 Torrens Street VICTOR HARBOR 5211 (08)85 52 1471 (08)85 52 1098 Eyre Electronics 15B Forsyth Street WHYALLA 5600 (08)86 45 4764 (08)86 45 5576

Page 16

TAS

Name Address Phone Fax

R.M Electronics 32 Strahan Street BURNIE SOUTH 7320 (03)64 31 8922 (03)64 31 89 22

Somerset Electronics 16 Douglas Street EAST DEVONPORT 7310 (03)64 27 0016

D.J. Hingston 95 James Road SPREIGHTON 7310 (03)64 27 2145 (03)64 27 2145 Integrated Components 54A Albert Road MOONAH 7009 (03)62 78 1932 (03)62 78 8387 K.T. National Electronics 1 Hobart Road SANDHILL 7249 (03)63 44 5665 (03)63 43 0466

VIC

Name Address Phone Fax Border Video & TV Service 362 Griffith Road LAVINGTON 2641 (02)60 40 2229 (02)60 40 2184

Greene's Television Services 149 Hummfray Street BALLARAT 3350 (03)53 32 6256 (03)53 32 7597 Ted Rivett Services 145 Creswick Road BALLARAT 3550 (03)53 32 6371 (03)53 33 4002

Proud’s Hi Fi 78- 80 Pall Mall BENDIGO 3550 (03)54 42 2722 (03)54 42 2522 Jav Electronics 65 Mackie Road BENTLEIGH EAST 3165 (03)95 70 4911 (03)95 63 8722

B M Tronics 197 Murray Street COLAC 3250 (03)52 32 1504 (03)52 32 1935

Unitech Services 72 Maroondah Highway CROYDON 3136 (03)97 25 2222 (03)97 25 2804 T & C Electronics Service 31 Pegleg Road EAGLEHAWK 3556 (03)54 46 3000 (03)54 46 3022

Echuca TV & Video Service 1/7 Mitchell Street ECHUCA 3564 (03)54 80 7874 Fawkner TV Service 123 Jukes Road FAWKNER 3060 (03)93 59 5836 (03)93 59 5048

Central Appliance Service 222 Moorabool Street GEELONG 3200 (03)52 22 1418 (03)52 22 1418 RTD Services Pty Ltd 25-29 Fairlie Street GEELONG NORTH 3215 (03)52 78 9766 (03)52 78 3545 Linke Electrical Repairs 82 Londsdale Street HAMILTON 3300 (03)55 72 5788 (03)55 72 4090 Frank Ritchie Electrical P/L 9 Victoria Street KERANG 3579 (03)54 52 2908 (03)54 52 2908

Watpace Electronics 62 Wingara Avenue KEILOR EAST 3033 (03)93 36 4042 (03)93 36 3768

Harold Hurren 26 Fitzroy Street KILMORE 3764 (03)57 82 1327 (03)57 82 1487 Soundwave Electronics 2B Holt Street LEONGATHA 3953 (03)56 62 3665 (03)56 62 3665

Inpulse Electronics 3 Sloane Street MARIBYRNONG 3032 (03)93 17 4000 (03)39 17 4040

Sunshine Electronics Aust Shop 2, 17 Moore Street MOE 3825 (03)51 26 1110 (03)51 26 1275 Peninsula VCR Repairs

1/8 Virginia Street MORNINGTON 3931 (03)59 75 0800 (03)59 76 2300

Ferguson Electronics 116 Orange Avenue MILDURA 3500 (03)50 23 5846 (03)50 21 2690 Bensi TV Electrical Pty. Ltd. 128 Nicholson Street ORBOST 3888 (03)51 54 1454 (03)51 54 1344 G & R Video & TV Services Pty. 24 Dunkirk Avenue SHEPPARTON 3630 (03)58 21 0258 (03)58 21 8187

Inpulse Electronics 496 Whitehorse Road SURREY HILLS 3027 (03)93 17 4000 (03)98 36 5922

Swantronics 45 Campbell Street SWAN HILL 3585 (03)50 33 1633 (03)50 33 1287 Earl & Becker 4-26 Shakespeare Street TRARALGON 3844 (03)51 74 8454 (03)51 74 8454

Tellycare (Nugents) 105 Queen Street WARRAGUL 3820 (03)56 22 1102 (03)56 22 1102

John B. Electronics Shop 94 High Street WODONGA 3690 (02)60 56 1066 (03)57 28 7299

Page 17

WA Name Address Phone Fax

Albany TV Service Shop 8 35-37 Campbell Road ALBANY 6330 (08)98 41 1573 (08)98 42 5958

Excel Electronics 3 Newman Court NICKOL 6725 (08)91 44 1266 (08)91 44 1266

North West Electronics 42 Fredrick Street BROOME 6725 (08)91 92 5003 (08)91 92 6003

Elricks TV Service 62 Spencer Street BUNBURY 6230 (08)97 21 4047 (08)97 21 1161 Busselton TV & Video 65B Strelley Street BUSSELTON 6280 (08)97 54 4457 (08)97 54 4824 Electronic Plus Unit 3/11 Egan Street CARNARVON 6701 (08)99 41 3690 (08)99 41 3660 Esperance Communications 33 Norseman Road ESPERANCE 6450 (08)90 71 3344 (08)90 71 4545 Bird Electronics 14 Abraham Street GERALDTON 6530 (08)99 64 1631 (08)99 21 7584 Geraldton Radio & TV Service 26 Anzac Terrace GERALDTON 6530 (08)99 64 2777 (08)99 64 2776

Oz West Electronics 6/200 Winton Road JOONDALUP 6027 (08)93 00 1066 Printek Electronics 1 Lesueur Drive JURIEN BAY 6516 (08)96 52 1664 (08)96 52 1664

Kalgoorlie Electronics 395 Hannan Street KALGOORLIE 6430 (08)90 21 1420 (08)90 21 1420 J & P Electronics 3/88 Albany Hwy KOJONUP 6395 (08)98 31 1991 (08)98 31 1991 Tuckerbox Retravision White Gum Street/P.O. BOX 941 KUNUNNURRA 6743 (08)91 68 1100 (08)91 68 2491 Waytec Electronics Unit 3, 10 Thornborough Road MANDURAH 6210 (08)95 82 0882 (08)95 82 0352 Manjimup TV Service 88 Giblett Street / P.O. BOX 370 MANJUMUP 6258 (08)97 71 1598 (08)97 72 4025 Chris's TV & Satelite 66 Barrack Street MERREDIN 6415 (08)90 41 1484 (08)90 41 1484

G & J Suckling Radio & TV 1 Hale Street NARROGIN 6312 (08)98 81 2148 (08)98 81 3129

Proton 21A Charles Street NORTHAM 6401 (08)96 22 3168 (08)96 22 3168

TEAC Perth Service Centre 273 Great Eastern Highway BELMONT 6104 (08)94 79 6499 (08)94 79 6544

Charles Hunt Electronics 25 Brodie Court BALDIVIS 6171 (08)63 63 5593 (08)95 24 2890

Page 18

TEAC CUSTOMER CARE CENTRE (TCCC)

Free call: 1800 656 700

Between Monday to Friday - EST 9AM to 5PM
